Operation
WAREMA
climatronic® 3.x

2

Control Systems Helpline
[phone]
(or [e-mail])
Table of contents
1 Operating elements ...........................3
2 Start menu...........................................4
3 Main menu...........................................6
4 Operating.............................................8
5 Settings ............................................. 11
5.1 Sun control............................... 11
5.2 Dawn/dusk control................. 15
5.3 Time switch.............................. 18
5.4 Leave......................................... 20
5.5 Absent ...................................... 21
6 Scenes .............................................. 23
7 Measuring values ............................ 25
8 System............................................... 28
9 Problems and causes .................... 30
10 Cleaning............................................ 31

3
1 Operating elements



Display
2Function wheel
Rotate (in both directions):
Select menus or change values.
Press: Select highlighted menu item
or apply set value.
3Function buttons
Depending on the information on the
display, different processes can be
triggered with the function buttons.
4SD card slot
For saving the settings of your
WAREMA climatronic® or for loading
saved settings or settings that were
changed through a PC.
5USB interface
For connecting to a PC. This allows
the WAREMA climatronic® to be
operated on a PC.

4
2 Start menu







AMenu name
BDate and time
The symbol appears when
the DCF77 time signal has been
received.
CStatus display
The symbols are only displayed when
a status is active.
A fault occurred. Fault messages
are displayed in the fault menu
([Start menu]→[Measuring
values]→[Faults]).
Online mode
(control via a connected PC)
Leave function active
Absent function active
DCurrent weather data

5
EIndicator of whether the control
functions are active
FIndicator of whether Absent is
activated
GIndicator of the button functions in the
current menu
Button Function
Main menu You can select channels,
groups and scenes in the
main menu if you want to oper-
ate a product manually.
See Chapter 3 on page 6.
Control
mode
Switching comfort control
functions on and off
For indicator see E
The safety functions
(e.g. wind monitoring) cannot
be switched off.
Absent Switching the Absent function
on and off
For indicator see Fand
Previously specified sun shad-
ing positions and states can
be retrieved for the duration
of your absence with this
function.
Measuring
values
Display of all recorded meas-
uring values and curves.
In addition, a list of all the
move and switch command
triggers as well as faults can
be displayed.
See Chapter 7 on page 25.

6
3 Main menu





Pressing the [Main menu] function button
in the start menu takes you to the main
menu. From most menus, you can return
here with the [Main menu] function
button.
In the main menu you will find the table
of created channels, groups and scenes,
which you can select with the function
wheel. Rotating the function wheel
moves the cursor line highlighted in col-
our. Press the function wheel to select.
AChannel
The WAREMA climatronic® is
equipped with 64 channels. Each
channel can control either a single
product (e.g. an awning) or several
products of the same type
(e.g. three external venetian blinds).

7
BGroup
Channels with identical products
can also be combined into a group.
For example, if you have created
a channel for the roller shutters of
each room, then all roller shutters of
the building can be combined into a
group and operated together.
CScene
A scenario (e.g. “roller shutter up,
light off, heating off” when leaving
the flat) can be saved (“learned”) in a
scene and be called up again at any
time.
DWhen you see a small triangle
(or ) on the right at the edge of
the display, you can scroll the table
further up or down with the function
wheel!
EThe following functions are assigned
to the buttons in the main menu:
Button Function
Settings Call up settings menus
<< >> Scroll through the menu en-
tries page by page
Start menu Back to the start menu

8
4 Operating
If you select a channel in the main menu,
the [Manual operation] menu opens.
Here you can operate the products in the
channel with the function buttons or by
specifying a value.
Slat products
 Press the UP STOP DOWN function
buttons in order to operate.
A brief push of the button (shorter
than approx. 0.6seconds) triggers a
tilting impulse of the slats.
A Tilt symbol is displayed below the
product figure.

9
A longer push of the button (longer
than approx. 0.6seconds) triggers a
movement.
A corresponding Move symbol is
displayed below the product figure.
OR
 Select Position or Slat angle with
the function wheel and press.
The line below becomes orange.
 Turn function wheel until the dis-
played value changes as desired.
 Press function wheel to confirm the
value.
The products in the channel move to
the new position.

10
Awnings, roller shutters, windows
 Operate these products as described
earlier for slat products.
Difference:
Pushing a button always immediate-
ly triggers a move command. The
Slat angle setting option is not
displayed here.
Switchable products
 Press the ON OFF function buttons in
order to operate.
Switchable products are e.g. lights, fans,
heaters and air conditioners.
Operating via a WAREMA
climatronic® WebControl is
described in the WebControl
manual.

11
5 Settings
The comfort functions are used for the
automatic control of your connected
products. They can be set separately for
each channel.
AUTIONC
Changing operator settings
may impact the safety of the
unit or reduce its effective-
ness. Please consult a qual-
ified specialist if you are not
sure about the effects of a
modification.
5.1 Sun control
The sun control is one of the main
comfort functions of the WAREMA
climatronic® because the most important
control mode for sun shading products is
control depending on brightness. When
the PHOTO measuring value exceeds
the SUN limit value, the sun shading
products are lowered. When the PHOTO
measuring value falls below the CLOUD
limit value, the sun shading products are
raised again.

12
 Press the [Settings] function button
in the main menu and select the
following menu: [Comfort
functions]→[“Channel name”]
→[Sun control]
The following view appears in the
display:
The following parameters can be
changed:
Button Function
Sun control
ON/OFF
Activate or deactivate
sun control
Limit value
SUN
specifies the brightness
level above which the
sun shading product of
this channel should be
lowered

13
Button Function
Delay
SUN
Delay time, to prevent
the product from being
lowered immediately as
soon as the brightness
changes
Position
SUN
specifies the posi-
tion to which a sun
shading product is
to be lowered when
Limit value SUN is
reached.
Slat angle
SUN
Slat angle, which is
set after reaching the
Position SUN
Limit value
CLEAR
specifies the brightness
level above which the
sun shading product
moves to an intermedi-
ate position (e.g. when
the sky is covered but
still bright)
Delay
CLEAR
Delay time, to prevent
the product from being
moved immediately as
soon as the brightness
changes
Position
CLEAR
specifies the posi-
tion to which a sun
shading product is
to be lowered when
Limit value CLEAR is
reached.
Slat angle
CLEAR
Slat angle, which is
set after reaching the
Position CLEAR

14
Button Function
Limit value
CLOUD
specifies the brightness
level above which the
sun shading product of
this channel should be
raised
Delay
CLOUD
Delay time, to prevent
the product from being
raised immediately as
soon as the brightness
changes
Position
CLOUD
specifies the posi-
tion to which a sun
shading product is
to be moved when
Limit value CLOUD is
reached
Slat angle
CLOUD
Slat angle, which is
set after reaching the
Position CLOUD
Active during
leave?
Activate or deactivate
sun control during your
leave
Active during
presence?
Activate or deactivate
sun control during your
presence
Active during
absence?
Activate or deactivate
sun control during your
absence
The sun control is not effective during a
wind, precipitation or ice alarm. After the
alarm has been cancelled, the automatic
sun control becomes active again and
resumes evaluating the brightness.

15
5.2 Dawn/dusk control
The dawn/dusk control is a WAREMA
climatronic® comfort function used to
control the sun shading system or mainly
visual privacy depending on dawn or
dusk. The “Dawn/dusk” weather station
measuring value is used to register the
brightness. When the Dawn/dusk meas-
uring value exceeds the set Limit value
DAWN for 5minutes, the sun shading
product moves to the DAWN position.
When the Dawn/dusk measuring value
falls below the set Limit value DUSK
for 5minutes, the sun shading product
moves to the DUSK position.
 Press the [Settings] function
button in the main menu and select
the menu [Comfort functions]
→ ["Channel name"] →
[Dawn/dusk control].
The following view appears in the
display:

16
The following parameters can be
changed:
Button Function
Dawn/dusk
control
ON/OFF
Activate or deactivate
dawn/dusk control
Limit value
DAWN
specifies the brightness
at which a sun shading
product is to be moved in
the morning
Position
DAWN
specifies the position to
which the sun shading
product is to move at
dawn
Slat angle
DAWN
Slat angle, which is
set after reaching the
Position DAWN
Auto control
DAWN
Set whether the comfort
control modes are to be
enabled, disabled or left
unchanged

17
Button Function
Limit value
DUSK
specifies the brightness
at which a sun shading
product is to be moved to
the Position DUSK
Position
DUSK
specifies the position to
which the sun shading
product is to move at
dusk
Slat angle
DUSK
Slat angle, which is
set after reaching the
Position DUSK
Auto control
DUSK
Set whether the comfort
control modes are to be
enabled, disabled or left
unchanged
Active during
leave?
Activate or deactivate
dawn/dusk control during
your leave
Active during
presence?
Activate or deactivate
dawn/dusk control during
your presence
Active during
absence?
Activate or deactivate
dawn/dusk control during
your absence
The dawn/dusk control is not effective
during a wind, precipitation or ice alarm.
The dawn/dusk control continues after
the alarm has been cancelled, any
potential command is executed.

18
5.3 Time switch
The time switch makes it possible to
raise or lower sun shading products or
other products at a specific time for each
channel.
Four switching times are available for
every day. Furthermore, the position and
subsequent tilting of the slats of a slat
product can be programmed with differ-
ent slat angles.
 Press the [Settings] function
button in the main menu, go to the
menu [Comfort functions] →
[“Channel name”] → [Timer switch]
and select the desired day.
The timer menu for this day appears.

19
 Enter the desired switch time and
position/slat angle.
In the example above the sun shading
system is moved to 0% at 8:00 a.m. and
back to 100% at 10:00 p.m. The com-
fort functions are enabled, meaning that
the sun shading system can be moved
automatically with the control modes
(e.g.sun control).
 Enter at the end of the list whether
the function should be active in cer-
tain states (e.g. Absent).

20
5.4 Leave
This menu allows you to adjust the
position of the sun shading product
and, if applicable, the slat angle for the
selected channel during your leave. The
move command is executed once at the
beginning of your leave.
 Press the [Settings] function button
in the main menu and then go to
the menu [Comfort functions] →
["Channel name"] → [Leave].
The following view appears in the
display:
 Enter the desired position/slat angle.
The function button [---] leaves the
position/slat angle unchanged.
