WALL'S REFRIGERATION SOLUTIONS Maxivision slim V User manual

•The cabinet should be positioned on a
flat, level surface and the levelling feet
wound down.
•A 5cm gap must be left between the
sides and rear faces of the cabinet and
the wall or any other fixture or fittings.
The side and rear grilles must be
kept unobstructed at all times.
•Please note the cabinet will not perform
in ambient temperatures over 35OC.
•Site the cabinet away from external
sources of heat, eg. radiators, direct
sunlight etc.
Quick Start Guid
Positioning Your Cabinet
Operating Your Cabinet
Actual size of gap required at the rear and sides of the cabinet
For equipment purchased before 13th August 2005 Wall's Refrigeration Solutions
will make a commercial charge on the customer which covers both the disposal
of the unit(s) and the associated distribution costs.
Unilever UK Ltd T/A Walls Refrigeration Solutions, Trafford Park Road, Stretford,
Manchester M17 1NH Phone: [phone]
Sales enquiries: [email protected]
Service enquiries: [email protected]
www.wallsrefrigerationsolutions.com
•The cabinet should be left to stand for 4
hours after delivery before being
plugged in for the first time.
•The cabinet should be plugged into a
suitable 13 amp electrical supply. It
should be plugged directly into the
mains supply socket and not
attached to an extension lead or
adaptor.
•It will take approximately 24 hours for
the cabinet to get down to the required
temperature. Ice Cream should not
be put inside the cabinet until
temperature has been reached.
•Once plugged in and switched on at the
mains supply socket it will begin to
work. Please note that there is no on /
off switch.
Maxivision slim V
Quick Start Guid
Maxivision Slim V
Thank you for purchasing a
Maxivision V cabinet.
This guide is designed to ensure you
get the optimum performance from
your Maxivision V at all times.
By positioning and operating the
cabinet correctly and then following a
few steps to look after it, your
Maxivision V will run properly and
efficiently.
5cm gap all around
Picture may vary
Point of sale
Wall's ice cream branded point of sale is available from P.O.S. Direct. Tel: [phone]
Warranty
Your cabinet is supplied with a 3 years parts and Labour warranty to protect you against
manufacturers defects. If you need assistance please call: 0161 366 2500
Wall’s Refrigeration Solutions Customer Service Department on 0161 366 2500
In order to log a service call you will need to provide the serial number for the cabinet at
fault. This can be found on the information plate that is located on the back of the cabinet.
Use this space to make a note of the serial number for future reference using a ball point
pen:
SERIAL NUMBER
Please note that the basic checks detailed in this guide are usually excluded from the
warranty. See standard terms and conditions for further information.
Wall's Refrigeration Solutions reserve the right to charge for faults not covered by the
warranty.
If you are in any doubt contact our Customer Services Department.
Cabinet Contents Insurance
Please note that your cabinet warranty excludes any liability for loss of product or your
insurance excess no matter how caused.
We recommend that you check your Store Policy to ascertain if you are covered for such an
eventuality and if not then take separate insurance. It is recommended that you run your
freezer for 24 hours before placing stock inside.
Waste Electrical & Electronic Regulations (WEEE)
In accordance with the WEEE regulations Wall's Refrigeration Solutions is responsible for
the final disposal of all equipment purchased on or after the 13th August 2005 - customers
will be charged for the distribution costs at the time of collecting the unit.
QSG Ma ivision V Page 1

•If the correct temperature is not being
maintained then adjustments to the cabinet
can be made.
•The controller can be found on the right
hand side of the top cover. To check the
current temperature press the up or
down arrow and then leave for 5 sec to
show cabinet temperature
•To change the set point press up / down
arrow s and set point will flash, press up /
down to get desired set point and leave 10
seconds to time out and set point will be
saved.
•To turn on the light press the bottom left
button the button will be either a light or
SC on the button
•When ice begins to build up on the inside of
the freezer (approximately 1cm or 1⁄2 an inch
thick) this indicates that defrosting is
required. This should be carried out at
least once every six months or more
frequently depending on location and use
•Empty the cabinet of all products, isolate
the unit by completely removing the plug
from the power supply, open all lids / doors.
•Never use sharp implements to scrape the
ice as this may damage the walls.
•When the ice has melted use a cloth to
remove the excess water inside and then
dry off any residual moisture with a soft
dry cloth.
•Plug back into power supply and close all
lids. Please note that it may take up to 24
hours for the cabinet to get back down to
temperature.
Looking After Your Cabinet - Defrost
Problem Solving
In the unlikely event that your cabinet is not operating to its optimum performance, you are
responsible for ensuring that the following basic checks have been carried out before
calling out an engineer.
Cabinet not running correctly:
1. Check the electrical supply.
2. Check the fuse in the mains plug is OK.
3. Check the Controller set point hasn't been lowered or turned off.
4. If the cabinet is plugged into an extension lead, unplug it and plug directly into the mains
supply.
Cabinet is not at the correct temperature:
1. Check that a good air space has been left around the cabinet minimum 5cm.
2. Check the cabinet is not near a heat source if so move it elsewhere
3. Check the lids / doors have not been left open.
4. Check the load line has not been exceeded.
5. Check that the controller has been set correctly.
6. Check if there is a build up of ice inside.
7. Check the condenser grill is not blocked with dust or debris.
Lighting
Your Maxivision V LED is fitted with low energy high quality LED lighting which is
warranted for 3 years from date of purchase.
•This cabinet is not designed to be able to
freeze liquid, eg. ice pops. These should be
frozen before putting them in.
•Do not exceed the load line on the inside of
the freezer. Doing so will result in reduced
performance of your cabinet.
•Always keep lids closed whenever possible.
Operating Your Cabinet continued...
Temperature Adjustment
Looking After Your Cabinet
•Health & Safety: Before checking and
cleaning the condenser the unit should
be isolated by unplugging it.
•Even though this cabinet is fitted with a low
maintenance condenser that should
not require cleaning for long periods of
time, it should still be inspected at least
once a year for signs of any substantial
dust or debris build up.
•Caution: Before removing the
compressor housing cover, always isolate
the unit by completely removing the
plug from the power supply. All work
on the electrical system and the
refrigeration system must be performed by
suitably qualified staff.
•To clean the condenser: Isolate the power
supply to the freezer and remove the rear
grill. Using a soft brush or vacuum
cleaner very carefully clean the dust or
debris from the condenser. Once cleaned
replace the grill and switch the power
supply back on.
DO NOT EXCEED LOAD LINE LEVEL
QSG Ma ivision IV LED:1 30/01/2017 11:30 Page 3
