VUEROID D20-Q2 User manual

Quick Start Guide
V1.0 English
The product is a dashboard camera.
Make sure to understand the contents of the manual to use the product correctly.
D20-Q2⁺
D20-Q2 Series
D20-Q2E
QHD Dual Dashcam / Wi-Fi &
Smart ADAS
QHD Dual Dashcam / Wi-Fi

Precautions Before Using the Product
Package Contents
Warning
Caution
Do not expose this product to rain, moisture or water under any circumstances,
doing so may result in the risk of electric shock or 󽗉re.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in this instruction unless you are quali󽗉ed to do so. Please make sure
to have the unit serviced by a quali󽗉ed service technician if you are facing with
some cases as follows;
1. The unit has been exposed to rain or water.
2. The unit does not seem to operate normally.
3. The unit shows a marked change in performance.
VUEROID does not warranty any defects that can be caused by owner’s fault
VUEROID is not responsible for any damaged that occur while driving.
Dashcam
Quick Manual
12V Power Cable
Rear View Camera Hardwiring Cable
(3m/9.8ft)
Micro SD Card
Rear View Camera Cable
(6m/19.6ft)
SD Card Adaptor & Case
Wind Shield Tape
Option

QHD DUAL
FOV 145°
CMOS
Image Sensor
Prevent Discharge
ADAS
Time Lapse
Safety
Camera Alert
Format Free
Night Vision
Built-in GPS
Product Overview
Key Features
(*ADAS, Safety Camera Alert, and Built-in GPS are not included with D20-Q2E)
❿
⓬ ⓭
❷
❸
❶
❻❺ ❼ ❽❹
❾⓫
Mark Description
❶CAM Input Port Used to connect the rear camera
❷DC-IN Power Port Used to connect the power cable
❸Wi-Fi Dongle Wi-Fi dongle for Wi-Fi network connection
❹Camera Lens Front camera for video recording
❺Front LED Indicate parking status and provides security e󽗈ect
❻Mount Installation Mount
❼Memory Card Slot Insert a memory card
❽Power Switch Power ON/OFF switch
❾Voice Button Press more than 3 seconds : Voice guidance ON/OFF
Press less than 3 seconds : Voice recording ON/OFF
❿
Manual Recording Button Press to start manual recording
⓫Wi-Fi Button Press to connect the product to smartphone via Wi-Fi network
⓬Speaker Speaker for voice guidance
⓭MIC Microphone for voice recording

Device Installation
Caution
1. Main Device Installation
(1) Select and clean the area where the product will be installed.
(2) Remove the Wind Shield tape 󽗉lm.
(3) Attach the device.
(4) Connect the rear view camera and connect the power cable.
To avoid interrupted reception with other devices such as a navigation,
make sure the wiring is not overlapped with enough space in between.
1
3
2
4
⚠
- Make sure to install the device in a safe area and that the engine is OFF.
- Please check if the Micro SD card is inserted correctly before connecting to power.
- Make sure the installation area is clean.
- Unplug the DC power if you are not using the device for a long period of time.
- Do not drop the product as it may not function properly.
- During extreme high temperatures or hot weathers, parking indoors is
suggested.

2. Connecting Hardwiring Cable
3. Rear View Camera Installation
Caution When Inserting Micro SD Card
-
Do not apply excessive force on the Micro SD card or insert in the wrong direction.
Any actions which may cause an SD card error, will be the responsibility of the user.
- Please test the Micro SD card for errors frequently and because it is a consumable
item, it should be replaced periodically.
- Make sure the device is turned o󽗈 when you pull out the SD card.
- Any issues arisen by using a di󽗈erent Micro SD card besides VUEROID’s are the
responsibilities of the user.
- Store important recordings into other devices (ex, PC).
(1) Select and clean the area where the product will be installed.
(2) Remove the Wind Shield tape 󽗉lm.
(3) Connect the rear view camera and connect the power cable.
Before installation, make sure the engine is turned o󽗈.
Make sure the installation area is cleaned.
Make sure the installation area doesn’t interfere with the window’s
infrared rays.
Please visit a professional installer
to connect hardwire cable.
1 32
BLACK : GND
YELLOW : BAT (B+)
RED : ACC
⚠
⚠
⚠
⚠

Turn on the “Wi-Fi” button on the dashcam.
Then it shows a SSID (VUEROID_D20-Q2_XXXXXX) on the list of Wi-Fi network.
(1) Tap on “OK” once the pop-up screen is shown and it says “Connect to device”.
(2) You’ll be greeted by a SSID in the form of VUEROID_D20-Q2_XXXXXX in a given
Wi-Fi network listing.
Tap on that SSID and key in a default PW(12345678).
Using Wi-Fi Application
1. Wi-Fi Application Download and Installation
2. Wi-Fi Application Registration
Search “VUEROID Dashcam” on the App Store (iPhone), Play Store (Android) then
install.
1 2

❺
❷
❶
❹❸
❻
❶Wi-Fi Status Display Wi-Fi status and the
name of the connected device.
❷Wi-Fi Connect Enable or Disable Wi-Fi
connection.
❸Live Viewer View the front / rear live stream.
❹File Viewer Find the recording 󽗉les in
di󽗈erent folders.
❺History
Find the trip data and travel
route by dates.
(*not included in D20-Q2E)
❻Setting Allows user to get unit’s settings
switched.
❶Left / Right
Reverse
Switch to Left / Right viewing
image.
❷Snapshot Capture the display image.
❸Full Screen Display the full screen.
❹CH
(Front / Rear)
Switch to Front / Rear camera
image.
❺ADAS
Initialize the ADAS calibration
setting. Enable or disable
following fuctions
1) LDWS
2) FVSA
3) FCW
4) RCW
5) Safety camera Alert
(*not included in D20-Q2E)
3. Wi-Fi Application Start-up Screen
4. Live View Mode
❺
❹❸
❷❶

ADAS Setting
ADAS
You can Enable or Disable a lane departure warning system (LDWS), a Front
Vehicle Start Alarm (FVSA), a Forward Collision Warning System (FCWS), a Rear
Collision Warning (RCW), and set their options.
Safety Camera Alert
When the vehicle approaches or passes the speed limit zone, the safety camera
alert system will Collect GPS signals and safety camera data. Refer to the
following instructions to enable or disable this feature.
Download will be available on the VUEROID website (http://www.vueroid.com/
support/download).
(*not included in D20-Q2E)

❶Drive
Drive recordings videos are saved. Recorded
videos are saved in 1 minute segment with an
auto-looping mechanism.
❷Event
Event-triggered videos are saved in 30 seconds,
from 10 seconds before detection to 20 seconds
after detection.
❸Parked
Park recordings videos are saved. Max 30
seconds of recording 󽗉les including motion /
impact event recordings are saved.
❹Manual
Manual recordings videos are saved in 30
seconds, from 10 seconds before manual
recording button is pushed to 20 seconds after.
❺Phone Recordings videos saved in the smart phone are
saved.
5. View the Recordings (File Viewer)
6. Travel Log
The recording 󽗉les in the D20 unit can be viewed
through the File Viewer. Each folder support the
thumbnail view with front / rear options.
It logs every trip you take and reports like mileage
and trip time, as well as any impact events that
might have occurred on the road.
❺❹❸❷❶
(*not included in D20-Q2E)

7. GPS Mapping within the App
Yours Itineraries can be safely stored in the History Menu so that you can access
all your previous car rids.
Plus, Travel-log drive will help drivers or 󽗊eet managers to 󽗉nd a vehicle’s current
Location using the VUEROID Mobile app. Captured by the VUEROID Built-in
antenna, the vehicle’s location, speed, and direction of travel is shown in the
mobile app on a Google maps display.
(*not included in D20-Q2E)

Recording Settings for image quality, Power saver,
parking mode time.
Event Settings for impact and motion events
sensitivity while parking.
Sound Settings for voice recording options
and speaker volume.
Time Settings for standard time and the
current time.
Memory Settings for memory allocation / Micro
SD card Format.
System Settings for system / Reboot.
8. Review & Edit Footage on the App
9. Con󽗉guration (Setting)
With this app you can
immediately access your
footage directly on your
smartphone. Make quick
edits to trim the excess
and keep only the best
parts.
It gives you a complete control over your dash cam’s
settings.
Each given categories can be seen as follows

Using Desktop Software
1. Download PC Viewer
2. PC Viewer Compatibility
3. Start PC Viewer
Open the Internet browser then download the PC Viewer on the following link in
below.
http://www.vueroid.com/support/download
The PC viewer is compatible for both Windows and Mac OS computers.
Open the installed VUEROID D20 Viewer on the desktop.
Before opening the viewer, make sure the Micro SD card is inserted.

Item Description
Camera
CIS Front / Rear : SONY Starvis 5M (IMX335)
Resolution Front / Rear : 2560 x 1440 @ 30fps
View Angle Front / Rear : (D)145° x (H)115° x (V)62°
Memory Card Micro SD Card (16GB / 32GB / 64GB / 128GB / 256GB)
GPS Built-in Antenna (*not included in D20-Q2E)
LED Indicators Front : Security & Status LED / Rear : Security LED
G-Sensor 3-Axis Acceleration Sensor, +2g / -2g
Speaker Built-in Speaker (Voice Guide)
Microphone Built-in Microphone
Video Codec H.264 High Pro󽗉le
Recording Mode Normal / Event / Manual / Parking (Motion & Time lapse)
Dimensions Front : 112mm x 72mm x 35mm
Rear : 52mm x 29mm x 42mm
Weight Front : 107.5g / Rear : 28g
Power Input DC 12V ~ 24V
Power Consumption Max. 5.4W at 12V
Operating Temp. -20°C ~ 70°C (-4°F ~ 158°F)
High Temp. Cut-o󽗈 Approximate 70°C (158°F) / Battery Discharge Prevention
Product Spec
Product Speci󽗉cations
General Speci󽗉cations
Item Description
Certi󽗉cations FCC, CE, ROHS, RCM
Software IOS & Android compatible mobile app
Window & Mac compatible PC viewer

Frequently Asked Questions
Q1. Is it possible to use the product regardless of types of cars such as a
passenger car or a commercial vehicle?
The product for both 12V and 24V can be used regardless of types of cars.
Q2. What is a low voltage prevention function (vehicle battery discharge)?
The product is embedded with a low voltage prevention function. It is available to
set voltage values through environment setting. If the voltage of a vehicle drops
below the set value, the power of the product is turned o󽗈 automatically.
Q3. No impact has occurred but a video 󽗉le is saved in an event folder.
The product detects impacts through a G sensor of the dashcam. An impact is
saved in an event folder when the product detects shaking of a vehicle going over
a speed bump or in other situations. It is possible to adjust the sensitivity of the G
sensor (an impact sensor) through environment setting.
Q4. I cannot not turn on the power.
Check if the power cord is connected properly. If it is connected properly, check
the status of the battery. The lifespan of a fuse may be expired. If a problem is not
solved even after the fuse is replaced, contact the customer service. ([e-mail])
Firmware / Safety Camera DB update
Full Manual / Firmware / Safety Camera DB, Download is available on the VUEROID
website (http://www.vueroid.com/support/download).
Warrenty Information
All dashcams sold from VUEROID include a 1 year manufacturer warranty (6 months
for SD card).
The warranty does not apply to the following
1) Cosmetic damage, such as scratches, and dents.
2) Damage caused by accident, abuse or natural disaster.
3) Damage caused by service performed by anyone who is not an authorized service
provider of VUEROID.
4) Damage to a product by not using supplied power or accessories in the package.
http://www.vueroid.com
