Walker Edison W58ADR2D User manual

P.1
W58ADR2D
Assembly Instructions
Please visit our website for the most current instructions, assembly tips, to report damage
or request parts. www.walkeredson.com
Copyright © 2018, by Walker Edson Furniture Co., LLC, All rights reserved.
Revised 07/2020

P.2

P.3
Right side panel
Top panel
Foot crossbeam
Base
Left side panel
Left center panel
1
2
3
4
5
6
7
01 pcs
Back panel
Center shelf
10
11
Left door
Right door
12
13
Door crossbeam
14
Right center panel
01 pcs
01 pcs
01 pcs
01 pcs
01 pcs
02 pcs
01 pcs
01 pcs
01 pcs
01 pcs
04 pcs
1
Description QtyPart# Description QtyPart#
Front / Back croosbeam
902 pcs
Foot
804 pcs
Side shelf
15 02 pcs
2
3
4
5
6
7
8
9
10
11
12
13
14
15
7
8
8
8
9
14
14
14
15

P.4
GWall anchor 01 pc
EWasher 02 pcs
PØ6mm 01 pc
A
B
C
D
F
M
H
Ø8*30mm Wooden dowel 40 pcs
28 pcs
Screw 12 pcs
Ø4,0*30mm Screw
13 pcs
08 pcs
Ø10*10 Nail 22 pcs
19 pcs
Hammer
recommended for assembly
(not included)
Ø4,0*40mm
Hinge 04 pcs
JK
L Corner 02 pcs
Screw
Ø4,0*25mm
Screw
Ø4,5*35mm
Screw
Ø4,0*16mm
R02 pc
S04 pc
Silicone
Slap Hole
N08 pc
Ø6*8mm Support

P.5
Insert Wooden dowel (A) into part (4), (5), (7), (9), and (11).
Step 1
Step 2
AØ8*30mm 12
AØ8*30mm 28
Insert Wooden dowel (A) into part (2) and (3).
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
2x
4
5
11
9
7
2
3
N
N
N
N
N
N
N
N
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
2x
N
N
Insert Support (N) into part (4) and (5).
Insert Support (N) into part (2) and (3).
NØ6*8mm 04
NØ6*8mm 04

P.6
Step 3
Step 4
Secure part (7) to part (8) with screw (F).
Secure part (7) to part (9) with screw (F).
F04
Ø4,5*35mm
F04
Ø4,5*35mm
F
F
F
F
F
F
F
F
7
7
7
9
9
8
8
2x

P.7
Step 5
Step 6
Secure part (4), (5) to part (11).
B12
Ø4,0*30mm
Secure part (2), (3), (4), (5) to part (1) with screw (B).
B
B
B
B
B
B
B
B
4
4
5
5
11
3
2
1
H+E
GG
E
H
E02 G01 H01
Ø4,0*16mm
Attach hardware (G) part (1), with screw (H+E).

P.8
Step 7
Step 8
First, Secure part (6) with screw (C).
C
C12
Ø4,0*40mm
C
C
C
C
C
C
C
C
C
C
C
C
6
B06
Ø4,0*30mm
B
B
B
B
Then, Secure part (11) with screw (B).
B
Secure part (9) to part (6) with screw (B).
B10
Ø4,0*30mm
B
B
B
B
B
B
B
B
BB
9
9
11

P.9
Step 9
Step 10
Secure back panel (10) to body with nails (M)
MØ10*10 22
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
10
G
H04
Ø4,0*16mm
H
JK
D
H
H
JK
H
D
D
D
D
DH
H
JK
12
12
14
14
Attach hardware (JK) part (12), with screw (H).
Secure part (14) to part (12) with screw (B).
D06
Ø4,0*25mm JK 02

P.10
Step 11
Step 12
P.10
JK 02
H04
Ø4,0*16mm
Attach hardware (JK) part (13), with screw (H).
Secure part (14) to part (13) with screw (B).
H
JK
D
H
H
JK
H
D
D
D
D
D
13
13
14
14
D06
Ø4,0*25mm
H
H
JK
15
15
