PPS-400 Portable Power Supply Quick Start Manual
Portable
Power Supply
Manuel de démarrage rapide
Kurzanleitung
Manual de inicio rápido
Guida rapida
Instrukcja szybkiego
uruchomienia
Краткое руководство по

EN
PPS-400 Portable Power Supply Quick Start Manual PPS-400 Portable Power Supply Quick Start Manual
23
Product Description
The WAI PPS-400 Portable Power Supply is housed in a lightweight
aluminium alloy shell giving it a stylish appearance. The unit is powered by a
lithium battery, with its advanced manufacturing technology it can output
both AC and DC currents enabling it to charge a wide range of electronic
products. The WAI PPS-400 can be used as both a UPS (Uninterruptible
Power Supply) and an outdoor emergency backup power supply.
Its lithium battery has a total capacity of 426.24WH/115200mAh, providing
a steady stream of power for the load. It’s 220V(110V) AC and 12V/5V DC
outputs with LED torch light and capacity display make it suitable for a varie-
ty of dierent equipment such as drones, mobile phones, tablet computers,
laptops, desktop computers, photographic equipment, electric scooters,
electric bikes etc. Oers great convenience for use at home, for travel,
outdoor work, camping, caravanning, boating and leisure.
1x WAI PPS-400 Portable Power Supply
1x AC Power Cable
1x In-Car Charge Cable
1x DC Adaptor Cable
1x Instructions
12v 40W Solar Panel
Solar Panel Charging Cable
In the Box: Optional Extras:
WAI PPS-400
WARNING: To reduce the risk of injury or damage to electrical devices, read
the instructions prior to using the charger.
CLEANING: Never use solvents or other harsh chemicals to clean the
charger unit. Use a cloth dampened with water to wipe down the unit, never
immerse in water or let water get inside the unit.
PROTECTING THE ENVIRONMENT: This charger unit contains a Lithium-ion
battery and other materials that can be recovered or recycled. Please
recycle according to local provisions, do not place in household waste.
ELECTRIC SHOCK RISK: Do not open, modify or dismantle the charger
unit. There are no serviceable parts inside.
OUTSIDE USE: Do not expose the charger unit to rain or wet conditions, it
is not waterproof. Water entering the unit will increase the risk of electric
shock.

EN
PPS-400 Portable Power Supply Quick Start Manual PPS-400 Portable Power Supply Quick Start Manual
45
1- LED lamp
2- LED lamp switch
3- Heat vents
4- AC output switch
5- AC input socket
6- Solar or car charging socket
7- DC output switch
8- LCD capacity display
9- USB 5V output
10- DC 12V output
SOLAR CHARGE
LAMP
ON/OFF
DC
ON/OFF
USB USB
AC ON/OFF CAPACITY DISPLAY
DC 12V DC 12V
AC INPUT
Front Panel Controls
AC OUTPUT AC OUTPUT
11- Cooling Fan
12- AC Universal Socket
Rear Panel
SOLAR CHARGE
USB USB
AC ON/OFF CAPACITY DISPLAY
DC 12V DC 12V
AC INPUT
AC INPUT
SOLAR CHARGE
USB USB
AC ON/OFF CAPACITY DISPLAY
DC 12V DC 12V
Red lights indicate unit is charging.
Display will show % charge of battery
Green lights indicate the unit is fully
charged. Display will show 100%
To use the LED lamp (1) press the ON/OFF button
To use the DC output function, press the DC ON/OFF button (7), this will
enable you to use DC 12V (10 and 5V USB (9) sockets (When not in use, turn
o the button so as not to drain the lithium battery)
To use the AC output function, press the AC ON/OFF button (4), this will
enable you to use AC sockets on the rear of the unit (When not in use, turn
o the button so as not to drain the lithium battery)
When using the AC output, make sure the AC LED indicator light on the panel
is green, then insert the electrical appliance into the AC output port. DO NOT
use if the LED indicator light on the panel is red.
The LCD display screen (8) shows the remaining power of the Portable
Power Supply (Remaining power is shown as a percentage, 0-100%)
When the power of the unit is insucient you will hear an alarm prompt
Connect the unit to a power supply via the AC Input (5) or Solar Charge (6) to
continue use. Whilst charging the unit, the charging indicator light on the
end panel will be red and change to green when it is 100% full
When using solar power to charge the unit, the voltage should not exceed
18V, more than this will damage the unit. When the solar panel is connected
to charge the unit the indicator light on the panel should be bright, if it’s not
bright check the connection or adjust the solar panel to face the sun at an
angle of 30 degrees
When using a car-mounted cigarette lighter to charge the unit the charging
indicator light on the end panel will be red and change to green when it is
100% full. This product only supports charging on a 12V car battery
To use the UPS function, rst insert the input AC cable into the AC input
socket, then plug the AC cable into the mains electricity socket, the input
indicator on the panel will light green indicating that it can be used. When the
AC button is pushed on, the AC ON/OFF indicator light is green, and then the
electrical appliance can be plugged into an AC output socket
If the power of an electrical appliance exceeds the power that the unit itself
can carry, the unit enters a protective mode, disconnects the load and
restarts the unit
If the unit is used in extreme weather temperatures it may overheat during
use, overload protection may activate. If it does put the machine in a cool
place to cool down before continuing to use












Operating Instructions

EN
PPS-400 Portable Power Supply Quick Start Manual PPS-400 Portable Power Supply Quick Start Manual
67
WAI PPS-400 Parameters
Inverter AC
output frequency 220V/50HZ and 110V/60HZ (Two frequencies)
Input voltage Supports AC wide voltage, wide frequency input
Input fuse 220V/3A ,110V/5A
Switching time
mains to inverter Within 10ms
Inverter AC
output voltage
No-load 220V output voltage between 220-226V
No-load 110V output voltage between 110-116V"
Inverter AC
ripple voltage Less than 700 mv
Inverter AC
output waveform AC pure sine wave
Inverter AC
rated power
220V rated power 400W,430 W overload protection
110 V rated power 400W,430W overload protection
Discharge
eciency
standards
 When battery voltage is above 16V, the eciency is 95%
 When battery voltage is above 14V, the eciency is 96%
 Eciency is 80% when the voltage is below 12V
 Average eciency 86%
Battery power
 When the battery voltage is higher than 18V, overload
protection, no external output
When the battery voltage is below 13V, under voltage
protection, no external output
 When the voltage is below 13.8 V the buzzer alarms
When battery voltage is below 12V unit automatically
shuts down
When the voltage returns to 14.4V unit restarts
Solar charging
Circuit design for boost constant current to battery
charge, PWM mode
 The solar input voltage range is 6-18V
Boost constant current after re-large the power allowed
to charge into the battery does not exceed 70W
 Solar panels can only be lled with 70W of power
426.24Wh 115200mAh
Rated 400W, Max 430W Overload Protection
AC 110V~220V 50/60Hz
220V 50Hz or 110V 60Hz 2 versions
Two channels 12V (9-12.6V) output total current 10A (no
overload and short circuit protection function), two 5V 3A
USB output (with short circuit overload protection function)
1W
Standard 12V, allowed charge power 70W (More than 70W
solar panels can only be lled with 70W)
Using a solar charging port, allowing a voltage of 12V and
a charge power of 70W
AC pure sine wave
Within 10 ms
No output after overload, disconnect load, restart recovery
No AC output short circuit, short circuit will damage the
unit
Cycle life of more than 800 times
Net Weight:3.3kg Gross Weight: 3.8kg
12.2cm(W) x 13.0cm(H) x 29.3cm(L)
Silver body black end panels
Battery Capacity
Output Power
Input Voltage
Output Voltage
DC Output
LED Lamp
Solar Charging
Car Charging
Output
UPS Blackout
Reaction Time
AC Overload
AC Short Circuit
Lithium Battery
Weight
Size
Colour
Technical Specication

EN
PPS-400 Portable Power Supply Quick Start Manual PPS-400 Portable Power Supply Quick Start Manual
89
WAI PPS-400 Parameters (Cont.)
In-Car charging In-Car charging is only for small 12V batteries
24V batteries are not suitable and will damage devices
Charging time
Charge current of 4.6A can charge the battery to more
than 90% in 7 hours
It can be used when the electricity quantity is shown to
be 100%.
When fully charged indicator lights turn green within
11 hours
Working temp
and protective
temp
When the internal temperature reaches 50-55 degrees the
charger will automatically activate the cooling fans; if the
chargers temperature reaches 85-90 degrees, the charger
automatically shuts down and stops AC output
12V output
12V output is stable between 12V and 12.6V
Two 12V output ports share a steady voltage module
The total output current is 10A
Overload protection and short circuit protection function
USB 5V output
5V output is stable between 5V and 5.2V
Two 5V output ports share a steady voltage module
The total output current is 3A
Overload protection and short circuit protection function
Power
consumption
Average internal DC power consumption is 0.5W
Average internal AC power consumption is within 5W
LED Light
Indicators
AC indicator green light ‘Normal’, red light ‘Fault’
AC charging indicator light red when charging, green
when fully charged
Solar charging indicator light red when charging, green
when fully charged
Capacity
Display
Battery power level 0-100%
When the battery power is displayed at 100%, the
battery capacity is more than 90%
Light function The LED light has a power of 1W
Charging Modes PPS-400
Home 240V/110V
Input
DC Output AC Output
Vehicle (12V only) Solar Panel
(Not included)
5V
12V
