VT VendMine Connect T313 User manual

Propiedad de Vendwatch Telematics - Condencial
VM CONNECT T313
USER MANUAL
Version 0.07

Propiedad de Vendwatch Telematics - Condencial
+
DATE VERSION CHANGES
MARCH 12, 2016 0.01 Initial Draft
MARCH 18, 2016 0.02 Installation Feedback
APRIL 12, 2016 0.03 Added EPay display status
JUNE 1, 2016 0.04 Swapped the mounting brackets
solely to magnets
JUNE 3, 2016 0.05 Replaced picture of device with
magnet-captive clips
JUNE 4, 2016 0.06 Wiring Diagram, Door Switch
“NO”and “NC” explanation
JUNE 15, 2016 0.07 Improve Extension DWG

Propiedad de Vendwatch Telematics - Condencial
PURPOSE
The sections that follow describes how to install the Vendwatch Telematics (VT) VendMine (VM) Connect T313
Telemetry Device in Vending Machines using general guidelines applicable to a universal principle of operation.
Other documents would detail specic mounting location and cable routing for the various models available in
the market from different manufacturers.
Before proceeding with the installation verify that the VM IS NOT POWERED and Alternating Current
(AC) or High Tension Voltage is not connected to the vending machine.

Propiedad de Vendwatch Telematics - Condencial
UNPACKING THE UNIT
Each container includes the T313 Telemetry Device, the telemetry antenna and the accessories kit. Clips to
mount the enclosure and splice connectors to connect the door switch are found inside the kit amongst other
items necessary to complete the professional appearance of the installation.

Propiedad de Vendwatch Telematics - Condencial
MOUNTING THE DEVICE
VM come in a variety of versions, models and their respective revisions. Two magnet-captive mounting clips,
included in the kit, provide exibility of installation; the desired location is accomplished by inserting the clips
right-to-left or left-to-right (see picture below), allowing the unit to be attached to any internal VM unused wall.
The units is intended to be mounted with the LEDs facing the installer and the cables hanging to the oor.
LEFT MOUNTRIGHT MOUNT

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE CABLES
The next step after the the unit is secured in the VM chassis is to connect the cables to their respective
interfaces. The T313 Telemetry device has 6 distinctive cables connecting the unit to the VM controller Direct
EXchange (DEX) port, the Electronic Payment (EPay) System, the Multi Drop Bus (MDB) serving the legacy
payment system, the Door Switch and Temperature Sensors and the antenna cable.
DEX
EPAY
MDB
DSS
TCS
ANT
From left to right the function of the cables protruding from the T313 Telemetry Device are: DEX, EPay, MDB,
Door Switch Sensors (DSS), Temperature Control Sensors (TCS) and the Antenna.

Propiedad de Vendwatch Telematics - Condencial
MOUNTING THE ANTENNA
The External Antenna will be mounted on top right side of the door and on the same side of the machine
where the T303 Telemetry Device is installed. To do this, you will need to drill a 5/8 hole using the conical drill
bit as shown.
Once drilling is completed, remove the hex nut from the antenna and insert the cable into the hole from the
outside, now tighten the nut from the inside of the machine. Connect the Antenna to the corresponding connector
in the VM Connect Device.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE DEX CABLE
The Telemetry T313 Device requests Sales, Health and Status of the VM by connecting to the Direct EXchange
(DEX) connector. The VM Controller (VMC), the intelligence behind the VM functionality, provides a DEX interface
connector, ¼” phone jack, in some models solder directly on the board and other models as a dongle.
Find the DEX ¼” phone jack and connect the T313 Telemetry Device ¼” phone plug into it as illustrated below.
The cable provides a spare ¼” phone jack to facilitate connecting additional devices on the DEX port.

Propiedad de Vendwatch Telematics - Condencial
MOUNTING THE EPAY UNIT
The Electronic Payment (EPay) unit should be mounted on the VM using, as a minimum, two of the mounting
metal inserts in the back of the EPay unit.
When necessary, an additional perforation of the chassis is required to accommodate proper routing of the EPay
interface cable.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE EPAY UNIT
Find the EPay cable on the T313 Telemetry Device and connect the cables together. Additional 1 meter extension
cables can be purchased if the distance between the T313 and the EPay devices exceeds 1.5 meters.
Upon powering up the unit the EPay unit will display “Reader Currently Disabled”, once initialized the legend
changes to “Tap or Swipe Card t Vend”; during Dex reads, the legend would be “Processing Data Back Soon”.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE MDB
The VMC provides power and controls the legacy payment system by allowing multiple devices to connect to the
MDB bus. The installation would require to nd the last device on the MDB bus and connect the T313 Telemetry
Device at the end.
If the last device on the bus does not have a spare connector, the installation would require to disconnect the last
device on the bus and connect the T313 Telemetry Device as second to last on the bus as illustrated below.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE DOOR SWITCH
The cable used to connect the device to the VM door switch has 6 wires providing 3 separate functions; each
using dedicated color wires based on VM instrumentation as follows:
• NC Pair: RED/ORANGE
• NO Pair: BROWN/BLACK
• VT NO Switch Kit available for sale: GREEN/YELLOW
The VM is equipped with a door switch connected to the VMC; typically, one of the poles is connected to
what’s universally referred as common (return, ground or shield); the other pole is commonly referred as
the “hot wire” and reects the state of the door. The door switch is determined to be in a “NORMAL”
state when the plunger “IS NOT” retracted hence the term Normally Closed (NC) or Normally Open (NO).

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE DOOR SWITCH
The switch is wired one of two ways, Poles are Normally Open (NO) or Poles are Normally Closed (NC). When the
door is open and the switch plunger is fully extended, the “NO” POLE and the “COMMON” POLE ARE NOT
making contact while the “NC” POLE and the “COMMON” POLE ARE making contact with each other.

To facilitate the integration of the VM door switch with the Telemetry device, a test tool universally known as a
continuity tester would be used. The tool indicates when two points make contact when a led or a buzzer,
instrumented in the tool, emanates light or sound as depicted below.
OPEN CIRCUIT
CLOSED CIRCUIT

Propiedad de Vendwatch Telematics - Condencial
FINDING THE COMMON POLE
Connect the continuity test tool alligator clip to the shield of the Dex connector as shown
Locate the switch, it must have two wired poles, however it may have a third pole that would not be wired. After
locating the door switch, use the tip of the the continuity tester tool to make contact with one of the wired poles.
If the light of the Continuity Tester Tool turns ON, press and release the Door Switch button, if the light is still ON
no matter what state the Door Switch is in, then you have found the Common Pole. The Dex port and the
Common Pole are both ground, so stay connected to the Dex port
Switch in
Normal state
(Button
Extended)
YES YES
Touching
Wired Pole
!
YES YES
Light/Sound
ON
!
NO YES
Switch Type
!
NO
(Normall
y Open)
NC (Normally
Closed)
Wire Pair
Color to be
used
!
Brown/
Black Red/Orange

Propiedad de Vendwatch Telematics - Condencial
FINDING THE COMMON POLE
Now make contact with the the other pole to validate the switch model and the poles connectivity.
DOOR SWITCH LIGHT / SOUND POLE TYPE SWITCH TYPE
Extended or Pressed YES Common Unknown
Extended NO NO Normally Open
Pressed YES NO Normally Open
Extended YES NC Normally Closed
Two distinctive connecting options, “NO” or “NC” are available based on the results of the continuity test.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE T313 TELEMETRY WITH A NORMALLY CLOSED (NC) DOOR SWITCH
Following the results of the test above, cut the wire connected to the “NC” pole of switch.
1. Locate the RED Wire in the Door Switch Cable of the T313 Telemetry and splice it with the wire still
connected to the switch using one of the UY2 connector.
2. Locate the ORANGE Wire in the Door Switch Cable of the T313 Telemetry and splice it with the other side of
the previously cut wire using one of the UY2 connector. This wire is now connected to the VMC controller.

Propiedad de Vendwatch Telematics - Condencial
CONNECTING THE T313 TELEMETRY WITH A NORMALLY OPEN (NO) DOOR SWITCH
Following the results of the test above, cut the wire connected to “NO” pole of the switch.
1. Locate the BLACK Wire in the Door Switch Cable of the T313 Telemetry and splice it with the wire still
connected to the switch using one of the UY2 connector.
2. Locate the BROWN Wire in the Door Switch Cable of the T313 Telemetry and splice it with the other side of
the previously cut wire using one of the UY2 connector. This wire is now connected to the VMC controller.

Propiedad de Vendwatch Telematics - Condencial
ADDING DOOR SWITCH EXTENSION CABLE
When the Door Switch is installed far from the VM Controller, an extension will be provided with two wires,
BLACK and RED.

To connect the extension to a “NO” switch, using a Wire Connector join the T310 Black wire with the
extension’s Black wire and the T310 Brown wire with the extension’s Red wire, now the Black and Red wires
will be available. Cut the “NO” wire and join the Black one to the Door Switch and the Red one to the VMC.
NORMALLY OPEN (NO) WIRING DIAGRAM WITH EXTENSION
T31x
Coffee
Black
VMC
Red
Black
To connect the extension to a “NC” switch, using a Wire Connector join the T310 Red wire with the extension’s
Red wire and the T310 Orange wire with the extension’s Black wire, now the Black and Red wires will be
available. Cut the “NC” wire and join the Red one to the Door Switch and the Black one to the VMC.
T31x
Normally Closed (NC) wiring diagram with extension
Red
Orange
VMC
Red
Black

Propiedad de Vendwatch Telematics - Condencial
THE DEVICE INDICATORS
Power led
Telemetry led
Status led
ESN number
Rell button
VT LOGO
Cong SW
Model number
The device has icons on the front of the device indicating different functions for ease of installation. The label
at the front top of the unit contains the Model of the unit, the label at the front bottom of the unit houses the
Electronic Serial Number (ESN).
The “GEAR” icon illustrate the location of the conguration switch; a special key will be provided to
qualied technicians who have been trained in the art of troubleshooting the device.
The “TOUCH” icon illustrate the location of the “Rell Button”. By placing a nger, preferably the
thumb, over the icon the device would determined that a button has been depressed. The behaviour of the
device’s LEDs will be described in the following sections.

Propiedad de Vendwatch Telematics - Condencial
THE BEHAVIOUR OF THE POWER LED
STATE ILLUMINATION DESCRIPTION
On Solid Green VM is powered on AND the device is connected to MDB
Off Off VM is powered off OR the device is disconnected from the MDB; if the Telemetry or
Status LED are illuminated solid or blinking, it is running on battery.
THE BEHAVIOUR OF THE TELEMETRY LED
STATE ILLUMINATION DESCRIPTION
Radio On Solid Green Power was applied to the Telemetry module
Radio Off Off Power was removed from the Telemetry module
Radio Training Green, On 50% Radio is searching for available networks
Radio Connected Green, On 87% Radio is connected to selected network
THE BEHAVIOUR OF THE STATUS LED
STATE ILLUMINATION DESCRIPTION
Off Off The device is off
Booting Up Green, On 50% The device is getting up to the normal state
Normal Green, Solid The device is in normal state
Programing Purple, Blinking 50% The device is being programmed
Alert Orange, Solid The device has detected issues
Handheld Blue, Solid The device is connected to VM Guide/Care
Battery Red, Blinking 50% The device is running on battery
Rell White, Blinking 50% The device is reading DEX
Mfg Testing Purple, Blinking 50% The device is running manufacturing test
