Vynco VAF16 User manual

INSTALLATION INSTRUCTIONS
AUCKLAND
9 Levene Place, Mount Wellington
PO Box 12 249, Penrose, Auckland 1061
New Zealand
P [phone] F [phone]
VYNCO INDUSTRIES (NZ) LIMITED
CHRISTCHURCH
388 Tuam Street, Phillipstown, Christchurch, 8011
PO Box 9022, Tower Junction, Christchurch 8149
New Zealand
P [phone] F [phone]
E [email protected]
VYNCO.CO.NZ
VAF16 - IN-LINE AXIAL FAN
INSV0016
SPECIFICATIONS
Input Voltage 230 - 240V AC, 50Hz
Power 20W
No. of Blades 9
Duct Size 150mm
IP Rating IP44
Operating Temperature -10 to 70°C
Air Pressure 125Pa
SAFETY
Make sure the power is switched off before installing
the fan.
Don’t use the fan if the power cord or plug
is damaged.
Return to the wholesaler for faulty product process
through electrician.
Don’t use the fan if it’s damaged, malfunctions or
is dropped. The fan is designed for indoor use only.
Don’t put any insulation around or over the fan.
For inline duct use, airow is ducted outside.
This xed appliance is not intended for use by
persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instructions concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
This product should be installed by a suitably
qualied person in accordance with Australian
and New Zealand wiring rules.
IP44
WARRANTY
This product is covered by the standard 5 Year Vynco
Warranty - proof of purchase is required. Please
contact Vynco for details of returns procedure.
NOTE: This product contains NO user serviceable parts.

INSTALLATION INSTRUCTIONS
VYNCO.CO.NZ
INSTALLATION PROCEDURE
STEP 1
The preferred method is to mount the fan base onto
a solid surface, in the roof space at least 2.3m above
the oor, by screwing it to the timber trusses. Use at
least No. 6 x 1/2 inch screws.
STEP 2
Keep the fan at least 50mm away from
surrounding structures.
STEP 3
Attach 150mm ducting onto each end of the fan
using duct tape.
STEP 4
Make sure the ducting is not impeding the fan blade.
The duct should be pulled tight and cut to length,
and connected to the internal grille and external
grille, otherwise the performance of the fan will
be affected.
STEP 5
Attach the fan to the mounted fan base. Ensure all
4 snap hooks are secured correctly. Plug the fan into
a power point.
182.0
Protect tabs
in packaging
Protect tabs
in packaging
301.0
Protect tabs in
packaging
175.0
A
DETAIL A
SCALE 1 : 2
REVISIONS
REVISION DATE
FINISH:
MATERIAL:
REVISION:
DESCRIPTION:
SHEET 1 OF 1
A3
SIZE
APPROVED BY:
PART No:
388 Tuam St
Christchurch
New Zealand
P: 03 379 9283
W: vynco.co.nz
UNLESS OTHERWISE STATED ALL DIMENSIONS ARE IN MILLIMETRES
ALL CRITICAL TOLERANCES SPECIFIED IN DRAWING
NON SPECIFIED TOLERANCES:
LINEAR: 0.0 ±0.5 0.00 ±0.1 ANGULAR: ±0.5°
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF VYNCO INDUSTRIES
(N.Z.) LTD. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION
OF VYNCO INDUSTRIES (N.Z.) LTD IS PROHIBITED.
DRAWN BY:
DRAWN DATE:
CHANGE BY:
CHANGE DATE:
APPROVED DATE:
- - - -
-
-
-
koopsq
9/20/2019
-
-
9/20/2019
koopsq
DRAWING NOT TO SCALE
110.0
208.0 OVERALL
175.0 OVERALL
153.6
296.0 OVERALL
172.0
311 3
2
4 5
Note:
Fan assembly including flexible cable and plug (ITEM NO. 4)
supplied by third party.
REVISIONS
REVISION DATE
-01 19-02-2019 First release
-02 19-06-2019 Prototype prerelease to H&G
-03 29-07-2019 Change fan design to suit H&G EC fan
-04 29-07-2019 Added note for supplier.
A 09-09-2019 PRODUCTION RELEASE
SPECIFICATIONS
VOLTAGE [VAC at 50/60 Hz] 220-240
POWER [W] ~18
CURRENT [A] 0.14
AIRFLOW @ 0 Pa [m3/h] >400
RPM TBC
DUCT SIZE [mm] 150
CLIMATE CLASS T
NOISE LEVEL @ 3m [dBA] <38 dBA
IP (INSTALLED) IP44
INTERNAL TERMAL
PROTECTION
MANUAL RESET
BEARING TYPE
626Z Deep groove
ball bearing
ITEM NO.
PartNo DESCRIPTION QTY.
1 24336-104 F16 SPIGOT 2
2 24336-003 F16 Mounting Plate 1
3
-
M4 x 16 PAN HEAD SCREW
CROSS
8
4 - 17251 EC MOTOR 1
5454
M4 NUT 8
FINISH:
MATERIAL:
REVISION:
DESCRIPTION:
SHEET 1 OF 1
A3
SIZE
APPROVED BY:
PART No:
388 Tuam St
Christchurch
New Zealand
P: 03 379 9283
W: vynco.co.nz
UNLESS OTHERWISE STATED ALL DIMENSIONS ARE IN MILLIMETRES
ALL CRITICAL TOLERANCES SPECIFIED IN DRAWING
NON SPECIFIED TOLERANCES:
LINEAR: 0.0 ±0.5 0.00 ±0.1 ANGULAR: ±0.5°
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF VYNCO INDUSTRIES
(N.Z.) LTD. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION
OF VYNCO INDUSTRIES (N.Z.) LTD IS PROHIBITED.
DRAWN BY:
DRAWN DATE:
CHANGE BY:
CHANGE DATE:
APPROVED DATE:
A - DRAFT 24336-000
F16 AXIAL FAN ASSY
koopsq
9/9/2019
K
09/09/2019
2/19/2019
koopsq
DRAWING NOT TO SCALE
VAF16 - IN-LINE AXIAL FAN
