Voxx CarLink ASCL4 User manual
Activation Guide
Device to be Activated
3. Choose Your CarLink Plan:
a) CarLink: Basic
•This feature will let you remotely lock, unlock and start your vehicle all
from your Smartphone.
b) CarLink: Premium
•Daily Vehicle diagnostic and Fuel reports, real time Complete GPS
tracking, Parked recovery information, RoadsideAssistance, Auto
Crash SOS, Emergency Response service, Insurance discount
program, rewards points program.
Activate Your Device
Activate Your Device
4. Your Cart:
Choose Your State: State selection is needed to
calculate the sales tax.
Verify Cart is correct and click ‘Make Purchase’ to
continue.
Confirmation
Activate Your Device
5. Fill Out the Account
Creation Form
Your username and password
will be saved the exact way you
submit them –they are case
sensitive when you log in.
Your password must contain at
least one letter, at least one capital
letter, at least one special
character, at least one number and
it must be at least 8 characters
long.
6. Completing the form will send a registration email to the
associated account. Log in to that email account and
follow the ‘Registration Link’
7. After clicking the link you will be redirected to the CarLink
Log In page –Log In using your previously created
Username and Password
•http://www.CarLinkUSA.com/login
Activate Your Device
8. Please review the End User License Agreement and click
“Accept” to continue.
Activate Your Device
9. Once logged in –Click ‘Create Vehicle’ and fill out your
vehicle information.
10.In the Add Vehicle pop up click ‘Create Driver’ – fill out
with appropriate information.
11.Power the device to associate with account.
Activate Your Device
Installation Process
1. Plug device into OBDII port.
2. Start the vehicle, you should see green, yellow and red flashing LEDs on the front of the
device. (Checking for License/Network)
3. If for any reason you do NOT see the LEDs flashing after this process, unplug the device and
repeat steps 1 and 2.
4. Now that the device is plugged in, the wireless activation may take up to 10 to 15 minutes.
Please leave the device plugged in for at least 10 to 15 minutes to confirm that the activation
was successful.
5. Once the Yellow and Red LEDs are SOLID and the Green LED is
slowly flashing - the device is successfully activated. (Synced)
NOTE: Data may not appear on your account until you go for a drive.
6. Log into your CarLink Application and navigate to the Location tab.
Here you can view the most recent location your vehicle.
NOTE: If you do not see data on your account, unplug your device and repeat steps 1-6.
Please follow these steps to power up your
device and test network/GPS connection –
the activation may take up to 15 Minutes:
LED
Function
Proper
Activation Blinking Slowly Blinking Rapidly
RED Power Solid Light N/A N/A
YELLOW
Cellular Solid Light No GPS or Wireless
Connection
NO Wireless
Connection
GREEN OBD Blinking Light
Proper Activation
N/A
For more information, including FAQs, please visit www.CarLinkUSA.com
For technical assistance, please call 1-800-300-4550
The Device LED’s will rapidly blink when checking license & network. In all other instances they will flash as follows:
LED Disconnected Time Plugged in: 0 Seconds
Power: NO Synced: NO Data/GPS: NO
Installed: NO
N N N Engine: OFF
LED Checking for License Time Plugged in: 1-90 Seconds
Power: YES Synced: NO Data/GPS: NO
Installed: YES
FB FB FB Engine: Running
LED Syncing Time Plugged in: 2-5 Minutes
Power: YES Synced: NO Data/GPS: Possible
Installed: YES
S SB SB Engine: Running
LED Synced Time Plugged in: 5-10 Minutes
Power: YES Synced: YES Data/GPS: YES
Installed: YES
S S SB Engine: Running
* Unplugging your CC 2.0 Device will UN-SYNC your device *
When SYNCED your CC 2.0 Device will connect “instantly”
LED Checkingfor Network
Time Plugged in: 1-2 Minutes
Power: YES Synced: NO Data/GPS: Possible
Installed: YES
S FB SB Engine: Running
00:00
~10:00
? ?
LED KEY:
S = SOLID SB = SLOW BLINK FB = Fast Blink N = No Light
Power
Power Cellular Ground
Cellular Ground
Power Cellular Ground
Power Cellular Ground
Power Cellular Ground
Power Cellular Ground
?
Below is a chart to show you the different states of your device. When you first plug
in your device, it will need to go through each state before it is capable of tracking
and reporting data. If you unplug your device, the syncing process must be
repeated.
Syncing Your Device
1.625 ”
2.5 ”
0.875 ”
LED
Function
Proper
Activation Blinking Slowly Blinking Rapidly
RED Power Solid Light N/A N/A
YELLOW
Cellular Solid Light No GPS or Wireless
Connection
NO Wireless
Connection
GREEN OBD Blinking Light
Proper Activation
N/A
For more information, including FAQs, please visit www.CarLinkUSA.com
For technical assistance, please call 1-800-300-4550
The Device LED’s will rapidly blink during license verification. In all other instances they will flash as follows:
Your Device
Car Link plugs directly into the vehicles OBDII port
under the dash which is located within 3 feet of the driver’s
seat –NO tools are required to access.
For certain applications, the Car Link module may
interfere with driver’s knees or the customer may want to
hide the module. For those instances a “Y-harness” may be
purchased as an additional accessory from the online store:
www.shopvoxx.com
For customer or technical support please call Audiovox Car Link support:
1-800-300-4550
9am –9pm (Eastern) Mon –Friday
10am –2pm (Eastern) Sat
© 2013 Audiovox Electronics Corp. All Rights Reserved.
** requires the Zoomsafer app to be downloaded Support on Android 2.3.3 and iOS 6.01
Android is a trademark of Google Inc. Use of this trademark is subject to Google Permissions.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
