WÄRTSILÄ JOVYTEC P Series User manual

BAX 3345
Operating Manual
Wärtsilä
JOVYTEC P
700VA –3kVA

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 2 -
Index
Date
Name
Revision
0
2014-06-20
Chr. Fechteler
14/375
1
2014-10-29
Chr. Fechteler
14/600
2
2017-08-14
D. Busboom
17/262
3
4
5
6
7
8
9
10

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 3 -
N O T E S !
Notes concerning this operating manual
Thank you for deciding to purchase this uninterrupted power supply units (UPS) out of the series JOVYTEC P. It represents reliable
protection for the attached consumers.
Please read through this manual very carefully
This manual contains regulations covering safety, installation and operating methods which will help you guarantee to obtain the full
performance und operational readiness which the UPS can offer.
Put this manual in a place of safe keeping
It contains important regulations for safe use of this UPS and for reaching manufacturer services if, for some reason, correct operation
of the UPS is in doubt.
Keep or reuse the packaging material
The packaging material for the UPS was designed with great care to protect its contents against damage during transport. This material
is also useful if you ever have to send the UPS back for checking. Damage which occurs during transport is not covered by the warranty
provisions.
Duty to instruct persons
This operating manual is to be read through carefully before assembly and first use of the UPS by persons who will be working with or
on the UPS.
This operating manual is an integral part of the UPS. The operator of this device is required to make this operating manual available in
an unlimited fashion to every group of persons who transport the UPS, commission it, maintain it or who do any other kind of work on
this device.
Validity
This operating manual is in line with state-of-the-art UPS technology at its time of publishing. The contents are not part of the contract
but simply serve as a source of information.
Wärtsilä JOVYATLAS EUROATLAS GmbH reserves the right to make any necessary changes to the contents and technology
described in this operating manual without having to make an announcement to this effect. We cannot be held responsible for any errors
or improper information in this operating manual since there is no duty upon the company to update this operating manual on an
ongoing basis.
Loss of warranty
Our deliveries and services rendered are subject to the General Delivery Conditions for Products of the Electrical Industry as well as
our General Sales Conditions. We reserve full rights to make any changes to this operating manual, in particular to technical data,
operation, dimensions and weights. We request that you make any claims concerning delivered goods within eight days after arrival of
the goods together with the packing slip. Complaints made later than this cannot be considered.
Wärtsilä JOVYATLAS EUROATLAS GmbH will annul all duties such as promises to offer a warranty period, service contracts etc.
without warning if any spare parts other than original parts are used for maintenance and repair purposes.
Handling
This operating manual for the UPS is constructed in such a way that all work required for commissioning, maintenance and repair can
be conducted by appropriate skilled personnel.
The Service Hotline
There is further information available under Chapter 8 “Service information“for questions about the UPS unit, about the operating
manual, service etc.
Copyright
Any passing on, duplication and/or transfer by means of electronic or mechanical means, also extracts thereof, of this operating manual,
requires express prior written permission.
Copyright Wärtsilä JOVYATLAS EUROATLAS GmbH. All rights reserved.

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 4 -
TABLE OF CONTENT
1. GENERAL NOTES 6
2. DESCRIPTION OF THE SYSTEM 6
3. GENERAL DESCRIPTION OF THE FUNCTION 7
4. TECHNICAL DATA 9
5. DIMENSIONS AND VIEWS 14
5.1 JOVYTEC P 700 –P 1500 14
5.2 REAR VIEW JOVYTEC P 700 –P 1000 15
5.3 REAR VIEW JOVYTEC P 1500 16
5.4 JOVYTEC P 2000 –P 3000 17
5.5 REAR VIEW JOVYTEC P 2000 –P 3000 17
6. ELECTRICAL CONNECTION 18
6.2 COMMISSIONING 20
6.3 UPS SHUT-DOWN 20
7. OPERATING AND INDICATING ELEMENTS 21
7.1 LED AND FUNCTION KEYS 21
7.2 PARAMETERS 22
7.3 CONFIGURATION 22
7.4 TABLE OF THE ADJUSTABLE PARAMETERS 23
7.5 AUTOMATIC/MANUAL BATTERY TEST 23
7.6 OFFLINE MODE 24
7.7 FREE RUNNING MODE 24
7.7.1 FREE RUNNING ON 24
7.7.2 FREE RUNNING OFF 24
7.7.3 SETTING THE BYPASS TOLERANCE + ACTIVATION/DEACTIVATION OF THE BYPASS 24
7.7.4 FREE RUNNING ON, BYPASS DEACTIVATED 24
7.7.5 FREE RUNNING ON, BYPASS ACTIVATED 25
7.7.6 GENERATOR MODE 26
7.8 ERROR MESSAGES AND THEIR REMOVAL 26
7.8.1 OPTICAL AND ACOUSTICAL ERROR MESSAGES 26
8. SERVICE INFORMATION 27
9. REMOTE MONITORING 27
9.1 CONNECTING THE UPS TO THE COMPUTER 27

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 5 -
9.2 ASSIGNMENT OF THE RS232 INTERFACE 27
9.3 USB PORT (OPTIONAL) 28
10. SPECIAL EQUIPMENT 28
10.1 ELECTRONIC STOP FUNCTION 28
11. MANUAL BYPASS (OPTIONAL) 28
12. RELAY CARD (OPTIONAL) 29
13.1 TECHNICAL DATA / AUTONOMY TIMES 31
13.2 VIEWS 32
13.2.1 BATTERY CABINET B10 - B12 32
13.2.2 BATTERY CABINET BM1 33
13.2.3 BATTERY CABINET BM2 33
13.2.4 BATTERY CABINET BM3 33
13.3 CONNECTION 34
13.3.1 BATTERY CABINETS B10/B11/B12 34
13.3.2 BATTERY CABINET BM1 –BM3 35
13.4 BATTERY OPERATION 36
13.5 SERVICE LIFE OF BATTERIES 36
13.6 INSTRUCTIONS FOR USING THE BATTERIES 36
14. REPLACING AN INTERNAL UPS BATTERY 37
15. NOTES 38

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 6 -
N O T E!
The UPS should be attached to the mains supply and switched on at the latest 4
weeks after receipt in order to prevent the battery discharging itself.
P L E A S E N O T E!
In order to exclude the possibility of overloading or constant switching over to bypass
due to consumer generated non-sinusoidal current peaks, no devices such as laser
printers, fax machines as well as devices operating with a similar technology should be
connected to the UPS.
In cases where it is essential that such devices be operated then a UPS must be
selected whose capacity can match the maximum possible current peaks.
Devices with power reduction due to half wave power consumption, (e.g. coffee
machines, hair dryers) can lead to immediate destruction of the power-output stage. The
battery is not galvanically isolated from the mains so occurrence of a mains voltage at
the battery terminals is possible! The UPS unit does not have an output transformer and
is therefore not galvanically isolated from the mains!!
P L E A S E N O T E!
The batteries used are just designed for the required bridging time to meet the
nominal load of the UPS. Operation of the UPS unit in free running mode for a
longer period of time on battery can damage the batteries. This effect is due to
the nature of the battery since for a longer discharge period the final
discharging voltage is not reached.
1. General notes
The device may only be opened by trained specialists.
The system is to be connected up and earthed according to VDE regulations. Provisions of the local energy
–supply company must be observed.
The ventilation slits on the front and rear sides must not be covered and a distance from the wall of at least
100 mm is essential.
The UPS unit is built according to Protection Class IP 21 and is designed for installation in heated internal
spaces (at 20°C). A lower operating temperature lowers the bridging time.
No devices with a connecting cable in excess of 10 metres in length should be connected to the UPS. This
measure serves to ensure observance of the EMC standard.
No alterations should be made to the UPS unit. The warranty will expire in cases of inappropriate physical
interventions.
2. Description of the System
Power supply devices of the model range JOVYTEC P are particularly suited for supplying important power
consumers in industry and the office such as personal computer, computer-controlled devices, PLCs and
similar equipment. The output voltage is sinusoidal. In normal cases the attached consumers are supplied
with power from the installed rectifier and installed inverter from the mains power supply network (online
operation). Any disturbances in the mains such as voltage peaks, voltage drops, harmonic distortions or
noises etc. are filtered out. The installed battery is constantly being charged up by means of a charging
rectifier with a charge preservation charging stage which is gentle on the batteries.

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 7 -
P L E A S E N O T E !
The output of the UPS unit also carries a voltage in the case of a power failure!
This is why the installation engineer must mark the outputs and power
sockets on the UPS unit clearly according to EN 62040.
Input
Battery
Rectifier Inverter
Ouput
Manual Bypass
Input
Battery
Rectifier Inverter
Output
Manual Bypass
3. General description of the function
Normal operation
During normal operation the battery and the inverter are supplied with power via a rectifier (online operation).
The change-over from alternating voltage to direct voltage and back to alternating voltage again is achieved
by a sinusoid output voltage with a low distortion factor. The direct voltage is also needed for charging the
battery. The inverter supplies the attached consumers.
Figure 1: Block diagram “Normal operation“
Power failure
In the case of a power failure, the energy needed by the inverter is taken from the battery. At the output the
voltage from the inverter is still available.
Figure 2: Block diagram “Power failure“

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 8 -
Input
Battery
Rectifier Inverter
Output
Manual Bypass
Input
Battery
Rectifier Inveter
Output
P L E A S E N O T E!
An operating fault can lead to total loss of power supply to the attached power
consumer loads! A power failure for a switched in manual bypass will lead to
crashing of the power consumer loads!
Fault in the inverter or an overload (bypass operation)
In the case of a fault occurring in the inverter or an overload, a switch-over device switches the load back to
the mains. This means that, in the case of a power failure, the connected consumers will no longer be
supplied with power.
Figure 3: Block diagram “Fault in the inverter“
Manual bypass (service bypass)
If there is a fault in the UPS unit and service work must be undertaken, the UPS unit is fitted with an internal
bypass for that purpose. When actuating the manual bypass, the load is directly supplied from the mains.
This means that, in the case of a power failure, the connected consumers will no longer be supplied with
power. When using the manual bypass it is essential to observe the formalism described in Chapter 11.4.
Other procedures could lead to destruction of the UPS unit or crashing of the power consumer loads.
Figure 4: Block diagram “Manual bypass“

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 9 -
4. Technical data
JOVYTEC P 700
Output power
cos 0,7 ind.
700VA / 490W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current with standard charger
3A
Current with additional charger
3,9A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power Factor
0,98
External fuse protection
D01/10A
Battery
(installed in battery pack inside the
ups)
Direct current link voltage
24V
Backup time
10min. at 100% load
13min. at 80% load
27min.at 50% load
Type
Maintenance free, closed lead acid batteries
Charging time
< 8 hours for 90% charged battery
Output
Voltage
230V Standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by ups
Power factor
cos 0,7 ind.
Phase
Single phase
Distorsion factor
< 3% at linear load
Overload behaviour
100 to 125% for 60 seconds
125 –150% for 10s
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operation mode
Switch over behaviour
Power failure
0ms
Overload switching
Automatic overload switching by the ups
Noise level
At a distance of 1m
< 45dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non condensing
Storage at …
20°C (recommended) with Battery
-20°C to 50°C without Battery
Interfaces
RS 232-Interface
Optional:
USB-Interface
Relay card
AS/400 - Adapter
SNMP - Adapter
Supports power management and diagnosis such as BATTERY
LOW, UPS ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS Device
Width
152mm
Depth
420mm
Heights
238mm
Weight UPS
approx. 8,5 kg
Weight UPS incl. Battery
approx. 13,8 kg
Scope of delivery
Hardware/Software
UPS unit JOVYTEC P 700
Manual BAX 3345E
Interface cable
Software UPSMON

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 10 -
JOVYTEC P 1000
Output power
cos 0,7 ind.
1000VA / 700W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current with standard charger
4A
Current with additional charger
5,2A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power Factor
0,98
External fuse protection
D01/10A
Battery
(installed in battery pack inside the
ups)
Direct current link voltage
36V
Backup time
10min. at 100% load
15min. at 80% load
27min.at 50% load
Type
Maintenance free, closed lead acid batteries
Charging time
< 8 Stunden for 90% charged battery
Output
Voltage
230V Standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by ups
Power factor
cos 0,7 ind.
Phase
Single phase
Distorsion factor
< 3% at linear load
Overload behaviour
100 to 125% for 60 seconds
125 –150% for 10s
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operation mode
Switch over behaviour
Power failure
0ms
Overload switching
Automatic overload switching by the ups
Noise level
At a distance of 1m
< 45dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non condensing
Storage at …
20°C (recommended) with Battery
-20°C to 50°C without Battery
Interfaces
RS 232-Interface
Optional:
USB-Interface
Relay card
AS/400 - Adapter
SNMP - Adapter
Supports power management and diagnosis such as BATTERY
LOW, UPS ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS Device
Width
152mm
Depth
420mm
Heights
238mm
Weight UPS
approx. 9,4 kg
Weight UPS incl. Battery
approx. 17,4 kg
Scope of delivery
Hardware/Software
UPS unit JOVYTEC P 1000
Manual BAX 3345E
Interface cable
Software UPSMON

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 11 -
JOVYTEC P 1500
Output power
cos 0,7 ind.
1500VA / 1050W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current with standard charger
5,7A
Current with additional charger
6,9A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power Factor
0,98
External fuse protection
D01/10A
Battery
(installed in battery pack inside the
ups)
Direct current link voltage
36V
Backup time
6min. at 100% load
10min. at 80% load
23min.at 50% load
Type
Maintenance free, closed lead acid batteries
Charging time
< 8 Stunden for 90% charged battery
Output
Voltage
230V Standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by ups
Power factor
cos 0,7 ind.
Phase
Single phase
Distorsion factor
< 3% at linear load
Overload behaviour
100 to 125% for 60 seconds
125 –150% for 10s
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operation mode
Switch over behaviour
Power failure
0ms
Overload switching
Automatic overload switching by the ups
Noise level
At a distance of 1m
< 50dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non condensing
Storage at …
20°C (recommended) with Battery
-20°C to 50°C without Battery
Interfaces
RS 232-Interface
Optional:
USB-Interface
Relay card
AS/400 - Adapter
SNMP - Adapter
Supports power management and diagnosis such as BATTERY
LOW, UPS ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS Device
Width
152mm
Depth
420mm
Heights
238mm
Weight UPS
approx. 10,4 kg
Weight UPS incl. Battery
approx. 18,5 kg
Scope of delivery
Hardware/Software
UPS unit JOVYTEC P 1500
Manual BAX 3345E
Interface cable
Software UPSMON

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 12 -
JOVYTEC P 2000
Output power
cos 0,7 ind.
2000VA / 1400W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current with standard charger
7,7A
Current with additional charger
10,1A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power Factor
0,98
External fuse protection
D01/10A
Battery
(installed in battery pack inside the
ups)
Direct current link voltage
72V
Backup time
8min. at 100% load
13min. at 80% load
28min.at 50% load
Type
Maintenance free, closed lead acid batteries
Charging time
< 8 Stunden for 90% charged battery
Output
Voltage
230V Standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment by ups
Power factor
cos 0,7 ind.
Phase
Single phase
Distorsion factor
< 3% at linear load
Overload behaviour
100 to 125% for 60 seconds
125 –150% for 10s
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operation mode
Switch over behaviour
Power failure
0ms
Overload switching
Automatic overload switching by the ups
Noise level
At a distance of 1m
< 50dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non condensing
Storage at …
20°C (recommended) with Battery
-20°C to 50°C without Battery
Interfaces
RS 232-Interface
Optional:
USB-Interface
Relay card
AS/400 - Adapter
SNMP - Adapter
Supports power management and diagnosis such as BATTERY
LOW, UPS ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS Device
Width
225mm
Depth
425mm
Heights
360mm
Weight UPS
approx. 16,2 kg
Weight UPS incl. Battery
approx. 32,2 kg
Scope of delivery
Hardware/Software
UPS unit JOVYTEC P 2000
Manual BAX 3345E
Interface cable
Software UPSMON

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 13 -
JOVYTEC P 3000
Output power
cos 0,7 ind.
3000VA / 2100W
Network supply
Voltage
230V
Input voltage ranges
168V - 276V (0-100% load)
140 - 159V (0-70% load)
120 - 139V (0-40% load)
Current with standard charger
12A
Current with additional charger
14,4A
Frequency
50Hz ±3Hz or 60Hz ±3Hz
Phase
Single phase
Power Factor
0,98
External fuse protection
D01/10A
Battery
(installed in battery pack inside the
ups)
Direct current link voltage
72V
Backup time
5min. at 100% load
12min. at 80% load
23min.at 50% load
Type
Maintenance free, closed lead acid batteries
Charging time
< 8 Stunden for 90% charged battery
Output
Voltage
230V Standard (208V / 220V / 240V selectable at the panel)
Frequency
Automatic adjustment via of the ups
Power factor
cos 0,7 ind.
Phase
Single phase
Distorsion factor
< 3% at linear load
Overload behaviour
100 to 125% for 60 seconds
125 –150% for 10s
Crest Factor
3 : 1
Efficiency
AC to AC
88 - 98% according to the operation mode
Switch over behaviour
Power failure
0ms
Overload switching
Automatic overload switching by the ups
Noise level
At a distance of 1m
< 50dB(A)
Environment
Temperature
0°C to 40°C
+15 … +25°C (recommended)
Air humidity
0% to 95%, non condensing
Storage at …
20°C (recommended) with Battery
-20°C to 50°C without Battery
Interfaces
RS 232-Interface
Optional:
USB-Interface
Relay card
AS/400 - Adapter
SNMP - Adapter
Supports power management and diagnosis such as BATTERY
LOW, UPS ON/OFF
Software is compatible with operating systems such as: Windows
95/98/NT/2000/XP, Novell, Unix, etc current operating systems.
Dimensions
UPS Device
Width
225mm
Depth
425mm
Heights
360mm
Weight UPS
approx. 17 kg
Weight UPS incl. Battery
approx. 33 kg
Scope of delivery
Hardware/Software
UPS unit JOVYTEC P 3000
Manual BAX 3345E
Interface cable
Software UPSMON

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 14 -
238
152
5. Dimensions and views
5.1 JOVYTEC P 700 –P 1500

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 15 -
Relay Card
USB –Interface
(option)
Connector for
external Battery
Load output socket
Cold output socket for
consumers
5.2 Rear view JOVYTEC P 700 –P 1000
Electronic - Stop
RS232 - Interface
TAE –Protection Circuit
Fan
Input Fuse
Mains Input Plug

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 16 -
USB –Interface
(option)
5.3 Rear view JOVYTEC P 1500
Electronic - Stop
RS 232 - Interface
TAE –Protection Circuit
Fan
Input Fuse
Main Input Plug
Relay Card
Connector
for external
Battery
Load Output Sockets

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 17 -
225
360
5.4 JOVYTEC P 2000 –P 3000

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 18 -
5.5 Rear view JOVYTEC P 2000 –P 3000
Fan
Fan
TAE –Protection Circuit
RS232 - Interface
Electronic - Stop
Input Fuse
Mains Input Plug
Electronic - Stop
Relay Card
USB –Interface
(option)
Connector for
external Battery
Output Fuses
Cold Output Socket for
Load
Load Output Sockets

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 19 -
6. Electrical connection
The UPS units in the series JOVYTEC P are simply connected via the installed mains connection socket
(input connector for non-heating apparatus) and the 1.5 metre long mains connection cable (cable for non-
heating apparatus) to the power socket for non-heating apparatus provided.
One proceeds as follows:
1. Plug the mains input cable (cable for non-heating apparatus) provided into the foreseen power socket
for non-heating apparatus.
2. Attach the power consumers via the protective contact socket.
3. Connect up the battery cabinet supplied (optional for longer autonomy times) via the battery
connection jack.
4. All connecting up work is now complete.
P L E A S E N O T E!
Only trained personnel are allowed to work on the UPS unit.
Observe all corresponding safety regulations.
Marking of cables is to be according to DIN EN 60445!
When connecting to the UPS unit, ensure use of an adequately sized protective-
conductor connection!
P L E A S E N O T E!
When working on the batteries it is possible for dangerous situations to arise
due to a high DC voltage and high short-circuit currents.
This work on the device must only be conducted when accompanied by use of
suitable protective measures such as insulated tools, eye and hand protection
etc.

Wärtsilä JOVYTEC P 700VA –3kVA BAX 3345 - 20 -
6.2 Commissioning
Note: The unit fans run as soon as the input voltage is applied!!
The UPS unit can now be started by pressing the ON/OFF button in the front panel for 3 seconds; a
message appears in the display: Switching on procedure. The UPS unit now starts a self-test routine
during which its internal functions are tested and the mains synchronisation and the inverter are started. The
message “Battery mode“ is shown in the display during the self-test and the LED´s ON for UPS ON and
ON-LINE output voltage light up. The message “Operation“ appears in the display. The consumers to be
supplied can now be switched on.
Please contact us if anything different happens.
6.3 UPS Shut-down
When shutting down the unit please proceed as follows:
- Switch off all consumers
- Press the ON/OFF button in the front panel for 3 seconds. An acoustic sound (bleep) is emitted while
pressing the ON/OFF button and the message: Switching off soon appears in the display, and then
the message “UPS OFF“. The UPS unit is now shut-down. Please note: The device fans continue to
run as long as the input voltage is applied.
P L E A S E N OT E!
The unit should be started over the input mains. If the input mains is not available for a short
time then it is also possible to start the unit over the external battery. It is a basic prerequisite for
this operating mode that the UPS unit was one time operated over the energy supplier’s mains
network. Please note that when starting over the external battery, the maximum time the output
voltage is available to you is the autonomy time. The UPS unit will also start with the previously
stored parameters, i.e. if the mains previously had 50 Hz then the UPS will also generate 50 Hz on
the output side.
P L E A S E N OT E!
The voltage specification on the UPS must coincide with the voltage specification on the battery
cabinet (DIRECT CURRENT LINK VOLTAGE) otherwise there is danger of destroying internal
components of the UPS or destruction of the battery.
This manual suits for next models
5
Table of contents
Other WÄRTSILÄ UPS manuals

WÄRTSILÄ
WÄRTSILÄ JOVYSTAR-DELTA User manual

WÄRTSILÄ
WÄRTSILÄ JOVYTEC L Series User manual

WÄRTSILÄ
WÄRTSILÄ JOVYTEC PMS 2002K User manual

WÄRTSILÄ
WÄRTSILÄ JOVYCUBE 160 User manual

WÄRTSILÄ
WÄRTSILÄ JOVYSTAR HP 200 kVA User manual

WÄRTSILÄ
WÄRTSILÄ JOVYTEC POWERMASTER PMS 6000 User manual

WÄRTSILÄ
WÄRTSILÄ JOVYSTAR COMPACT S BAX 5452 User manual

WÄRTSILÄ
WÄRTSILÄ JOVYREC D600 G120/10 User manual

WÄRTSILÄ
WÄRTSILÄ JOVYATLAS POWERMASTER S 6000-P User manual
