VTOMAN Jump 600X User manual

Jump 600X Portable Power Station
User Manual
●Thank you for choosing Vtoman portable power station.
● Please read the user manual carefully and follow the instructions
in the manual to use the product correctly.
Model No.: PB-20

CONTENTS
1.Specifications
2.Package List
3.Safety Instructions
3.1 Usage
3.2 Personal Precautions
3.3 Disposal Guide
4.Product Features
4.1 Product Details
4.2 LCD Screen Introduction
5.Product Operating Instructions
5.1 Power & Function On/Off
5.2 Recharge Methods & Recharge Time
5.3 Battery Capacity Expansion
5.4 Use of LED Flashlight
6.FAQs
7.Troubleshooting
8.Storage & Maintenance
9.Warranty
10.Contact Us
1
2
2
4
3
5
5
6
7
8
8
9
11
11
12
13

1.Specifications
General Info
Product Name Jump 600X Power Station
Net Weight 6.64 KG (14.8 lbs)
Dimensions 260*220*215 mm (10.2*8.7*8.6 inch)
Certification FCC, RoHS, UN38.3, CE
Battery Info
Capacity 299Wh
Battery Type LiFePO4
Cycle Life 3000 cycles to 80%
Output Ports
AC (x2) Total 600W(Peak 1200W), 110V~60Hz,
Pure Sine Wave
USB-A (x2) 5V 2.4A, 12W Max per port
USB-A (x1) 5V 3A, 9V 2A, 12V 1.5A, 18W Max
USB-C (x1) 5V 3A, 9V 3A, 12V 3A, 15V 3A,
20V 3A, 60W Max
DC5521 (x2) 12V 10A, total 120W for all DC ports
Car Charger (x1) 12V 10A, total 120W for all DC ports
Input Ports
DC5521 (x1) DC12-30V (100W Max )
Environment Operating Temperature
Operating Temperature -20°C～55°C (-4°F to 131°F)
Charging Temperature 0°C～55°C (32°F to 131°F)
11

2.Package List
3.Safety Instructions
Jump 600X Power Station Car Charger Cable AC Charger & Charging Cable
USB-C to USB-C Cable USB-A to USB-C Cable User Manual
No. Item
1
2
3
4
5
6
1
1
1
1
1
1
Jump 600X Power Station
AC Charger & Charging Cable
USB-C to USB-C Cable
USB-A to USB-C Cable
Car Charger Cable
User Manual
110V/600W
24V/3.75A, 90W Max
/
/
Cigarette lighter to DC5521
English version
Qty. Specification
Please kindly check all accessories are complete. If any parts
missing, please feel free to contact us at [email protected].
3.1 Usage
When using this product, basic precautions should always be
followed, including the following:
1.Read all the instructions before using the product.
2.To reduce the risk of injury, close supervision is necessary when
the product is used near children.
2

3.Do not put fingers or hands into the product.
4.Use of an attachment not recommended or sold by power
pack manufacturer may result in a risk of fire, electric shock, or
injury to persons.
5.To reduce risk of damage to the electric plug and cord, pull the
plug rather than the cord when disconnecting the power pack.
6.Do not use a battery pack or appliance that is damaged or
modified. Damaged or modified batteries may exhibit unpre-
dictable behavior resulting in fire, explosion or risk of injury.
7.Do not operate the power pack with a damaged cord or plug,
or a damaged output cable.
8.Do not disassemble the power pack, take it to a qualified
service person when service or repair is required. Incorrect reas-
sembly may result in a risk of fire or electric shock.
9.To reduce the risk of electric shock, unplug the power pack
form the outlet before attempting any instructed servicing.
3.2 Personal Precautions
1.Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
2.Wear complete eye protection and clothing protection. Avoid
touching eyes while working near battery.
3.If battery acid contacts skin or clothing, wash immediately
with soap and water. If acid enters eye, immediately flood eye
with running cold water for at least 10 minutes and get medical
attention immediately.
4.NEVER smoke or allow a spark or flame in vicinity of battery or
engine.
5.Be extra cautious to reduce risk of dropping a metal tool onto
battery. It might spark or short-circuit battery or other electrical
part that may cause explosion.
6.When charging the internal battery, work in a well ventilated
area and do not restrict ventilation in any way.
7.Under abusive conditions, liquid may be ejected from the bat-
tery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
3

Liquid ejected from the battery may cause irritation or burns.
8.Do not expose a power pack to fire or excessive temperature.
Exposure to fire or temperature above 265°F(130°C) may cause
explosion.
9. Have servicing performed by a qualified repair person using
only identical replacement parts. This will ensure that the safety
of the product is maintained.
3.3 Disposal Guide
1.If conditions permit, make sure that the battery is fully
discharged before disposing it in a designated battery recycling
bin. The product contains batteries with potentially dangerous
chemicals, so it is strictly prohibited to dispose of it in ordinary
trash cans. For more details, please follow the local laws and
regulations on battery recycling and disposal.
2.If the battery cannot be fully discharged due to a product
failure, please do not dispose of the battery directly in the bat-
tery recycling box. In such case, you should contact a profession-
al battery recycling company for further processing.
3. Please dispose of over-discharged batteries that cannot be
recharged.
4

4.Product Features
4.1 Product Details
4.2 LCD Screen Introduction
5
Remaining Charge/Discharge Time
Remaining Battery Percentage
DC Input 12-30V
LCD Display LED Light
Backup
battery port
AC Output
110V/600W
DC Output
12V/10A
AC Output
USB-C Output12V DC Output USB-A Output
Input/Output
Power
USB-C Output / 60W Max
USB-A Output / 12W Max
USB-A Output / 12W Max
USB-A Output / 18W Max

5.Product Operating Instructions
5.1 Power & Function On/Off
1.Power On: Short press any button to power on the product
and enter the standby state, the LCD Screen will light up and the
battery level indicator icon will display.
2.Power Off: Turn off all outputs manually, then the product
enters the standby state and will shut down after 30 minutes.
3.AC Output On/Off: Short press the AC Button to use the AC
output; Short press the AC Button again to turn if off.
4.DC Output On/Off: Short press the DC Button to use the 12V
DC output; Short press the DC Button again to turn if off.
5.USB-A & USB-C On/Off: Short press the USB Button to use
the USB-A & USB-C output; Short press the USB Button again to
turn if off.
6
Warm Tips:
2.V-Beyond Technology: It allows you to run devices over 600
watts but no more than 1200 watts on Jump 600X power station.
It would lower the output voltage to bring the power back down
without tripping the overload protection, so that yo can continue
to run those devices. It's suitable for resistive loads such as lights,
space heaters, toasters, ovens, and coffee makers, etc. But please
note that it's NOT suitable for complex electronics such as com-
puters, TVs, refrigerators, etc.
1.Auto Shut-off Feature: When any output switch of the battery
is turned on, the battery will maintain continuous output for 6
hours. After 6 hours, the battery starts to detect the load current
and lasts for 2 hours. There are three situations as follows:
1) If no load is detected within 2 hours, the battery will automat
ically shut down;
2) When the load is detected within 2 hours, the battery will
continue to output;
3) If it is detected that the load is turned on and then turned off
within 2 hours, the load detection will be restarted for 2 hours
after the load is turned off.

5.2 Recharge Methods & Recharge Time
1.Recharge Time
Warm Tips: Before use, please plug your Jump 600X power
station into the wall until it is fully charged.
2.Recharge by Wall Charger
You can use the wall charger that comes in the package to
recharge the Jump 600X power station. The recharging time is
about 3-3.5 hours.
3.Recharge by Car Charger
You can recharge the Jump 600X power station through the DC
Input Port with a car charger. Jump 600X supports 12V car char-
gers, and the recharging time is about 3-3.5 hours.
7
90W Wall Charger 12V Car Charger 100W Solar Panel
3-3.5 Hours 3-3.5 Hours 3.5-4.5 Hours
4.Recharge by Solar Panel
You can connect a Vtoman VS110 110W Solar Panel to recharge
Jump 600X power station, the recharge time is about 3.5-4.5
hours (depending on sunlight intensity).
Wall Outlet

5.3 Battery Capacity Expansion
Vtoman Jump 600X Portable Power Station can expand its
battery capacity from 299Wh to 939Wh with Jump 600X Extra
Battery(Sold separately), so that it can power your devices for a
longer time.
5.4 Use of LED Flashlight
The Jump 600X Power Station features a LED flashlight with 5
mode. Please follow the instructions below to enter different
modes:
If connecting with your own solar panel, please make sure the
working voltage of the solar panel is between 12-30V to
recharge properly.
Jump 600X Extra BatteryJump 600X Portable Power Station
To expand the battery capacity, you just need to connect the
Jump 600X Portable Power Station to the Jump 600X Extra
Battery with a CP3500 cable.
The CP3500 cable will get hot during work,please DO NOT
touch the CP3500 cable in avoid of scalding！
8
DC5521 Connector
Vtoman VS110 Solar Panel Jump 600X

6.FAQs
(1)Weak Light Mode: Short press the LED button on the power
station to turn on the light, it enters the weak light mode;
(2)Medium Light Mode: Press the LED button twice to enter
medium light mode;
(3)Strong Light Mode: Press the LED button three times to
enter strong light mode;
(4)Strobe Mode: Press the LED button four times to enter strobe
mode;
(5)SOS Mode: Press the LED button five times to enter SOS
mode. Press the LED button again to turn the light off.
1. What devices can the Jump 600X power?
With 600W rated power and 1200W peak power, Jump 600X
can normally power devices with rated power no more than
600W. Besides, with Vtoman's V-Beyond Technology, Jump
600X can run resistive loads over 600 watts but no more than
1200 watts such as lights, space heaters, toasters, ovens, and
coffee makers, etc.
2.How to know the working time for my device?
Working time=299Wh*0.85 / operating power of your device.
3.How long can Jump 600X charge my devices?
The charging time is shown on the product’s LCD Screen, which
can be used to estimate the charging time of most appliances
with stable power usage.
4.Can the Jump 600X be charged while using?
Yes, Jump 600X supports pass-through charging. You can
recharge the power station while charging your device.
9

5.Can the Jump 600X be used as a UPS?
No, the Jump 600X can't be used as UPS, because you need to
press the button manually to turn on the AC/DC/USB output, it
cannot turn on automatically.
6.Are the DC output ports regulated 12V?
Yes, 2 DC5521 output ports and 1 cigarette lighter are regulated
12V voltage, the specifications are 12V/10A, the maximum output
power is 120W in total (single port is 120W Max; 3 ports are also
120W Max in total).
7.What kind of solar panel does Jump 600X suppport?
To charge Jump 600X properly, the solar panels need to meet
the following requirements:
1)The working voltage of solar panel is between 12V-30V;
2)The solar panel has a DC5521 adapter(or converted into a
DC5521 connector). For example, some solar panels come with
MC4 interface, then you just need to use an MC4 to DC5521
adapter cable to convert.
Warm Tip: It's recommended to use our Vtoman VS110 110W
solar panel to recharge Jump 600X power station for better
charging experience.
8. Does Jump 600X has MPPT feature?
Yes, all Vtoman power stations are built-in MPPT feature. You
don't need to use an extra MPPT controller to connect the Jump
600X power station with your solar panel.
10

7.Troubleshooting
8.Storage & Maintenance
1.Before storing, please turn off the product first, and then store
it in a dry, ventilated place at room temperature, away from
water, heat, and other metal objects.
2.For long-term storage, please discharge the battery to about
60%-80% before storing, and recharge it every 2 to 3 months to
extend its battery life.
3.When using the battery every day, it is recommended to
charge the battery to about 90% when charging, and leave
about 10% when discharging.
to
ell.
r
se.
P
l
ll.
Problem Cause Solution
No output power
Your device is not
connected to the
power station well.
Connect your device
the power station w
Output switch is not
turned on.
Turn on the output
switch manually.
Battery is low. Recharge the powe
station fully before u
Output breaks down
during use
Your device’s operating
power is too low,
causing the product
turns off automatically.
Please turn on the
power again.
roduct cannot charge
Charger is not well
connected to the
power station or wall
outlet .
Please make sure al
connections are we
Connection is well, but
the charger indicator is
off. Charger is broken.
Please contact with
Vtoman customer
service.
11

9.Warranty
4.Please use or store the product in an environment temperature
between 68°F to 86°F. For safety, please do not store the product
in an environment temperature higher than 113°F or lower than
14°F for a long time.
5.To clean the product, please gently wipe it with a dry, soft,
clean cloth or paper towel.
Note: We only provide the warranty for the consumer who pur-
chased our products through Amazon or Vtoman website.
VTOMAN warrants to the original consumer that Vtoman prod-
ucts will be free from defects in workmanship and materials
under normal use during the applicable warranty period as
determined in the "Warranty Period" section below, subject to
the "Exclusions" clause below.
Warranty Period
The warranty period of the VTOMAN portable power station is 24
months. Consumers need to provide a sales receipt for the first
purchase or other reasonable documentary proof to determine
the start date of the warranty period. Under normal circum-
stances, the warranty period is calculated from the date of pur-
chase by the original consumer.
Exchange
If VTOMAN products cannot be operated due to defects in work-
manship or materials during the applicable warranty period,
Vtoman will provide free replacement, and VTOMAN will bear
the freight. In addition, the replacement product will bear the
remaining warranty period of the original product.
12

Refund
VTOMAN provides a 30-day money-back guarantee for products
purchased directly from VTOMAN. If you are not satisfied for any
reason, just let us know within 30 days. Once we receive the
product and confirm its validity, we will refund the full amount.
Please check before returning: (1) You purchased the product
directly from VTOMAN ; (2) You contact Vtoman and start the
return process within 30 days of the original delivery date; (3) The
product is returned in its original packaging, including all mate-
rials, in a new or as-new state.
Exclusions
VTOMAN's warranty does not apply to:
1. Misuse, abuse, modification, accidental damage, or use for
any other purpose other than those authorized in the current
product information of VTOMAN;
2. Attempt to repair by anyone outside the authorized organi-
zation;
3. Appearance damage due to using;
4. Non-original consumer purchasers;
5. The VTOMAN warranty does not apply to battery cells.
If you have any questions during using Vtoman products,
please feel free to contact with us at [email protected].
Contact Us
13

華佳商事 株式会社
MADE IN CHINA
