VSSI Premier Owner's manual

Premier
Mobile Electric Lift Table
Features & Operation
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Charging the Batteries . . . . . . . . . . . . . . . . . . 2
Optional Scale Features/Operation . . . . . . . . 3
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 4
Care & Cleaning . . . . . . . . . . . . . . . . . . . . . . . 4
Product Warranty . . . . . . . . . . . . . . . . . . . . . . 5
Table of Contents

Installation
Thank you for purchasing the Premier
Mobile Electric Lift Table!
Open the package carefully. Please
inspect shipping carton and contents for
any visible damage.This is important in
the event that any breakage has occurred
during transit.
The Premier Mobile Electric Lift Table
arrives pre-assembled, requiring only
minor attention to be fully serviceable.
After removing the table from its packag-
ing, the table needs to be placed in the
desired position within your facility.This
is accomplished easily since the table is
on casters. Use the simple hand control
to raise or lower the height of the table.
It may be necessary to lift the Premier
Mobile Electric Lift Table to remove it
from the pallet. NEVER pick up the table
by the stainless steel top! Lift by grasping
the frame of the table base. Stainless steel
NOTE:
PLEASE SAVE ALL
PACKAGING
UNTIL CERTAIN
YOU ARE SATISFIED
WITH THE PRODUCT
base covers are attached with Velcro®
tabs, so be sure to reach far enough
under edges of the base to be lifting
by the frame, not the cover.
The Premier Mobile Electric Lift Table is
protected during shipping with a white
plastic film covering the stainless steel.
Peel off the plastic film before using.
Refer to “Care and Cleaning” instructions.
Charging the Batteries
Very important!
Please read carefully!
The Premier Mobile Electric Lift Table
utilizes rechargeable batteries to enable
raising and lowering the table without
having to be plugged into a power outlet
at all times. Over draining these batteries
will inhibit their ability to fully recharge,
so it is very important to keep the
batteries charged. Keep the table plugged
in and in charging mode when not in use.
To Charge Batteries:
To charge batteries, plug the table into a
standard power outlet.We recommend
charging the table every night, overnight,
and more frequently if the table is
being used continuously throughout
the day without being plugged in.
The table needs to be unplugged for
normal use. Remove AC power cord from
wall outlet when not charging batteries.
2

Scale Features/Operation
Using The Control Panel:
Push to turn unit on. Display
shows the following:
^^^^ – self test
vssi – checks display segments
u 1.7 – software revision
b xx.x – battery voltage
(varies with AC plug
in and internal 9v
battery.) A reading of
6.0v indicates the need
for battery replacement;
the unit will shut off at
a reading of 5.5v.
0.0 – ready to weigh
Push and hold until display
indicates unit shift.
Display will show “conv” until
the conversion is complete.
Push the RECALL button –
The display will show the
message “rECL” then alternately
flash between the last stable
weight and the “ rECL” message.
Press ON/ZERO button to return
to normal weighing.Works only
with hold function active.
Features:
Tare Function:
Any weight within the scale capacity can
be zeroed out by pressing the ON/ZERO
button.When the weight is removed, the
display flashes the tared weight. Press
ON/ZERO button to return to normal
weighing.
Weighing Function:
Display will blank out until a close range
of the weight is reached.With the hold
function active, the display will show the
stable weight and the “hold” indication.
The displayed weight will lock until the
weight is removed.
ON
ZERO
LB/KG
RECALL
Weight Hold:
Press and hold the ON/ZERO button.
While holding the ON/ZERO button,
press and hold the RECALL button.
Display will show “zero” then “ h on” or
“h off ”. Release buttons when selection
is made. Default setting is “ h on ”.
Automatic Shut Off:
In AC mode, the indicator will shut
off in one hour. In battery mode, the
indicator will shut off in one minute.
Calibration:
Press and hold the ON/ZERO button.
While holding the ON/ZERO button,
press and hold the LB/KG button.After
approximately 3 seconds the message
on the display will change from “ zero”
to “CAL”. Release both buttons and the
display will show “C0” message.
Make sure the platform is empty and
press the ON/ZERO button.The indicator
will show a count down from “16” to “ 1”
then will show “C 50”. Place a 50 lb
weight on the platform and press the
ON/ZERO button.The indicator will
show a count down from “16” to “1”
then will show “ 50.0”.The indicator is
now calibrated and has automatically
returned to normal weight mode.
Switching from AC to DC:
You must first unplug the AC adapter
from the wall. Second, unplug the
cord from the display.Then press the
ON/ZERO button to turn the indicator
back on.
Switching from DC to AC:
Plug the AC adapter into a standard wall
socket and the cord into the AC outlet
on the back of the display.Then press
the ON/ZERO button to turn the
indicator back on.
3

4
Troubleshooting
Indicators:
Messages on the readout indicate
operating condition:
Indicates weight on scale
OL exceeds capacity or
malfunction of scale display.
Indicates malfunctioning
OPEN of base or cable, or the
scale needs to be calibrated.
Indicates batteries are
discharged.
In The Event Of A Problem:
In the event that a problem occurs, a VSSI
factory technician is ready to assist you.
In order to save time, please check the
following items before calling:
•Does the readout display have a
message that indicates what the
problem is? Refer to “Indicators”
at left for descriptions.
•Check all cables/connections.
•Unplug AC power and battery, then
plug-in again to reset the scale.
VSSI Tech Support: 1-800-299-9525
Care & Cleaning
The Premier Mobile Electric Lift Table
may be cleaned with any commercially
available product recommended for use
on stainless steel. Frequent cleaning will
prolong the life and help maintain the
natural luster of the stainless steel.
To prevent scratching, use a soft cloth
to clean the stainless steel exam surface.
If scrubbing is necessary, use a nylon or
plastic type scrubber.When cleaning,
always rub in the direction of the “grain”
of the metal.
To remove minor scratches, we
recommend using a 3M ScotchBrite®
scouring pad rubbed lightly in the
direction of the “grain” of the metal.
Never use steel wool or steel
brushes when cleaning stainless steel.
Steel particles may become embedded
into the stainless steel and cause rust.
Avoid use of chlorine bleach
for cleaning. Chlorides, bromides,
iodides and thiocyanates will cause
pitting, corrosion and discoloration of the
metal. If using bleach, clean thoroughly
with water to remove bleach residue.
Avoid excessive moisture.
The Premier Mobile Electric Lift Table
contains electronic components that may
be damaged by excessive exposure to
moisture.When cleaning the table or
mopping the floor around the table, be
careful not to splash water under the
table base.

5
01/08 ©2008, VSSI, Inc.
Product Satisfaction Policy
In the event that the customer is not fully satisfied with the products
purchased,VSSI, Inc. may, at its own discretion, arrange for the customer’s
account to be credited (excluding shipping charges) or replace the product.
The customer must notify VSSI of any claim of nonconformity or defect in
writing within 30 days from the date of receipt.The product must be
returned to VSSI in its original packaging, undamaged and showing no
unusual wear within 20 days of the customer’s written notice.
To return an item, follow these simple instructions:
•Call VSSI, Inc. for complete instructions (800-299-9525)
•A sales representative will give you a Return Authorization Number
•If a Restocking Fee applies, you will be informed at this time
•Label the boxes with this Return Authorization Number
(All items must have a Return Authorization Number)
•Return the items, postage/freight prepaid
If necessary, the VSSI sales representative will assist you with
freight arrangements.
Note: Custom orders and/or custom colors may not be returned.
Product Warranty
This product is warranted for 1 year from the date of delivery
to the original purchaser only. If equipped with the built-in
VSSI Way™ Scale, Scale is warranted for 2 years.Warranty is only
applicable if customer complies with all instructions and
specifications furnished by VSSI, Inc. relating to installation,
care, and application. Customer agrees that they will not modify,
misapply, or misuse product in any manner which deviates
from the VSSI, Inc. instructions.Any repairs, alterations,
or services provided by parties other than VSSI, Inc.
or its authorized representatives may void warranty.
The buyer is responsible for all freight charges on returned items.
