MODEL: LG500 Economy Free Standing Gas Fryer
LG500
FREE STANDING ECONOMY GAS FRYER
STANDARD FEATURES
Stainless steel fry tank, 65 - 70 lb. capacity.
Large cold zone area.
11/4" full port ball type drain valve.
Stainless steel front and door.
G90 high grade galvanized non corrosive finish sides and
back.
Door liner for added stability.
Set of four nickel plated legs adjustable to 7".
Twin fry baskets with plastic coated handles.
150,000 BTU/hr. input.
Behind the door snap action millivolt thermostat control ad-
justs from 200° to 400°F with standing pilot.
Millivolt System - Requires no electric hook-up.
Hi-limit shut-off protector shuts off gas combination valve and
standing pilot.
Built in flue deflector.
Nickel plated tube rack.
Earth magnet to secure closed door.
Easily removable stainless steel basket hanger for cleaning.
Vulcan-Hart (Vulcan) warrants the LG500 Gas Fryer to be
free of defects in materials and workmanship for a period of
1 year from the date of original installation.
Stainless steel fry tank will be warranted for 1 year. If tank is
found to have a leak and is verified by an authorized service
agency, the entire LG500 fryer will be replaced. Replace-
ment fryer will be warranted for the balance of the original
warranty.
ACCESSORIES
Casters 6" adjustable to 7", 2 locking, 2 non-locking
Stainless steel tank cover.
Grease protector strips.
Single large basket - 183/4"w x 131/4"d x 51/2"h.
Set of twin baskets - 91/4"w x 131/4"d x 6"h.
Set of tri-baskets - 51/2"w x 11"d x 41/2"h.
FRYMATE - VX21 add-on Frymate™ Dump Station.
Flexible gas hose with quick disconnect.
SPECIFICATIONS:
65 - 70 lb. capacity free standing model gas fryer, Vulcan-Hart
Model No. LG500. Stainless steel front and door. Set of four
6" nickel plated steel legs adjustable to 7". Stainless steel fry
tank with five heat exchanger tubes and a "V" shaped large
cold zone. 11/4" full port ball type drain valve. Twin fry
baskets with plastic coated handles. 150,000 BTU/hr. input.
Behind the door snap action millivolt thermostat control
adjusts from 200° to 400°F.
Overall dimensions: 21"w x 301/4"d x 361/4"h.
CSA design certified. NSF listed.
SPECIFYTYPEOFGASWHENORDERING.
Natural Gas
Propane Gas
SPECIFYALTITUDE:
Natural Gas for above 2000 ft
Propane Gas for above 3500 ft.
LG500 Shown

Printed On Recycled Pap
er
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32940 (4-08)
LG500
FREE STANDING GAS FRYER
OVERALL WORKING TANK FRY COMP. APPROX.
MODEL WIDTH DEPTH HEIGHT HEIGHT SIZE BTU/HR. CAPACITY SHP.WT.
LG500 21" 30
1
/ 4 "47
1
/ 8 "36
1
/ 4 "19
1
/ 2 " x 14" 150,000 65 - 70 lbs. 275 lbs./125 kg
IMPORTANT
1. A combination valve with pressure regulator is provided with
this unit.
Natural Gas 4.0" (102 mm) W.C.
Propane Gas 10.0" (279 mm) W.C.
2. An adequate ventilation system is required for Commercial
Cooking Equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269. When writing refer to NFPA No. 96.
3. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
4. All models require a 16" (407 mm) minimum clearance to
adjacent open top burner units.
5. This appliance is manufactured for commercial installation
only and is not intended for home use.
SERVICE CONNECTIONS:
P1 1/2" (13 mm) rear gas connection (single units).
