Wampler TERRAFORM User manual

DIMENSION
effect RATE; effect DEPTH; output
VOLUME; clean BLEND; VARIABLE
amount of bass
CHORUS
effect RATE; effect DEPTH; output
VOLUME; clean BLEND; VARIABLE
amount of bass
HARMONIC TREMOLO
speed/RATE; effect DEPTH; output
VOLUME;BLEND = crossover point;
VARIABLE = width
TREMOLO
effect RATE; effect DEPTH, output
VOLUME; BLEND = stereo width,
VARIABLE = waveform width
U VIBE
effect RATE; filter range DEPTH;
output VOLUME; clean BLEND;
VARIABLE waveshape
AUTO SWELL
effect RATE; effect DEPTH; output
VOLUME; clean BLEND; VARIABLE
pick attack speed
ROTARY
max horn speed RATE; max woofer
speed DEPTH; output VOLUME,
BLEND between horn/woofer,
VARIABLE ramp speed.
PHASER
effect RATE; DEPTH of filter
range, VARIABLE stereo width,
clean BLEND; output VOLUME
FLANGER
effect RATE; effect DEPTH (max=TZF);
output VOLUME; clean BLEND; VARIABLE
feedback level
ENVELOPE FILTER
attack speed/RATE; DEPTH envelope
sensitivity; output VOLUME, clean BLEND;
VARIABLE changes “Q”
AUTOWAH
autowah RATE; filter DEPTH; output
VOLUME; clean BLEND, VARIABLE
changes “Q”
(ALSO TOGGLES RAMP
FOR ROTARY)
NORMAL (STEREO/
MONO) and PRE/POST 9v - 18v DC CENTER
Terraform-QuickStart_6.25x5.25_Final_9-23-19.indd 1 9/25/19 9:43 AM

PRESET - Set your tone, HOLD the PRESET button until it flashes, select the patch location with the PRESET
button, and the hold it down again to store your tone in that location.
EXPRESSION - Hold down the bypass button and press TAP TEMPO, release both. Set the HEEL position of
the control, press TAP TEMPO, set the TOE position of the control, press the TAP TEMPO stomp to exit.
PRE/POST - On power up, hold both the BYPASS and TAP TEMPO stomps and power up. Set each effect by
selecting it and pressing BYPASS for pre (LED = green), or TAP TEMPO for post (LED = Blue), press the
PRESET button to save your preferences.
NORMAL
(out left for mono - use the right output as
well for stereo)
