VUEROID D30-QF2 User manual

D30-QF2
360° Video Display Dashcam
Quick Start Guide
V1.0 English
The product is a dashboard camera.
Make sure to understand the contents of the manual to use the product correctly.

Precautions Before Using the Product
Package Contents
Warning
Caution
Do not expose this product to rain, moisture or water under any circumstances,
doing so may result in the risk of electric shock or 󽗉re.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in this instruction unless you are quali󽗉ed to do so. Please make sure
to have the unit serviced by a quali󽗉ed service technician if you are facing with
some cases as follows;
1. The unit has been exposed to rain or water.
2. The unit does not seem to operate normally.
3. The unit shows a marked change in performance.
VUEROID does not warranty any defects that can be caused by owner’s fault
VUEROID is not responsible for any damaged that occur while driving.
Dashcam
Quick Manual Optional 12V Power Cable
Rear View Camera Hardwiring Cable
(3m/9.8ft)
Micro SD Card
(Option)
Rear View Camera Cable
(6m/19.6ft)
SD Card Adaptor & Case
Wind Shield Tape

Product Overview
Key Features
Dual Channel
FOV 360°
CMOS
Image Sensor
Prevent Discharge
ADAS
Time Lapse
Safety
Camera Alert
Format Free
Night Vision
Built-in GPS
❿ ⓬
❷
❸
❶
❻❺ ❼ ❽❹ ❾ ⓫
Mark Description
❶R-CAM input port Used to connect the rear view camera
❷DC-IN power port Used to connect the power cable
❸Parking mode switch Used to enable or disable the parking mode recording
❹Camera Lens Dashcam camera lens for video recording
❺Speaker Speaker for voice guidance
❻Security LED Indicate parking status and provides security e󽗈ect
❼Mount Installation Mount
❽Memory card slot Insert a memory card
❾Mic Microphone for voice recording
❿Power switch Power ON/OFF switch
⓫Status LED Indicate the recording status
⓬LCD Touch screen LCD

Device Installation
Caution
1. Main Device Installation
- Make sure to install the device in a safe area and that the engine is OFF.
- Please check if the Micro SD card is inserted correctly before connecting to power.
- Make sure the installation area is clean.
- Unplug the DC power if you are not using the device for a long period of time.
- Do not drop the product as it may not function properly.
- During extreme high temperatures or hot weathers, parking indoors is
suggested.
(1) Select and clean the area where the product will be installed.
(2) Remove the Wind Shield tape 󽗉lm.
(3) Attach the device.
(4) Connect the rear view camera and connect the power cable.
To avoid interrupted reception with other devices such as a navigation,
make sure the wiring is not overlapped with enough space in between.
1
3
2
4
⚠

2. Connecting Hardwiring Cable
3. Rear View Camera Installation
Caution When Inserting Micro SD Card
- Do not apply excessive force on the Micro SD card or insert in the wrong direction.
Any actions which may cause an SD card error, will be the responsibility of the user.
- Please test the Micro SD card for errors frequently and because it is a consumable
item, it should be replaced periodically.
- Make sure the device is turned o󽗈 when you pull out the SD card.
- Any issues arisen by using a di󽗈erent Micro SD card besides VUEROID’s are the
responsibilities of the user.
- Store important recordings into other devices (ex, PC).
(1) Select and clean the area where the product will be installed.
(2) Remove the Wind Shield tape 󽗉lm.
(3) Connect the rear view camera and connect the power cable.
Before installation, make sure the engine is turned o󽗈.
Make sure the installation area is cleaned.
Make sure the installation area doesn’t interfere with the window’s
infrared rays.
Please visit a professional installer
to connect hardwire cable.
1 32
BLACK : GND
YELLOW : BAT (B+)
RED : ACC
⚠
⚠
⚠
⚠

Product Spec
Product Speci󽗉cations
General Speci󽗉cations
Item Description
Camera
CIS Front : SONY Starvis 5M (IMX335)
Rear : SONY Starvis 2M (IMX307)
Resolution Front : 2560 x 1440 @ 30fps / Rear : 1920 x 1080 @ 30fps
View Angle Front : (D)360° x (H)240° x (V)240°
Rear : (D)134° x (H)105° x (V)80°
LCD 3.5” LCD / IPS Capacitive Touch (800 x 480)
Memory Card Micro SD Card (16GB / 32GB / 64GB / 128GB / 256GB)
GPS Built-in Antenna
LED Indicators Front : Security & Status LED / Rear : Security LED
G-Sensor 3-Axis Acceleration Sensor, +2g / -2g
Speaker Built-in Speaker (Voice Guide)
Microphone Built-in Microphone
Video Codec H.264 High Pro󽗉le
Recording Mode Normal / Event / Manual / Parking (Motion & Time lapse)
Dimensions Front : 100mm x 83mm x 39mm
Rear : 52mm x 29mm x 42mm
Weight Front : 175g / Rear : 28g
Power Input DC 12V ~ 24V
Power consumption Max. 5.5W at 12V
Operating Temp. -20°C ~ 70°C (-4°F ~ 158°F)
High Temp. Cut-o󽗈 Approximate 70°C (158°F) / Battery Discharge Prevention
Item Description
Certi󽗉cations FCC, CE, ROHS
Software IOS & Android compatible mobile app
Window & Mac compatible PC viewer

Drive & Basic Operation
Power Operation
1. When connecting a hard wiring (power) cable to the dashcam and turning o󽗈
the engine, the LED blinks for booting.
2. When a micro SD card is not inserted, a voice guidance, “There is No SD card”,
is announced.
1. When a car engine starts, the LED blinks. A logo appears on the LCD screen
and the product boots. If the product does not start, check the following:
- Is the dashcam connected to a DC power jack?
- Is the power switch of the dashcam “ON”?
2. After booting is complete, video recording is displayed on an LCD screen.
3. If a micro SD card is not inserted, a message, “A SD card cannot be recognized.
Insert the SD card”, appears along with a voice guidance, “A SD card cannot be
recognized.”
Do not manipulate the product while driving a vehicle.
A micro SD card should be inserted in the dashcam for recording.
For normal running of the dashcam, the power switch should be ON.
⚠
⚠
⚠

Note : Status Bar is always displayed and is located at the bottom of the
screen so that the driver can easily check it when mounted on a vehicle.
Screen Layout
1. Main Screen
2. STATUS BAR
❺ ❻ ❼❹❸❷
❶
❶
Manual
Recording
Press to start manual videos
recordings up 30 Sec (10 sec
prior, and 20 sec afterward)
❷ HDR
HDR On
HDR O󽗈
❸ GPS
GPS is Not Connected
GPS Signal is Lost
Receiving GPS Signal
❹
Camera
Channel
Front Camera Recording
Front + Rear Camera
Recording
❺ ADAS
ADAS is On
ADAS is O󽗈
❻ Audio
Audio Recording is On
Audio Recording is O󽗈
❼
Recording
Mode
Continuous Mode
Recording
Parking Mode Recording
Event Mode Recording
Manual Mode Recording

Live View Mode Setting
Touch a screen switching icon to switch in the following order:
❶ 4 split → ❷ 2 split → ❸ Front → ❹ Rear screen
❶Audio Recording Audio recording turn On / O󽗈
❷Volume Control Speaker Volume Low / Mid / High / O󽗈
❸Play List Recording video list
❹Setting View the con󽗉gure the dashcam Settings
❶Menu Press the Menu button to enter the dashcam’s Menu system
❷Live View Tap to switch live view mode
3. Menu & Live View
4. Menu Screen
❷❶
❹❸
❷❶

5. Play List
❶Event
Event-triggered videos are saved
in 30 seconds, from 10 seconds
before detection to 10 seconds
after detection.
❷Parked
Park recordings are saved. Max
30 seconds of recording 󽗉les
including motion / impact event
recordings are saved.
❸Drive
Drive recordings are saved.
Recorded videos are saved in
1 minute segment with an
auto-looping mechanism.
❹Manual
Manual recordings videos are
saved in 30 seconds, from
10 seconds before manual
recording button is pushed to
20 seconds after.
❶View Mode Switch between video
preview and list view
❷List Up Move to the beginning of
the list
❸Page up Move to the page up
❹Page Down Move to the page below
❺List Down Move to the end of the list
❶Play / Pause Play / Pause a video
❷Previous Play previous video
❸REW Rewind a video
❹FF Forward a video
❺Next Play next video
❺
❹
❸
❷
❶
❹
❸
❷
❶
❺❹❸❷
❶

6. Settings
Setting Menu Tree:
See below for the settings to be found
under each submenu
Following features are under development and will be applied through future updates.
Download will be available on the VUEROID website (http://www.vueroid.com/support/
download).
ADAS
You can Enable or Disable a lane departure warning system (LDWS), a Front Vehicle
Start Alarm (FVSA), a Forward Collision Warning System (FCWS), a Rear Collision
Warning (RCW), and set their options.
Safety Camera Alert
When the vehicle approaches or passes the speed limit zone, the safety camera
alert system will Collect GPS signals and safety camera data. Refer to the following
instructions to enable or disable this feature.
1. Tap Dash Cam Settings → Safety Camera Alert.
2. From Safety Camera, select Enabled or Disabled. The new setting is applied
automatically.
❶ Recording
1) Continuous recording
mode
2) Video Quality
3) HDR
❷Parking
Mode
1) Parking recording mode
2) Discharge cut-o󽗈 voltage
3) Discharge cut-o󽗈 time
❸
Event
Sensitivity
1) Impact sensitivity in
continuous mode
2) Impact sensitivity in
Parking mode
3) Front motion sensitivity
4) Rear motion sensitivity
❹ADAS
1) LDWS
2) LDWS Sensitivity
3) FVSA
4) FCW
5) RCW
6) Safety camera Alert
❺Memory 1) Memory allocation
2) Format
❻System
1) LCD operating time
2) LCD brightness
3) Rear view camera display
4) Security LED
5) Time setting
6) System information
❺ ❻❹
❸❷❶

Using Desktop Software
1. Download PC Viewer
2. PC Viewer Compatibility
3. Start PC Viewer
Open the Internet browser then download the PC Viewer on the following link in
below.
http://www.vueroid.com/support/download
The PC viewer is compatible for both Windows and Mac OS computers.
Open the installed VUEROID D30 Viewer on the desktop.
Before opening the viewer, make sure the Micro SD card is inserted.

Frequently Asked Questions
Q1. Is it possible to use the product regardless of types of cars such as a
passenger car or a commercial vehicle?
The product for both 12V and 24V can be used regardless of types of cars.
Q2. What is a low voltage prevention function (vehicle battery discharge)?
The product is embedded with a low voltage prevention function. It is available to
set voltage values through environment setting. If the voltage of a vehicle drops
below the set value, the power of the product is turned o󽗈 automatically.
Q3. No impact has occurred but a video 󽗉le is saved in an event folder.
The product detects impacts through a G sensor of the dashcam. An impact is
saved in an event folder when the product detects shaking of a vehicle going over
a speed bump or in other situations. It is possible to adjust the sensitivity of the G
sensor (an impact sensor) through environment setting.
Q4. I cannot not turn on the power.
Check if the power cord is connected properly. If it is connected properly, check
the status of the battery. The lifespan of a fuse may be expired. If a problem is not
solved even after the fuse is replaced, contact the customer service. ([e-mail])
Firmware / Safety Camera DB update
Full Manual / Firmware / Safety Camera DB, Download is available on the VUEROID
website (http://www.vueroid.com/support/download).
Warrenty Information
All dashcams sold from VUEROID include a 1 year manufacturer warranty (6 months
for SD card).
The warranty does not apply to the following
1) Cosmetic damage, such as scratches, and dents
2) Damage caused by accident, abuse or natural disaster.
3) Damage caused by service performed by anyone who is not an authorized service
provider of VUEROID
4) Damage to a product by not using supplied power or accessories in the package.
http://www.vueroid.com
