INSTALLATION INSTRUCTIONS
Decorative Pieces
3601/3602 Series
Installing Decorative Arms
1
DECORATIVE ARM
OPTIONAL A
DECORATIVE ARM
OPTIONAL B
Decorative Arm
Top Arm Ring
Set Screw
Bottom Arm Ring
Set Screw
Decorative Arm
Top Arm Ring
Set Screw
Bottom Arm Ring
Set Screw
Attach the decorative arms to the top and bottom arm rings as shown.
Secure them together with the provided set screws. Hand tighten until
snug.
Loosen the stem top and remove it from the top end of the stem.

www.voltlighting.com
- 2 -
2
INSTALL DECORATIVE ARM INSTALL DECORATIVE TUBE
Stem Top
Install Stem Top to Decorative Pieces
Insert the neck of the stem top to the top arm ring of the decorative arm
assembly or to the decorative tube. Secure them together with the set
screws and tighten until snug.
Insert the bulb with the correct wattage and type marked on the xture
label and push rmly into place.
CAUTION: Do not exceed maximum wattage marked on luminaire label.
Decorative
Arms Assembly
Set Screw
Neck
Decorative Tube
Set Screw
Neck
Top Arm Ring
Stem Top

[email protected] • 813.978.3700
- 3 -
3
INSTALL STEM TO
DECORATIVE ARMS ASSEMBLY
INSTALL STEM TO
DECORATIVE TUBE
Place the stem top with decorative arms assembly or the stem top with
the decorative tube over the bulb. Thread the stem top onto the stem and
hand tighten until snug.
Proceed to install stakes and shades to complete xture installation.
Install Decorative Pieces to Stem
Stem Top
Stem
Stem Top
Stem
Decorative
Arms Assembly
Decorative Tube
