Walter Straight-Mate 30-A 606 User manual



CAUTION: 
Fortoolsequippedwithoverload 
protection,whenthemotorshutsoff 
duetooverload,alwaysrunthemachine 
withnoloadforatleast3minutesto 
reducetemperaturebeforereturning 
tooperationtoavoidburn‐outofthe 
motor. 
ORIGINALINSTRUCTIONS 
Foryourpersonalsafety, 
READandUNDERSTANDbeforeusing. 
SAVETHESEINSTRUCTIONSFOR 
FUTUREREFERENCE. 

Straight‐Mate
TM

30‐A606 (110V)
30‐A626 (220V)

2









Model 6606A(Straight‐Mate110V)6626A(Straight‐Mate220V)
Powerinput  1300W,11.8A 1500W,6.8A
Voltage   115V~60Hz 220V~60Hz
NoLoadmin
‐1
  1600~4800 1600~4800
NRatedSpeedmin
‐1
 4800 4800
Spindle   5/8"‐11 M14
Max.WheelDiameter 150mm(6”) 150mm(6”)
NetWeight  3.4kg(7.48Lbs) 3.4kg(7.48Lbs)





3
GENERALSAFETYINSTRUCTIONS
WARNING!Readallsafetywarningsand
allinstructions.Failuretofollowthe
warningsandinstructionsmayresultin
electricshock,fireand/orseriousinjury.Saveall
warningsandinstructionsforfuturereference.The
term“powertool”inthewarningsreferstoyour
mainsoperated(corded)powertoolorbattery‐
operated(cordless)powertool.
1) WORKAREASAFETY
a. Keepworkareacleanandwelllit.Clutteredor
darkareasinviteaccidents.
b. Donotoperatepowertoolsinexplosive
atmospheres,suchasinthepresenceof
flammableliquids,gasesordust.Powertools
createsparkswhichmayignitethedustor
fumes.
c. Keepchildrenandbystandersawaywhile
operatingapowertool.Distractionscancause
youtolosecontrol.
2) ELECTRICALSAFETY
a. Powertoolplugsmustmatchtheoutlet.
Nevermodifythepluginanyway.Donotuse
anyadapterplugswithearthed(grounded)
powertools.
Unmodifiedplugsandmatchingoutletswill
reduceriskofelectricshock.
b. Avoidbodycontactwithearthedorgrounded
surfacessuchaspipes,radiators,rangesand
refrigerators.Thereisanincreasedriskof
electricshockifyourbodyisearthedor
grounded.
c. Donotexposepowertoolstorainorwet
conditions.Waterenteringapowertoolwill
increasetheriskofelectricshock.
d. Donotabusethecord.Neverusethecordfor
carrying,pullingorunpluggingthepowertool.
Keepcordawayfromheat,oil,sharpedgesor
movingparts.Damagedorentangledcords
increasetheriskofelectricshock.
e. Whenoperatingapowertooloutdoors,use
anextensioncordsuitableforoutdooruse.
Useofacordsuitableforoutdoorusereduces
theriskofelectricshock.
f. Ifoperatingapowertoolinadamplocationis
unavoidable,useanearthleakagecircuit
breaker.Useofanearthleakagecircuit
breakerreducestheriskofelectricshock.
3) PERSONALSAFETY
a. Stayalert,watchwhatyouaredoinganduse
commonsensewhenoperatingapowertool.
Donotuseapowertoolwhileyouaretiredor
undertheinfluenceofdrugs,alcoholor
medication.Amomentofinattentionwhile
operatingpowertoolsmayresultinserious
personalinjury.
b. Usepersonalprotectiveequipment.Always
weareyeprotection.Protectiveequipment
suchasdustmask,non‐skidsafetyshoes,hard
hat,orhearingprotectionusedforappropriate
conditionswillreducepersonalinjuries.
c. Preventunintentionalstarting.Ensurethe
switchisintheoff‐positionbeforeconnecting
topowersourceand/orbatterypack,picking
uporcarryingthetool.Carryingpowertools
withyourfingerontheswitchorenergising
powertoolsthathavetheswitchoninvites
accidents.
d. Removeanyadjustingkeyorwrenchbefore
turningthepowertoolon.Awrenchorakey
leftattachedtoarotatingpartofthepower
toolmayresultinpersonalinjury.
e. Donotoverreach.Keepproperfootingand
balanceatalltimes.Thisenablesbetter
controlofthepowertoolinunexpected
situations.
f. Dressproperly.Donotwearlooseclothingor
jewelry.Keepyourhair,clothingandgloves
awayfrommovingparts.Looseclothes,
jewelryorlonghaircanbecaughtinmoving
parts.
g. Ifdevicesareprovidedfortheconnectionof
dustextractionandcollectionfacilities,
ensuretheseareconnectedandproperly

4
used.Useofdustcollectioncanreduce
dustrelatedhazards.
h. h.Keephandlesandgraspingsurfacesdry,
cleanandfreefromoilandgrease.Slippery
handlesandgraspingsurfacesdonotallowfor
safehandlingandcontrolofthetoolin
unexpectedsituations.
4) POWERTOOLUSEANDCARE
a. Donotforcethepowertool.Usethecorrect
powertoolforyourapplication.Thecorrect
powertoolwilldothejobbetterandsaferat
therateforwhichitwasdesigned.
b. Donotusethepowertooliftheswitchdoes
notturnitonandoff.Anypowertoolthat
cannotbecontrolledwiththeswitchis
dangerousandmustberepaired.
c. Disconnecttheplugfromthepowersource
and/orthebatterypackfromthepowertool
beforemakinganyadjustments,changing
accessories,orstoringpowertools.Such
preventivesafetymeasuresreducetheriskof
startingthepowertoolaccidentally.
d. Storeidlepowertoolsoutofthereachof
childrenanddonotallowpersonsunfamiliar
withthepowertoolortheseinstructionsto
operatethepowertool.Powertoolsare
dangerousinthehandsofuntrainedusers.
e. Maintainpowertoolsandaccessories.Check
formisalignmentorbindingofmovingparts,
breakageofpartsandanyothercondition
thatmayaffectthepowertool’soperation.If
damaged,havethepowertoolrepaired
beforeuse.Manyaccidentsarecausedby
poorlymaintainedpowertools.
f. Keepcuttingtoolssharpandclean.Properly
maintainedcuttingtoolswithsharpcutting
edgesarelesslikelytobindandareeasierto
control.
g. Usethepowertool,accessoriesandtoolbits
etc.,inaccordancewiththeseinstructions,
takingintoaccounttheworkingconditions
andtheworktobeperformed.Useofthe
powertoolforoperationsdifferentfromthose
intended
couldresultinahazardoussituation.
h. Keephandlesandgraspingsurfacesdry,clean
andfreefromoilandgrease.Slipperyhandles
andgraspingsurfacesdonotallowforsafe
handlingandcontrolofthetoolinunexpected
situations.
5) SERVICE
Haveyourpowertoolservicedbyaqualifiedrepair
personusingonlyidenticalreplacementparts.This
willensurethatthesafetyofthepowertoolis
maintained.
Symbolsusedinthismanual
V…….......volts
A…….......amperes
Hz……......hertz
W……......watt
~………....alternatingcurrentn………..no
loadspeed
min
‐1
…......revolutionsorreciprocation
 perminute
.......Warningofgeneraldanger
.…classIItool
....readtheseinstructions
....Alwaysweareyeprotection
.....Alwayswearadustmask.
.....Alwayswearhearingprotection
.....Wearsafety‐approvedhardhat
DANGER!Keephandsawayfrom
cuttingareaandtheblade.
donotdisposeofelectrictools,
accessoriesandpackagingtogetherwith
householdwastematerial




5
SPECIFICSAFETYRULES

1. Keephandsawayfromrotatingwheelareaat
alltimes!
2. Prolongedbreathingofairbornedustfrom
grindingoperationsmayeffectrespiratory
function:
 Alwaysuseavacuumcleanerwithabag
approvedforfinedustinstalled.
 Alwaysweararespiratorapprovedfordust
andmist.
3. GrindingLEAD‐BASEDpaintisextremelytoxic
andshouldnotbeattempted.Onlyallow
professionalswithspecialtrainingand
equipmentperformthistask.
4. Maintainproperfootingandbalanceatall
times.Donotoverreach.
5. Alwayswearappropriatesafetyequipment
whenoperating.
6. Important:Aftercompletingoperation,switch
offtheswitchandwaitforthecoastingwheel
tostopcompletelybeforeputtingthetool
down.
7. Neveroperatethetoolinanareawith
flammablesolids,liquids,orgases.Sparksfrom
thecommutator/carbonbrushescouldcausea
fireorexplosion.
8. Therearecertainapplicationsforwhichthis
toolwasdesigned.Themanufacturerstrongly
recommendsthatthistoolNOTbemodified
and/orusedforanyapplicationotherthanfor
whichitwasdesigned.Ifyouhaveany
questionsrelativetoitsapplicationDONOT
usethetooluntilyouhavewrittenthe
manufacturerandhavebeenadvised.
9. Usethemachinewithbothhandsatalltimes.
Lossofcontrolcancausepersonalinjury.
10. Keeppowersupplycordclearfromthe
workingrangeofthemachine.Alwaysleadthe
cableawaybehindyou.
11. Immediatelyswitchoffthemachineifunusual
vibrationsorifothermalfunctionsoccur.
Checkthemachineinordertofindoutthe
cause.
12. Thedustthatariseswhenworkingwiththis
toolcanbeharmfultohealth.Useadust
absorptionsystemandwearasuitabledust
protectionmaskandremovedeposited
dustwithavacuumcleaner.
SAFETYWARNINGSCOMMONFOR
GRINDING,SANDING,WIREBRUSHING,
POLISHINGORABRASIVE
Cutting‐OffOperations:
a. Thispowertoolisintendedtofunctionasa
grinder,sander,wirebrush,polisherorcut‐off
tool.Readallsafetywarnings,instructions,
illustrationsandspecificationsprovidedwith
thispowertool.Failuretofollowall
instructionslistedbelowmayresultinelectric
shock,fireand/orseriousinjury.
b. Operationsotherthangrinding,sanding,wire
brushing,polishingorcutting‐offarenot
recommendedtobeperformedwiththis
powertool.Operationsforwhichthepower
toolwasnotdesignedmaycreateahazardand
causepersonalinjury.
c. Donotuseaccessorieswhicharenot
specificallydesignedandrecommendedby
thetoolmanufacturer.Justbecausethe
accessorycanbeattachedtoyourpowertool,
itdoesnotassuresafeoperation.
d. Theratedspeedoftheaccessorymustbeat
leastequaltothemaximumspeedmarkedon
thepowertool.Accessoriesrunningfaster
thantheirratedspeedcanbreakandflyapart.
e. Theoutsidediameterandthethicknessof
youraccessorymustbewithinthecapacity
ratingofyourpowertool.Incorrectlysized
accessoriescannotbeadequatelyguardedor
controlled.
f. Thearboursizeofwheels,flanges,backing
padsoranyotheraccessorymustproperlyfit
thespindleofthepowertool.Accessorieswith
arbourholesthatdonotmatchthemounting
hardwareofthepowertoolwillrunoutof
balance,vibrateexcessivelyandmaycauseloss
ofcontrol.
g. Donotuseadamagedaccessory.Beforeeach
useinspecttheaccessorysuchasabrasive
wheelsforchipsandcracks,backingpadfor

6
cracks,tearorexcesswear,wirebrushfor
looseorcrackedwires.Ifpowertoolor
accessoryisdropped,inspectfordamageor
installanundamaged
accessory.Afterinspectingandinstallingan
accessory,positionyourselfandbystanders
awayfromtheplaneoftherotatingaccessory
andrunthepowertoolatmaximumno‐load
speedforoneminute.Damagedaccessories
willnormallybreakapartduringthistesttime.
h. Wearpersonalprotectiveequipment.
Dependingonapplication,usefaceshield,
safetygogglesorsafetyglasses.As
appropriate,weardustmask,hearing
protectors,glovesandworkshopapron
capableofstoppingsmallabrasiveor
workpiecefragments.Theeyeprotectionmust
becapableofstoppingflyingdebrisgenerated
byvariousoperations.Thedustmaskor
respiratormustbecapableoffiltrating
particlesgeneratedbyyouroperation.
Prolongedexposuretohighintensitynoisemay
causehearingloss.
i. Keepbystandersasafedistanceawayfrom
workarea.Anyoneenteringtheworkarea
mustwearpersonalprotectiveequipment.
Fragmentsofworkpieceorofabroken
accessorymayflyawayandcauseinjury
beyondimmediateareaofoperation.
j. Holdthepowertoolbyinsulatedgripping
surfacesonly,whenperforminganoperation
wherethecuttingaccessorymaycontact
hiddenwiringoritsowncord.Cutting
accessorycontactinga"live"wiremaymake
exposedmetalpartsofthepowertool"live"
andcouldgivetheoperatoranelectricshock.
k. Positionthecordclearofthespinning
accessory.Ifyoulosecontrol,thecordmaybe
cutorsnaggedandyourhandorarmmaybe
pulledintothespinningaccessory.
l. Neverlaythepowertooldownuntilthe
accessoryhascometoacompletestop.The
spinningaccessorymaygrabthesurfaceand
pullthepowertooloutofyourcontrol.
m. Donotrunthepowertoolwhilecarryingitat
yourside.Accidentalcontactwiththespinning
accessorycouldsnagyourclothing,pullingthe
accessoryintoyourbody.
n. Regularlycleanthepowertool’sairvents.The
motor’sfanwilldrawthedustinsidethe
housingandexcessiveaccumulationof
powderedmetalmaycauseelectricalhazards.
o. Donotoperatethepowertoolnear
flammablematerials.Sparkscouldignitethese
materials.
p. Donotuseaccessoriesthatrequireliquid
coolants.Usingwaterorotherliquidcoolants
mayresultinelectrocutionorshock.
FURTHERSAFETYINSTRUCTIONSFORALL
OPERATIONSKickbackandRelated
Warnings
Kickbackisasuddenreactiontoapinchedor
snaggedrotatingwheel,backingpad,brushorany
otheraccessory.Pinchingorsnaggingcausesrapid
stallingoftherotatingaccessorywhichinturn
causestheuncontrolledpowertooltobeforcedin
thedirectionoppositeoftheaccessory’srotationat
thepointofthebinding.
Forexample,ifanabrasivewheelissnaggedor
pinchedbytheworkpiece,theedgeofthewheel
thatisenteringintothepinchpointcandigintothe
surfaceofthematerialcausingthewheeltoclimb
outorkickout.Thewheelmayeitherjumptoward
orawayfromtheoperator,dependingondirection
ofthewheel’smovementatthepointofpinching.
Abrasivewheelsmayalsobreakunderthese
conditions.
Kickbackistheresultofpowertoolmisuseand/or
incorrectoperatingproceduresorconditionsand
canbeavoidedbytakingproperprecautionsas
givenbelow.
a. Maintainafirmgriponthepowertooland
positionyourbodyandarmtoallowyouto
resistkickbackforces.Alwaysuseauxiliary
handle,ifprovided,formaximumcontrolover
kickbackortorquereactionduringstart‐up.
Theoperatorcancontroltorquereactionsor
kickbackforces,ifproperprecautionsare
taken.
b. Neverplaceyourhandneartherotating
accessory.Accessorymaykickbackoveryour
hand.

7
c. Donotpositionyourbodyintheareawhere
powertoolwillmoveifkickbackoccurs.
Kickbackwillpropelthetoolindirection
oppositetothewheel’smovementatthepoint
ofsnagging.
d. Usespecialcarewhenworkingcorners,sharp
edgesetc.Avoidbouncingandsnaggingthe
accessory.Corners,sharpedgesorbouncing
haveatendencytosnagtherotatingaccessory
andcauselossofcontrolorkickback.
e. Donotattachasawchainwoodcarvingblade
ortoothedsawblade.Suchbladescreate
frequentkickbackandlossofcontrol.
ADDITIONALSAFETYINSTRUCTIONS
FORGRINDINGANDCUTTING‐OFF
OPERATIONS
SafetyWarningsSpecificforGrindingandAbrasive
Cutting‐OffOperations:
a. Useonlywheeltypesthatarerecommended
foryourpowertoolandthespecificguard
designedfortheselectedwheel.Wheelsfor
whichthepowertoolwasnotdesignedcannot
beadequatelyguardedandareunsafe.
b. Theguardmustbesecurelyattachedtothe
powertoolandpositionedformaximum
safety,sotheleastamountofwheelis
exposedtowardstheoperator.Theguard
helpstoprotecttheoperatorfrombroken
wheelfragments,accidentalcontactwith
wheelandsparksthatcouldigniteclothing.
c. Wheelsmustbeusedonlyforrecommended
applications.Forexample:donotgrindwith
thesideofcut‐offwheel.Abrasivecut‐off
wheelsareintendedforperipheralgrinding,
sideforcesappliedtothesewheelsmaycause
themtoshatter.
d. Alwaysuseundamagedwheelflangesthatare
ofcorrectsizeandshapeforyourselected
wheel.Properwheelflangessupportthewheel
thusreducingthepossibilityofwheel
breakage.Flangesforcutoffwheelsmaybe
differentfromgrindingwheelflanges.
e. Donotuseworndownwheelsfromlarger
powertools.Wheelintendedforlargerpower
toolisnotsuitableforthehigherspeedofa
smallertoolandmayburst.
ADDITIONALSAFETYWARNINGSSPECIFIC
FORABRASIVECUTTINGOFF
OPERATIONS:
a. Do not “jam” the cut‐off wheel or apply
excessivepressure.Donotattempttomakean
excessivedepthofcut.  Overstressing  the
wheelincreasestheloadingandsusceptibility
totwistingorbindingofthewheelinthecutand
thepossibilityofkickbackorwheelbreakage.
b. Donotpositionyourbodyinlinewithand
behindtherotatingwheel.Whenthewheel,
atthepointofoperation,ismovingaway
fromyourbody,thepossiblekickbackmay
propelthespinningwheelandthepowertool
directlyatyou.
c. Whenwheelisbindingorwheninterrupting
acutforanyreason,switchoffthepower
toolandholdthepowertoolmotionlessuntil
the wheel comes to a complete stop.Never
attempttoremovethecut‐offwheelfrom
thecutwhilethewheelisinmotion
otherwisekickbackmayoccur.Investigateand
takecorrectiveactiontoeliminatethecause
ofwheelbinding.
d. Donotrestartthecuttingoperationinthe
workpiece.Letthewheelreachfullspeedand
carefullyreenterthecut.Thewheelmaybind,
walkuporkickbackifthepowertoolisrestarted
intheworkpiece.
e. Supportpanelsoranyoversizedworkpiece
tominimizetheriskofwheelpinchingand
kickback.Largeworkpiecestendtosagunder
theirownweight.Supportsmustbeplaced
undertheworkpiecenearthelineofcutand
neartheedgeoftheworkpieceonbothsides
ofthewheel.
f. Useextracautionwhenmakinga“pocket
cut”intoexistingwallsorotherblindareas.
The protruding wheel may cut gas or water
pipes,electricalwiringorobjectsthatcancause
kickback.
WARNINGS:Thebladeguardmustalwaysbelocked
bythelockscrewinitsdetentinthecentral

8
position.Neverchangetheangleoftheguardto
anyotherposition.
Theendcoveronthebladeguardmustneverbe
removed.Neverattempttooperatethemachine
withoutallofitsbladeguardsinplace.

FUNCTIONALDESCRIPTION
ThisStraightGrinderisdesignedforgrindingwithan
abrasivewheelandmayalsobeusedforbuffingand
polishingwhenfittedwiththeappropriate
accessories.
ELECTRICALCONNECTION
Thenetworkvoltagemustconformtothevoltage
indicatedonthetoolnameplate.Underno
circumstancesshouldthetoolbeusedwhenthe
powersupplycableisdamaged.Adamagedcable
mustbereplacedimmediatelybyanauthorized
CustomerServiceCenter.Donottrytorepairthe
damagedcableyourself.Theuseofdamagedpower
cablescanleadtoanelectricshock.
EXTENSIONCABLE
Ifanextensioncableisrequired,itmusthavea
sufficientcross‐sectionsoastopreventanexcessive
dropinvoltageoroverheating.Anexcessivedropin
voltagereducestheoutputandcanleadtofailureof
themotor.Thefollowingtableshowsyouthe
correctcablediameterasafunctionofthecable
lengthforthismachine.Useonlyapproved
extensioncables.Neverusetwoextensioncables
together.Instead,useonelongone.
TotalExtension
CordLength(feet)

CordSize(AWG)

25  16 
50  12 
100  10 
150  8 
200  6 
UNPACKING
Carefullyremovethetoolandalllooseitemsfrom
theshippingcontainer.
Retainallpackingmaterialsuntilafteryouhave
inspectedandsatisfactorilyoperatedthemachine.
CARTONCONTENTS
1. StraightGrindermachine
2. Instructionmanual
3. Facespannerwrench
DONOTOPERATETHISTOOLUNTILYOUREAD
ANDUNDERSTANDTHEENTIREINSTRUCTION
MANUAL
TOINSTALLAWHEEL
1. Unplugthemachine.
2. PlacetheInnerFlange,thewheelandthenthe
FlangeNutonthearbor.
3. UsingFaceSpannerWrench,tightentheFlange
Nut.
4. Removalistheoppositeofassembly.





9
TOINSTALLTHEMANDRELARBOR
1. Unplugthemachine.
2. ThreadtheMandrelArborontothespindle.
3. Usingthetwoopenendwrenches,tightenthe
Mandrel.
4. InstallthedesiredaccessoryontotheMandrel.

STARTINGANDSTOPPINGTOOL
Makesurethatthepowercircuitvoltageisthesame
asthatshownonthespecificationplateofthe
machineandthatswitchis“OFF”beforeconnecting
thetooltothepowercircuit.
Switchingthemachineonandoff
Toswitchon: 
Whileholdingwiththelefthandonthefrontgrip
andtherighthandonthemainhandle,firstpress
thelockbuttonthensqueezethetriggerswitchto
the"on"position.Anticipateandbereadyforthe
start‐uptorquewhenthemachinefirststarts.

CAUTION:Thismachineisequippedwithalockoff
typeswitch.Itisnotpossibletoturnonthetrigger
switchuntilthelockbuttonisfirstpressed.Trying
toforcetheswitchonwithoutpressingthelock
buttoncoulddamagetheswitch.
Toswitchoff: 
Releasethetriggerswitch.

ADJUSTINGTHEROTATIONSPEED
Thespeedofthemachineisvariabletosuitdifferent
tasks.Itcanbeadjustedfrom1600/minupto
4800/minbyusingthethumbwheel.turninthe
rightwarddirectiontoincreasethespeedandinthe
leftwarddirectiontodecreasethespeed.

HOWTOUSETHETOOL
Effectivecontrolofthismachinerequirestwo‐
handedoperationformaximumsafetyandcontrol.
Theproperholdistokeeponehandonthemain
handleandtheotherhandonthegrip.Itisvitally
importanttokeepstablefootingatalltimes.
GRINDINGOPERATIONS
Oncethemachineissetupandallsafetymeasures
andequipmentareinplace,beginbyturningonthe
machine.
Begingrinding.Itisnotnecessarytouseexcessive
downforce.Allowthemachinetoworkatthepace
itwasintended.
WARNING:Whenevergrindingsmallworkpieces
alwaystakemeasurestoclamptheworkpieces
down.Otherwisetheywillbeflungwithgreatforce
bythegrindingwheel,causingahazard.




10
6) MAINTENANCE
Every50hoursofoperationblowcompressedair
throughthemotorwhilerunningatnoloadtoclean
outaccumulateddust.(Ifoperatinginespecially
dustyconditions,performthisoperationmore
often.)
KEEPTOOLCLEAN
Periodicallyblowoutallairpassageswithdry
compressedair.Allplasticpartsshouldbecleaned
withasoftdampcloth.NEVERusesolventstoclean
plasticparts.Theycouldpossiblydissolveor
otherwisedamagethematerial.Wearsafety
glasseswhileusingcompressedair.
THECARBONBRUSHES
Thecarbonbrushesareanormalwearingpartand
mustbereplacedwhentheyreachtheirwearlimit.
NOTE:Checkingandreplacingthecarbonbrushes
shouldbeentrustedtoaqualifiedservicecenter.
Thecarbonbrushesfurnishedwilllastapproximately
50hoursofrunningtimeor10,000on/offcycles.
Replacebothcarbonbrusheswheneitherhasless
than1/4"lengthofcarbonremaining.Toinspector
replacebrushes,firstunplugthemachineandlayit
onitsside.Toinspectorreplacebrushes,first
unplugthemachine.Carefullyremovethe4screws
toseparatetherearhandlehalvesandthenremove
the4screwswhichconnectthehandletothemotor
housing.Liftawaytheleft‐handhandlehalffirst.
Therewillstillbewiresconnectedtotherear
handle,sotakecarethatthesearenotstressed.
Simplyholdtherearhandleofftooneside.Next
removethetwoscrewsholdingontheElectronics
UnittoallowaccesstotheBrushscrews.Holdthe
ElectronicsUnitofftoonesideandavoidstressing
thewires.Rotatethespiralspringtorelievethe
tensiononthebrushandslideitoutoftheholder.
Unscrewthetwoscrewswhichholdthebrushleads
andremovetheCarbonBrushes.
NOTE:WhenputtingtheCarbonBrushesbackinto
theCarbonBrushHoldersitisessentialthatboth
flangesgobackinsidetheholder.
NOTE:Toreinstallthesamebrushes,firstmake
surethebrushesgobackinthewaytheycameout.
Otherwiseabreak‐inperiodwilloccurthatwill
reducemotorperformanceandincreasebrush
wear.
Replacingisthereverseofremoval.WhenReplacing
allcovers,takegreatcarethatallwiresareinplace
andnotinapositiontobepinchedwhentheyare
retightened.Itisrecommendedthat,atleastoncea
year,youtakethetooltoanAuthorizedService
Centerforathoroughcleaningandlubrication.

Ifthereplacementofthepowersupplycordis
necessary,thishastobedonebythe
manufacturerortheiragentinordertoavoida
safetyhazard.
WARNING:Allrepairsmustbeentrustedtoan
authorizedservicecenter.Incorrectlyperformed
repairscouldleadtoinjuryordeath.

