VOVO Imunsen M-003W User manual

Imunsen Portable Air Purifier
User Manual
V O V O CO R P O R AT I O N

01
Dear Customers
Thank you very much for purchasing
the Imunsen air purifier.
Please read the manual carefully for
correct and safe use.
This manual includes the warranty.
Please note the date and the
location of the purchase, and keep
the manual at a safe place.

Table of Contents
02
Product Introduction
Basic Components
Part names
Assembling Guide
Installation Guide
Product Functions
Managing the Product
Cypress Wood Filter
Warranty
Precautions
Product Specification
FAQ
Inquiries
Warranty
User Guide
Maintenance
Precautions
Product Information
05
06
03
07
09
10
11
12
13
14
15
16
17

Please switch off the product and unplug the
power cord before moving the product.
Moving the product.
Installation
03
Precautions
Precautions
In the vehicle
Do not install the product where there is a flammable
gas leak or possibility of a leak. Keep the product out of
direct sunlight, excessive heat, and water. Do not install
the product on uneven or inclined surfaces. Do not
install the product where there is a lot of industrial oil,
smoke or metalic dust. Install the product so the inlet
and outlet of the product are not completely blocked.
Do not install the product in locations besides the
vehicle cup holder. Fix the product firmly to the
vehicle cup holder. Place the product firmly into the
vehicle cup holder. Product fits into cupholders with
75mm diameter and 50mm height or more. Only
available for vehicle with voltage of DC 5V.
When using
Do not let water or foreign objects inside the product.
Do not touch the power cord with wet hands. Do not
put foreign objects or fingers inside the air inlet and
outlet. When used with heaters, it is necessary to
ventilate in order to prevent carbon monoxide
poisoning. Do not unplug the power cord while the
product is running.

04
Precautions
Precautions
In the vehicle
When using
When using the product, the proper temperature is
0 ~ 40 ℃. Proper temperature for storing the product is
-10 ~ 70 ℃. Be careful not to spill liquids such as water
or drinks on the bottom of the cup holder. Do not
place the product in direct sunlight.
1. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
2. Children should be supervised to ensure that they
do not play with the appliance.
3. The instructions for appliances having a part of class
III construction supplied from a detachable power
supply unit shall state that the appliance is only to be
used with the power supply unit provided with the
appliance.
The instructions for class III appliances shall state that
it must only be supplied at safety extra low voltage
corresponding to the marking on the appliance.

Cleaning
Restrictions on use
05
In the event of anomalies such as strange smells,
sounds, high temperatures, or irregular winds from
the product, please immediately stop using the
product. If the product is submerged in water,
contact service center. Do not let the moisture
emitted from the humidifier directly exposed to the
product. Do not use in places with high tempera-
ture or high humidity. Do not disassemble, repair or
remodel the product. Do not place heavy objects on
the product or subject it to a shock.
Please make sure to switch off the product before
cleaning. Do not spray water on the product or wipe
it with benzene, thinner, alcohol, acetone, etc. Do
not disassemble and clean the insides of the product.
Precautions
Precautions

Base (1)
Cyprees Wood filter (1)
Circular filter (1)
C type Charging Cable (1)
USB Car Charger Adapter (1)
User Guide,
Warranty (1)
VO V O C O R P O R AT I O N
Product Introduction
Basic Components
06
Imunsen portable air purifier
user manual

Wind Speed in
3 Levels with
LED Display
Air Outlet
Power &
Wind Speed
Control Button
Cypress Wood
Filter
Base Part
LED Light
Air Inlet
Product Introduction
Part Names
07
Filter Replacement
Indicator

1. Please remove the
vinyl cover from the base.
3. Please connect the
USB cable into the
product.
User Guide
Assembling Guide
08
2. Pull off the protection
film on the Cyprees
Wood filter.

User Guide
09
How to Seperate Cypress Oil Capsule
from the Device (optional)
1. Turn the bottom part
of the device
counter-clockwise to
separate the flter.
2. Find the capsule
holder on the upper
side of the filter and
pull it out.
3. Separate the Cypress
Oil Capsule from the
capsule holder.
4. Peel off the
protective film from the
capsule.
Insertion of the capsule follows
the same process.

Indoor Use
In the vehicle,
Do not install on bumpy or inclined floors
User Guide
Installation Guide
10
The product fits into cupholders with 75mm/2.9inches
diameter and 50mm/1.9inches height or more.

Power
Wind Speed (3 Levels)
Power on / Power off
Use to adjust the fan speed
Low Medium High
Press the product for more than
1.5 seconds to turn it ON / OFF.
Low > Medium > High level in order.
User Guide
Product Functions
11
Automatic Filter Replacement
Indicator
Filter Replacement Indicator
LED indicator will blink for 5 seconds to
let you know to replace the filter when
the device is turned on.
After replacing the filter, push the power
button for 3 seconds and the LED light
will stop blinking.

Recommended replacement cycle for
the circular filter is 1 year.
Exterior Cleaning
Filter Cleaning
1. Use a vaccum cleaner
to remove the dust from the
air inlet and outlet.
2. Use a soft cloth to gently
wipe the exterior.
1. Remove the pre-filter
from the product
2. Use a vacuum cleaner to
remove large dust from
the prefilter
Maintenance
Managing the Product
12
Do not wash with water,
if so, filter life will be reduced
Remove the circular filter by
holding the base and the rest
of the product and turning it.

Following cases are not qualifiable
for return or exchange.
Knots Texture
difference Dent or
damage Warp
·Products made by processing solid wood
may have knots.
·Occasional scratches caused by work during
production are not defective.
·Colors and wood texture may vary due to the
nature of the wood and may differ from the
photo due to lighting.
·Solid wood absorbs and expands in summer,
and it shrinks in winter.
Maintenance
Cypress Wood Filter
13

When exposed to direct sunlight, the
color or shape may change, so keep the
product under the shade.
Avoid hot or humid places because it is
sensitive to temperature and humidity.
Do not place heavy objects on the
product. It may bend or split.
Following cases are not qualifiable
for return or exchange.
After a period of use, even if the scent is
minimal, the effect of cypress wood remains.
Temperature change causes expansion and
contraction in the cypress wood filter. This
is a natural phenomenon with solid wood
that stabilizes after repeated expansion and
contraction.
·With time, you may have a size change of
about 1~2mm/0.03~0.07inches or split
wood. This is a natural phenomenon with
natural materials.
Maintenance
Cypress Wood Filter
14

Warranty
One year from the date of the purchase
This warranty does not apply to
the following
1. Unauthorized repair, misuse, collision, negligence,
accidental liiquid damage, modification, disassembly,
Using third party components, or destroying them, or
changing labels and anti-counterfeiting markings.
2. If the mentioned warranty has already been expired.
3. Unforeseeable damage caused by natural disaster
or any events out of the company’s control.
Note: Please keep the packaging for about
1 month for safe transportation.
Warranty card is at the back of the manual.
Maintenance
Warranty
15

Model Name
- Portable Air Purifier (M-003 W / M-003 R / M-003 B)
(M-003 DW / M-003 DR / M-003 DB )
Product Size - 68mm x 68mm x 172mm
2.6 in x 2.6 in x 6.7 in
Product Weight - About 300g / 0.6lb (including the filter)
Voltage - DC 5V
Power Consumption - 2.5W
Cable - C type Charging Cable , USB Car Charger Adapter
Color - White / Red / Black
Certification - FCC, CE, CB, RoHS, PSE
Country of Origin - South Korea
Filter
Circular Filter: Pre Filter + HEPA Filter +
Deodorization Filter (Replacement Cycle: Approx. 1 year)
Cypress Wood Filter
Product Specification
Specifications
16

Troubleshooting
FAQ
·The power does not turn on.
·Filter replacement indicator is still
blinking after replacing the filter
·Push the power button for more than
5 seconds.
·Properly assemble the filter.
·Did you push the power button for
more than 5 seconds after replacing the
filter?
·Is the filter properly assembled?
Symptoms
Things to
check
·Is the USB plug connected properly?
·Is the LED indicator at the front turned
on?
Possible
Solutions
Possible
Solutions
·Properly connect the product with USB
plug.
·Please accurately press the power
button to operate.
Symptoms
Things to
check
17

Possible
Solutions
·The wind is not coming out.
·The wind power is weak.
·The level for wind speed doesn't change.
Symptoms
Things to
check
·Is the filter properly assembled?
·Is the filter contaminated? (contamina-
tion may affect the airflow and the power)
·Please check if the filter is properly
assembled.
·Please clean the filter.
Symptoms
· The shape of the Cypress wood filter has
changed.
·Please refer to page 13 for more details.
Things to
check
·Cypress wood filter is sensitive to
temperature and humidity (water)
18
Troubleshooting
FAQ
Possible
Solutions

Possible
Solutions
Possible
Solutions
·Air outlet has a strange odor.
Symptoms
Things to
check
·Was the product used in areas where
many people smoked, or in kitchen areas
cooking food?
·Was the product brought from a different
location?
·Filter has the tendency to absorb odor,
thus temporarily could emit odor.
This will eventually fade away.
·The product may still emit odors from the
previously used locations.
Symptoms
·Filter does not have the cypress scent
anymore.
Things to
check
·The filter may lose its scent, but the
effect of cypress wood remains.
19
Troubleshooting
FAQ
If you desire stronger cypress scent,
please purchase Cypress wood oil
capsule separately from our website and
simply replace it. It only applies when the
model of the air purifier is either
M-003DW/DR/DB.
