Vynco E1V2 User manual

E1V2 EV Charger
Installation Manual
WWW.VYNCO.CO.NZ

3
WWW.VYNCO.CO.NZ
CONTENTS PAGE
Carton Contents 4
Mounting Instructions 4
Installation Safety Precautions 5
Wiring Instructions 6
Electrical Connections 7
Commissioning 8
Technical Specications 9
Servicing and Replacement Parts / Warranty 10
TABLE OF CONTENTS

WWW.VYNCO.CO.NZ
4
The following parts should be inside the carton:
• E1V2 charger
• Black metal mounting plate
• Installation manual
• User operating manual
• Installation screws
If any of the parts are missing or damaged contact your supplier or Vynco for assistance
before installing the charger.
CARTON CONTENTS
Remove 1 screw from each side
Remove 1 screw from the bottom
• Select a suitable mounting position on a wall.
The position must be at least 800mm above the oor or
ground and 300mm from any wall or corner. Ensure the
mounting plate is level – use a spirit level on the top face.
• Using the two mounting holes in the centre line of the plate,
screw the black mounting plate to the wall using suitable
mounting screws.
• Ensure the mounting plate is screwed securely into timber
a wall stud or concrete.
To mount the E1V2 Electric Vehicle Charger on a wall:
• Remove the black mounting plate from the charger.
MOUNTING INSTRUCTIONS

5
WWW.VYNCO.CO.NZ
INSTALLATION SAFETY PRECAUTIONS
• This electric vehicle charger is designed to be installed in both indoor and outdoor
areas. Avoid areas exposed to the extremes of weather.
• Do not install this charger where it may get damaged from vehicles, bikes, machinery
or other moving objects.
• Ensure there is adequate clearance around the charger for safe operation.

WWW.VYNCO.CO.NZ
6
WIRING INSTRUCTIONS
Caution:
This product must be installed and wired according to the Worksafe Electric Vehicle Charging
Safety Guidelines – available at www.worksafe.govt.nz. All electrical connections are to be
carried out by a New Zealand Registered Electrician.
This EV charger must be permanently connected to a power supply and be supplied from
a dedicated nal sub-circuit.
The nal sub-circuit and EV charger must be protected by a suitable MCB and RCCB (Type B).
This EV charger requires a Single Phase 32A Supply - (Phase, Neutral and Earth).
Vynco recommends that this EV charger is protected by a Type B RCCB tted at the switchboard.
Wiring:
• Run the cabling to the EV Charger position:
• On the EV charger remove the 6 screws holding
on the back plate.
Caution – Do not lose the screws as they
are required to maintain the IP rating.
• Incoming supply must enter the charger either:
1. Through the back entry gland
2. Through the surface mount gland
Back Wiring Run the cabling through the hole in the mounting plate into the wall
cavity.
Surface Wiring Run the cabling into the bottom of the EV charger. Only use the left
hand gland (viewed from front).

7
WWW.VYNCO.CO.NZ
ELECTRICAL CONNECTIONS
This charger requires a Single Phase 32A, Phase, Neutral and Earth supply.
N = Neutral (Blue or Black).
L1 = Phase (Brown or Red).
PE = Earth (Green/Yellow).
If using the cable gland ensure the cable clamp adequately secures the incoming supply.
Do not remove any other screws or try to access the internal components.
No user servicable parts are contained inside the charger.
• Replace the cover after wiring and secure with the 6 cover plate screws.
• Fit the charger back on the wall plate and replace the 3 mounting screws.

WWW.VYNCO.CO.NZ
8
COMMISSIONING
Caution:
After installation the installer is required to ensure the EV charger functions and is safe to use.
• Ensure that the installation complies with the requirements listed in the WorkSafe
New Zealand Electric Vehicle Charging Safety Guidelines.
• Verify that the RCD is correct for the installation – normally Type B 30mA.
All Type B RCCBs have the following symbols on them.
• Verify that the overcurrent protection device is suitable for Single Phase - 32A.
• Verify that EV charger is in an area accessible to the electric vehicle for charging and
it is minimum 800mm off the oor.
• Verify that there is an isolator located close to the EV charger and labelled.
• This EV charger must be tested to ensure that it operates.
• Check if the charger functions by charging an Electric Vehicle or use a specialised EV tester.
• Check if the earth monitoring system functions and turns the charger OFF if there is an
Earth fault.
• Test the Type B RCCB using a RCD tester set up for testing a Type B RCD.
The SDoC for this product is available from www.vynco.co.nz
Note: Commercial Installations may require that the EV charger is tested and tagged every
12 months.

WWW.VYNCO.CO.NZ
9
TECHNICAL SPECIFICATIONS - E1V2
Electrical
Ratings
Rated Input Voltage 230V a.c. +- 10% - Single Phase
Frequency 50Hz
Maximum Power 7.4kW
Rated Current 32A maximum
(permanent connection)
Standby Power <6W
Electrical
Protection
RCCB Protection None supplied – Type B RCCB
required to be tted at the
switchboard.
RCCB - minimum 32A – 2 Pole.
Additional Internal Protection Under/Over Voltage, Short Circuit,
Under/Over Temperature,
Phase Protection
Equipment Protection Class Class 1
Environmental Ratings
Suitable For Use Indoors or Outdoors.
Restricted access location
Protection Rating IP54
Working Temperature Range -30°C to +55°C
Working Humidity 5% to 95% without condensation
Maximum Elevation <2000 Metres
Average Mean Time Before Failure
(MTBF)
100,000 operations
Overall Dimensions 211mm x 345mm x 122mm
(L x W x D)
Installation Surface, wall or post mount
(post not provided)
Weight < 4.0kgs
Operational Ratings
Activation Method Plug in and charging starts
automatically after 20 seconds
Emergency Disconnection Emergency Stop Button
LED Status Indication Blue – Power Available
Green Flashing – Charging
Red Flashing – Fault
Charging Method Mode 3
Compliance / Instructions
Electrical Standards Compliance IEC 61851-1:2017,
IEC 61851-23 (Mode 3)
Supplier Declaration of Conformity
(SDoC) / Instructions
Available from - www.vynco.co.nz
Installation and Operating Instructions available from www.vynco.co.nz

10
WWW.VYNCO.CO.NZ
This product is covered by the standard 3 year Vynco Warranty - proof of purchase is required.
Please contact Vynco for details of returns procedure.
NOTE: This product contains NO user serviceable parts.
WARRANTY
All contents and diagrams contained in this manual are copyrighted and are not to be reproduced in
any form without written permission of Vynco Industries Ltd.
SERVICING AND REPLACEMENT PARTS
Servicing:
The E1V2 Electric Vehicle Charger does not contain any user serviceable parts.
Replacement Parts:
Only Vynco supplied replacement parts can be used to repair this electric vehicle charger.
Contact Vynco for assistance.

Christchurch Ofce
388-396 Tuam Street, Phillipstown, Christchurch 8011
PO Box 9022, Tower Junction, Christchurch 8149
P ([phone] F ([phone]
E [email protected]
Auckland Ofce
9 Levene Place, Mt Wellington, Auckland 1061
PO Box 12 249, Penrose, Auckland 1642
P ([phone] F ([phone]
E [email protected]
INSV0043 V1
