Warmbier 7100.181 User manual

Wolfgang WarmbierGmbH & Co. KG
Systeme gegenElektrostatik
UntereGießwiesen21
78247 Hilzingen, Germany
www.warmbier.com
User'sManual
SafetyPips
(7100.181)
ContinuousWrist Strap Monitor

SafetyPips- User's manual
Part No.:7100.181
_
Page 2 of 4V2020-12
nIntroduction
The SafetyPips isacontinuous wriststrap monitor. The person wearingthe wristband is
grounded andcheckedpermanentlybyameasurementofresistance and body capacity.
Even incaseoflowbattery,electrostaticcharges aresafelydissipatedtoground.
When measuring the inputresistance ofthe instrumenttoground,please use avoltage
above 15 Volt becauseofthe 12Volt protection zener diodes fitted inthe instrument.
nInstallation
1.Fixthe SafetyPips attheworking placewherethetwosignalLED'scanbeseen.
2.Connectthe instrument grounding cordtoground.
3.Open the batterycompartment andcontactthebattery.
nOperation
Putonthewriststrapandconnectthe coil cordsnap totheSafetyPipsfrontconnector. The
instrumentisswitchedonby connecting the coil cord.
The SafetyPips monitorstheconnecting cordsand the contactbetween the wriststrap and
the humanskinby testingpermanentlyifthe resistance and the bodycapacityofthe person
wearing thewriststrap iswithinthespecified range.
Battery
compartment
LEDindicator
Wrist strap connector
with 10
mm snap
Illustration:
Optionalbracket forfixing the instrument
undera work bench (Part no.: 7100.181.H)

SafetyPips- User's manual
Part No.:7100.181
_
Page 3 of 4V2020-12
nSignalsandpossibleerrorconditions
Green
LEDflashes
Resistance andcapacityareinthe ratedrange
RedLEDflashes insyncwithbuzzer
Reason:
The measured resistanceistoohigh
Measures:
Check ifthe wriststrap isfixed tighttotheskin
Check if grounding wireorthe coil cordarebroken
RedLEDand buzzerarepermanent on
Reason:
The measured resistanceistoolow
Measures: Check ifthe coil cordcontains asafetyresistor
Check for aninsulation failure
or atobigcapacitytoconductive tablemats
NoLEDindication andno power-onbeep
Reason:
Batteryempty
Measures: Replace the battery
nCalibration
ACalibration Unit isavailabletocheck the SafetyPips
correctfunction and values (Partno.: 7100.181.C)
nModelsand accessories
Availablemodels:
Part No. Description
7100.181 SafetyPips with10mm snap, grounding cordwith4mmring
terminal
7100.181.K SafetyPips withrelay output, 230Vpowersupply,
without audiblealarm
Availableaccessories:
Part No. Description
7100.181.C
Calibration Unit for SafetyPips
7100.181.H Mounting bracketforSafetyPips
7100.181.103 Power supply230VAC/9VDC for SafetyPips with
Part-No.:7100.181

SafetyPips- User's manual
Part No.:7100.181
_
Page 4 of 4V2020-12
nTechnicaldata
Power supply: 9Vbatteryaccording toIEC/DIN6F22
Batterylife: > 1year (for8operating hoursperday, passindicator active)
Connectors: 10 mmsnap forcoil cords
Test voltage (open circuit) DC < 0,01 Volt
AC < 4,00 Volt
Test current at1,0MWload: DC < 0,01 µA
AC < 1,00 µA
Case: ABS, black,dissipative (except thenameplate)
Operating conditions: Temperaturerange:+ 10°C to+ 40°C
Relative humidity: 20%to80 %
Dimensions: 125 x60x26 mm
Weight: app. 140g (including the battery)
nInputimpedances
Pass (greenLEDflashing)
Lower rated value: 1MOhm- 10%
Upper rated value: 100 pF± 10%+2MOhm± 10%
Faultcondition(redLEDand beep)
Lower rated value (permanentred): < 400KOhm
Upper rated value (flashing red): > 5MOhm
nWastedisposal
According toWEEEDirective 2012/19/EU the device ismarkedwiththissymbol.
Thisdevice mustthereforenot bedisposed of withthehouseholdwaste.
Batteries or rechargeablebatteries must bedisposed atthearranged collection pointsor
according tothe relevantnationalguidelines.
