SPECTROPHOTOMETER
CM-2500d
High performance, low cost
portable spectrophotometer.
Mac OS 9.2J illustrator 10J
CM-2600d_cover.ai 2006.11.21

MAV ø8mm
Target mask
Simultaneous measurement of SCI and SCE displays the
data on the LCD in only 1.5 seconds. Unlike conventional
spectrophotometers, there is no need to mechanically
switch between SCI and SCE mode. This improves
working efficiency and provides stable measured data
since the measurement area does not shift when the mode
is switched. And also Relativity Gloss Value can be
displayed by using Numerical Gloss Control.
• SCI is a method in which measurements are
taken with the specular reflection included.
For this reason, it minimizes influences of the
surface condition of a sample, and is
especially suitable for color quality control and
Computer Color Matching.
• SCE is a method in which measurements are
taken excluding the specular reflection. This
type of measurement provides results similar
to those observed visually.
The battery-powered small, light body allows the instrument to be
placed in any position at the sample surface.
The CM-2500d's large LCD display and its reverse display
function provide easy reading, irrespective of which hand it is
held in. Using your finger, the navigation wheel allows simple,
user friendly operation.
( Turn) ( Push)
The optics use an integrating sphere to provide diffuse
illumination/8-degree viewing system.
The CM-2500d conforms to all widely accepted standards
including ISO, JIS, DIN, CIE and ASTM, and generates
measurements in color spaces such as L*a*b*, Yxy,
Munsell and CMC.
Promotes accurate, consistent color communication.
Conforms to widely-accepted industry standards and
allows measurements in all popular color spaces.
The user can choose the most suitable measurement area
for the target. The easy-to-carry body with the illuminated
viewfinder enables the user to position the instrument on
the target quickly and accurately.
Allows measurement in any position.
Compact, lightweight, with an easy-to-operate
navigation wheel and large LCD display.
Simultaneous measurement of SCI (specular component included) and SCE (specular component excluded).
Advanced Numerical Gloss Control.
The number of moving parts in the instrument is minimized
through the introduction of numerical control technology.
The CM-2500d can be used with confidence, since it has
been developed, manufactured and calibrated to meet ISO
9001 requirements.
High reliability and long life.
Maintenance-free design.
Measures the target with high accuracy.
Easy-to-carry stylish body with an
illuminated viewfinder.
Light source for SCI
For paints, plastics, automobiles, ceramics, architectural interiors, textile, paper, food etc.
Light source for
specular component
Mac OS 10.3.7Jillustrator 10J
CM-2500d(E)_inside.ai 2006.11.22
Designed for versatility in various applications, the CM-2500d is a portable
integrating sphere spectrophotometer incorporating Numerical Gloss Control.
Illuminated viewfinder
Numerical Gloss Control
Light source for specular component
Light source for SCI
Expanded LCD display (64 x 240 dots)
Displays large quantities of information
(simultaneous display of SCI and SCE data etc.)
d/8 integrating sphere
optics that conform to
industry standards
High-accuracy sensor
Measures at 10nm intervals for the full wavelength range.
Excellent repeatability
Easy-to-carry, compact
and light body
670g (without batteries)
The LCD specifications are subject to
change without prior notice.
For plastics, paints, resins and consumer products
Relativity Gloss Value
For pharmaceuticals, cosmetics, printing, building materials, textiles, food etc.In various applications
Finder
Powerful partnership between
CM-2500d and
Color Data Software
SpectraMagicTM NX enables you to perform comprehensive color
inspection and analysis of incoming raw materials, in process
production, and outbound color critical goods and materials in
virtually any industry. With SpectraMagicTM NX you can insert digital
images with measured data. Measure samples in any of 8
universally accepted color spaces. Select from 15 illuminants, and
up to 40 indices to determine specific color and appearance
properties, such as strength, brightness, haze, yellowness, opacity
and strength. You can even configure up to 3 customized color
equations. Reports range from simple Pass/Fail to trend charts,
histograms, color plots, and spectral graphs. SpectraMagicTM NX
comes with predefined templates using skin technology, or you can
create your own templates. For illustrations and explanations to
understanding color and color measurement technology, there is a
link to Konica Minolta's well known and respected “Precise Color
Communication”. Step by step navigation help. SpectraMagicTM NX
conforms to FDA 21 CFR Part 11 assuring integrity and reliability of
data records.
•Windows®is a trademark of Microsoft Corporation in the USA and other countries.
(Optional)
Supports Windows®2000/XP
SpectraMagicTM NX
SpectraMagicTM NX

For correct use and for your safety, be sure to read the
instruction manual before using the instrument.
Always connect the instrument to the specified
power supply voltage. Improper connection
may cause a fire or electric shock.
Be sure to use the specified batteries. Using
improper batteries may cause a fire or electric
shock.
Certificate No : JQA-E-80027
Registration Date : March 12, 1997
Certificate No : YKA 0937154
Registration Date : March 3, 1995
System Diagram
Standard Accessories
*1 Operating temperature/humidity range of products for North America : 5 to 40˚C, relative humidity 80% or less (at 31˚C) with no condensation
Specifications
Optional Accessories
193
69
96
AA-size
battery (x4)
AC Adapter AC-A17
AC Adapter AC-A23 (for Korea)
Vinyl cover
Dust cover CM-A152
Target mask ø8 mm
CM-A146
CM-2500d
RS232C cable
IF-A16
Hard case CM-A148
Dust cover set CM-A149
Zero calibration box CM-A32
Personal Computer
(commercially available)
White calibration plate CM-A145
d/8 (diffuse illumination, 8-degree viewing ), equipped with simultaneous
measurement of SCI (specular component included)/SCE(specular
component excluded) Conforms to CIE No.15,ISO 7724/1,ASTM E1164,
DIN 5033 Teil7 and JIS Z8722 Condition C standard.
ø52mm
Silicon photodiode array (dual 40 elements)
Diffraction grating
360nm to 740nm
10nm
Approx. 10nm
0 to 175%, resolution: 0.01%
2 pulsed xenon lamps
Approx. 1.5 seconds (approx. 2 seconds for fluorescent measurement)
3 seconds for SCI/SCE (4 seconds for fluorescent measurement)
Alkaline manganese:approx. 1000 measurements
MAV: ø8mm/ø11mm
Spectral Reflectance:Standard deviation within 0.1% (360 to 380nm within 0.2%)
Colorimetric Value : Standard deviation within ∆E*ab 0.04(Measurement
conditions:White calibration plate measured 30 times
at 10-second intervals after white calibration was performed)
within ∆E*ab 0.2 (MAV/SCI) Average for 12BCRA Series II color
tiles compared to values measured with master body.
Single measurement/automatic averaging of multiple measurements
(auto mode: 3, 5, 8 times/manual mode)
RS-232C standard
2/10 degrees (CIE 1931/2°,CIE 1964/10°)
A, C, D50, D65, F2, F6, F7, F8, F10, F11, F12 (simultaneous evaluation
is possible using two light sources)
Spectral value/graph, colorimetric value, color difference value/graph,
PASS/FAIL result
L*a*b*, L*C*h, CMC (1:1), CMC (2:1), CIE94, Hunter Lab, Yxy, Munsell,
XYZ, MI, WI (ASTM E313), YI (ASTM E313/ASTM D1925), ISO Brightness
(ISO 2470), Density status A/T, WI/Tint (CIE/Ganz), CIE00
1700 pieces of data (as SCI/SCE 1 data) * 700 pieces of data in the “ defined in COND.” mode.
* Total of the sample data for the COND and TASK modes and color difference target data
Tolerance for color difference (both box and eliptical tolerances can be set)
4 AA-size battery or AC adapter
69 x 96 x 193mm
Approx. 670g (without batteries)
5 to 40˚C, relative humidity 80% or less (at 35˚C) with no
condensation
0 to 45˚C, relative humidity 80% or less (at 35˚C) with no
condensation
White calibration plate, Target mask ø8mm, RS-232C cable,
AC adapter, AA-size battery (x4)
Hard case, Dust cover set, Dust cover,
SpectraMagic
TM
NX(software), Zero calibration box
Illumination/
viewing system
Sphere Size
Light-receiving element
Spectral separation device
Wavelength range
Wavelength pitch
Half bandwidth
Reflectance range
Light source
Measurement time
Minimum interval
between measurements
Battery perfomance
Measurement/
illumination area
Repeatability
Inter instrument
agreement
Measurement
mode
Interface
Observer
Illuminant
Display data
Color space/
colorimetric data
Data memory
Tolerance Display
Power source
Size (WxHxD)
Weight
Operating temperature/
humidity range (*1)
Storage temperature/
humidity range
Standard
accessories
Optional
Accessories
High inter-instrument agreement between the
portable CM-2500d spectrophotometer and the
desktop CM-3000 series make it easy to build a
total color control network.
R&D
Quality control Production
CM-3700d
CM-3600d
Company
B
In-house color control Color control among companies
R&D
Quality Production
Company
A
R&D
Quality Production
CM-2500d CM-2500d
Dimensions (Units:mm) CM-2500d
Color control network by spectrophotometer
AGMGPK
Printed in Japan9242-4879-41
2001 KONICA MINOLTA SENSING, INC.
SAFETY PRECAUTIONS
11
CM-S100w
SpectraMagicTM NX
* The specifications and
drawings given here are
subject to change without
prior notice.
