Operating manual
Wärtsilä
JOVYTEC PMS
2002K / 3002K

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 2 -
Index
Date
Name
Issue
0
2013-04-03
A. Heller
Original
1
2014-11-07
Chr. Fechteler
14 / 608
2
2015-11-12
Chr. Fechteler
15 / 609
3
2015-12-04
Chr. Fechteler
15 / 651
4
5
6
7
8
9
10

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 3 -
N O T E S !
Notes concerning this operating manual
Thank you for deciding to purchase this uninterrupted power supply units (UPS) out of the series JOVYATLAS JOVYTEC P. It
represents reliable protection for the attached consumers.
Please read through this manual very carefully
This manual contains regulations covering safety, installation and operating methods which will help you guarantee to obtain the full
performance und operational readiness which the UPS can offer.
Put this manual in a place of safe keeping
It contains important regulations for safe use of this UPS and for reaching manufacturer services if, for some reason, correct operation
of the UPS is in doubt.
Keep or reuse the packaging material
The packaging material for the UPS was designed with great care to protect its contents against damage during transport. This material
is also useful if you ever have to send the UPS back for checking. Damage which occurs during transport is not covered by the warranty
provisions.
Duty to instruct persons
This operating manual is to be read through carefully before assembly and first use of the UPS by persons who will be working with or
on the UPS.
This operating manual is an integral part of the UPS. The operator of this device is required to make this operating manual available in
an unlimited fashion to every group of persons who transport the UPS, commission it, maintain it or who do any other kind of work on
this device.
Validity
This operating manual is in line with state-of-the-art UPS technology at its time of publishing. The contents are not part of the contract
but simply serve as a source of information.
Wärtsilä JOVYATLAS EUROATLAS GmbH reserves the right to make any necessary changes to the contents and technology
described in this operating manual without having to make an announcement to this effect. We cannot be held responsible for any errors
or improper information in this operating manual since there is no duty upon the company to update this operating manual on an
ongoing basis.
Loss of warranty
Our deliveries and services rendered are subject to the General Delivery Conditions for Products of the Electrical Industry as well as
our General Sales Conditions. We reserve full rights to make any changes to this operating manual, in particular to technical data,
operation, dimensions and weights. We request that you make any claims concerning delivered goods within eight days after arrival of
the goods together with the packing slip. Complaints made later than this cannot be considered.
Wärtsilä JOVYATLAS EUROATLAS GmbH will annul all duties such as promises to offer a warranty period, service contracts etc.
without warning if any spare parts other than original parts are used for maintenance and repair purposes.
Handling
This operating manual for the UPS is constructed in such a way that all work required for commissioning, maintenance and repair can
be conducted by appropriate skilled personnel.
The Service Hotline
There is further information available under Chapter 8 “Service information“ for questions about the UPS unit, about the operating
manual, service etc.
Copyright
Any passing on, duplication and/or transfer by means of electronic or mechanical means, also extracts thereof, of this operating manual,
requires express prior written permission.
Copyright Wärtsilä JOVYATLAS EUROATLAS GmbH. All rights reserved.

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 4 -
TABLE OF CONTENTS
Chapter Contents Page
1. GENERAL NOTES 6
2. DESCRIPTION OF THE SYSTEM 6
3. GENERAL DESCRIPTION OF THE FUNCTION 7
4. TECHNICAL DATA 9
5. DIMENSIONS AND VIEWS 12
5.1 FRONT VIEW 13
5.2 REAR VIEW (230V – VERSION) 14
5.2 REAR VIEW (115V – VERSION) 14
5.2 POWERPACK FRONT AND REAR VIEW 15
5.3 INSTALLATION 16
6. ELECTRICAL CONNECTION 17
6.2 COMMISSIONING THE UPS UNIT 18
6.3 SHUTTING-DOWN THE UPS UNIT 18
7. OPERATING AND INDICATING ELEMENTS 19
7.1 LED AND FUNCTION KEYS 19
7.2 PARAMETERS 20
7.3 CONFIGURATION 21
7.4 TABLE OF THE ADJUSTABLE PARAMETERS 21
7.5 MANUAL TESTING 22
7.6 OFFLINE MODE 22
7.7 FREE RUNNING MODE 22
7.7.1 FREE RUNNING ON 22
7.7.2 FREE RUNNING OFF 22
7.8 BYPASS TOLERANCE / BYPASS-ACTIVATION/DEACTIVATION 23
7.8.1 FREE RUNNING ON, BYPASS DEACTIVATED 23
7.8.2 FREE RUNNING ON, BYPASS ACTIVATED 23

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 5 -
7.8.3 GENERATOR MODE 24
7.9 ERROR MESSAGES AND THEIR REMOVAL 24
7.9.1 OPTICAL AND ACOUSTICAL ERROR MESSAGES 24
8. SERVICE INFORMATION 25
9. REMOTE MONITORING 25
9.1 CONNECTING THE UPS TO THE COMPUTER 25
9.2 ASSIGNMENT OF THE RS232 INTERFACE 25
9.3 USB PORT (OPTIONAL) 26
10. SPECIAL EQUIPMENT 26
10.1 ELECTRONIC STOP FUNCTION 26
11. MANUAL BYPASS (OPTIONAL) 26
12. POTENTIAL FREE SIGNALS FROM THE RELAY CARD (OPTIONAL) 27
12.1 DESCRIPTION OF THE RELAY CARD 27
13. POWERPACK S 1002 29
13.1 EXTENDED BACKUP TIMES 29
13.2 BATTERY OPERATION 29
13.3 SERVICE LIFE OF BATTERIES 30
13.4 INSTRUCTIONS FOR USING THE BATTERIES 30
14. REPLACING AN INTERNAL UPS BATTERY 31
15. NOTES 32

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 6 -
N O T E!
The UPS should be attached to the mains supply and switched on at the latest 4
weeks after receipt in order to prevent the battery discharging itself.
P L E A S E N O T E!
In order to exclude the possibility of overloading or constant switching over to bypass
due to consumer generated non-sinusoidal current peaks, no devices such as laser
printers, fax machines as well as devices operating with a similar technology should be
connected to the UPS.
In cases where it is essential that such devices be operated then a UPS must be
selected whose capacity can match the maximum possible current peaks.
Devices with power reduction due to half wave power consumption, (e.g. coffee
machines, hair dryers) can lead to immediate destruction of the power-output stage. The
battery is not galvanically isolated from the mains so occurrence of a mains voltage at
the battery terminals is possible! The UPS unit does not have an output transformer and
is therefore not galvanically isolated from the mains!!
P L E A S E N O T E!
The batteries used are just designed for the required backup time to supply
the nominal load of the UPS. Operation of the UPS unit in free running mode
for a longer period of time on battery can damage the batteries. This effect is
due to the nature of the battery since for a longer discharge period the final
discharging voltage is not reached.
1. General notes
The device may only be opened by trained specialists.
The system is to be connected up and earthed according to VDE regulations. Provisions of the local energy
– supply company must be observed.
The ventilation slits on the front and rear sides must not be covered and a distance from the wall of at least
100 mm is essential.
The UPS unit is built according to Protection Class IP 21 and is designed for installation in heated internal
spaces (at 20°C). A lower operating temperature lowers the bridging time.
No devices with a connecting cable in excess of 10 metres in length should be connected to the UPS. This
measure serves to ensure observance of the EMC standard.
No alterations should be made to the UPS unit. The warranty will expire in cases of inappropriate physical
interventions.
2. Description of the System
Power supply devices of the model range WÄRTSILÄ JOVYTEC PMS are particularly suited for supplying
critical loads in industry and the office such as personal computer, computer-controlled devices, PLCs and
similar equipment. The output voltage is sinusoidal. In normal cases the attached consumers are supplied
with power from the installed rectifier and installed inverter from the mains power supply network (online
operation). Any disturbances in the mains such as voltage peaks, voltage drops, harmonic distortions or
noises etc. are filtered out. The installed battery is constantly being charged up by means of a charging
rectifier with a charge preservation charging stage which is gentle on the batteries.

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 7 -
P L E A S E N O T E !
The output of the UPS unit also carries a voltage in the case of a power failure!
This is why the installation engineer must mark the outputs and power
sockets on the UPS unit clearly according to EN 62040.
Input
Battery
Rectifier Inverter
Ouput
Manual Bypass
Input
Battery
Rectifier Inverter
Output
Manual Bypass
3. General description of the function
Normal operation
During normal operation the battery and the inverter are supplied with power via a rectifier (online operation).
The change-over from alternating voltage to direct voltage and back to alternating voltage again is achieved
by a sinusoid output voltage with a low distortion factor. The direct voltage is also needed for charging the
battery. The inverter supplies the attached consumers.
Figure 1: Block diagram “Normal operation“
Power failure
In the case of a power failure, the energy needed by the inverter is taken from the battery. At the output the
voltage from the inverter is still available.
Figure 2: Block diagram “Power failure“

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 8 -
Input
Battery
Rectifier Inverter
Output
Manual Bypass
Input
Battery
Rectifier Inveter
Output
P L E A S E N O T E!
An operating fault can lead to total loss of power supply to the attached power
consumer loads! A power failure for a switched in manual bypass will lead to
crashing of the power consumer loads!
Fault in the inverter or an overload (bypass operation)
In the case of a fault occurring in the inverter or an overload, a switch-over device switches the load back to
the mains. This means that, in the case of a power failure, the connected consumers will no longer be
supplied with power.
Figure 3: Block diagram “Fault in the inverter“
Manual bypass (service bypass)
If there is a fault in the UPS unit and service work must be undertaken, the UPS unit is fitted with an internal
bypass for that purpose. When actuating the manual bypass, the load is directly supplied from the mains.
This means that, in the case of a power failure, the connected consumers will no longer be supplied with
power. When using the manual bypass it is essential to observe the chapter “UPS internal manual bypass”.
Other procedures could lead to destruction of the UPS unit or crashing of the power consumer loads.
Figure 4: Block diagram “Manual bypass“

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 9 -
4. Technical data
WÄRTSILÄ JOVYTEC PMS 2002K
Output
cos  0,7 ind.
2000VA / 1400W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current
7,3A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power factor
0.98
External fuse protection
D01/16A
Battery
(installed in the
battery rack
POWERPACK
S 1002)
Direct current link voltage
72 V
Backup time
(1 Battery unit)
7min. @ 100% load
9min. @ 80% load
17min. @ 50% load
Backup time
(2 Battery units)
20min. @ 100% load
25min. @ 80% load
45min. @ 50% load
Type
Maintenance-free, VRLA batteries
Charging time
< 8 hours for a 90% recharge
Output
Voltage
230V standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by means of internal control-logic of UPS
Power factor
cos 0,7 ind.
Phase
Single phase
Distortion factor
< 3% for a linear load
Overload behaviour
100 to 125% for 60 seconds
125 – 150% for 10 seconds
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operating mode
Load transfer
characteristic
Power failure
0 ms
Overload switching
Automatic transfer of the load
Noise level
At an approx distance of
1 metre
< 40dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non-condensing
Storage at …
20°C (recommended)
-20 .... +50°C (without battery)
Interfaces
RS 232 interface
Optional:
USB interface
Relay card
AS/400 - adapter
SNMP - adapter
Supports power management and diagnosis such as BATTERY LOW, UPS
ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS rack
Width
19“
Depth
425 mm
Height
2RU
Dimensions
battery rack
Width
19“
Depth
425 mm
Height
2RU
Weight of UPS
UPS
approx. 10 kg
Weight of UPS
incl. battery
UPS incl. 1 Batteryunit
about 22.5 kg
Scope of delivery
Hardware/software
UPS unit WÄRTSILÄ JOVYTEC PMS 2002K
Battery rack POWERPACK S 1002 (according to backup time: 1-2)
Manual BAX 4837E
Interface cable
Software UPSMON (No support)

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 10 -
WÄRTSILÄ JOVYTEC PMS 3002K (115V – Version)
Output
cos  0,7 ind.
3000VA / 2100W
Network supply
Voltage
115V
Input voltage ranges
80V - 144V (0-100% load)
70 - 79V (0-70% load)
60 - 69V (0-40% load)
Current
20A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power factor
0.98
External fuse protection
D02/25A
Battery
(installed in the
battery rack
POWERPACK
S 1002)
Direct current link voltage
72 V
Backup time
(1 Battery unit)
5min. @ 100% load
6min. @ 80% load
12min. @ 50% load
Backup time
(2 Battery units)
15min. @ 100% load
18min. @ 80% load
32min. @ 50% load
Backup time
(3 Battery units)
25min. @ 100% load
28min. @ 80% load
58min. @ 50% load
Type
Maintenance-free, VRLA batteries
Charging time
< 8 hours for a 90% recharge
Output
Voltage
115V standard (100V / 110V / 115V / 120V / 127V selectable at the panel)
Frequency
Automatic adjustment by means of internal control-logic of UPS
Power factor
cos 0,7 ind.
Phase
Single phase
Distortion factor
< 3% for a linear load
Overload behaviour
100 to 125% for 60 seconds
125 – 150% for 10 seconds
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 95% according to the operating mode
Load transfer
characteristic
Power failure
0 ms
Overload switching
Automatic transfer of the load
Noise level
At an approx distance of
1 metre
< 50dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non-condensing
Storage at …
20°C (recommended)
-20 .... +50°C (without battery)
Interfaces
RS 232 interface
Optional:
USB interface
Relay card
AS/400 - adapter
SNMP - adapter
Supports power management and diagnosis such as BATTERY LOW, UPS
ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS rack
Width
19“
Depth
425 mm
Height
2RU (89mm)
Dimensions
battery rack
Width
19“
Depth
425 mm
Height
2RU (89mm)
Weight of UPS
UPS
approx. 11 kg
Weight of UPS
incl. battery
UPS incl. 1 Batteryunit
about 22.5 kg
Scope of delivery
Hardware/software
UPS unit WÄRTSILÄ JOVYTEC PMS 3002K
Battery rack POWERPACK S 1002 (according to backup time: 1-3)
Manual BAX 4837E
Interface cable
Software UPSMON (No support)

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 11 -
WÄRTSILÄ JOVYTEC PMS 3002K (230V – Version)
Output
cos  0,7 ind.
3000VA / 2100W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current
11A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power factor
0.98
External fuse protection
D01/16A
Battery
(installed in the
battery rack
POWERPACK
S 1002)
Direct current link voltage
72 V
Backup time
(1 Battery unit)
5min. @ 100% load
6min. @ 80% load
12min. @ 50% load
Backup time
(2 Battery units)
15min. @ 100% load
18min. @ 80% load
32min. @ 50% load
Backup time
(3 Battery units)
25min. @ 100% load
28min. @ 80% load
58min. @ 50% load
Type
Maintenance-free, VRLA batteries
Charging time
< 8 hours for a 90% recharge
Output
Voltage
230V standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by means of internal control-logic of UPS
Power factor
cos 0,7 ind.
Phase
Single phase
Distortion factor
< 3% for a linear load
Overload behaviour
100 to 125% for 60 seconds
125 – 150% for 10 seconds
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operating mode
Load transfer
characteristic
Power failure
0 ms
Overload switching
Automatic transfer of the load
Noise level
At an approx distance of
1 metre
< 53dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non-condensing
Storage at …
20°C (recommended)
-20 .... +50°C (without battery)
Interfaces
RS 232 interface
Optional:
USB interface
Relay card
AS/400 - adapter
SNMP - adapter
Supports power management and diagnosis such as BATTERY LOW, UPS
ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS rack
Width
19“
Depth
425 mm
Height
2RU
Dimensions
battery rack
Width
19“
Depth
425 mm
Height
2RU
Weight of UPS
UPS
approx. 11 kg
Weight of UPS
incl. battery
UPS incl. 1 Batteryunit
about 22.5 kg
Scope of delivery
Hardware/software
UPS unit WÄRTSILÄ JOVYTEC PMS 3002K
Battery rack POWERPACK S 1002 (according to backup time: 1-3)
Manual BAX 4837E
Interface cable
Software UPSMON (No support)

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 12 -
2He
19“
428
425
5. Dimensions and views
Picture 1: Front view
Picture 2: Top view

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 13 -
5.1 Front view
1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
Picture 7: Front view
Position
Designation
1.
Mounting angle left
2.
Grip left
3.
Ventilation inlet
4.
Removable display cover (battery change)
5.
Display indicator
6.
Mounting angle right
7.
Grip right
8.
LED operation, lights green if the UPS is switched on
9.
LED operation, lights green when in UPS and bypass mode and signalises that the output
voltage is present.
10.
LED battery operation, lights yellow if there is a power failure
11.
LED battery operation, lights yellow if the UPS is in bypass mode
12.
LED – UPS fault, lights red in case of an internal fault
13.
FUNC key for selecting the parameters
14.
ENTER key for querying set parameters
15.
ON/OFF button for switching the UPS unit on and off

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 14 -
5.2 Rear view (230V – Version)
1 2 3 4 5 6
7 8 9 10 11
Picture 8: Rear view WÄRTSILÄ JOVYTEC PMS 2002K/3002K (230V)
Position
Designation
1.
Cover for optional interface (Relay-board or SNMP)
2.
RS 232 – Interface
3.
Cover for optional USB-Interface
4.
Fan
5.
Battery jack (external battery pack)l)
6.
UPS - output
7.
UPS – Input (C13-plug)
8.
Input fuse 15A (2002K) / Input-fuse-automat (3002k)
9.
Electronic-Stop (for external contact)
10.
UPS – outputsockets (IEC)
11.
Ouput fuse 15A
5.2 Rear view (115V – Version)
Picture 9: Rear view WÄRTSILÄ JOVYTEC PMS 3002K (115V)
Option
L1 N PE
L1 N PE

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 15 -
5.2 Powerpack Front and Rear View
Picture 10: Front view
1 2
Picture 11: Rear view
Position
Designation
1.
Connecting jack for an optional additional battery pack
2.
Battery cable for UPS

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 16 -
5.3 Installation
For installation the two supplied angles are to be mounted on both sides as shown on the sketch

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 17 -
6. Electrical connection
The UPS unit in the series POWERMASTER is simply connected by means of the supplied input cable and
the input socket.
One proceeds as follows:
1. Plug the mains input cable provided into the suitable power socket.
2. Attach the critical loads by means of the output sockets.
3. Connect up the battery pack supplied by means of the the battery connection.
4. All connecting up work is now complete.
P L E A S E N O T E!
Only trained personnel are allowed to work on the UPS unit.
Observe all corresponding safety regulations.
Marking of cables is to be according to DIN EN 60445!
When connecting to the UPS unit, ensure use of an adequately sized protective-
conductor connection!
P L E A S E N O T E!
When working on the batteries it is possible for dangerous situations to arise
due to a high DC voltage and high short-circuit currents.
This work on the device must only be conducted when accompanied by use of
suitable protective measures such as insulated tools, eye and hand protection
etc.

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 18 -
6.2 Commissioning the UPS unit
Take note: The unit fans run as soon as the input voltage is applied!!
The UPS unit can now be started by pressing the ON/OFF button in the front panel for 3 seconds; a
message appears in the display: Switching on procedure. The UPS unit now starts a self-test routine
during which its internal functions are tested and the mains synchronisation and the inverter are started. The
message “Battery mode“ is shown in the display during the self-test and the LED´s ON for UPS ON and
ON-LINE output voltage light up. The message “Operation“ appears in the display. The loads to be
supplied can now be switched on.
Please contact us if anything different happens.
6.3 Shutting-down the UPS unit
When shutting down the unit please proceed as follows:
- Switch off all consumers
- Press the ON/OFF button in the front panel for 3 seconds. An acoustic sound (bleep) is emitted while
pressing the ON/OFF button and the message: Switching off soon appears in the display, and then
the message “UPS OFF“. The UPS unit is now shut-down. Please note: The internal fans of the UPS
will continue to run as long as the input voltage is applied.
P L E A S E N OT E!
The unit should be started over the input mains. If the input mains is not available for a short
time then it is also possible to start the unit over the external battery. It is a basic prerequisite for
this operating mode that the UPS unit was one time operated over the energy supplier’s mains
network. Please note that when starting over the external battery, the maximum time the output
voltage is available to you is the autonomy time. The UPS unit will also start with the previously
stored parameters, i. e. if the mains previously had 50 Hz then the UPS will also generate 50 Hz
on the output side.
P L E A S E N OT E!
The DC-voltage specification on the UPS must match to the voltage specification on the battery
cabinet (DIRECT CURRENT LINK VOLTAGE) otherwise there is danger of destroying internal
components of the UPS or destruction of the battery.

Wärtsilä JOVYTEC PMS 2002K / 3002K BAX 4837E - 19 -
7. Operating and indicating elements
7.1 LED and Function Keys
1. LC-Display
The LC-display informs about the operating modes, menu points and parameters.
2. ON/OFF button
The UPS unit can be switched on and off using the ON/OFF button. The formalism is as follows:
The UPS unit is switched on by pressing the ON/OFF button for about 3 seconds.
The UPS unit is switched off by pressing the ON/OFF button for about 3 seconds.
3. ENTER key
The ENTER key can be used to query the parameters which have been set for the UPS unit. Pressing the
ENTER key for 2 seconds on a running UPS unit will automatically cause the first parameter to be displayed for
10 seconds. Pressing the ENTER button again allows one to manoeuvre through the parameters. If the next
parameter is not selected within 10 seconds then the UPS unit indicates its condition again.
4. FUNC key
The FUNC key can be used to set a parameter such as the output voltage etc.
The formalism is as follows:
Press the FUNC key on a running UPS unit for 2 seconds to start the menu for the UPS unit parameters.
Pressing of the ENTER button selects the parameter to be altered. Once the parameter to be altered is reached
then the desired value can be selected by pressing the FUNC button. Pressing the ENTER button a second
time accepts the desired parameter and stores it.
The function and condition in which the UPS unit currently finds itself is displayed over 5 LED´s in the
function panel.
The conditions are as follows:
5. ON Operation : This LED lights green in case the UPS is switched on
6. ON-LINE Operation : This LED lights green both in UPS mode and in
bypass mode, signalling output voltage available.
7. ON-BAT Battery operation : This LED lights yellow for battery operation
( Input power failure)
8. BYPASS BYPASS : This LED lights yellow indicating UPS-bypass mode
9. FAULT FAULT : This LED lights red in case of an internal error of the UPS,
and an accoustic signal is emitted. Press any key in the
function panel and the alarm will be switched off. The cause
of the alarm is shown in the display.
