VS Sassoon Turbo Power Clipper VSM318DNA User manual

Model VSM318DNA
TURBO POWER CLIPPER

IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, especially when children are
present, basic safety instructions should always be followed,
including the following:
Polythene bags over product or package may be dangerous. To
avoid danger of suffocation, keep this wrapper away from babies
and children. This bag is not a toy.
DANGER: Unplug unit when not in use. All appliances are electrically
live even when switched off.
WARNING:This appliance must not be taken
into a bathroom.
•Thisapplianceshouldonlybeusedasdescribedinthisbooklet.
Please retain for reference.
•Donotimmerseinwaterorotherliquids.
•Donotuseinthebath,ornearbasinsorothervesselscontaining
water.
•Donotreachforanappliancethathasfallenintowater.Unplug
immediately.
•Takecaretoavoidcontactbetweenthemovingbladesoftheunit
and the skin, paying particular attention to the face, neck and
hands.
•This appliance is not intended for use by young children or
infirm persons without supervision. Young children should be
supervised to ensure that they do not play with the appliance.
IMPORTANT: Always unplug the appliance when not in use or before
cleaning.Donotleaveunattendedwhenpluggedinorswitchedon.
•DonotuseanyattachmentsotherthanthosesuppliedbyConair
Australia Pty Ltd.
•Donot use the appliancewith damaged or brokenattachment
combs or with any teeth missing from the blades, as injury may
occur.
•Usethisapplianceonlyforits intended use asdescribedwithin
this instruction booklet.
•Thisapplianceisnotintendedforcommercialuse.
•Neverdroporinsertanyobjectintoanyopening.
•Ensure appliance is switched off before plugging it into the
power outlet.
•Donotplaceapplianceonanysurfacewhileitisoperating.
•Donotuse outdoorsoroperatewhere aerosol(spray)products
are being used or where oxygen is being administered.
•Keepthecordawayfromheatedsurfaces.
•Donotusethis applianceifthesupplycord isdamaged.Inthe
event of damage, discontinue use immediately and contact
your dealer for instructions on returning it for examination or
exchange.
•Afterusedonotwrapthecordaroundtheapplianceasintime
thismaycausethecordtofracture.Coilcordlooselybytheside
of the appliance in storage.
•Always ensure that the voltage to be used corresponds to the
voltage marked on the unit.
•For additional protection, the installation of a residual current
device(RCD)witharatedoperatingcurrentnotexceeding30mA
is advisable in the electrical current circuit supplying the bathroom.
Ask your installer for advice.
TURBO POWER CLIPPER
Thank-you for purchasing the VS Sassoon for men Turbo Power
Clipper, a professional grade rechargeable clipper with titanium
blades,tapercontroland50%more powertogiveyoutheedge
you need in looking good.
The Turbo Power Clipper is a direct drive cord/cordless powerful
clipper with a range of accessories.

INSTRUCTIONS FOR USE
CORDED USE – OPERATION WITH THE POWER CORD
IMPORTANT: Only use the mains adaptor supplied with this
appliance.
1.Ensuretheclipperisswitchedoff.
2.Connect the adaptor to the base of the clipper and plug the
adaptorintoasuitableAC100/240Vmainssocket.
3.Theclipperisnowreadyforuse.
•NOTE:Theclippershouldnotbeusedforlongerthan20minutes
when operated from the mains.
CORDLESS USE - CHARGING
1.Ensuretheclipperisswitchedoff.
2.Connect the adaptor to the base of the clipper and plug the
adaptor into the mains.
3.The Charging Indicator Light will indicate that the adaptor is
connected to the main unit and is plugged in.
4.When charging for the rst time, or when the clipper has not
been used for a considerable time, the appliance must be charged
continuouslyfor16hours.Thiswillprovidearound40minutesof
use.
5.Ordinarily,thisclippermaybechargedovernight.
6.Oncetheclipperischarged,unplugtheadaptorfromthemains
and disconnect from the appliance.
7. The appliance is now ready for use.
BEFORE USE
Always inspect the appliance to ensure the clipper head is free from
hair,etc.andisrunningsmoothly.Checkalsoforsignsofdamage
andensurethatthetipsofthetwobladesareparallel.Failuretodo
this can result in injury.
1)TitaniumBladetechnology
2)TurboBoostPowerButton
3)5positiontaperadjustment
lever
4)On/Offswitch
5)ChargingIndicatorlight
6)Chargingadaptor
7)8xClipperCuttingguides
8)Leftandrightearcombguides
9)Barbercomb
10)BladeCover
11)CleaningBrush
12)Lubricatingoil
13)Storagepouch
14)6sectioningclips
15)Noseandear
trimmer head
16)2xblendingcomb
attachments for
20mmtrimmer
2
12 13
11
16
15
7
4
3
5
614
8
10
9
1
Features:

Theapplianceissuppliedwithaleftandrightearcombguideand8
hair combs. The comb guides are marked with the following grade
number:
  Grade1=3mm
Grade 2 = 6mm
  Grade3=9.5mm
  Grade4=13mm
Grade 5 = 16mm
Grade 6 = 19mm
Grade 7 = 22mm
  Grade8=25mm
USING THE COMB GUIDES
1.Ensuretheclipperisswitchedoff.
2. Slide the comb guide over the top and sides of the blades and
pull down over the back of the blades until it clicks into place.
TO REMOVE COMB GUIDE
1. Switch the appliance off.
2. Push the base of the comb guide away from the blades.
ADJUSTABLE TAPER LEVER
The adjustable taper lever enables the cutting length to be adjusted
between grade lengths.
1. To increase the cutting length, push the lever down.
2. To reduce the cutting length, push the lever up.
BEST CUTTING PERFORMANCE
1.Ensuretheclipperissufcientlycharged.
2. Use on clean, dry hair that has been combed until tangle-free.
3.Attachtheappropriateclipperguideasrequired.Ifusingmore
thanonegrade,startwiththelongerrst.
4.Switchtheclipperon.
5. Hold the clipper against the hair, the teeth of the clipper pointing
upwards, yet flat against the head.
6.Movetheclipperupwardsandoutwardsthroughthehair,alittle
at a time clipping against the direction of the hair growth.
7.Theclipperwillworkmostefcientlywhencuttingthroughthe
hairatitsownspeed.Neverforcetheclipper.
8.Neverswitchtheclipperoffwhilstinthehair.
TURBO BOOST FEATURE
Thisclipperisequippedwithaturboboostbutton.Whenactivated,
thiswillprovide15%morecuttingpower.Thisisusefulforcutting
through thicker hair.
CLEANING & MAINTENANCE
After each use, clean the head as follows:
1. Switch the clipper off or unplug if mains operated.
2.Removetheheadfromtheclipperasshownbelow(g1).
3.Usingthecleaningbrush,gentlybrushandblowanyhairsfrom
the blade and head.
4.Replace the head as shown below (g 2). Make sure that the
taper lever is set to the lowest position before replacing blade.
5.Donotdisassemblethebladesforcleaning.
When used regularly, it is advisable to oil the blades before use.
After cleaning, switch the appliance on, and oil the blades by
addingafewdropsoftheoilsuppliedoverthe blades. Only use
thelubricatingoilsuppliedwiththisapplianceasthisisspecically
formulated for high speed clippers and does not evaporate or slow
the blades.
Fig.1 Fig.2

BATTERY DISPOSAL
ThisappliancecontainsNi-MHbatteries.Toprotecttheenvironment,
the appliance must be disposed of safely at the end of its life. Please
take to a recycling centre for safe disposal.
LIMITED TWO YEAR WARRANTY
This product is subject to the express warranty given on the
warranty card included with the product, as may be amended by
reference to and in accordance with the terms of the warranty
cardsdisplayedonVSForMenwebsitewww.vsformen.com.au
Please retain a copy of your purchase receipt as proof of purchase
within the warranty period.
®
IB-13/069A
Vidal Sassoon and related logos are trademarks of
TheProcter&GambleCompanyusedunderlicencebyConair
ConairAustraliaPtyLtd.
Suite101,18RodboroughRd
FrenchsForestNSW,2086
AustraliaCustomerServiceHotline(Australia):1800650263
CustomerServicee-mail:[e-mail]
ConairNewZealandLimited,POBOX251159,Pakuranga,Auckland
1706NewZealand
CustomerServiceHotline(NewZealand):0800266247
