VTOMAN FlashSpeed 1500 User manual

FlashSpeed 1500 Portable Power Station
User Manual
●Thank you for choosing Vtoman portable power station.
● Please read the user manual carefully and follow the instructions
in the manual to use the product correctly.
Model No.: PB-58

CONTENTS
1.Specifications
2.Package List
3.Safety Instructions
3.1 Usage
3.2 Personal Precautions
3.3 Disposal Guide
4.Product Features
4.1 Product Details
4.2 LCD Screen Introduction
5.Product Operating Instructions
5.1 Power & Function On/Off
5.2 Recharge Methods & Recharge Time
5.3 Battery Capacity Expansion
5.4 Use of LED Flashlight
5.5 Uninterruptible Power Supply (UPS)
6.FAQs
7.Troubleshooting
8.Storage & Maintenance
9.Warranty
10.Contact Us
1
2
2
4
3
5
5
6
7
8
8
9
9
11
11
12
13

1.Specifications
General Info
Product Name FlashSpeed 1500 Power Station
Net Weight 18.8KG(41.4 lbs)
Dimensions 393*280*270mm(15.5x11x10.6 inch)
Certification FCC, RoHS, UN38.3, CE
Battery Info
Capacity 1548Wh
Battery Type LiFePO4
Cycle Life 3000 cycles to 80%
Output Ports
AC Output(x3) 1500W(Peak 3000W) in total,
110V~60Hz, Pure Sine Wave
USB-A Output(x3) 5V 2.4A, 12W Max per port
USB-A Output(x1) 5V 3A, 9V 2A, 12V 1.5A, 18W Max
USB-C Output(x2) 5V 3A, 9V 3A, 12V 3A, 15V 3A,
20V 3A, 20V 5A, 100W Max per port
DC5521 Output(x2) 12V 10A, 120W Max in total
Car Charger(x1) 12V 10A, 120W Max in total
Input Ports
AC Input(x1)
DC Input(x1)
Anderson Input(x1)
Environment Operating Temperature
Operating Temperature -20℃~55℃(-4℉to 131℉)
Charging Temperature 0℃~55℃(32℉to 131℉)
11
90-140V, 1500W Max
12-20V, 200W Max
30-60V, 400W Max

2.Package List
3.Safety Instructions
FlashSpeed 1500 Power Station Car Charger Cable
USB-C to USB-C Cable USB-A to USB-C Cable User Manual
No. Item
1
2
3
4
5
6
1
1
1
1
1
1
FlashSpeed 1500 Power Station
AC Charging Cable
USB-C to USB-C Cable
USB-A to USB-C Cable
Car Charger Cable
User Manual
110V/1500W
/
/
/
/
English version
Qty. Specification
Please kindly check all accessories are complete. If any parts
missing, please feel free to contact us at [email protected].
3.1 Usage
When using this product, basic precautions should always be
followed, including the following:
1.Read all the instructions before using the product.
2.To reduce the risk of injury, close supervision is necessary when
the product is used near children.
2
AC charging cable x1

3.Do not put fingers or hands into the product.
4.Use of an attachment not recommended or sold by power
pack manufacturer may result in a risk of fire, electric shock, or
injury to persons.
5.To reduce risk of damage to the electric plug and cord, pull the
plug rather than the cord when disconnecting the power pack.
6.Do not use a battery pack or appliance that is damaged or
modified. Damaged or modified batteries may exhibit unpre-
dictable behavior resulting in fire, explosion or risk of injury.
7.Do not operate the power pack with a damaged cord or plug,
or a damaged output cable.
8.Do not disassemble the power pack, take it to a qualified
service person when service or repair is required. Incorrect reas-
sembly may result in a risk of fire or electric shock.
9.To reduce the risk of electric shock, unplug the power pack
form the outlet before attempting any instructed servicing.
3.2 Personal Precautions
1.Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
2.Wear complete eye protection and clothing protection. Avoid
touching eyes while working near battery.
3.If battery acid contacts skin or clothing, wash immediately
with soap and water. If acid enters eye, immediately flood eye
with running cold water for at least 10 minutes and get medical
attention immediately.
4.NEVER smoke or allow a spark or flame in vicinity of battery or
engine.
5.Be extra cautious to reduce risk of dropping a metal tool onto
battery. It might spark or short-circuit battery or other electrical
part that may cause explosion.
6.When charging the internal battery, work in a well ventilated
area and do not restrict ventilation in any way.
7.Under abusive conditions, liquid may be ejected from the bat-
tery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
3

Liquid ejected from the battery may cause irritation or burns.
8.Do not expose a power pack to fire or excessive temperature.
Exposure to fire or temperature above 265°F(130°C) may cause
explosion.
9.Have servicing performed by a qualified repair person using
only identical replacement parts. This will ensure that the safety
of the product is maintained.
3.3 Disposal Guide
1. If conditions permit, make sure that the battery is fully
discharged before disposing it in a designated battery recycling
bin. The product contains batteries with potentially dangerous
chemicals, so it is strictly prohibited to dispose of it in ordinary
trash cans. For more details, please follow the local laws and
regulations on battery recycling and disposal.
2. If the battery cannot be fully discharged due to a product
failure, please do not dispose of the battery directly in the bat-
tery recycling box. In such case, you should contact a profession-
al battery recycling company for further processing.
3. Please dispose of over-discharged batteries that cannot be
recharged.
4

4.Product Features
4.1 Product Details
4.2 LCD Screen Introduction
5
Remaining Battery Percentage
AC Output
TYPE-C Output12V DC Output USB-A Output
Input/Output
Power
USB-C Output
100W Max per port
DC Output
12V/10A
USB-A Output 12W Max
USB-A Output 12W Max
USB-A Output 12W Max
LCD Display
USB-A Quick Charge 18W Max
AC Output
110V/1500W
AC Input
1500W Max
Extra Battery Port
DC Input
200W Max
Anderson Input
400W Max

5.Product Operating Instructions
5.1 Power & Function On/Off
1.Power On: Short press any button to power on the product
and enter the standby state, the LCD Screen will light up and the
battery level indicator icon will display.
2.Power Off: Turn off all outputs manually, then the product
enters the standby state and will shut down after 30 minutes.
3.AC Output On/Off: Short press the AC Button to use the AC
output; Short press the AC Button again to turn if off.
4.DC Output On/Off: Short press the DC Button to use the 12V
DC output; Short press the DC Button again to turn if off.
5.USB-A & USB-C On/Off: Short press the USB Button to use
the USB-A & USB-C output; Short press the USB Button again to
turn if off.
6
V-Beyond Technology: It allows you to run devices over 1500
watts but no more than 3000 watts on FlashSpeed 1500 power
station. It would lower the output voltage to bring the power back
down without tripping the overload protection, so that yo can
continue to run those devices. It's suitable for resistive loads such
as lights, space heaters, toasters, ovens, and coffee makers, etc.
But please note that it's NOT suitable for complex electronics
such as computers, TVs, refrigerators, etc.

5.2 Recharge Methods & Recharge Time
1.Recharge Time
Warm Tips: Before use, please plug your FlashSpeed 1500 power
station into the wall until it is fully charged.
2.Recharge by AC Outlet
You can use the AC charging cable through the AC Input Port to
recharge the FlashSpeed 1500 power station. The recharging
time is about 1 hour.
3.Recharge by Car Outlet
You can recharge the FlashSpeed 1500 through the DC Input
Port with a car charging cable. The recharging time is about 12-14
hours.
7
Car Outlet 400W Solar Panels
1 Hours 12-14 Hours 4-8 Hours
4.Recharge by Solar Panel
You can connect a Vtoman VS400 400W Solar Panel to
recharge FlashSpeed 1500 power station, the recharge time is
about 4-8 hours (depending on sunlight intensity).
Wall Outlet
Wall Outlet
1
AC Charging Cable
Car Charger Cable

5.3 Battery Capacity Expansion
Vtoman FlashSpeed 1500 portable power station can expand
its battery capacity from 1548Wh to 3096Wh with FlashSpeed
1500 Extra Battery (Sold separately), so that it can power your
devices for a longer time.
5.4 Use of LED Flashlight
The FlashSpeed 1500 Power Station features a LED flashlight
with 5 mode. Please follow the instructions below to enter
different modes:
If connecting with your own solar panel, please make sure the
working voltage of the solar panel is between 30-60V to
recharge properly.
FlashSpeed 1500 Extra BatteryFlashSpeed 1500 Power Station
To expand the battery capacity, you just need to connect the
FlashSpeed 1500 Portable Power Station to the FlashSpeed
1500 Extra Battery via a CP3500 cable(Included in the package
of FlashSpeed 1500 Extra Battery).
The CP3500 cable will get hot during work,please DO NOT
touch the CP3500 cable in avoid of scalding！
8
Anderson connector
BACK UP
Vtoman VS400 Solar Panel FlashSpeed 1500

6.FAQs
5.5 Uninterrupted Power Supply (UPS)
To use the UPS function, connect the Power Station to a wall
outlet with the AC charging cable, then press the AC button
and connect your devices via the AC output ports.
(1)Weak Light Mode: Short press the LED button on the power
station to turn on the light, it enters the weak light mode;
(2)Medium Light Mode: Press the LED button twice to enter
medium light mode;
(3)Strong Light Mode: Press the LED button three times to
enter strong light mode;
(4)Strobe Mode: Press the LED button four times to enter strobe
mode;
(5)SOS Mode: Press the LED button five times to enter SOS
mode. Press the LED button again to turn the light off.
9
Wall outlet
Your device
1. What devices can the FlashSpeed 1500 power?
With 1500W rated power and 3000W peak power, FlashSpeed
1500 can normally power devices with rated power no more
than 1500W. Besides, with Vtoman's V-Beyond Technology,
FlashSpeed 1500 can run resistive loads over 1500 watts but no
more than 3000 watts such as lights, space heaters, toasters,
ovens, and coffee makers, etc.
2.How to know the working time for my device?
Working time=1548Wh*0.85 / operating power of your device.

10
3.Can the FlashSpeed 1500 be charged while using?
Yes, FlashSpeed 1500 supports pass-through charging. You can
recharge the power station while charging your device.
4.Can the FlashSpeed 1500 be used as a UPS?
Yes, the FlashSpeed 1500 has the UPS(Uninterrupted Power
Supply) function.
5.Are the DC output ports regulated 12V?
Yes, the voltage of DC5521 output ports and the car cigarette port
are regulated 12V.
6.What kind of solar panel does FlashSpeed 1500 suppport?
To charge FlashSpeed 1500 through the Anderson solar input
port, the solar panels need to meet the following requirements:
1)The working voltage of solar panel is between 30V-60V;
2)The solar panel has an Anderson adapter(or converted into
Anderson connector). For example, some solar panels come with
MC4 interface, then you just need to use an MC4 to Anderson
adapter cable to convert.
Warm Tip: It's recommended to use our Vtoman VS400 400W
solar panel to recharge FlashSpeed 1500 power station for better
charging experience.
7. Does FlashSpeed 1500 has MPPT feature?
Yes, all Vtoman power stations are built-in MPPT feature. You
don't need to get an extra MPPT controller to connect the Flash-
Speed 1500 power station with your solar panel.

7.Troubleshooting
8.Storage & Maintenance
1.Before storing, please turn off the product first, and then store
it in a dry, ventilated place at room temperature, away from
water, heat, and other metal objects.
2.For long-term storage, please discharge the battery to about
60%-80% before storing, and recharge it every 2 to 3 months to
extend its battery life.
3.When using the battery every day, it is recommended to
charge the battery to about 90% when charging, and leave
about 10% when discharging.
Problem Cause Solution
11
Product has no
output power.
Product doesn't get
a charge by AC Input.
Product doesn't get a
charge by Solar Input.
You device is not
connected to the power
station well.
Output switch is not
turned on.
Battery is low.
The charger is not well
connected to the power
station or wall outlet.
Connection is well, but
the display doesn't
show charging watts.
Solar panels are not
placed under the
sunlight.
The solar panel is not
compactiable with the
power station.
Check the connection
between the power station
and your device. Make sure
it's well connected.
Turn on the AC/DC/USB
output switch manually.
And the corresponding
output method will be
displayed on the display.
Recharge the power
station fully before use.
Check the connection
between the power
station and the AC outlet.
Please contact with
Vtoman customer service
at [email protected].
Please place the solar
panel under direct
sunlight to get the best
solar charging effect.
Please make sure the
working voltage of your
solar panel is between
30V to 60V, or it won't
charge the power station.

9.Warranty
4.Please use or store the product in an environment temperature
between 68°F to 86°F. For safety, please do not store the product
in an environment temperature higher than 113°F or lower than
14°F for a long time.
5.To clean the product, please gently wipe it with a dry, soft,
clean cloth or paper towel.
Note: We only provide the warranty for the consumer who pur-
chased our products through Amazon or Vtoman website.
VTOMAN warrants to the original consumer that Vtoman prod-
ucts will be free from defects in workmanship and materials
under normal use during the applicable warranty period as
determined in the "Warranty Period" section below, subject to
the "Exclusions" clause below.
Warranty Period
The warranty period of the VTOMAN portable power station is 24
months. Consumers need to provide a sales receipt for the first
purchase or other reasonable documentary proof to determine
the start date of the warranty period. Under normal circum-
stances, the warranty period is calculated from the date of pur-
chase by the original consumer.
Exchange
If VTOMAN products cannot be operated due to defects in work-
manship or materials during the applicable warranty period,
Vtoman will provide free replacement, and VTOMAN will bear
the freight. In addition, the replacement product will bear the
remaining warranty period of the original product.
12

Refund
VTOMAN provides a 30-day money-back guarantee for products
purchased directly from VTOMAN. If you are not satisfied for any
reason, just let us know within 30 days. Once we receive the
product and confirm its validity, we will refund the full amount.
Please check before returning: (1) You purchased the product
directly from VTOMAN ; (2) You contact Vtoman and start the
return process within 30 days of the original delivery date; (3) The
product is returned in its original packaging, including all mate-
rials, in a new or as-new state.
Exclusions
VTOMAN's warranty does not apply to:
1. Misuse, abuse, modification, accidental damage, or use for
any other purpose other than those authorized in the current
product information of VTOMAN;
2. Attempt to repair by anyone outside the authorized organi-
zation;
3. Appearance damage due to using;
4. Non-original consumer purchasers;
5. The VTOMAN warranty does not apply to battery cells.
If you have any questions during using Vtoman products,
please feel free to contact with us at [email protected].
Contact Us
13

華佳商事 株式会社
MADE IN CHINA

4.07.12.3741
PB58款英文说明书， LOGO：VTOAMN，型号：FlashSpeed 1500，容量:1548WH,
骑马钉装，128G铜版,彩色印刷，145*210MM ,20230726更新 符合ROHS
