Honeywell Domonial CMI Series User guide

02/2011
Domonial CMI/CME
Installer’s manual 3
Manuel d’installateur 27

Page 2 of 52
02/2011

Page 3 of 52
02/2011
E
N
G
L
I
S
H
Contents
Introduction............................................................................................. 5
Installation procedure.............................................................................. 7
Plan the installation ................................................................................. 8
Mount the panel .................................................................................... 10
Wire the panel ....................................................................................... 11
Register the TCU keypad ........................................................................ 12
Mount, register and programme devices ............................................... 13
Set the date and time............................................................................. 14
Save the configuration ........................................................................... 14
Test the installation ............................................................................... 15
Exit programming mode......................................................................... 16
Fit the panel cover ................................................................................. 16
Register a TAG........................................................................................ 17
Test after arming the system ................................................................. 18
Specification .......................................................................................... 19
List of codes ........................................................................................... 21

Page 4 of 52
02/2011

Page 5 of 52
02/2011
E
N
G
L
I
S
H
Introduction
Domonial is a wireless control panel with a built-in siren, digital communicator and audio
verification system. The radio link between the various components of the system allows easy
installation with only a small amount of cabling (mains, and when specified, PSTN, X10 or a wired
intercom terminal). This version can be used with the HF and the M wireless device ranges, for
example DO800M.
After recording a wireless Audio device, all HF wireless device can not work your installation.
Domonial can be programmed using the following tools:
DOMOPC programming tool. Refer to the DOMOPC online help guide for full details.
A TCU keypad
This guide describes how to program the panel using a TCU keypad. A complete list of
programming codes is provided at the end of this manual.
Panel Label
Commercial reference
Product file reference
Serial number Note: The format of
Date of manufacture date is yymmdd
The software version number is marked on a label on the box containing the panel (e.g. SW: L06) and
on a small label on the PCB.
The LED Indicators
The panel comes in two designs, depending on the version. Both designs have LED indicator lights
showing the status of the system.
LED latout for the classic version
State/LED
Mains Supply
Arm/Disarm
Perimeter
Fault
Intruder Alarm
Memory
Technical
Alarm Memory
Colour
Green
Green
Yellow
Red
Red
LED latout for the EN version
State/LED
Mains Supply
Fault Area
System Fault
Tamper Fault
Intruder Fault
Colour
Green
Green
Yellow
Red
Red
CMI8UK-STD-7
97AGC0B
75000C6C8
100320

Page 6 of 52
02/2011
E
N
G
L
I
S
H
System operation
Once installed the Domonial alarm allows the surveillance of three different areas per site:
Area A = the perimeter or ground floor
Area B = the rest of the house
An optional Area C. The configuration of Area C depends upon the general
parameters “Annex arming linked to Total” and “Annex disarming linked
to Total”
Total set (all devices in the house –equivalent to Away in the UK)
Part set (a subset of the total set, usually installed as perimeter devices –
equivalent to Home in the UK)
Annex set (an additional set of devices, for example a second perimeter or
a garage –not generally used in the UK)
Arming and disarming
arming and disarming can be performed using:
Keypads and keyfobs, which can be associated with total or part sets, the annex set, or all
sets.
DTMF codes over the phone.
programming tools. This function is available depending on product version and country
regulations
Users
Keyfobs, keypads and codes, with which to access the alarm system, can be assigned to
a maximum of 10 users (including a master user). Each user can have a code and/or
a TAG for each keypad.
System operation by users can be detected, stored and reported to the monitoring station. In
addition, Domonial can be programmed to take a set of pictures when the system is armed or
disarmed that are sent to the monitoring station. Dedicated profiles for limited time access
and clocking are also available on some versions of the product.
Alarm detection
The access route devices can be set up as follows:
Immediate: direct trigger, a device is outside the access route
Delayed: with an entry/exit delay programmable from 0 to 90 seconds
(for total, part or annex areas)
Mixed: direct trigger or delayed if a delayed device was activated first.
Technical devices, such as a flood/temperature sensor, are permanently armed and trigger
independently of arming status.

Page 7 of 52
02/2011
E
N
G
L
I
S
H
Alarm signalling
The following sounder operating modes can be programmed:
Standard siren
Siren activated after intrusion or after intrusion and PSTN failure
Siren activated on tamper detection only when system is armed or independent
of arming status
Siren activated on fire detection
Intruder siren duration can be programmed to a maximum of 4 minutes.
Activation of the sounder can also be postponed until after the alarm signal has been transmitted.
Fire siren duration is fixed to 5 minutes and can be delayed for up to 5 minutes.
Alarm transmission
Domonial is equipped with a digital transmitter for sending information via PSTN, optional
GSM/GPRS card, or optional Ethernet card to the following:
A telephone (PSTN, GSM voice)
An Alarm Receiving Centre using the following protocols: Secom3, Surtec, Cesa, Contact ID
Note: Data networks, such as GSM data or GPRS, use the SECOM3 protocol.
Installation procedure
The rest of this manual is designed to be followed in sequence and describes the following
main tasks:
Equipment siting (planning and installation)
Registration of wireless devices
Basic programming
Device and alarm testing
Contents of the box
Check that your Domonial box contains the following:
Domonial alarm panel, plus the User Manual
1 Stocko, four-pin connector inside the panel for the telephone connection
Breakout tabs for covering unused wire passages
A Velcro strap for securing the battery
A 4 V 3.5 Ah back-up battery is required, and is sold separately by Honeywell: part numbers
ELECKSON BPEL040035 or SONNENSCHEIN A504/3.5S.

Page 8 of 52
02/2011
E
N
G
L
I
S
H
Plan the installation
To ensure the installation process is successful we recommend that you mark the position
of the system components on a drawing of the building.
A layout drawing is shown on the following page to help you plan the wiring into and out
of the panel.
Select positions for the panel and peripheral devices to maximise GSM signal level (if used),
audio coverage (if used), and wireless radio signal levels.
Note: Radio transmission is attenuated when sent through wood, Artex, brick, concrete, and steel
reinforcements. It is reflected by metal surfaces such as mirrors, steel sheeting, aluminium steam-
arrestor, and fine-mesh wire-netting.
Avoid these locations:
Metal objects, for example water tanks
230 VAC cables or consumer units
Close proximity to loud speakers
When used, the telephone line to the control panel must be as discrete as possible, and guarded
by a detector.
To ensure that alarm transmission takes priority over other telephone communications, always
position the panel after the exchange line and before all telephone extensions in the home.
If the site is equipped with an ADSL line, use a central ADSL filter after the exchange line
to separate telephone extensions and ADSL extensions.
For mains connection, the panel can be connected either via a socket outlet or directly to
a fused outlet.

Page 9 of 52
02/2011
E
N
G
L
I
S
H
Panel internal layout and connections
1 mounting holes
2 mains connector (J1)
3 X10 connector (J9)
4 output voltage (J8)
5 PSTN connector (J2)
6 optional plug-in module, if fitted
(GSM/GPRS card shown)
7 SIM holder (GSM/GPRS module only)
8 tamper switch
9 status LEDs
10 RJ45 connector
11 microphone
12 external audio enable (J11)
13 call button
14 external antenna power (J14)
15 external antenna connector (J15)
16 external audio power and external
tamper connector (J6)
17 external audio connector (J7)
18 internal antenna
19 built-in speaker
20 battery compartment

Page 10 of 52
02/2011
E
N
G
L
I
S
H
Mount the panel
Prior to starting the installation process call your alarm receiving centre (ARC) and ask them to
ignore any alarms during the installation and setup process.
WARNING: MOUNT THE PANEL SO THE BATTERY TERMINALS ARE AT THE
TOP. ANY OTHER ORIENTATION MAY RESULT IN LEAKS FROM THE BATTERY.
1. Remove the cover from control panel.
2. Hold the panel in its selected mounting position and mark the mounting hole locations, using
the panel as a template.
Note: Ensure the wall is flat enough to compress the tamper switch spring. Use fixings
adequate to support the weight of the panel and battery.
Caution: Do not drill holes with the panel in place.
3. Remove the panel from the wall and drill the mounting holes.
4. Insert the battery in the panel, and then
secure it with the Velcro strap as shown.
Caution: Do not connect the battery
until later.
5. If it is required, install a GSM/GPRS module
(shown), or Ethernet module, in the dashed
area on the drawing.
6. If using GSM communications, fit a SIM card
as shown.
7. Feed the mains and phone wiring through the base of panel, and screw the panel to the wall.

Page 11 of 52
02/2011
E
N
G
L
I
S
H
Wire the panel
Mains wiring must be carried out in accordance with national and local regulations and guidelines.
WARNING: ANY ELECTRICAL WORK ON THE CONTROL PANEL MUST BE
CARRIED OUT BY QUALIFIED PERSONNEL.
CAUTION: DO NOT LEAVE THE BATTERY CONNECTED TO THE CONTROL
PANEL WITHOUT MAINS POWER.
1. Using 2 x 0.75 mm2flexible cable or 2 x 1 mm2
rigid wire, connect the mains wiring and
secure it in place with a cable tie.
Use the second tie point if you route the cable
vertically down and out of the panel.
Caution: To prevent equipment failure,
connect the battery wires to the correct
terminals on the battery.
2. Connect the battery wires.
3. If required, connect a PSTN cable using
the 4-pin Stocko connector.
4. If required, connect an X10 device as shown.
5. If required, connect a remote intercom
terminal (TP800) as shown and described
below. Ensure that jumper J11 (8) is fitted.
J7 connector J6 connector
1 CMD 4 external tamper
2 microphone 5 external tamper
3 speaker 6 −audio power
7 + audio power
6. Switch on the mains supply to the panel.
Follow the next procedure to register the TCU
keypad

Page 12 of 52
02/2011
E
N
G
L
I
S
H
Register the TCU keypad
Refer to the TCU installation instructions before starting this part of the process. Register the TCU
near to the panel so you can hear the audible feedback.
Note: If programming takes longer than 1 hour, replace the TCU battery before handing over
to the end user.
1. Press the tamper switch on the panel until you hear a click,
and then hold for 3 seconds. This places the panel in
programming mode.
2. Insert the battery into the TCU keypad.
3. Press P, the programming switch on the TCU keypad. The
panel will sound an audible beep if registration has been
successful. Replace the battery cover.
4. On the TCU keypad press or to select your
language, and then press . The four main menu
options are displayed.
5. Press to select the PROGRAMMING option.
The ENGINEER: TYPE CODE screen is displayed.
6. Using the keypad, type the engineer code, and then
press . By default the REGISTER option is highlighted.
Note: The code can be found in the list of codes (table
10-Access Codes) at the end of this manual.
Note: If you re-enter programming mode using a registered
TCU keypad, omit the following steps and start modifying
or adding devices.
7. Press to select REGISTER. The word REGISTERING is
displayed on the screen.
8. Press and together. The panel will sound an audible
beep if registration has been successful, and the VIEW
DEVICE screen is displayed.
9. Follow the next procedure to add devices to your system.

Page 13 of 52
02/2011
E
N
G
L
I
S
H
Mount, register and programme devices
Take each wireless device in turn to its mounting position, together with the TCU, and then carry
out the following procedure for each one.
1. Mount the device according to the device's documentation. Do not add the battery
at this time.
2. Press twice to return to the programming submenu,
ensure REGISTER is highlighted, and then press .
The word REGISTERING is displayed on the screen.
3. Insert the battery in the device, according to the device instructions.
4. Press the tamper on the device (check the device
instructions, some devices may not have a tamper). The
serial number, type and radio level are displayed on the TCU.
5. Check the radio level. It should be greater than 3 for devices,
and greater than 4 for audio wireless devices.
6. Place the cover on the device, or place the device on its
socket (refer to the device instructions).
7. Press to display the MODIFY DEVICE menu. Although it
is optional, we recommend you complete the next step and
apply a meaningful label to the device.
8. Press to select LABEL. Press several times to
remove the default label, type a new label, and then
press .
This completes the basic registration of a device, however you can also set the following:
On the MODIFY DEVICE menu, select EDIT to change the device default settings to meet your
system's particular requirements. A list of codes is provided at the end of this manual.
On the MODIFY DEVICE menu, select CHANNEL to change the channel number. This is not
recommended unless specified by your alarm service supplier. By default, channel numbers
are assigned automatically when a device is registered.
Repeat this procedure, as necessary, for all devices in the system.

Page 14 of 52
02/2011
E
N
G
L
I
S
H
Set the date and time
1. On the TCU, press twice to return to the programming
submenu.
2. Press until DATE & TIME is highlighted, and then
press .
3. Enter the date and then the time using the keypad.
If necessary, press or to scroll left or
right and make changes.
Note: The date format is language dependent.
4. Press to save your settings.
Save the configuration
Caution: Do not forget to save your configuration!!
Note: If all the panel LEDs light in succession after saving a configuration, one or more parameters
has been set with an incorrect value. Installation cannot be completed until the values
are corrected.
1. Press several times to highlight SAVE+QUIT.
2. Press .
The SAVE CHANGES message is displayed?.
3. Press .
A PLEASE WAIT message is displayed for a few seconds
before main menu is finally displayed.
4. On the main menu, ensure PROGRAMMING is highlighted,
and then press .
5. Using the keypad, type the engineer code,
and then press .
The programming options are then displayed.
Follow the next procedure to test the installation.

Page 15 of 52
02/2011
E
N
G
L
I
S
H
Test the installation
Use this procedure to make sure the system is programmed and working correctly.
Panel test
1. On the programming submenu, use to highlight
SYSTEM DIAG., and then press .
The PANEL VERSION screen is displayed.
2. Press to display the PANEL STATUS screen.
3. Check that OK appears next to each line.
Note: Tamper will remain as KO until the panel cover is
replaced. If you press and hold the panel tamper switch,
KO will change to OK.
4. Press to display the DEVICES STATUS screen.
5. Check that OK appears next to each line, and then press
to return to the programming submenu.
6. Press to highlight TRANSM. STATUS,
and then press .
7. Check that OK appears next to any installed communication
devices. If a GSM card is installed check that the level is
greater than 15.

Page 16 of 52
02/2011
E
N
G
L
I
S
H
Device communication test
Apply this test to make sure each wireless device communicates with the panel when
it is activated (triggered).
Note: Alarm testing is carried out later.
1. Press to highlight RADIO SCAN, and then press .
WAITING FOR RECEPTION is displayed on the screen.
2. Activate a device (to activate a smoke detector use an
approved testing product). The radio scan test screen
is displayed.
3. Check that there is an RF signal level for the device being tested. It should be greater than
3 for devices, and greater than 4 for audio wireless devices.
4. Press , and repeat the procedure from step 2. until all devices have been activated.
5. Press to quit the test.
Exit programming mode
1. On the programming menu, press to highlight SAVE+QUIT, and then press .
2. On the main menu, press to highlight QUIT, and then press to leave programming
mode.
3. Wait until the TCU screen goes blank.
The TCU is now in User Mode.
Fit the panel cover
When you have installed and tested all of the devices, fit the appropriate blanking plugs to the
panel cover, and then fit the cover to the panel base.

Page 17 of 52
02/2011
E
N
G
L
I
S
H
Register a TAG
To meet the requirements of EN50131-1 a TAG must be used to arm and disarm the system.
Therefore, it may be necessary to register a TAG during the installation process.
Note: We recommend you register a TAG and always use it to arm and disarm the system, even if
it is not a mandatory requirement.
1. On the TCU, press to wake up the keypad, and then press again to
highlight USERS.
2. Press , to access the USERS screen.
3. Press to highlight TAGS, and then press . The
USER ACCESS screen is displayed.
4. Enter the 6-digit Master User Code. The TAGS screen is
displayed, with M (the master user) highlighted.
5. Press to display the TAGS ALLOWED ? message.
6. Press to display the PRESENT TAG message.
7. Place your master TAG close to the TCU keypad TAG reader
(between, and below the and buttons).
The ACCEPT NEW TAG message is displayed?
8. Press to accept the new TAG.
9. The TAG is now registered and can be used to arm and disarm the system.

Page 18 of 52
02/2011
E
N
G
L
I
S
H
Test after arming the system
Although use of a TCU keypad is described here, you can use any Domonial keypad to perform
this test. The and icons vary slightly from one keypad to another.
Generate alarm events
1. Place the TCU keypad in its base.
Note: You cannot arm the Total Set without doing this.
2. On the keypad, press , the Part Set arm button. The PRESENT TAG message is displayed.
3. Place your master TAG close to the keypad TAG reader. The arming process starts to count
down from 60s. At the end of this time the PART SET IS NOW ARMED message is displayed.
4. Activate a device (the alarm will sound).
Note: It is unnecessary to test smoke detectors a second time.
5. Place the TAG to the keypad to disarm the system and cancel the alarm.
6. Reset the device.
7. Repeat the test from step 2 and test the next device. Continue testing until all devices in the
Part Set have been tested.
Repeat the whole process for the remaining devices in the system. To do this, press in step 2.
to arm the Total Set.
View the alarm events
1. Ensure the TCU screen is blank. If not, press .
2. Press or to display the user menu.
3. Press or to highlight the EVENTS menu option,
and then press . The latest event is displayed.
4. Press to scroll back through the events and make sure all the alarms you generated
have been recorded.
5. Press to quit the EVENTS screen.
6. Call your alarm receiving centre (ARC) to verify that they have received the alarm signals.
This concludes the installation. After providing training to the end user, call the ARC and ask them
to start monitoring the installation.

Page 19 of 52
02/2011
E
N
G
L
I
S
H
Specification
Features
3 protected sets (Total, Part, Annex)
Management of wireless peripherals of the Domonial 800 range (HF and M)
Digital transmission format : Secom3, Cesa, Surtec, contact ID
Other format : phone
Built-in and/or external audio half-duplex system
Built-in capability to support wireless audio
8 phone numbers / 6 call cycles
Events log for 1000 events
Built-in siren
Panel tamper on opened cover or off the mounting set-up
Remote parameter feeding from PC and Domodem-GSM; locally from computer
Physical
MTBF
20 years
Dimensions
Height: 183 mm
Width: 235 mm / 295 mm depending on cover
Max depth: 50 mm / 56 mm
Temperature
(EN50130-1 Standard)
Operating: −10°C to +55°C
Storage: −40°C to +70°C
Relative humidity
< 85%
Weight (with battery)
1280 g (2.8 lbs)

Page 20 of 52
02/2011
E
N
G
L
I
S
H
Electrical
Power supply
Ut: 230 V~ 50 Hz, 35 mA (typical)
Mains current at Ut
module not fitted
with GPRS module
Normal: 54 mA
66 mA (Idle)
Calling: 127 mA
202 mA (GSM)
312 mA (GPRS)
Battery
Type: 4 V 3.5 Ah max
Fault: when battery voltage < 3.85 V (fault is reset after
20 minutes of charging)
Battery Life: 40 Hrs (with GSM/GPRS module)
Voltage output
(for audio terminal)
4 V +/−5%, 300 mA max.
250 mA ripple
Radio
Radio frequency
868 MHz (FM narrow band)
Number of channels
Total: 32
Sensors: 30
Keyfobs: 10
Keypads: 4
Sirens: 4 (indoor and outdoor)
Standard*CAMIR/CAMIR-N: 10
IRVPI800M: 5
External trigger** CAMIR/CAMIR-N: 5
Radio jamming detection
Detection of transmission in the band for more than 30s over a
period of 60s
*Taking pictures upon intrusion alarm
** Taking pictures upon intrusion alarm + capability of accepting a trigger signal to take a picture
