Wacker Neuson E09-01 User manual

Machine model E09-01 (1404)
Edition 2.7
Order no. 1000164553
Language en
Operator’s Manual
Track excavator
1404

Legend
Edition Issued
1.2 07/2008
1.3 11/2009
2.0 01/2010
2.1 03/2011
2.4 09/2011
2.5 06/2012
2.6 01/2013
2.7 02/2016
Copyright © 2016 Wacker Neuson Linz GmbH, Hörsching
Printed in Austria
All rights reserved
This document may be used by the receiver only for the designated purpose. It may in no way be duplicated or
translated in any other language, in whole or in part, without prior permission in writing from the manufacturer.
The cover features the machine with possible optional equipment.
Photographs and graphics are symbolic representations and may differ from the actual products.
Original Operator’s Manual
Wacker Neuson Linz GmbH
Flughafenstr. 7
A-4063 Hörsching
Phone [phone]
E-mail: [email protected]
www.wackerneuson.com
Document: BA 1404 en
Order no.: 1000164553
Edition: 2.7
Documentation
Title Language Order no.
Operator’s Manual en 1000164553
Spare parts list de/en/fr 1000163718
Spare parts list de/it/es 1000163719

BA 1404 en – Edition 2.7 * Ba1404en2_7IVZ.fm 1-1
Table of contents
Table of contents
Introduction
Important information on this Operator’s Manual ............................................................... 1-1
Machine overview ................................................................................................................ 1-2
Brief description ................................................................................................................... 1-3
Traveling drive ................................................................................................... 1-3
Operating hydraulics .......................................................................................... 1-3
Cooling system .................................................................................................. 1-3
Cab (ROPS) ...................................................................................................... 1-3
Model designations and trade names ................................................................ 1-4
Fields of application, attachments ...................................................................................... 1-4
Use: attachment ................................................................................................ 1-4
Regulations .......................................................................................................................... 1-5
Operator qualification and requirements for safe operation .............................. 1-5
EC Declaration of Conformity 1404 .................................................................................... 1-6
Type labels and component numbers ................................................................................ 1-7
Overview of adhesive labels ............................................................................ 1-10
Overview of safety labels ................................................................................. 1-13
Fire extinguisher ................................................................................................................ 1-18
Safety instructions
Identification of warnings and dangers ............................................................................... 2-1
Warranty .............................................................................................................................. 2-1
Disposal ............................................................................................................................... 2-1
Designated use and exemption from liability ...................................................................... 2-2
General conduct and safety instructions ............................................................................ 2-3
Organizational measures ................................................................................... 2-3
Selection and qualification of personnel, basic responsibilities ......................... 2-4
Safety instructions regarding operation .............................................................................. 2-5
Normal operation ............................................................................................... 2-5
Cabin/canopy ..................................................................................................... 2-7
Explanation of abbreviations ............................................................................. 2-7
Checks when reversing the machine ................................................................................. 2-7
Applications with lifting gear ................................................................................................ 2-7
Trailers and attachments ..................................................................................................... 2-8
Transportation ...................................................................................................................... 2-8
Working in the area of underground electric lines .............................................................. 2-8
Working near overhead electric lines ................................................................................. 2-9
Safety instructions for maintenance ................................................................................... 2-9
Warning of special hazards ............................................................................................... 2-11
Electrical energy .............................................................................................. 2-11
Gas, dust, steam, smoke ................................................................................. 2-11
Hydraulic system ............................................................................................. 2-11
Noise ............................................................................................................... 2-12
Oil, grease and other chemical substances ..................................................... 2-12
Battery ................................................................................................................................ 2-12
Air intake .......................................................................................................... 2-12
Tracks .............................................................................................................. 2-12
Hammer operation ............................................................................................................. 2-13
Safety instructions ........................................................................................... 2-13
Working with a hammer ................................................................................... 2-13
Operation
Table of contents

1-2 BA 1404 en – Edition 2.7 * * Ba1404en2_7IVZ.fm
Table of contents
Cabin overview .................................................................................................................... 3-2
Cabin overview (legend) ..................................................................................................... 3-3
Instrument panel overview ................................................................................................. 3-4
Instrument panel overview (legend) ................................................................................... 3-5
Putting into operation .......................................................................................................... 3-6
Safety instructions ............................................................................................. 3-6
Putting into operation for the first time ............................................................... 3-6
Running-in period .............................................................................................. 3-6
Check lists ............................................................................................................................ 3-7
Start-up checklist ............................................................................................... 3-7
Operation checklist ............................................................................................ 3-8
Parking checklist ................................................................................................ 3-8
Driving the excavator ........................................................................................................... 3-9
Preheating start switch (overview) ..................................................................... 3-9
Throttle lever overview ....................................................................................... 3-9
Speed range selection ..................................................................................... 3-10
Indicator lights and warning lights (overview) ................................................. 3-10
Before starting the engine ................................................................................ 3-13
Starting the engine: general ............................................................................. 3-13
Procedure ........................................................................................................ 3-13
Starting with the drive interlock (option) ........................................................... 3-14
Starting with the drive interlock – internal transponder (option) (from serial number
AG00673) ........................................................................................................ 3-14
Starting at low temperatures ............................................................................ 3-16
When the engine has started ... ....................................................................... 3-16
Engine warm-up ............................................................................................... 3-16
Jump-starting the engine (supply battery) ....................................................... 3-17
Starting machine travel .................................................................................... 3-18
Drive levers ...................................................................................................... 3-18
Hydraulic brake ................................................................................................ 3-19
Stabilizer blade as a parking brake .................................................................. 3-19
Operating temperature range .......................................................................... 3-19
Machine travel on slopes .................................................................................................. 3-20
Stabilizer blade operation .................................................................................................. 3-22
Changing the width of the stabilizer blade ....................................................... 3-24
Telescopic travel gear (option) ......................................................................................... 3-25
Retract or extend the telescopic travel gear .................................................... 3-26
Upper carriage lock ........................................................................................................... 3-28
Parking the machine ......................................................................................................... 3-28
Parking the machine on slopes ........................................................................................ 3-29
Light system ....................................................................................................................... 3-30
Roof lights (option) ........................................................................................... 3-30
Interior light ...................................................................................................... 3-30
Rotating beacon (option) ................................................................................. 3-31
Cab heating and ventilation .............................................................................................. 3-31
Heating adjustment .......................................................................................... 3-32
Washer system .................................................................................................................. 3-32
Tank for washer system ................................................................................... 3-32
Seat adjustment ................................................................................................................ 3-33
Weight adjustment ........................................................................................... 3-33
Horizontal adjustment ...................................................................................... 3-34
Backrest adjustment ........................................................................................ 3-34
Seat belt ............................................................................................................................. 3-34
Retracting belt (option) ...................................................................................................... 3-36
Emergency exit (with cab option) ..................................................................................... 3-37
Front window (with cab option) (up to serial number AF05320) ..................................... 3-38
Front window (from serial number AG02423) .................................................. 3-39

BA 1404 en – Edition 2.7 * Ba1404en2_7IVZ.fm 1-3
Table of contents
Opening/closing the front window .................................................................... 3-39
Opening/closing the lower front window .......................................................... 3-40
Door (with cab option) ....................................................................................................... 3-40
Cab/canopy entry and exit ................................................................................................ 3-42
Safety instructions regarding entry and exit .................................................... 3-42
Engine cover ...................................................................................................................... 3-43
Battery master switch ........................................................................................................ 3-44
Mirrors (option) ................................................................................................................... 3-45
Towing the track excavator ............................................................................................... 3-47
Towing ............................................................................................................. 3-47
Crane-lifting the machine .................................................................................................. 3-48
Loading and transporting the machine ............................................................ 3-52
Tying down the machine .................................................................................. 3-53
Protective structures .......................................................................................................... 3-54
Definition of the term “Protective Structure” .................................................... 3-54
Mechanical integrity ......................................................................................... 3-54
Definition of FOPS levels ................................................................................. 3-54
Responsibility for machine equipped with protective structures ...................... 3-54
Protective FOPS structure/small screen – category I (option from serial no.
AG02423) ........................................................................................................ 3-55
Protective FOPS structure/large screen – category II (option) ........................ 3-57
......................................................................................................................... 3-58
Shatter protection for canopy (option) ............................................................. 3-59
Travel signal (option) ......................................................................................................... 3-61
Machine operation ............................................................................................................. 3-62
General safety instructions .............................................................................. 3-62
Control levers/ISO controls: overview .............................................................................. 3-63
Control lever on the left ................................................................................... 3-63
Boom swivel controls ....................................................................................... 3-63
Auxiliary hydraulics .......................................................................................... 3-64
Right-hand control lever .................................................................................. 3-65
Emergency lowering ........................................................................................ 3-65
Rotating the upper carriage ............................................................................. 3-66
Swivel unit brake ............................................................................................. 3-66
Changeover valve for SAE/ISO controls (option) ............................................................ 3-67
Control lever on the left ................................................................................... 3-67
Control lever on the right ................................................................................. 3-67
Directional valve position ................................................................................. 3-68
Directional valve .............................................................................................. 3-68
Release the pressure in the operating hydraulics ............................................................ 3-69
Releasing pressure .......................................................................................... 3-69
Re-equipping attachments ................................................................................................ 3-70
Specific safety instructions .............................................................................. 3-70
Removing a bucket .......................................................................................... 3-70
Installing a bucket ............................................................................................ 3-71
Quickhitch (option) ........................................................................................... 3-71
Hydraulic quickhitch – Easy Lock (option) ....................................................... 3-72
Picking up an attachment ................................................................................ 3-73
Setting down an attachment ............................................................................ 3-75
Connections for auxiliary hydraulics ................................................................ 3-76
Grab couplings ................................................................................................ 3-77
Attachments ..................................................................................................... 3-77
Maintenance of attachments ........................................................................... 3-77
Working with the standard bucket .................................................................................... 3-77
General information regarding work operation ................................................ 3-78
Inadmissible work procedures ......................................................................... 3-78
Excavator work position ................................................................................... 3-80

1-4 BA 1404 en – Edition 2.7 * * Ba1404en2_7IVZ.fm
Table of contents
Bucket position when digging .......................................................................... 3-80
Excavating trenches ........................................................................................ 3-80
Loading ............................................................................................................ 3-81
Grading ............................................................................................................ 3-81
Excavating trenches laterally ........................................................................... 3-81
Grading .............................................................................................................................. 3-83
Grading ............................................................................................................ 3-83
Working alongside trenches ............................................................................ 3-84
Malfunctions
Engine trouble .................................................................................................................... 4-1
Maintenance
Introduction .......................................................................................................................... 5-1
Fuel system ......................................................................................................................... 5-2
Specific safety instructions ................................................................................ 5-2
Refueling ............................................................................................................ 5-2
Draining the fuel ................................................................................................. 5-3
Stationary fuel pumps ........................................................................................ 5-3
Bleeding the fuel system .................................................................................... 5-4
Fuel prefilter with water separator ..................................................................... 5-5
Engine lubrication system ................................................................................................... 5-6
Checking the oil level ......................................................................................... 5-6
Adding engine oil ............................................................................................... 5-7
Engine cooling system ........................................................................................................ 5-8
Specific safety instructions ................................................................................ 5-8
Checking the coolant level/adding coolant ........................................................ 5-9
Air filter (up to serial number AG03170) ........................................................................... 5-11
Air intake .......................................................................................................... 5-11
Replacing the filter ........................................................................................... 5-12
Air filter (from serial no. AG03171) ................................................................................... 5-13
Air intake .......................................................................................................... 5-13
Replacing air filter elements ............................................................................ 5-14
Replacing the cabin air filter .............................................................................................. 5-16
V-belt .................................................................................................................................. 5-17
Checking V-belt tension ................................................................................... 5-17
Tightening the V-belt (alternator) ..................................................................... 5-18
Checking the V-belt of the alternator ............................................................... 5-19
Hydraulic system ............................................................................................................... 5-20
Important information on the hydraulic system ................................................ 5-20
Checking the hydraulic oil level ....................................................................... 5-21
Adding hydraulic oil .......................................................................................... 5-21
Important notices on the use of biodegradable oil ........................................... 5-22
Checking hydraulic pressure lines ................................................................... 5-23
Overview of lubrication points ........................................................................................... 5-24
Parking the machine ........................................................................................ 5-25
Lubricating the ball bearing race of the live ring .............................................. 5-25
Lubricating the teeth of the live ring ................................................................. 5-26
Lubrication points of hydraulic quickhitch (option) ........................................... 5-26
Tracks ................................................................................................................................ 5-27
Checking track tension .................................................................................... 5-27
Setting the tracks ............................................................................................. 5-28
Traveling drive ................................................................................................................... 5-29
Maintenance of attachments ............................................................................ 5-29
Electrical system ................................................................................................................ 5-29
Specific safety instructions .............................................................................. 5-29
Servicing and maintenance at regular intervals ............................................... 5-29
Instructions concerning specific components .................................................. 5-29

BA 1404 en – Edition 2.7 * Ba1404en2_7IVZ.fm 1-5
Table of contents
Alternator ......................................................................................................... 5-30
Battery ............................................................................................................. 5-31
General maintenance ........................................................................................................ 5-32
Cleaning .......................................................................................................... 5-32
General instructions for all areas of the machine ............................................ 5-32
Inside the cabin ............................................................................................... 5-33
Exterior of the machine .................................................................................... 5-33
Engine compartment ....................................................................................... 5-33
Threaded fittings and attachments .................................................................. 5-33
Pivots and hinges ............................................................................................ 5-33
Preparatory work before taking out of service .................................................................. 5-34
Maintenance when out of service for a longer period of time .......................................... 5-34
Putting into operation again ............................................................................. 5-34
Fluids and lubricants .......................................................................................................... 5-35
Additional oil change and filter replacement (hydraulic system) ...................... 5-36
Maintenance plan (overview) ............................................................................................ 5-38
Maintenance label ............................................................................................................. 5-42
Explanation of symbols on the maintenance label .......................................... 5-42
Technical data
Chassis ................................................................................................................................ 6-1
Engine .................................................................................................................................. 6-1
Hydraulic system ................................................................................................................. 6-2
Travel gear and swivel unit ................................................................................................. 6-3
Stabilizer blade .................................................................................................................... 6-3
Operating hydraulics ........................................................................................................... 6-3
Electrical system .................................................................................................................. 6-4
Fuses on control lever base on the left .............................................................. 6-4
Main fuse and relays in the engine compartment .............................................. 6-4
Noise levels .......................................................................................................................... 6-5
Vibration ............................................................................................................................... 6-5
Coolantcompound table ...................................................................................................... 6-7
Dimensions .......................................................................................................................... 6-8
Lift capacity tables ............................................................................................................. 6-10
Safety instructions – lift capacity tables ........................................................... 6-10
Lift capacity table (standard chassis and canopy) ........................................................... 6-11
Lift capacity table with long stick (Standard chassis and canopy) (option) ..................... 6-12
Lift capacity table with cabin (option) and telescopic undercarriage (option) ................. 6-13
Lift capacity table with cabin (option), long dipper arm (option) and telescopic undercarriage
(option) ............................................................................................................................... 6-14

1-6 BA 1404 en – Edition 2.7 * * Ba1404en2_7IVZ.fm
Table of contents

BA 1404 en – Edition 2.7 * Ba1404en2_7SIX.fm 1-1
Index
A
Abbreviations .........................................................................................1-1
Air filter .................................................................................................5-11
Air intake .................................................................................... 5-11, 5-13
Applications with lifting gear ..................................................................2-7
B
Battery .................................................................................................5-31
Battery master switch (model 1404) ....................................................3-44
Biodegradable oil .................................................................................5-22
C
Cabin air filter .......................................................................................5-16
Check lists .............................................................................................3-7
Check the oil level ..................................................................................5-6
Crane-lifting bracket .............................................................................3-48
D
Designated use and exemption from liability .........................................2-2
Driving the excavator .............................................................................3-9
F
Fasten ..................................................................................................3-36
Fire extinguisher ..................................................................................1-18
Fluids and lubricants ............................................................................5-35
H
Hammer operation ...............................................................................2-13
Heating ................................................................................................3-31
Hydraulic system .................................................................................5-20
I
Indicator lights and warning lights ........................................................3-10
Instrument panel overview ............................................................. 3-4, 3-5
Interior light ..........................................................................................3-30
L
Legal regulations ...................................................................................1-5
Light system .........................................................................................3-33
Lowering the boom with the engine stopped .......................................3-65
Lubricating the live ring (ball bearing) ..................................................5-25
Lubricating the teeth of the live ring .....................................................5-26
M
Machine
Brief description .............................................................................. 1-3
Fields of application ........................................................................ 1-4
Loading and transporting .............................................................. 3-52
Overview ........................................................................................ 1-2
Machine travel on slopes ..................................................................... 3-20
Maintenance .......................................................................................... 5-1
Adding coolant ................................................................................ 5-9
Adding engine oil ............................................................................ 5-7
Adding hydraulic oil ...................................................................... 5-21
Air filter ................................................................................ 5-12, 5-14
Battery .......................................................................................... 5-31
Biodegradable oil .......................................................................... 5-22
Bleeding the fuel system ................................................................ 5-4
Check the oil level .......................................................................... 5-6
Checking the coolant level ............................................................. 5-9
Checking the engine oil level .......................................................... 5-6
Checking the hydraulic oil level .................................................... 5-21
Electrical system .......................................................................... 5-29
Engine and hydraulics cooling system ........................................... 5-8
Fluids and lubricants .................................................................... 5-35
Fuel system .................................................................................... 5-2
General maintenance ................................................................... 5-32
Hydraulic pressure lines ............................................................... 5-23
Instructions concerning specific components ............................... 5-29
Maintenance plan ......................................................................... 5-38
Pivots and hinges ......................................................................... 5-33
Servicing and maintenance at regular intervals ........................... 5-29
Threaded fittings ........................................................................... 5-33
Threaded fittings and attachments ............................................... 5-33
Track maintenance ....................................................................... 5-27
Maintenance label ............................................................................... 5-42
Mirrors (option) .................................................................................... 3-45
N
Noise levels ......................................................................................... 1-11
Note
On this Operator’s Manual ............................................................. 1-1
O
Operation ............................................................................................... 3-1
Auxiliary hydraulics ....................................................................... 3-64
Before starting the engine ............................................................ 3-13
Boom swivel controls .................................................................... 3-63
Cabin overview ............................................................................... 3-2
Cabin overview (legend) ................................................................. 3-3
Instrument panel overview ............................................................. 3-4
Instrument panel overview (legend) ............................................... 3-5
Parking the machine ..................................................................... 3-28
Starting machine travel ................................................................. 3-18
Starting the engine ....................................................................... 3-13
P
Preheating start switch .......................................................................... 3-9
Putting into operation ............................................................................ 3-2
Check lists ...................................................................................... 3-7
Putting into operation for the first time ............................................ 3-6
Safety instructions .......................................................................... 3-6
Index
I

1-2 BA 1404 en – Edition 2.7 * * Ba1404en2_7SIX.fm
Index
R
Refueling ................................................................................................5-2
Rotating beacon ...................................................................................3-31
Running-in period ..................................................................................3-6
S
Safety instructions .................................................................................2-1
Applications with lifting gear ...........................................................2-7
General conduct .............................................................................2-3
Identification ....................................................................................2-1
Maintenance ...................................................................................2-9
Operation ........................................................................................2-5
Special hazards ............................................................................2-11
Trailers and attachments ................................................................2-8
Transportation .................................................................................2-8
Seat adjustment ...................................................................................3-33
Backrest adjustment .....................................................................3-34
Horizontal adjustment ...................................................................3-34
Weight adjustment ........................................................................3-33
Shatter protection ................................................................................3-59
Starting aid ...........................................................................................3-17
T
Technical data .......................................................................................6-1
Chassis ...........................................................................................6-1
Coolant compound table .................................................................6-7
Dimensions .....................................................................................6-8
Electrical system .............................................................................6-4
Engine .............................................................................................6-1
Hydraulic system ............................................................................6-2
Noise levels ....................................................................................6-5
Stabilizer blade ...............................................................................6-3
Travel gear and swivel unit .............................................................6-3
Vibration ..........................................................................................6-5
Work hydraulics ..............................................................................6-3
Track maintenance ..............................................................................5-27
V
V-belt ...................................................................................................5-17
Ventilation ............................................................................................3-31
Ventilation, fresh air ......................................................................3-31
W
Warranty ................................................................................................2-1
Washer system .......................................................................... 3-32, 3-33
Reservoir ......................................................................................3-32
Working
Freeing the machine .....................................................................3-81
Recommendations ........................................................................3-81

BA 1404 en – Edition 2.7 * 1404b110.fm 1-1
Introduction
1 Introduction
1.1 Important information on this Operator’s Manual
The Operator’s Manual is stored in the storage bin at the rear of the seat.
This Operator’s Manual contains important information on how to work safely, correctly,
and economically with the machine. Therefore, it aims not only at new personnel, but it
also serves as a reference for experienced personnel. It helps to avoid hazardous situa-
tions and reduce repair costs and downtimes. Furthermore, the reliability and the service
life of the machine will be increased by following the instructions in the Operator’s Manual.
This is why the Operator’s Manual must always be kept at hand in the machine.
Your own safety, as well as the safety of others, depends to a great extent on how the
machine is moved and operated. Carefully read the Operator’s Manual before putting the
machine into operation. This Operator’s Manual will help to familiarize yourself more easily
with the machine, thereby enabling you to use it more safely and efficiently.
Follow chapter “Safety Instructions” in particular. As a rule, keep the following in mind:
Careful and prudent working is the best way to avoid accidents!
Operational safety and readiness of the machine do not only depend on your skill, but also
on maintenance and servicing of the machine. This is why regular maintenance and ser-
vicing is absolutely necessary.
Extensive maintenance and repair work must always be performed by a Wacker Neuson
service center. Use only original spare parts for repairs. This ensures operational safety
and readiness of your machine, and maintains its value.
• Special equipment and superstructures are not described in this Operator’s Manual.
• We reserve the right to improve the technical standard of our machines without
adapting the Operator’s Manual.
• Modifying Wacker Neuson products and fitting them with additional equipment and
attachments not included in our delivery program requires Wacker Neuson’s written
authorization, otherwise warranty and product liability for possible damage caused by
these modifications shall not be applicable.
• Subject to modifications and printing errors.
Your Wacker Neuson dealer will be pleased to answer any further questions regarding the
machine or the Operator’s Manual.
Abbreviations/symbols
• Identifies a list
• Subdivision within lists or an activity. Follow the steps in the recommended order
☞Identifies an activity
➥Description of the effects or results of an activity
w/o. Fig. = without figure
„Opt.“ = Option
Stated whenever controls or other components of the machine are installed as an option.
This symbol shows the travel direction – for better orientation in figures and
graphics.

1-2 BA 1404 en – Edition 2.7 * * 1404b110.fm
Introduction
1.2 Machine overview
Abb. 1: Machine outside views
1 Lights
2 Boom light
3 Handhold
4 Auxiliary hydraulics
5 Lifting eye/tie-down point
6 Door arrester
7 Door handle and lock
8 Rotating beacon
9 Rear light
10 Exhaust pipe
11 Lubrication point for track tension
12 Engine air intake
4
5
6
8
9
2
4
7
10
3
5
1
1
8
12

BA 1404 en – Edition 2.7 * 1404b110.fm 1-3
Introduction
1.3 Brief description
The model 1404 excavator is a self-propelled work machine.
Get informed on and follow the legal regulations of your country.
This machine is a versatile and powerful helper for moving earth, gravel and debris on con-
struction sites and elsewhere. A wide range of attachments accounts for the numerous
applications of the machine, among others hammer and grab applications.
See chapter 1.4 Fields of application, attachments for further applications.
The main components of the machine are:
• ROPS (Roll Over Protective Structure) tested canopy (open version)
• ROPS (Roll Over Protective Structure) tested cab (closed version, option)
• Model 1404: water-cooled Yanmar three cylinder diesel engine
• Sturdy steel sheet chassis Rubber mounted motor
Notice!
The machine can be equipped with the “Telematic” option (for transmitting oper-
ating data, location, etc. via satellite)!
Traveling drive The diesel engine permanently drives the gear pump whose oil flow is sent to a hydraulic
motor.
Operating hydraulics The diesel engine drives the joint gear pump for the work hydraulics. The oil flow of this
pump depends on the diesel engine speed only.
Cooling system The indicator lights in the instrument panel of the machine ensure constant monitoring of
the engine and hydraulic oil temperature, as well as of the coolant temperature and level.
Cab (ROPS) Modifying or performing improper repair work on the cabin is dangerous. Do not modify the
cabin. Repair work may only be performed by a Wacker Neuson service center. If the cab
has been damaged, check it before resuming work and have it repaired if necessary.
Please contact a Wacker Neuson dealer for support. Failure to follow this precautionary
measure can lead to serious or fatal injuries. The cab has been specially designed for the
driver’s protection in case of an accident.
Fasten your seat belt, otherwise you can be thrown around or even outside the cab and
crushed. Therefore always fasten your seat belt as you drive and work with the machine.
Tighten the seat belt before putting the machine into operation.

1-4 BA 1404 en – Edition 2.7 * * 1404b110.fm
Introduction
Model designations and trade names
1.4 Fields of application, attachments
The attachments will decide in the first place how the excavator is used.
Caution!
In order to avoid damage to the machine, only the attachments listed below
have been certified for installation on the machine.
☞Please contact an authorized workshop if you wish to use other attach-
ments.
Using tools of other manufacturers, or tools which have been released for other excavator
types, can reduce the machine’s output and stability considerably, and can also cause
damage to the machine and injuries to the operator or the personnel.
Always compare the weight of the attachment and its maximum payload with the indica-
tions in the lift capacity table. Never exceed the maximum payload stated in the lift capac-
ity table.
Use: attachment Possible attachments
Type Trade name Differentiating factor
E09-01 Tier IV final (until 2012) 1404 Motor: 3TNV76-SNS2
E09-01 Tier IV final (starting 2012) Motor: 3TNV80F-SSNS2
Description of attachment Weight Capacity Remarks
Mechanical quickhitch 17 kg (37.4 lbs) Operation of Wacker Neuson quickhitch systems
requires this quickhitch mount
Easy Lock quickhitch 19 kg (41.8 lbs)
Backhoe bucket 250 mm (9.8") wide 30 kg (66.1 lbs) 23 l (0.8 ft3)Mechanical quickhitch
31 kg (68.3 lbs) 23 l (0.8 ft3)Hydraulic quickhitch (Easy Lock)
Backhoe bucket 300 mm (11.8") wide 32 kg (70.5 lbs) 28 l (1.0 ft3)Mechanical quickhitch
34 kg (75 lbs) 28 l (1.0 ft3)Hydraulic quickhitch (Easy Lock)
Backhoe bucket 400 mm (1'-4") wide 37 kg (81.6 lbs) 35 l (1.2 ft3)Mechanical quickhitch
39 kg (86 lbs) 37 l (1.3 ft3)Hydraulic quickhitch (Easy Lock)
Backhoe bucket 500 mm (1'-8") wide 43 kg (94.8 lbs) 44 l (1.55 ft3)Mechanical quickhitch
47 kg (103.6 lbs) 46 l (1.6 ft3)Hydraulic quickhitch (Easy Lock)
Backhoe bucket 600 mm (1‘12”) wide 63 kg (138.9 lbs) 53 l (1.9 ft3)Mechanical quickhitch
53 kg (116.8 lbs) 55 l (1.9 ft3)Hydraulic quickhitch (Easy Lock)
Offset bucket 850 mm (2'-9") wide -- -- Mechanical quickhitch
86 kg (189.6 lbs) 54 l (1.9 ft3)Hydraulic quickhitch (Easy Lock)
Offset bucket 1000 mm (3'-3") wide -- -- Mechanical quickhitch
93 kg (205 lbs) 63 l (2.2 ft3)Hydraulic quickhitch (Easy Lock)
Ditch cleaning bucket 850 mm (2‘9”)
wide
-- -- Mechanical quickhitch
63 kg (138.9 lbs) 82 l (2.9 ft3)Hydraulic quickhitch (Easy Lock)
Ditch cleaning bucket 1000 mm (3'-3")
wide
66 kg (145.5 lbs) 82 l (2.9 ft3)Mechanical quickhitch
72 kg (158.7 lbs) 78 l (2.75 ft3)Hydraulic quickhitch (Easy Lock)

BA 1404 en – Edition 2.7 * 1404b110.fm 1-5
Introduction
1.5 Regulations
Requirements to be met by the operator
Earth moving machines may be driven and serviced only by persons who meet the follow-
ing requirements:
• 18 years or older
• Physically and mentally suited for this work
• Persons have been instructed in driving and servicing the earth moving machine and
have proven their qualifications to the contractor
• Persons are expected to perform work reliably.
Persons have been appointed by the contractor for driving and servicing the earth moving
machine.
Observe the legal regulations of your country.
Operator qualification and requirements for safe operation
Among other things, safe machine operation depends on the following points:
• Machine model and its equipment
• Machine maintenance
• Work and driving speed.
• Nature of ground and work environment
The most important points are the operator’s qualification and power of judgement. A well-
trained operator following the Operator’s Manual and maintenance plan ensures a long
service life and durability of the machine.
Specific training enables the operator to acquire, among other things, the following skills:
• The correct assessment of work situations.
• The feel for the vehicle
• Recognition of potential hazardous situations
• Safe working by making the correct decisions for man, vehicle and the environment.
The operator is at risk if the machine is not operated correctly.
Follow the operating procedures and instructions described for the machine.
Access to the machine or machine operation is prohibited for children and persons under
the influence of alcohol, drugs, or medicine.
Ditch cleaning bucket 1200 mm (3‘11”)
wide
-- -- Mechanical quickhitch
94 kg (207.2 lbs) 84 l (2.95 ft3)Hydraulic quickhitch (Easy Lock)
Hammer NE 8 88 kg (149 lbs)
Hammer NE 12 110 kg (242.5 lbs)
Description of attachment Weight Capacity Remarks

1-6 BA 1404 en – Edition 2.7 * * 1404b110.fm
Introduction
1.6 EC Declaration of Conformity 1404
The indications specified above correspond to the existing information at time of going to press. They have possibly changed in the mean-
time (refer to the original declaration of conformity supplied with the machine). Applies to EU countries, and countries with legislation sim-
ilar to that of the EU. Applies to all machines with CE marks that have not been modified without authorization since the product was
placed on the market.
Manufacturer
Wacker Neuson Linz GmbH, Flughafenstr. 7, 4063 Hörsching, Austria
Product
Declaration of conformity
Notified body according to Directive 2006/42/EC, appendix XI:
DGUV Test-, Prüf- und Zertifizierungsstelle
Fachausschuss Bauwesen, Landsberger Str. 309, 80687 Munich, Germany
Distinguishing EU number 0515
Notified body involved in procedure
TÜV SÜD Industrie Service GmbH
Westendstr. 199
D-80686 Munich
Directives and standards
We hereby declare that this product corresponds to the relevant regulations of the following Directives and standards:
2006/42/EC, 2005/88/EC, 2000/14/EC;
DIN EN ISO 12100-1, DIN EN ISO 12100-2, DIN EN 474-1 and DIN EN 474-5 (except for point C.3.3),
DIN EN ISO 3471, EN ISO 3744, DIN EN ISO 3449
Authorized representative for the compilation of technical documentation
Thomas Köck, team leader technical documentation
Flughafenstr. 7
4063 Hörsching
Austria
Machine designation Hydraulic excavator
Model/version E09-01
Trade name 1404
Serial number --
Output in kW 13,2
Measured sound power level dB(A) 92,2
Guaranteed sound power level dB(A) 93
Johannes Mahringer,
Managing director
EC Declaration of Conformity

BA 1404 en – Edition 2.7 * 1404b110.fm 1-7
Introduction
1.7 Type labels and component numbers
Notice!
Type, quantity, and position of the labels depend on options, country and machine.
Serial number
The serial number is stamped on the machine chassis.
It is also located on the type label.
The type label is located at the front left on the machine chassis (at cab level)
Type label indications (up to serial no. AG03933)
Machine designation: HYDRAULIC EXCAVATOR
Model: ---------------
Model year: ---------------
CEE no. (EEC no.) ---------------
Output: ---------------
Serial no.: ---------------
Max. payload: ---------------
GWR: ---------------
Operating weight: ---------------
Front GAWR: ---------------
Transport weight: ---------------
Rear GAWR: ---------------
Version: ---------------
Type label indications (from serial no. AG03934)
Machine designation: HYDRAULIC EXCAVATOR
Serial no.: (machine serial no.) ---------------
Model: (machine model) ---------------
Performance: (output) ---------------
Version: (type) ---------------
Operating weight: ---------------
Transport weight: ---------------
GWR: ---------------
Max. payload: ---------------
Front GAWR: ---------------
Rear GAWR: ---------------
CEE no. (EEC no.) ---------------
Model year: ---------------
Other information – see chapter 6 Technical data on page 6-1
Abb. 1: Position of type label
Abb. 2: Type label (symbolic representation)
HYDRAULIC EXCAVATOR
Abb. 3: Type label (symbolic representation)
HYDRAULIC EXCAVATOR

1-8 BA 1404 en – Edition 2.7 * * 1404b110.fm
Introduction
7/8-digit serial number (up to 2012)
17-digit serial number (from 2012)
For easier machine identification, Wacker Neuson introduced a 17-digit serial number for
compact equipment in 2012 (for example for excavators). This serial number includes
additional data, for example, the manufacturer code and the production site.
Notice!
Wacker Neuson components (for example, Easy Lock, offset bucket, rollbar) have
numeric serial numbers only.
Cabin number
The type label is located at the upper left of the cab frame.
123
AD 51001 D
Abb. 4:
Position Description
1Machine version
2Serial number
3Equipment feature (optional)
12345 6
WNC E 1301 A PAL 00400
A
S
D
Abb. 5:
Position Description
1Manufacturer code
2Machine model
AUnit
SCompact loader
DDumper
EExcavator
3Internal model designation
4Check letter
5Production site
6Serial number
Abb. 6: Cab type label (up to serial number AF05320)
(symbolic representation)

BA 1404 en – Edition 2.7 * 1404b110.fm 1-9
Introduction
The type label is located on the left of the cab frame.
Engine number
The type label is located on the cylinder-head cover (engine).
Example: Yanmar 46557
Type label for protective FOPS structure (category I)
The type label is located inside the light cover on the left.
Type label for protective FOPS structure (category II)
The type label is located on the right-hand side of the protective screen.
Abb. 7: Cab type label (from serial number AG02423 –
symbolic representation)
Abb. 8: Diesel engine number
Abb. 9: Position of type label for protective FOPS structure
(category I)
Abb. 10: Position of type label for protective FOPS structure
(category II)

1-10 BA 1404 en – Edition 2.7 * * 1404b110.fm
Introduction
Overview of adhesive labels
The following states signs and symbols which are not unequivocally comprehensible. They
do not contain explanatory text and are not explained in the following chapters.
