Vonnic VVR4004HMFD User manual

Ver. 1.0.1
H.264 Video Compression
Digital Video Recorder
User Guide
About This User Guide
Before operating the unit, please read this user guide thoroughly and retain it for future
reference.

Page 2
Warning
Cautions
1. Read User Guide – After unpacking this product, please read the user guide carefully, and
follow all the operating and other instructions.
2. Power Sources – This product should be operated only from the type of power source indicated
on the label. If not sure of the type of power supply, consult with the product dealer.
3. Ventilation – Slots and openings on the unit are for ventilation and to ensure reliable operating
of the product and to protect it from overheating, and these openings must not be blocked or
covered. The product is recommended to be placed in a well ventilated area.
4. Heat – The product should be placed away from heat sources such as radiators, stoves, and
other products that produce heat.
5. Water and Moisture – Do not use this product near water. Do not exceed the humidity
specifications for the product as detailed in the user guide.
6. Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use only compressed air to clean the product.
7. Power Cord Protection – Power-supply cords should not be routed so that they are likely to be
walked on or pinched by items placed against them.
8. Overloading – DO not overload wall outlets; extension cords, or uninterruptible power supply.
9. Lighting – For added protection for this product during a storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to
the product due to lighting and power line surges.
10. Object and Liquid – Never insert foreign objects into the DVR, as it may touch dangerous
voltage points or short-out parts that could result in a fire or electrical shock. Never spill liquid
of any kind on the product.
11. Accessories – Do not place this product on an unstable cart; stand, tripod, bracket, or table. The
product may fall, causing serious personal injury and serious damage to the product.
12. Disc Tray – Keep fingers well clear of the disc tray as it is closing. Neglecting to do so may
cause serious personal injury and serious damage to the product.
13. Burden – No not place any heavy objects on the product.
14. Disc – Do not use a cracked, deformed, or repaired disc. These discs can be easily broken and
may cause serious personal injury and cause product malfunction.
15. Replaceable Batteries – CAUTION: Risk of Explosion if the battery is replaced by an
incorrect type. Dispose used batteries according to the instructions.
16. Servicing – Do not attempt to service this product. Opening or removing covers may expose the
user to dangerous voltage or other hazards. Unauthorized substitutions may result in fire electric
shock or other hazards. Serving should be performed only by a qualified and experienced
personnel.

Page 3
Notes
Handling
 Please retain the original shipping carton and/or packing materials supplied with this
product. To ensure the integrity of this product when shipping or moving, repackage the
unit as it was originally received. Do not use liquids, such as aerosol spray, near this
product. Do not leave rubber or plastic objects in contact with this product for long
periods of time. The product may become warm after long periods of use.
Locating
 Place the unit on a level surface. Do not place the unit on a shaky or unstable surface
such as a wobbling table or an inclined stand. If the unit is placed next to a TV, radio, or
VCR, the playback picture may become poor and the sound may be distorted. If this
happens, place the unit away from the TV, radio, or VCR.
Maintenance
 This DVR is designed to last for long periods of time. To keep the DVR always
operational, we recommend regular inspection maintenance (Cleaning or replacement).
For details, contact the nearest dealer.

Page 4
Contents
1. Product Components.................................................................................................................................... 8
2. Features ......................................................................................................................................................... 9
3. Specifications .............................................................................................................................................. 10
3-1. VVR4004SEFD, VVR4008SE, VVR4016SE ........................................................................................... 10
3-2. VVR4004HMFD, VVR4008HM, VVR4016HM ..................................................................................... 11
3-3. VVR4008HFD, VVR4016HFD ............................................................................................................... 13
3-4. VVR4016HSFD ..................................................................................................................................... 14
3-5. VVRHD0405M, VVRHD0805M, VVRHD1620M ................................................................................. 16
3-6. VVRHHD1002D .................................................................................................................................... 18
4. Front Panel Controls ................................................................................................................................... 20
4-1. VVR4004SEFD, VVR4008SE, VVR4016SE ........................................................................................... 20
4-2. VVR4004HMFD, VVR4008HM, VVR4016HM, VVR4008HFD, VVR4016HFD .................................... 20
4-3. VVR4016HSFD, VVRHD1620M, VVRHHD1002D................................................................................ 21
5. Rear Panel Connectors ............................................................................................................................... 22
5-1. VVR4004SEFD, VVR4008SE, VVR4016SE ........................................................................................... 22
5-2. VVR4004HMFD, VVR4008HM, VVR4016HM, VVR4008HFD, VVR4016HFD .................................... 23
5-3. VVR4016HSFD ..................................................................................................................................... 23
5-4. VVRHD0405M, VVRHD0805M, VVRHD1620M ................................................................................. 24
6. Remote Control........................................................................................................................................... 26
7. Connection Guide ....................................................................................................................................... 27
7-1. Connecting the Monitor ..................................................................................................................... 27
7-2. Video Inputs......................................................................................................................................... 27
7-3. Connecting to a Network .................................................................................................................... 27
7-4. Connecting Audio ................................................................................................................................ 27
7-5. Connecting a PTZ Camera ................................................................................................................... 27
7-6. Turning on the DVR ............................................................................................................................. 27
7-7. Using the Power Button ..................................................................................................................... 27
7-8. Setting the Remote Controller ID....................................................................................................... 28
7-9. First Time Booting ............................................................................................................................... 28
7-10. Basic Mouse Functions ..................................................................................................................... 28
8. SETUP MENU ............................................................................................................................................... 29
8-1. DISPLAY Setup ..................................................................................................................................... 30

Page 5
8-2. RECORD Setup ..................................................................................................................................... 31
8-3. DEVICE Setup ....................................................................................................................................... 33
8-5. STORAGE Setup ................................................................................................................................... 35
8-6. SYSTEM Setup ...................................................................................................................................... 38
8-7. SECURITY Setup ................................................................................................................................... 41
8-8. NETWORK Setup.................................................................................................................................. 43
8-9. CONFIG Setup ...................................................................................................................................... 45
9. OPERATION ................................................................................................................................................. 47
9-1. Live Display Mode ............................................................................................................................... 47
9-2. Icons ..................................................................................................................................................... 47
9-3. Search .................................................................................................................................................. 48
9-4. Playback ............................................................................................................................................... 52
9-5.Backup................................................................................................................................................... 53
9-6.Backup data playback .......................................................................................................................... 54
9-6-1. AVI Format – Media Player ......................................................................................................... 54
9-6-2. NSF Format - HD Player .............................................................................................................. 55
9-7.PTZ Control ........................................................................................................................................... 56
10. Remote Setup ........................................................................................................................................... 57
10-1. DISPLAY .............................................................................................................................................. 58
10-2. RECORD .............................................................................................................................................. 58
10-3. DEVICE ............................................................................................................................................... 59
10-4. STORAGE ............................................................................................................................................ 60
10-5. SYSTEM .............................................................................................................................................. 61
10-6. NETWORK .......................................................................................................................................... 62
10-7. REMOTE UPGRADE ........................................................................................................................... 63
10-8. INFORMATION................................................................................................................................... 63
11. DDNS Registration .................................................................................................................................... 64
12. NETWORK VIEWER ................................................................................................................................... 66
12-1. PC System Requirement ................................................................................................................... 66
12-2. Installation ......................................................................................................................................... 66
12-3. Live Mode .......................................................................................................................................... 67
12-4. Search Mode ..................................................................................................................................... 69
12-5. Operation........................................................................................................................................... 70
12-5-1. Digital Zoom ............................................................................................................................... 70

Page 6
12-5-2. Full Screen Display ..................................................................................................................... 70
12-5-3. Playback Buttons ....................................................................................................................... 71
12-5-4. Timeline Bar ............................................................................................................................... 71
12-5-5. Backup ........................................................................................................................................ 72
12-6. Local Setup ........................................................................................................................................ 73
12-6-1. General ....................................................................................................................................... 73
12-6-2.Site ............................................................................................................................................... 74
12-6-3. Event ........................................................................................................................................... 76
12-6-4. Event Search .............................................................................................................................. 77
12-6-5. Record ........................................................................................................................................ 77
12-6-6. Disk ............................................................................................................................................. 78
12-6-7.Display ......................................................................................................................................... 79
13. CMS ............................................................................................................................................................ 80
13-1. PC System Requirement ................................................................................................................... 80
13-2. Installation ......................................................................................................................................... 80
13-2. Live Mode .......................................................................................................................................... 81
13-3. Operations ......................................................................................................................................... 82
13-3-1. Group Management .................................................................................................................. 82
13-3-2. Connection ................................................................................................................................. 83
13-3-3. Playback ..................................................................................................................................... 84
13-3-4. Setup .......................................................................................................................................... 85
14. Web Client ................................................................................................................................................. 86
14-1. PC System Requirement ................................................................................................................... 86
14-2. Installation ........................................................................................................................................ 86
14-3. Live Mode .......................................................................................................................................... 87
14-4. Search Mode ..................................................................................................................................... 89
14-5. Operations ......................................................................................................................................... 91
14-5-1. Digital Zoom ............................................................................................................................... 91
14-5-2. Playback Buttons ....................................................................................................................... 91
14-5-3. Web Client Backup .................................................................................................................... 92
15. Smartphone Viewer App .......................................................................................................................... 92
15-1. Viewer for iPhone ............................................................................................................................. 92
15-1-1. Live.............................................................................................................................................. 92
15-1-2.PTZ Control ................................................................................................................................. 93

Page 7
15-1-3. Playback ..................................................................................................................................... 94
15-2. Viewer for Android Phone ................................................................................................................ 95
15-2-1. Live/Playback ............................................................................................................................. 95

Page 8
1. Product Components
Please make sure the following components are included as specified below.
DVR Set
Client Software CD, User Guide
Remote Control , Battery1.5V
Mouse
HDD Mounting Bracket & Screw*
SATA Cable, SATA Power Cable
HDD & DVD-RW Mounting Screw
HDD & DVD-RW Mounting Bracket
Power Cable & Power Adapter
(1 EA)
Power Cable (110V or 220V) (1 EA)*
*For VVR4016HSFD, VVRHD1620M, and VVRHHD1002D only

Page 9
2. Features
• H.264 video compression
• QUADPLEX: Simultaneous live or playback while recording, network transfer, and
backup
• USB 2.0 port for backup, firmware upgrade, configuration export/import, or USB
mouse
• Individual channel operation such as FPS, quality, recording mode, & detection zone
• Various network access: Network client SW, web-viewer, smart phone APP, and CMS
• Remote setup and remote upgrade
• Remote access via PC, MAC®, or smart phones
• Recording by schedule, continuous, alarm, motion, or continuous
• Free DDNS server
• Bandwidth control
• E-mail event notification
• NTP (Network Time Protocol)
• Watermark
• Synchronized audio
• Bi-directional audio
• Time stamp over backup data
• Easy and various data backup via DVD, USB flash drive, USB external HDD, and network
• HDD S.M.A.R.T status check and alert via e-mail or internal beep
• USB mouse, IR remote control
• Multi OSD languages
• Made in Korea

Page
10
3. Specifications
Please note that specifications and unit exterior design are subject to change without notification
3-1. VVR4004SEFD, VVR4008SE, VVR4016SE
Model
VVR4004SEFD VVR4008SE VVR4016SE
Recording Performance D1 * 120FPS CIF * 240FPS CIF * 480FPS
Video
Input Channel 4 channels 8 channels 16 channels
Input Level Composite, 1.0Vp-p, 75ohm
Output
VGA 1 VGA (Max. 1280x1024)
HDMI -
HD-SDI -
LOOP -
BNC 1 (Switchable to SPOT)
SPOT
Audio Input & Output 1 Line input & 1 Line output
Audio Codec G.711 (ADPCM)
Alarm Sensor Input -
Alarm Output -
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 120fps - 120fps
Half D1 120fps - 240fps
CIF 120fps 240fps 480fps
HD
Resolution
1280X720 - - -
1920X1080 - - -
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution Yes
Pre Recording Up to 10 sec Min. 15 seconds and Max. 20 minutes
Post Recording Up to 30 sec Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 8, 16
Playback Speed x1/4 ~ x16 x1/4 ~ x16 x1/4 ~ x8
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD 2TB
Internal HDD Number
1EA
ESATA -
Backup
USB Flash drive Video & Still Image

Page
11
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F
Menu Display GUI
Input Method Mouse, Remote control
Serial PTZ control -
Termination -
Console (RS-232C) -
Network
Dynamic DNS Yes
Network Interface 10/100 base-TX Ethernet (RJ-45)
Network Streaming CIF @ 60fps CIF @ 120fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage DC 12V 2.5A DC 12V 5A
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 2.8 Lbs (4.4 Lbs) 3 Lbs (4.6 Lbs) 3.4 Lbs (6.6 Lbs)
Dimension
Unit Dimension (W x H x D) 10.6" x 7.5" x 1.8" 10.6" x 7.5" x 1.8" 13.3" x 10.2" x 2.5"
3-2. VVR4004HMFD, VVR4008HM, VVR4016HM
Model VVR4004HMFD VVR4008HM VVR4016HM
Recording Performance D1 * 120FPS Half D1 * 240FPS CIF * 480FPS
Video
Input Channel 4 channels 8 channels 16 channels
Input Level Composite, 1.0Vp-p, 75ohm
Output
VGA 1 VGA (Max. 1080p)
HDMI 1 HDMI (Max. 1080p)
HD-SDI -
LOOP -
BNC 1 channel
SPOT 1 channel
Audio Input & Output 4 Line input & 1 Line output
Audio Codec G.711 (ADPCM)

Page
12
Alarm Sensor Input 4ch (NC/NO Selectable)
Alarm Output 1 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 120fps 120fps 120fps
Half D1 120fps 240fps 240fps
CIF 120fps 240fps 480fps
HD
Resolution
1280X720 - - -
1920X1080 - - -
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 8, 16
Playback Speed x1/4 ~ x32 x1/4 ~ x16 x1/4 ~ x8
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD 2TB
Internal HDD Number
1EA (2EA without DVD-RW)
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F Menu Display GUI
Input Method Mouse, Front Buttons, Remote control, Key Board
Serial PTZ control 1 RS-485
Termination -
Console (RS-232C) 1 (for Development use only, Reserved for POS)
Network
Dynamic DNS Yes
Network Interface 10/100 base-TX Ethernet (RJ-45)
Network Streaming CIF @ 60fps CIF @ 120fps CIF @ 240fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio

Page
13
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage DC 12V 5A
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 3 Lbs (4.6 Lbs)
Dimension
Unit Dimension (W x H x D) 14.96" x 13.38" x 2.83"
3-3. VVR4008HFD, VVR4016HFD
Model VVR4008HFD VVR4016HFD
Recording Performance D1 * 240FPS D1 * 480FPS
Video
Input Channel 8 channels 16 channels
Input Level Composite, 1.0Vp-p, 75ohm
Output
VGA 1 VGA (Max. 1080p)
HDMI 1 HDMI (Max. 1080p)
HD-SDI -
LOOP -
BNC 1 channel
SPOT 1 channel
Audio Input & Output 4 Line input & 1 Line output
Audio Codec G.711 (ADPCM)
Alarm Sensor Input 4ch (NC/NO Selectable)
Alarm Output 1 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 240fps 480fps
Half D1 240fps 480fps
CIF 240fps 480fps
HD
Resolution
1280X720 - -
1920X1080 - -
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution
Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4, 8 1, 4, 8, 16

Page
14
Playback Speed x1/4 ~ x64
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD 3TB
Internal HDD Number
2EA (3EA without DVD-RW)
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F
Menu Display GUI
Input Method Mouse, Front Buttons, Remote control, Key Board
Serial PTZ control 1 RS-485
Termination -
Console (RS-232C) 1 (for Development use only, Reserved for POS)
Network
Dynamic DNS Yes
Network Interface 10/100/1000 base-TX Ethernet (RJ-45)
Network Streaming D1/CIF @ 240fps D1/CIF @ 480fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage DC 12V 5A
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 9 Lbs (13.6 Lbs)
Dimension
Unit Dimension (W x H x D) 14.96" x 13.38" x 2.83"
3-4. VVR4016HSFD
Model VVR4016HSFD
Recording Performance D1 * 480FPS
Video Input Channel 16 channels Input Level Composite, 1.0Vp-p, 75ohm
Output
VGA 1 VGA (Max. 1080p)

Page
15
HDMI 1 HDMI (Max. 1080p)
HD-SDI -
LOOP 16 channels
BNC 1 channel
SPOT 4 channel
Audio Input & Output 16 Line input & 1 Line output
Audio Codec G.711 (ADPCM)
Alarm Sensor Input 16ch (NC/NO Selectable)
Alarm Output 4 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 480fps
Half D1 480fps
CIF 480fps
HD
Resolution
1280X720 -
1920X1080 -
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4, 8, 16
Playback Speed x1/4 ~ x32
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD 2TB
Internal HDD Number
2EA (4EA without DVD-RW)
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F Menu Display GUI
Input Method Mouse, Front Buttons, Remote control, Key Board
Serial PTZ control 2 RS-485
Termination 2
Console (RS-232C) 1 (for Development use only, Reserved for POS)
Network Dynamic DNS Yes

Page
16
Network Interface 10/100/1000 base-TX Ethernet (RJ-45)
Network Streaming CIF/D1 @ 480fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage AC 100~120V/200~240V, 50/60Hz, 280W
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 15.0 Lbs (19.8 Lbs)
Dimension
Unit Dimension (W x H x D) 17.00" x 16.92" x 3.86"
3-5. VVRHD0405M, VVRHD0805M, VVRHD1620M
Model VVRHD0405M VVRHD0805M VVRHD1620M
Recording Performance 720p * 48FPS /
1080P * 20FPS
720p * 120FPS /
1080P * 40FPS
720p * 192FPS /
1080P * 80FPS
Video
Input Channel 4 channels 8 channels 16 channels
Input Level HDcctv/HD-SDI
Output
VGA 1 VGA (Max. 1080p)
HDMI 1 HDMI (Max. 1080p)
HD-SDI - - 1 channel
LOOP
BNC
SPOT
Audio Input & Output 4 Line input & 1
Line output
8 Line input & 1
Line output
16 Line input & 1 Line
output
Audio Codec G.711 (ADPCM)
Alarm Sensor Input 4ch (NC/NO
Selectable)
8ch (NC/NO
Selectable)
16ch (NC/NO
Selectable)
Alarm Output 1 Alarm out 2 Alarm out 4 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 - - -
Half D1 - - -
CIF - - -
HD 1280X720 48fps 96fps 192fps

Page
17
Resolution 1920X1080 20fps 40fps 80fps
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4 1, 4, 8 1, 4, 8, 16
Playback Speed x1/4 ~ x32 x1/4 ~ x16 x1/4 ~ x8
Search Mode Timeline, Event, Archive, Log
Storage
HDD
Interface Type Serial ATA I
Capacity of 1 HDD
2TB
Internal HDD
Number 1EA (2EA without DVD-RW) 2EA (4EA without DVD-RW)
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD
Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F Menu Display GUI
Input Method Mouse, Front Buttons, Remote control, Key Board
Serial PTZ control 1 RS-485 2 RS-485
Termination 1 2
Console (RS-232C) 1 (for Development use only)
Network
Dynamic DNS Yes
Network Interface 10/100/1000 base-TX Ethernet (RJ-45)
Network Streaming 640x360 / 320x180
@ 120fps
640x360 / 320x180
@ 240fps
1280x720 / 640x360
@ 240fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW
(1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage DC 12V 5A
AC
100~120V/200~240V,
50/60Hz, 280W
Allowable operation temperature 5°C - 40°C 5°C - 40°C

Page
18
Allowable operation humidity 0 - 90 % 0 - 90 %
Weight Unit Weight (Gross weight) 9 Lbs (13.6 Lbs) 15.0 Lbs (19.8 Lbs)
Dimension
Unit Dimension (W x H x D) 14.96" x 13.38" x 2.83" 17.00" x 16.92" x
3.86"
3-6. VVRHHD1002D
Model VVRHHD1002D
Recording Performance Analog: D1 Real time
HD: 720P * 60FPS / 1080P * 30FPS
Video
Input
Channel 10 channels
Input Level 8 CH Composite, 1.0Vp-p, 75ohm &
2 CH HDcctv/HD
-
SDI
Output
VGA 1 VGA (Max. 1080p)
HDMI 1 HDMI (Max. 1080p)
HD-SDI -
LOOP Analog 8 channels
BNC 1 channel
SPOT 4 channel
Audio Input & Output 10 Line input & 1 Line output
Audio Codec G.711 (ADPCM)
Alarm Sensor Input 10ch (NC/NO Selectable)
Alarm Output 4 Alarm out
Record
Compression H.264
Multi-operation QUADPLEX (Playback/Record/Network/Backup)
Analog
Resolution
D1 240fps
Half D1 240fps
CIF 240fps
HD
Resolution
1280X720 60fps
1920X1080 30fps
Recording quality grade 5 Grades
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection Motion detection setup by Grid
Recording by channel’s
Resolution Yes
Pre Recording Min. 15 seconds and Max. 20 minutes
Post Recording Min. 10 seconds and Max. 60 seconds
Display Frame Rate Real time
Playback
Multi-Decoding 1, 4
Playback Speed x1/4 ~ x32
Search Mode Timeline, Event, Archive, Log
Storage HDD
Interface Type Serial ATA I
Capacity of 1 HDD 2TB
Internal HDD Number
2EA (4EA without DVD-RW)

Page
19
ESATA 1
Backup
USB Flash drive Video & Still Image
USB External HDD Video & Still Image
Network Video & Still Image
USB Port 2 (Front 1, Rear 1)
User I/F Menu Display GUI
Input Method Mouse, IR Remote control, Key Board Control
Serial PTZ control 2 RS-485
Termination 2
Console (RS-232C) 1 (for Development use only)
Network
Dynamic DNS Yes
Network Interface 10/100/1000 base-TX Ethernet (RJ-45)
Network Streaming 640*360 / 1280*720 @ 120fps
Network
Access
Web viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
3G Mobile Viewer (1:1) Live, Search, PTZF, Two Way Audio
MAC viewer (1:1) Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade
Multi-sites Monitoring SW (1:n)
Live, Search, Backup, PTZF, Remote Setup, Remote Upgrade,
Two Way Audio
Features
DLS (Day Light Saving) Yes
Internal Beep By Alarm, Motion, Video Loss, HDD error
S/W Upgrade USB Flash drive, Remote Network
NTP Yes
Power Power Supply Voltage AC 100~120V/200~240V, 50/60Hz, 280W
Allowable operation temperature 5°C - 40°C
Allowable operation humidity 0 - 90 %
Weight Unit Weight (Gross weight) 15.0 Lbs (19.8 Lbs)
Dimension
Unit Dimension (W x H x D) 17.00" x 16.92" x 3.86"

Page
20
4. Front Panel Controls
4-1. VVR4004SEFD, VVR4008SE, VVR4016SE
VVR4004SEFD, VVR4008SE
VVR4016SE
1 Recording Indicator
Indicator LED when a specific CHANNEL is recording.
2 Power Indicator
Indicator LED when DVR is powered ON.
3 USB Port
Allows the user to connect a USB mouse or USB flash drive for BACK UP.
4-2. VVR4004HMFD, VVR4008HM, VVR4016HM,
VVR4008HFD, VVR4016HFD
1 Optical Drive Door
2 Camera Selection
Allows the user to select specific channels for single channel view.
3
Playback Buttons
