Vortran Stradus User manual

Stradus™ Laser
User Manual

www.vortranlaser.com
Vortran Laser User Manual Table of Contents
1.0 List of Tables i
2.0 List of Figures I
3.0Symbols A
4.0 Laser Safety 1
4.1 Compliance Standards 1
4.2 Vortran Laser Classification 2
4.3 Observations 2
4.4 Laser Safety Labels 2
4.5 Electrical Safety 3
4.6 Optical Safety 3
4.7 Vortran Laser Safety Features 4
4.7.1 Protective Housing 4
4.7.2 Power Indicator 4
4.7.3 Interlock Indicator 5
4.7.4 Remote Interlock Operation 6
4.7.5 Interlock Diagram 7
4.7.6 Laser Emission Indicator 8
4.7.7 Shutter 8
4.7.8 Key Switch 9
4.7.9 Laser Emission Delay 9
4.7.10 Computer Control 9
5.0 System Information 11
5.1 System Features 11
5.2 System Description 11
5.3 Power Supply Ratings 11
5.4 Environmental Operating Conditions 11
5.5 Block Diagram 12
6.0 Installation 13
6.1 System Installation Checklist 13
6.2 Unpacking and Inspection 14
6.3 Laser Mounting 15
6.3.1 Laser System Drawings 15
6.3.2 Heat Sink Requirements 16
6.3.3 Mounting Hardware 16
6.3.4 Torque Specification 16
6.3.5 USB Connection 17
6.3.6 Laser Control box 17
6.3.7 Power Supply Connection 17
6.3.8 RS-232 Connection 17
6.3.9 I/O Connections 18

www.vortranlaser.com
6.3.10 BNC Connector 19
6.3.11 Remote Interlock Plug 20
7.0 OEM Laser Installation 21
7.1 OEM Laser Installation Checklist 21
7.2 Laser Head Drawings 21
7.3 Heat Sink Requirements 22
7.4 Laser Mounting Hardware 22
7.5 Torque Specifications 22
7.6 Input Connector Specifications 23
7.7 Power Supply Requirements 23
7.8 Laser Head Pins 24
7.9 USB Connection 26
7.10 USB Drivers 26
7.11 RS-232 Connection and Protocol 27
8.0 Laser Operation 29
8.1 Laser Operation Checklist 29
8.2 Auto-start vs Manual Start 29
8.3 Laser Warm-up and Standby 30
8.4 Electrical Input / Output Functions 30
8.5 Laser Emission 32
8.5.1 Shutter Operation 32
8.5.2 Near-field Beam Quality 32
8.5.3 Far-field Beam Quality 33
8.5.4 Analog Power Control 33
8.6 Digital Modulation (Optional) 34
8.6.1 Digital Modulation Specification 34
8.6.2 SMB Connection 34
8.6.3 Operation 34
9.0 Computer Controlled Operation 37
9.1 USB Connection 37
9.2 RS-232 Connection and Setup 38
9.3 Command and Query Summary 39
9.3.1 Commands 39
9.3.2 Queries 40
9.4CommandDetail 41
9.5QueryDetail 49
9.6 Fault Codes 57

www.vortranlaser.com
10.0 Vortran Stradus™ Control Software 58
10.1 Supported Operating Systems 58
10.2CDContents 58
10.3 USB Driver Installation 58
10.4 Software Installation 62
10.5 Menu Items 66
10.5.1 Open Configuration File 66
10.5.2 Save Configuration File 66
10.5.3 Print Configuration Settings 67
10.5.4 Print Active Window 67
10.5.5 View Menu 67
10.5.6 Help Menu 67
10.5.7 Add RS-232 Laser Button 69
10.6 Home Screen 69
10.6.1 Status 70
10.6.2 Laser Hours 70
10.6.3 Digital Modulation 71
10.6.4 External Control 72
10.6.5 Emission 72
10.6.6 Laser Output 72
10.6.7 Base Plate Temperature 74
10.6.8 Diode Temperature 74
10.7 Information Screen 75
10.8 Terminal Screen 76
10.8.1 Script Mode 76
10.8.2 Control Buttons 77
10.8.3 Load Script File 78
10.8.4 Clear Window and Save Session File Log 78
10.9 Tool Bar 79
10.10 Status Bar 79
11.0Tutorials 81
11.1 External Laser Power Control 81
11.2 Laser Enable Modulation 84
11.3 Laser Diode Current and Direct Current Control 86
12.0 Troubleshooting Guide 87
12.1 Resolving Faults 87
12.2 Temperature Faults 89
12.3 Laser at Half Power 89
12.4 Poor Beam Quality 90

www.vortranlaser.com
13.0 Glossary 91
14.0Warranty 93
15.0 Returning Laser for Service 95
16.0 Contact Vortran Laser Technology 97

www.vortranlaser.com
i
1.0 List of Tables
Table Description Page
1 PackingList 14
2 RS-232 Pin Connections 17
3 Control Box I/O Pin Descriptions 19
4 Laser Head Pin Descriptions 24
5 RS-232 Laser Head Connections 27
6 Laser Head Pin Descriptions 31
7 Digital Modulation Specifications 34
8 USB Pin Descriptions 37
9 RS-232 Connections and Communication Protocol 38
10 Command and Query Summary 39
11 Command Detail 41
12 Query Detail 49
13 Fault Codes 57
14 Configuration File Settings 67
15 RS-232 Connections and Communication Protocol 81
16 Fault Code Resolution 88
17 Repacking Parts List 95

www.vortranlaser.com
ii

www.vortranlaser.com
I
2.0 List of Figures
Figure Description Page
1 Laser Safety Label Location 2
2 Serial Number Label 2
3 Laser Head Power Indicator 4
4 Control Box Power Indicator 4
5 Control Box Interlock Indicator 5
6 Remote Interlock Plug 6
7 Interlock Diagram 7
8 Laser Emission Indicator 8
9 Laser Shutter Positions 8
10 Control Box Key Switch 9
11 System Block Diagram 12
12 Laser Head Dimensions 15
13 Control Box Dimensions 15
14 Laser Head Torque Pattern 16
15 Mini-DIN Plug 18
16 I/O Pin Diagram 18
17 Remote Interlock Plug 20
18 Laser Head Dimensions 21
19 Laser Mounting Dimensions 21
20 Laser Mounting Torque Pattern 22
21 Laser Solder Connections 23
22 Laser Head Pin Numbers 24
23 I/O Pin Diagram 30
24 Laser Head Pin Numbers 31
25 Laser Head Shutter Positions 32
26 Near-field Beam Image 32
27 Far-field Beam Image 33
28 SMB Connector Location 34
29 Pulse Mode Example 35
30 USB Connector Location 37
31 USB Connector Diagram 37
32 Initial USB Connection Message 59
33 Computer Restart Message 59
34 Windows Device Manager 60
35 Computer Properties 60
36 System Properties 61
37 Initial Software Installation Screen 62
38 Software Installation Welcome Screen 63
39 Software Installation Location Screen 64
40 Software Installation Confirmation Screen 64

www.vortranlaser.com
II
41 Software Installation Progress Screen 64
42 Software Installation Completion Screen 65
43 File Menu 66
44 View Menu 68
45 Help Menu 68
46 Add RS-232 Laser Button 69
47 Home Screen 69
48 Laser Status Indicator 70
49 Laser Hours 70
50 Digital Modulation 71
51 External Control 72
52 Laser Emission Indicator 72
53 Laser Power and Current Indicators 73
54 Base Plate Temperature Indicator 73
55 Diode Temperature 74
56 Information Screen 75
57 Terminal Screen 76
58 Script Mode 76
59 Execute Script 77
60 Load Script File 77
61 Clear Window / Save Session File Log 78
62 Tool Bar 79
63 Status Bar 79
64 Control Box Front View 81
65 External Control Setting 82
66 DelayScript 84
67 Laser Enable I/O Pins 84
68 Laser Enable Laser Pins 85
69 Laser Current Home Screen Setup 86
70 Fault Pin 87

www.vortranlaser.com
A
3.0 Symbols
ESD – This symbol is used to alert the user of hazards associated
with Electro-static Discharge.
Laser Radiation – This symbol is used to alert the user of hazards
associated with optical radiation emitted from the laser.
CE Mark – This symbol represents the European Directive
Conformite Europeenne" to certifiy that a product has met EU
health, safety, and environmental requirements, which ensure
consumer safety. Manufacturers in the European Union (EU) and
abroad must meet CE marking requirements where applicable in
order to market their products in Europe.
Ground – This symbol represents electrical ground.
USB – This symbol is used to reference Universal Serial Bus
Communication.

www.vortranlaser.com
B
No Text on This Page

www.vortranlaser.com
1
4.0 Laser Safety
4.1 Compliance Standards
The Vortran Stradus™ Laser complies with CDRH safety requirements, based on
EN60825-1. The compliance is based on use with the Vortran Stradus™ Control
box. The control box contains the key switch, interlock and Emission LED
required for compliance. Secondary power and laser emission indicators are
located on the laser rear plate. The Vortran Laser CDRH accession number is
on file and available upon request.
The Vortran Laser has been tested and certified by an outside testing agency, to
comply with the following directives:
EMI Standard EN61326-1 Including:
EN55011 Class A radiated emissions
EN55011 Class A conducted emissions
EN61000-3-2 Power Line Harmonics
EN61000-3-3 Power Line Flicker
EMC Standard EN61326-1 Including:
EN61000-4-2 ESD
EN61000-4-3 Radiated Immunity
EN61000-4-4 Electrical Fast Transient
EN61000-4-5 Electrical Surge (L-L and L-E)
EN61000-4-6 Conducted Immunity (Power / I/O Lines)
EN61000-4 11 Power Line Dips and Brown Outs
LVD – Low Voltage Directive 73/23/EEC Including:
IEC61010-1 Standard for Electrical Equipment
LVD – Radiation Safety for Laser Products Including:
IEC 60825-1 Safety Standard for Laser Products

www.vortranlaser.com
2
4.2 Vortran Laser Classification
The Vortran laser conforms to Class IIIb requirements as specified by the Center
for Device and Radiological Health (CDRH). The Vortran laser emits visible or
invisible laser radiation from the aperture located in the front of the laser head.
The emitted wavelength and maximum power level are specified on the laser
safety label. The typical divergence for all Vortran Stradus™ lasers is 0.5mrad.
4.3 Observations
If the equipment is used in a manner not specified by Vortran Laser Technology,
the protection provided by the equipment may be impaired.
4.4 Laser Safety Labels
Laser Head Top View
Figure 1
Laser Safety Label Location
Compliant Laser Serial Number Label
OEM Non-Compliant Standard Compliant System
Figure 2
Laser Head Serial Number Label

www.vortranlaser.com
3
4.5 Electrical Safety
No hazardous voltages are contained in the Vortran laser head. The system
does not contain any user accessible components within the laser head or
control box. The warranty will void if the laser head or control box enclosures are
disassembled.
ESD
Vortran Laser Technology recommends proper ESD precautions are taken when
handling the laser head and control box. The Vortran Stradus™ Laser System is
designed with internal safeguards for protection from ESD. Even with the tested
design safeguards in place, high energy ESD discharge events may cause
damage to the laser system. Vortran Laser Technology recommends handling
and operating the laser system on a grounded work bench or optical table.
4.6 Optical Safety
Based on the properties associated with laser light, special optical safety
precautions are recommended by Vortran Laser Technology. Direct eye
exposure from the laser light emitted from the output aperture located on the
front of the laser head is considered dangerous. Vortran Laser Technology
recommends the use of proper laser safety eyewear when operating the laser
system. Please verify the wavelength of the laser being used and the
wavelength of laser eyewear is appropriate for the laser. The laser output should
be contained in a secure beam path. The user should be aware of propagation
associated with reflective and refractive optical components to be known prior to
laser exposure. The laser emission indicators located on the control box and
laser head, emit wavelength visible when using the proper laser safety eyewear.
Exercise caution when operating the laser with laser safety eyewear in place.
The use of laser safety eyewear provides additional protection to the user. This
use can eliminate the ability to see the beam path when the laser shutter is
open. Vortran Laser Technology recommends that all optical setups are
constructed at levels well below eye level for optical safety reasons.

www.vortranlaser.com
4
4.7 Vortran Laser Safety Features
4.7.1 Protective Housing – The Vortran Laser Head and Control box include a
protective housing. These housings are not intended to be removed by
the user and the warranty will be voided if user removal occurs. If the
housing is removed, the user may be exposed to laser radiation or line
voltage. Please return the laser or control box to the factory for any
required repair or service. The factory contact information is located at
the end of this manual.
4.7.2 Power Indicator – Power indicators are located on both the laser head
and control box. With the laser head connected to the control box, power
indicators will illuminate with the control box power switch in the “On”
position. These indicators are visible when using laser safety
eyewear. Please note the location of the power indicators on the
following images.
Figure 3
Laser Head Power Indicator
Figure 4
Control Box Power Indicator
CONTROL BOX ILLUMINATED
POWER SWITCH
LASER HEAD POWER INDICATOR

www.vortranlaser.com
5
4.7.3 Interlock Indicator – Two types of laser emission indicators are provided
by Vortran Laser Technology. The Vortran Stradus™ Control Box
Includes an Interlock Indicator. When the power switch is in the “ON”
position and the key switch is set to the “ON” position, the interlock
indicator will be illuminated. This is an indicator of interlock status only
and may not be a direct indicator of active laser emission. When the
indicator is active, laser emission is possible and the laser head should
be considered dangerous.
Laser emission is not possible if the key switch is in the “OFF”
position.
The interlock status is constantly monitored and reported by the
microprocessor in the laser head.
Computer accessible interlock status can be monitored continuously with
the Vortran Stradus™ Control software (Review the Software Section
for additionaliInformation). The interlock status is also accessible
with the ?IL query via RS-232 or USB.
Figure 5
Control Box Interlock Indicator
CONTROL BOX INTERLOCK INDICATOR

www.vortranlaser.com
6
4.7.4 Remote Interlock Operation – The laser control box includes a jack on
the rear panel for remote interlock operation. The Vortran Stradus™
Laser System is shipped with a mating plug for a remote interlock
connection. When the plug is installed and the plug connection is open,
laser emission is not possible. When the plug connection is installed and
closed and the key switch is in the “ON” position, laser emission is
possible.
THE REMOTE INTERLOCK PLUG IS NOT REQUIRED FOR NORMAL
LASER OPERATION
Figure 6
Remote Interlock Plug
A remote interlock device can be soldered to the Mono Plug center
(Tip Connection) and sleeve (Base Connection)

www.vortranlaser.com
7
4.7.5 Interlock Diagram
Figure 7
Interlock Diagram
4.7.6 Laser Emission Indicator – The Vortran Laser Head includes a laser
emission indicator. The wavelength of the indicator allows it to be viewed
when using laser safety eyewear. The laser emission indicator is

www.vortranlaser.com
8
controlled by the Vortran Laser microprocessor in the laser head and
will illuminate prior to laser emission, when the 5 second CDRH
delay is active. The indicator will be active when power is applied
and the interlock is closed and no fault conditions exist. Unlike the
Interlock Indicator, the Laser Emission Indicator does provide a direct
indication of laser emission and the laser head should be considered
dangerous when the indicator is active.
Figure 8
Laser Emission Indicator
4.7.7 Shutter – The slide operation of the Vortran Laser Shutter, provides the
ability to block the laser output when the emission status is active. The
shutter includes a detent to ensure the shutter remains in the fully
open or closed position. The shutter design ensures no laser light
will be emitted in the closed position. The laser top label provides
indication for the open and closed position. The shutter operates with
a horizontal sliding motion.
Figure 9
Laser Shutter Positions
4.7.8 Key Switch – The Vortran Laser Key Switch provides the ability to initiate,
halt or prevent laser emission. With the power on and the key switch in
the “ON” position, laser emission is possible. Possible laser emission
Open
Position
Closed
Position
LASER EMISSION
INDICATOR
Laser
Emission
Aperture
