Vulcan-Hart GHCB34S User manual

Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
0
8
7
2
A
1
0
0
9
O
S
I
.
o
C
t
r
a
H
-
n
a
c
l
u
V
F-32338 (2-05)
GHCB SERIES
HEAVY DUTY GAS CHAR-BROILER
WITH CABINET BASE
S
E
I
R
E
S
B
C
H
G
:
S
L
E
D
O
Me
s
a
B
t
e
n
i
b
a
C
h
t
i
w
r
e
l
i
o
r
B
-
r
a
h
C
s
a
G
y
t
u
D
y
v
a
e
H
GHCB34S 34" wide char-broiler, 96,000 BTU/hr.
STANDARD FEATURES
Stainless steel body and 6" adjustable legs.
11/4" diameter front gas manifold.
Heavy cast iron char-radiants and broiler grates.
55/16" wide grates are reversible for "level" broiling or self
cleaning. Cast-in pitched grease trough in each grate blade
provides fat run-o and controls are-ups.
One 16,000 BTU/hr. burner for each broiling grate.
Three manual control valves.
Pilot ignition system.
Underburner baing system reects heat upwards creating a
cool zone beneath the burners.
Large capacity grease collector.
One year limited parts and labor warranty.
OPTIONS
Stainless steel nishing back panel.
Common front top ledge up to 68" wide. (Not for use on griddle
tops, spreader plates and deep fat fryers.)
Cap and cover manifold end(s).
15/8" stainless steel toe base - 315/8" working height.
Set of four 5" diameter casters, two locking.
Stainless steel dolly frame with casters, up to 102" wide.
Second year extended limited parts and labor warranty.
ACCESSORIES
17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
23" high stainless steel single deck high shelf. (Common high
shelves available up to 72" wide.)
35"highstainlesssteel doubledeck highshelf. (Commonhigh
shelves available up to 72" wide.)
Round rod grate assembly.
Banking kit.
Grate scraper.
Grate lifter.
Gas pressure regulator (specify size and type of gas).
Flexible gas hose with quick disconnect and restraining de-
vice. Consult price book for available sizes.
SPECIFICATIONS
Heavy duty gas char-broiler with cabinet base, _____" wide, Vulcan-
-Hart Model No. ___. Stainless steel body and 6" adjustable legs.
11/4 " front gas manifold. Heavy cast iron char-radiants and
broiler grates. 5 5/16
" wide grates are reversible for “level” broiling
or self cleaning. Cast-in pitched grease trough in each grate
blade provides fat run-o and controls are-ups. One
16,000 BTU/hr. burner for each broiling grate, _______ BTU/hr.
total input. Three manual control valves. Pilot ignition system.
Underburner baing system reects heat upwards creating a
cool zone beneath the burners. Large capacity grease collector.
Exterior dimensions: ____"w x 39 1/8"d x 36" working height on
6" legs.
CSA design certied. NSF listed.
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
GHCB34S

Printed On Recycled Paper
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
F-32338 (05-06)
GHCB SERIES
HEAVY DUTY GAS CHAR-BROILER
WITH CABINET BASE
IMPORTANT
1. A gas pressure regulator suitable for battery or single unit
application must be furnished and installed. Natural gas 6.0"
W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cookingequipment.Informationmaybe obtainedinwritingto
theNational FireProtection Association,Batterymarch Park,
Quincy, MA 02269. When writing refer to NFPA No. 96.
3. These units are manufactured for installation in accordance
with ANSZ223.1a (latest edition), National Fuel Gas Code.
CopiesmaybeobtainedfromtheAmericanGasAssociation,
1515 Wilson Blvd., Arlington, VA 22209.
4. Clearances: Do not install near combustible surfaces.
5. Abackguardisrecommended tokeepheatandgreaseladen
air from damaging a kitchen wall. Please refer to spec sheet
F31537.
6. This appliance is manufactured for commercial installation
only and is not intended for home use.
S15BCHGledoMS43BCHGledoM
Model
GHCB34S 96,000 6 34" (864) 39 1/8" (994) 36" (914)
Dimensions in parentheis in millimeters.
Total BTU No. Burners Width Depth Wkg. Height Appx. Shp. Wt.
450 lbd./203kg
SIDE VIEW - GHCB SERIES
