Wali CS201 User manual

17.6 lbs.
(8 kg)
DVD WALL MOUNT
B S 17.6 lbs.(8 kg) including
CS201
WARNING
●Do not begin the installation of the product before you have r ead amd understood the
instructions and warnings contained in this installation sheet. if you have any question
regarding any of the instruction or warning, please contact you r local distributor
●Please refer to installation guide recommendation for required distance from wall to
avoid risk of property damage.
●This product should only be installed by someone of good mecha nical aptitude,with
experience and basic building, and fully understands.
●Make sure that the supporting surface will safely support the combined load of
the equipment and all attached hardware and components.
●If mounting to wood wall studs, make sure that mounting screws are anchored
into the center of the studs. Use of an “edge to edge” stud fin der is highly recommended.
●Always use an assistant or mechanical lifting equipment to saf ely lift and position
equipment.
●Tighten screws firml y, but do not over tingten. Over tightening can damage the
items, greatly reducing their holding powe r.
●This product intended for indoor use onl y. Using this product outdoors could
lead to product failure and personal injur y.
！
●Never exceed the maximum load capacity.
IMPORTANT:
Ensure you have received all
parts against the component
checklist prior to installing. If
any parts are missing or faulty,
call the franchiser for a replacement.
connect piece(x1)
D
ST5.5x50(x2) concrete anchor(x2) M5x14(x3)
plastic bush(x1)
plastic cover(x2)
3mm allen key(x1)
A B C
G
E
F
Tools required
●Phillips Head Screw driver
(200mm length exclude the handle)
●Electric drill and 8mm masonry bit for
concrete wall installation
●Marking Pen
●Hammer
WOOD STUD WALL MOUNTING:
1a
●Use a stud finder to locate the edges of the studs. Use of an
edge-to-edge stud finder is highly recommended.
Based on their edges, draw a vertical line down each stud’s center.
●Place wall plate on wall as a template. And mark the center
of the four mounting holes. Make sure that the mounting holes are
on the centerline of stud.
●Drill four 1/8”(3mm) dia. Holes 1.2”(30mm) deep. Secure it using
four screws(A), make sure that the wall
plate is level as shown in fig.1.1.
fig.1.1
SOLID BRICK AND CONCRETE BLOCK
MOUNTING:
1b
fig.1.2
●Use the wall plate as a template to mark four holes locations on the wall as
shown in fig.1.2.
●Pre-drill these holes with a 8mm masonry bit and depth is at least 50mm.
Insert a Concrete Anchor(B) into each of these holes. Attach the wall plate
to the wall using four screws(A), make sure that the wall plate is level as
shown in fig.1.2.
Assembling The Glass Holder
●Attach the connect piece to the glass holder using two screws and space reserved
3mm as shown in fig.2.1
●Use the same method to assemble the other glass holder
fig.2.1
2
INSTALL ATION MANUAL
[email protected]
glass shelf(x1)
decorative cover(x2)
glass holder(x1)
①②
④
③
wall plate(x1)
stud
A
B
A

Installing The Glass Holder
Insert the glass holders into the wall plate along the wall plate rail at the desired height respectively, and
then tighten two screws with a 3mm Allen key as shown in fig.3.1.
3
●Insert two decorative covers to the top and bottom of wall plate respectively and install two plastic covers
as shown in fig.3.2.
●You can adjust the height of the glass holders as needed. Loosen the screws with a 3mm Allen key(but not
remove) to adjust the glass holders at the desired height and then tighten screws with a 3mm Allen key as
shown in fig.3.2.
Installing The Glass Shelf
Place the glass shelf gently on the glass holders respectively. Attach the glass shelves to the glass
holders using screws and plastic bushes, tighten screws with a 3mm Allen key but not tighten completely at this
time. Center the glass shelves over holes, securely tighten screws with a 3mm Allen key as shown in fig.4.1.
4
Cable Management
●Once you have mounted the DVD bracket,
Check that they are sufficiently secured and
safety to use. You should check whether
screws are fixed well every two months.
●If you have any doubts regarding the
installation, please consult our retailer or
service department for details.
Maintenance
After installing the DVD wall mount, place DVD gently on the mounted glass shelves. Pull out the cable clip,
insert the cable into any of the opening of the clip, with one head of the cable inserted in the clip, insert the
clip into the main pole, take out the other head of the cable from another opening of the clip, then push the
clip until the end of the main pole.
5
fig.3.1
fig.3.2
adjustable in height
hide cable
fig.4.1
fig.5.1
(DVD is not included)
④
