Lighting Systems F7000-16
1BHFPG '4FSJFT1PJOU4PVSDF
Armstrong®TechZone™ Compatible
Features
1. Housing: Unitized body of extruded high-purity aluminum, partially recycled
pre-consumer, with die-cast ends welded in place; matched to fluorescent
modules in the series. All modules connect and suspend like fluorescent
modules.
2. Housing End: Die-cast aluminum, welded to the ends of the housing.
3. End Cap: Die-cast aluminum. Encloses the suspension cable and power feed
cord for the end of the run.
4. MR16: Lamping is 75W maximum. Transformer is electronic, 12V secondary,
120V or 277V primary (as specified) Gimbal ring provided as part of the module
and regressed into it. 45° aiming; accepts one standard Lytespan 2” (5.08cm)
filter or louver; regressed lamp pulls out for relamping. The 12” (30.48cm)
MR16 module can be cantilevered fromthe end of a run of fluorescent fixtures.
5. Metal Halide: Lamping is 20W or 39W. Ballast is electronic, 20W or 39W,
as specified, 120V or 277V, as specified. Connector accepts selected
Lytespan PowerArc Modular Track heads. Compatible Track heads include
standard Lytespan PowerArc modular track heads, which connect to the
module. 8300, 8303, 8304, 8313, 8314, 8316, and 83W4 with applicable
reflectors. Track heads and applicable reflectors must be specified and
ordered separately, including appropriate finish. Finish is powder-coated,
baked enamel, white or aluminum, as specified.
Ordering Information
1.63”
(4.14cm)
5.77” (14.66cm)
F7
Family Series
3
Type Lamps Color Wattage Voltage Length Options
7
3= Block 7= Point Source 1= 1 Lamp
2= 2 Lamps
4= 4 Lamps
AL = Aluminum
WH = White
7= 20W HID
8= 39W HID
9= 75W MR16
1= 120v
2= 277v
1= 1’ (30.48cm)
2= 2’ (90.96cm)
4= 4’ (121.92cm)
X4 = 4 Through
Wires
X5 = 5 Through
Wires
4
5
1
Complete Ordering Instructions below.
8. Power Feeds: Standard 18/3 power feed is rated for 10 amps. X4 power
feed is 18/4 and is rated for 7 amps. Observe amperage limitations and pro-
vide additional Intermediate Power Cables, as required. When providing an
additional power feed, the through wiring fromthe previous module must be
disconnected fromthe cannon plug and capped.
9. Mounting: Suspended by 1/16” (0.16cm) stainless steel cable, adjustable;
precisely modular 1’ (30.48cm), 2’ (90.96cm) or 4’ (121.92cm) suspension
centers; 4 1/2” (11.43cm) white canopy.
Labels
UL, cUL and I.B.E.W.
6. Electrical: Pre-wired with 18 gauge wires and polarized cannon plug con-
nectors for simultaneous mechanical/electrical connection. Factory installed
ballast disconnect allows the ballast to be disconnected fromand reconnected
to incoming power under load without turning the entire circuit off.
7. Finish: Powder-coated, baked enamel, white or aluminum, as specified.
