Warren Controls 2800 Series Instructions for use

This document covers the installation, operation and maintenance
of the Series 2800 Precision Globe Control Valves presented in the
“Series 2800 Product Specification”, including the 2820 Two-Way
Single Seat Valve, the 2828 Two-Way Single Seat Low Flow Valve, the
2830 Three-Way Mixing Valve, and the 2832 Three-Way Diverting/
Mixing Valve. Warren Controls Series 2800 Precision Globe Control
Valves feature rugged bronze or stainless steel bodies with a variety
of trim materials and port sizes. The equal percentage and linear
plugs in the 2-way valves and linear plugs in the 3-way valves
provide excellent modulating control of a wide variety of fluids
for pressure, temperature, level, and flow applications from –20 to
500ºF (dependent on contruction). The Series 2800 is ideally suited
where value and long life are important objectives for applications
including but not limited to the Chemical, Food & Beverage, General
Service, Refining, District Energy, and ideal for Pharmaceutical
Industries.
The instructions given herein cover generally the operation and
maintenance of subject equipment. Should any questions arise
which may not be answered specifically by these instructions,
they should be referred to Warren Controls Inc. for further detailed
information and technical assistance. This manual cannot possibly
cover every situation connected with the operation, adjustment,
inspection, test, overhaul and maintenance of the equipment
furnished. Every effort is made to prepare the text of this manual
so that engineering and design data is transformed into the most
easily understood wording. Warren Controls Inc., in furnishing this
equipment and this manual, must presume that the operation and
maintenance personnel assigned thereto have sufficient technical
knowledge and experience to apply sound safety and operational
practices which may not be covered herein. In applications where
Warren Controls Inc. furnished equipment is to be integrated with a
process or other machinery, these instructions should be thoroughly
reviewed to determine the proper integration of the equipment into
the overall plant operational procedures. Warren Controls does not
assume responsibility for the selection, use, or maintenance of any
product. Responsibility for proper selection, use, and maintenance
of any Warren Controls product remains solely with the purchaser
and end-user.
PRODUCT OVERVIEW
GENERAL INFORMATION
2800 IOM
TABLE OF CONTENTS
Overview ................................................Cover
Valve Identification.................................. 2-3
Information Present on Valve............... 4-5
Body vs. Application....................................6
Dimensions & Weights................................ 7
Installation & Operation......................... 8-9
Maintenance ...............................................10
Packing Adjustment..................................10
Parts/Overhaul ............................................10
Parts Kits ................................................. 11-16
Drawings................................................. 17-30
Installation Instructions & Maintenance Document
Series 28OO
PRECISION GLOBE CONTROL VALVES
2800_IOM_RevBa_1219

22600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
Series 2800 Precision Globe Control Valves are available with a
variety of actuators and accessories. These actuators and accessories
have separate instructions. For complete control valve installation,
operation, and maintenance instructions see also the instructions
for the actuator and accessories in use.
VALVE IDENTIFICATION
To use these instructions it is necessary to identify the configuration
of the valve. Factory assembled control valves have a nameplate
mounted on the actuator. The valve’s part number (P/N) is present
on the plate. The part number represents the configuration of the
control valve. To identify the valve’s type, size, actuator, accessories,
and other characteristics decode the part number using configura-
tion table. If the information is incomplete, incorrect, or not pres-
ent contact the factory with the valve serial number listed on the
plate. (See Information Present on Control Valves section for location
of part number, serial number, and other important information on
valve.)
ACTUATORS AND ACCESSORIES
Valve
Type Size
Body Ma
terial
End
Connection Trim Style Trim Material Trim Cv
20 2-Way
Single Seat
28 2-Way
Lo-Flow
30 3-Way
Mixing
32 3-Way
Diverting
050 1/2 inch
075 3/4 inch
100 1 inch
125 1-1/4
inch
150 1-1/2
inch
200 2 inch
B Bronze
F CF8M
S Screwed
B SCH 40
Buttweld End
F Full Port
1 1st Port
Reduction
2 2nd Port
Reduction
3 3rd Port
Reduction
4 4th Port
Reduction
NOTE:
Port reductions
only available on
Type 20/28/30.
Check factory for
availability.
Model
Packing Type
T Teflon
G Graphite
V Vacuum Service
L EPDM
Stainless Steel,
Type 20 Bodies
come standard w/
PEEK bearings. Used
for Temp. up to
500°F.
VALVE BODY
28N
E Equal %
L Linear
M Mod Lin
Types 30/32,
Linear Only
Types 28
Mod Lin Only
S 316SS *
B Bronze
6 Alloy 6
H 17-4 PH
T Teflon
P PEEK
NOTE:
* Type 28, 316SS
trim uses
harder
Nitronic
60 seat.
TEMPERATURE LIMITS
Valve
Type
Body
Material
& Code Trim Material & Code Packing Type & Code T MAX T MIN
20 2-Way
Single Seat
Bronze B316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK PEPDM L350ºF -20ºF
Bronze B316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK PTeflon T, Vacuum Service V400ºF 32ºF
Bronze B316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK PGraphite G400ºF -20ºF
CF8M F316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK PEPDM L350ºF -20ºF
CF8M F316 S, Alloy 6 6, 17-4 PH H, Teflon T, PEEK PTeflon T, Vacuum Service V450ºF 32ºF
CF8M FTeflon T, PEEK PGraphite G450ºF -20ºF
CF8M F316 S, 17-4 PH H, Alloy 6 6Graphite G500ºF -20ºF
28 2-Way
Low Flow
Bronze B316 S, Teflon T, PEEK PEPDM L350ºF -20ºF
Bronze B316 S, Teflon T, PEEK PTeflon T, Vacuum Service V400ºF 32ºF
Bronze B316 S, Teflon T, PEEK PGraphite G400ºF -20ºF
CF8M F316 S, Teflon T, PEEK PEPDM L350ºF -20ºF
CF8M F316 S, Teflon T, PEEK PTeflon T, Vacuum Service V450ºF 32ºF
CF8M FTeflon T, PEEK PGraphite G450ºF -20ºF
CF8M F316 SGraphite G500ºF -20ºF
30 3-Way
Mixing
Bronze B316 SEPDM L350ºF -20ºF
Bronze B316 STeflon T, Vacuum Service V400ºF 32ºF
Bronze B316 SGraphite G400ºF -20ºF
CF8M F316 SEPDM L350ºF -20ºF
CF8M F316 STeflon T, Vacuum Service V450ºF 32ºF
CF8M F316 SGraphite G500ºF -20ºF
32 3-Way
Diverting
Bronze BBronze BTeflon T, Vacuum Service V300ºF 32ºF
Bronze BBronze BGraphite G, EPDM L300ºF -20ºF
CF8M F316 SEPDM L350ºF -20ºF
CF8M F316 STeflon T, Vacuum Service V450ºF 32ºF
CF8M F316 SGraphite G500ºF -20ºF

3
Series 2800 2800_IOM_RevBa_1219
Actuator
Series Action Spring Range Handwheel Positioners, I/P’s & Limit Switches
Air Filter
Regulators
Special
Options
ASCO
Solenoids
0 None
R Reverse
Stem
Fail
Down
D Direct
Stem
Fail Up
00 None
DIAPHRAGMS:
49 DL49
(49 Sq.In.)
4X DL49XR
84 DL84
(84 Sq.In.)
8X DL84XR
(84 Ext.Rng.)
NOTE :
4X & 8X Only
in Xtra-High
Spring Range.
4X & 8X
verseActing for
2-Way Valves.
8X Directed
Acting for
3-Way Valves.
0 None
L Low 4-10 PSI
49R ; 3-9 PSI
49D, 84R/D
F Full 5-14 PSI
49R ; 4-13 PSI
49D; 3-15 PSI
84R/D
H High 9-15
PSI 84;115
10-14 PSI 49R
8-12 PSI 49D
X Xtra-High
DL49XR,
DL84XR
0 None
R Reverse
D Direct
NOTE :
Must match
action.
0 None
A Type 300,
0-30 PSI,
5 micron
Filter
B Type 300,
0-60 PSI
5 micron
Filter
D Type 350SS,
0-100 PSI,
25 micron
Filter
ACCESSORIES
0 None
120 VAC
COILS
A 8320G184
3-Way Brass
B 8320G202
3-Way SS
L EF8320G184
3-Way
EXP Br.
M F8320G202
3-Way
EXP SS
24 Vdc
COILS
Z 8320G184
3-Way Brass
ACTUATOR
ACTUATOR/BODY COMPATIBILITY:
Warren Controls does not assume responsibility for the selection, use, or maintenance of any
product. Responsibility for proper selection, use, and maintenance of any Warren Controls
product remains solely with the purchaser and end-user.
0 None
S Special
Opts or
Set-up
T SS Tubing
G SS Tagging
B SS Tubing
and Tagging
Note: Standard
pneumatic tubing is
copper. SS tubing “T”
is optional.
SS tagging “G” (Two
lines, 24 characters/
line) is optional.
SS tubing and
tagging together “B”
is optional.
0000 None
PosItioners :
2xP_ BLX Pneumatic
2xE_ BLX ElectroPneumatic
2xI_ BLX ElectroPneu. Intrn. Safe
2xX_ BLX ElectroPneu. Exp. Proof
2xF_ BLX ElectroPneu. Fail Freeze
76P_ Moore760 Pneumatic *
76E_ Moore760 Electro-Pneumatic *
TOZO ABB TZIDC 4-20mA.
*
THN_ ABB TZIDC 4-20mA w/HART
Intrn. Safe & Non-Incend
*
TPN_ ABB TZIDC PROFIBUS PA
Intrn. Safe & Non-Incend.
TFN_ ABB TZIDC FOUNDATION
Fieldbus Intrn. Safe & Non-
Incend.
THX_ ABB TZIDC 4-20mA w/HART
Exp. Proof
*
TPX_ ABB TZIDC PROFIBUS PA
Exp. Proof
TFX_ ABB TZIDC FOUNDATION
Fieldbus Exp. Proof
PROXIMITY SWITCHES:
PX11 Mark 1 Series - 2 ea. SPDT
PX12 Mark 1 Series - 2 ea. SPDT
w/2k Pot.
PX13 Mark 1 Series - 2 ea. SPDT
w/4-20 Feedback
PX14 Mark 1 Series - 4 ea. SPDT
PX15 Mark 1 Series - 6 ea. SPDT
I/P’s Use with Diaphragm Only
MAP1 Type 500X I/P, 3-9 PSI
MAP2 Type 500X I/P, 9-15 PSI
MAP3 Type 500X I/P, 3-15 PSI
MAP4 Type 500X I/P, 1-17 PSI
MAP5 Type 500X I/P, 6-30 PSI
MAP6 Type 550X I/P, 0-30 PSI
MAP9 Type 950X I/P, 3-15 EXP
0 No Additions
L w/Mech. Limit Swtitch’s
F w/4-20 Feedback
B w/Switch’s & Feedback
Note: L, F & B not
available for Bxl or BxX
4th digit spec.
F Full Range Signal,
3-15 PSI or 4-20mA
L Low of Split Range,
3-9 PSI or 4-12m A
H High of Split Range,
9-15 PSI or 12-20mA
xdigit spec.
4th digit spec.
* Available with Split
Ranges, Select “S” in
Special Options
FAILURE MODES:
MODE VALVE TYPE ACTUATOR ACTION
Closed 20/28 Reverse
Open 20/28 Direct
Upper Closed* 30/32 Direct
Upper Open 30/32 Reverse
*Standard
DIAPHRAGMS BODY
49 49 Sq.In. (DL49) For 28N Bodies
4X (DL49XR) For 28N Bodies
84 84 Sq.In. (DL84) For 28N Bodies
8X (DL84XR) For 28N Bodies
Individual Options
0No Additions
Fw/4-20 Feedback Module (4-
20mA w/HART Models ONLY)
Kw/Digital Position Feedback
Module (4-20mA w/HART Models
ONLY)
Lw/ 24VDC/AC Micro-Switch’s
(Exp. Proof Models ONLY)
Pw/Proximity Switch’s NC
Option Combinations (For
4-20mA w/HART Models ONLY)
A = F &K
B = F &L (Exp. Proof Models
ONLY)
C = F &P
E = K &L (Exp. Proof Models
ONLY)
G = K &P
J = F &K &L (Exp. Proof
Models ONLY)
M = F &K &P
See Actuators, Positioners, &
Accessories. Section of Product
Specication for details.

42600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
There is a great deal of information present on each control valve
ranging in importance from the part number and serial number to
the color of the paint and casting numbers. This information is im-
portant for identifying the valve, installing it correctly, and obtaining
parts. Examples of the current factory nameplates and flow arrow
plates used on Series 2800 control valves are shown here. The ac-
companying table identifies the information present and where to
find it on the control valve. There may also be other casting numbers
and foundry marks present that do not provide useful information.
Customer specific tagging may also present. The plates used, and
information present, on Warren Controls other product lines or older
valves may be different, contact the factory for details.
ACTUATOR NAMEPLATES
VBA NAMEPLATES
2-WAY 1/2 THRU 1 INCH • 2800 S/S VBA
3-WAY MIXING 1/2 THRU 1 INCH • 2800 S/S VBA
INDUSTRIAL VBA
INFORMATION PRESENT ON CONTROL VALVES
DL84 DL49

5
Series 2800 2800_IOM_RevBa_1219
PART NUMBER & SERIAL NUMBER
Information Symbol(s) Location Notes
Part number
(Configuration)
P/N On actuator • On Actuator Nameplate attached to leg(s) of actuator.
Serial number S/N On actuator
and
valve body
• On Actuator Nameplate attached to leg(s) of actuator.
• Sales order Number only stamped on valve body end connection (2800).*
*Number stamped using approximately 1/8 inch tall characters
FLOW DIRECTION(S)
Information Symbol(s) Location Notes
Flow direction
through valve
On valve body • On 2800 S/S VBA Nameplate attached to mounting boss on valve body
between the end conections (2800 S/S valves ½ thru 1 inch except S/S 2832).
• Arrow cast on valve body between the end connections (2800 S/S 2-way 1-1/4 thru 2
inch).
Inlet location INLET On valve body • Stamped on valve body inlet end connection (2-way 2800 bronze valves ½ thru 2 inch &
S/S valves 1-1/4 thru 2 inch).
Port locations
for 3-way valves
Uupper port,
Llower port,
Ccommon
port
On valve body • U, L, & C stamped on valve body end connections (3-way 2800 bronze valves ½ thru 2
inch & 3-way 2800 S/S valves 1-1/4 thru 2 inch & 1 inch S/S 2832).
INPUT SIGNAL & SUPPLY
Information Symbol(s) Location Notes
Input signal SIG On actuator • On Actuator Nameplate attached to leg(s) of actuator.
Supply pressure SUP or
SUPPLY
On actuator • On Actuator Nameplate attached to leg(s) of actuator.
VALVE ATTRIBUTES
Information Symbol(s) Location Notes
Maximum
temperature rating
of valve body
TMAX or
Tmax
On actuator
and
valve body
• On Actuator Nameplate attached to leg(s) of actuator.
• On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-1/4
thru 2 inch, & 1 inch except S/S 2832).
• On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except
1 inch S/S 2832).
Trim Cv
(Flow coefficient)
Cv On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate (2800 bronze valves ½ thru 2 inch & 2800 S/S valves 1-1/4
thru 2 inch, & 1 inch S/S 2832).
• On 2800 S/S VBA Nameplate attached to valve body between the end connections on
side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except 1 inch S/S 2832).
Trim style
(Characteristic)
CHAR On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate. (2800 bronze valves ½ thru 2 inch & 2800 S/S valves
1-1/4 thru 2, & 1 inch S/S 2832).
Trim material TRIM MATL On valve body • On Industrial VBA Nameplate wired to valve body between the end connections on
side opposite flow arrow plate. (2800 bronze valves ½ thru 2 inch & 2800 S/S valves
1-1/4 thru 2 inch, & 1 inch S/S 2832).
Valve size SIZE On valve body • On 2800 S/S VBA Nameplate attached to mounting boss on valve body between the
end connections on side opposite flow arrow plate (2800 S/S valves ½ thru 1 inch except
1 inch S/S 2832).
Valve body material On valve body • If CF8M is cast on the valve the valve body material is 316 stainless steel.
INFORMATION PRESENT ON CONTROL VALVE

62600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
BODY STYLE VERSUS APPLICATION
2828 2-Way Single Seat Low Flow
Unbalanced Valve
Low Flow Trim with ANSI Class IV and VI leakage rates.
Sizes: 1/2, 3/4, 1 inch
Body: ANSI B16.15 Bronze 250LB Threaded (NPT), 316
Stainless Steel 300LB Threaded (NPT), or 316 Stainless
Steel 300LB SCH 40 Buttweld (BWE) Stainless Steel
body valves contain Fluoraz 797 O-Ring upper and
lower body seals.*
Trim: Modified Linear, 316 Stainless Steel, TFE, or PEEK
Leakage Rates: ANSI Class IV (Stainless Steel Trim),
ANSI Class VI (TFE and PEEK Trim)
Packing: Long-Life Multi-Stack EPDM Lip Packing (-20 to 350°F)
Guided Low-Friction TFE V-Ring, Spring Loaded (+32
to 450°F), Adjustable Graphite Packing (-20 to 500°F)
Temperature: -20 to 400°F (Bronze 250LB Threaded Body)
-20 to 450°F (316 Stainless Steel 300LB Threaded or
Buttweld Body w/ TFE or PEEK Trim)
-20 to 500°F (316 Stainless Steel 300LB Threaded
Body or Buttweld Body w/ Stainless Steel Trim)
Rangeability: 40:1 for Cv 1.00 and 0.50.
20:1 for Cv 0.25
2820 2-Way Single Seat Unbalanced Valve
The most commonly applied solution with ANSI Class IV and VI leakage
rates.
Sizes: 1/2, 3/4, 1, 1-1/4, 1-1/2, 2 inch
Body: ANSI B16.15 Bronze 250LB Threaded (NPT), or 316
Stainless Steel 300LB Threaded (NPT), or 316 Stainless
Steel 300LB SCH 40 Buttweld (BWE) Stainless Steel
body valves contain Fluoraz 797 O-Ring upper and
lower body seals.*
Trim: EQ% or Linear, 316 Stainless Steel, Alloy 6, TFE, PEEK,
or 17-4 PH Hardened Stainless Steel
Leakage Rates: ANSI Class IV (Stainless Steel and Alloy 6 Trim), ANSI
Class VI (TFE and PEEK Trim)
Packing: Long-Life Multi-Stack EPDM Lip Packing (-20 to 350°F)
Guided Low-Friction TFE V-Ring, Spring Loaded (+32
to 450°F), Adjustable Graphite Packing (-20 to 500°F)
Temperature: -20 to 400°F (Bronze 250LB Threaded Body)
-20 to 450°F (316 Stainless Steel 300LB Threaded or
Buttweld Body w/ TFE or PEEK Trim)
-20 to 500°F (316 Stainless Steel 300LB Threaded or
Buttweld Body w/ Stainless Steel or Alloy 6 Trim)
Rangeability: 50:1
2830 3-Way Mixing Valve
This valve has two inlets and one outlet, and is the simplest solution
for mixing or bypass applications with an ANSI Class IV leakage rate. In
normal applications the inlet pressures are near equal and control is
possible from 5% to 95% of travel with inlet pressures up to 100 PSI.
Sizes: 1/2, 3/4, 1, 1-1/4, 1-1/2, 2 inch
Body: ANSI B16.15 Bronze 250LB Threaded (NPT), or 316
Stainless Steel 300LB Threaded (NPT), or 316 Stainless
Steel 300LB SCH 40 Buttweld (BWE) Stainless Steel body
valves contain Fluoraz 797 O-Ring upper and lower
body seals.*
Trim: Linear, 316 Stainless Steel
Packing: Long-Life Multi-Stack EPDM Lip Packing (-20 to 350°F)
Guided Low-Friction TFE V-Ring, Spring Loaded (+32 to
450°F), Adjustable Graphite Packing (-20 to 500°F)
Temperature: -20 to 400°F (Bronze 250LB Threaded)
-20 to 500°F (316 Stainless Steel 300LB Threaded or
Buttweld)
Rangeability: 50:1
2832 3-Way Diverting/Mixing Valve
Designed as a diverting valve with one inlet and two outlets with ANSI
Class III leakage rate. However, flow can be reversed for mixing if this port
configuration is desirable. The difference between the upper port and
lower port pressure must not exceed 50 PSID.
Sizes: 1, 1-1/2, 2 inch
Body: ANSI B16.15 Bronze 250LB Threaded (NPT), or 316
Stainless Steel 300LB Threaded (NPT), or 316 Stainless
Steel 300LB SCH 40 Buttweld (BWE) Stainless Steel body
valves contain Fluoraz 797 O-Ring upper and lower
body seals.*
Trim: Linear, Bronze (Bronze 250LB Threaded), or 316 Stainless
Steel (316 Stainless Steel 300LB Threaded or
Buttweld)
Packing: Long-Life Multi-Stack EPDM Lip Packing (-20 to 350°F)
Guided Low-Friction TFE V-Ring, Spring Loaded (+32 to
450°F), Adjustable Graphite Packing (-20 to 500°F)
O-Ring: EPR (Bronze 250LB Threaded), Fluoraz 797 (316
Stainless Steel 300LB Threaded or Buttweld)
Temperature: -20 to 300°F (Bronze 250LB Threaded)
-20 to 500°F (316 Stainless Steel 300LB Threaded or
Buttweld)
Rangeability: 50:1
Stem Down
The upper port opens
and the lower port closes
Upper PortLower Port
Common Port
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Lower Port
Common Port
Flow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortCommon Port
Lower Port
Flow
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Common Port
Lower Port
Flow
Flow Flow
Stem Down
The valve closes
Stem Up
The valve opens
FlowFlow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortLower Port
Common Port
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Lower Port
Common Port
Flow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortCommon Port
Lower Port
Flow
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Common Port
Lower Port
Flow
Flow Flow
Stem Down
The valve closes
Stem Up
The valve opens
FlowFlow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortLower Port
Common Port
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Lower Port
Common Port
Flow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortCommon Port
Lower Port
Flow
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Common Port
Lower Port
Flow
Flow Flow
Stem Down
The valve closes
Stem Up
The valve opens
FlowFlow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortLower Port
Common Port
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Lower Port
Common Port
Flow
Stem Down
The valve closes
Stem Up
The valve opens
Stem Down
The upper port opens
and the lower port closes
Upper PortCommon Port
Lower Port
Flow
Flow Flow
Stem Up
The upper port closes
and the lower port opens
Upper Port Common Port
Lower Port
Flow
Flow Flow
Stem Down
The valve closes
Stem Up
The valve opens
FlowFlow
Stem Down
The valve closes
Stem Up
The valve opens
2-WAY VALVES
(Control of Liquids, Gases, and Steam)
3-WAY VALVES
(Control of Liquids)
*NOTE: Fluoraz is NOT compatible with the following solvents: acetates, acetone,
benzene, carbon tetrachloride, ethers, Freons, ketons, lacquers, methyl ethyl ke-
tone, toluene.

7
Series 2800 2800_IOM_RevBa_1219
DIMENSIONS & WEIGHTS
1/2, 3/4, 1 1-1/4 & 1-1/2 2
A 250THD 4-7/8 5-3/4 6-1/2
300THD5 6-1/8 6-1/2
300BWE 15-3/8 16-7/817
B 250THD 2-3/4 3-1/4 3-5/8
300THD & BWE3 3-1/2 3-7/8
C 250THD 2-7/8 3-1/2 3-3/4
300THD & BWE 2-7/8 3-1/2 3-3/4
Dimension (IN)
2820
Weight (LB) 250THD 8-1/2 14-1/2 18-1/2
300THD8 15-1/219
300BWE 9-1/218 22-1/2
*Includes 1-3/8 inch for air fitting on direct acting diaphragm actuators
CF = Consult factory
Face to face dimensions conform to
Historical Warren Controls standard and
are NOT ANSI/ISA compatible.
Dimensions & Weights
2-Way or 3-Way
w/ DL49 or 49XR
2-Way or 3-Way
w/ DL84 or 84XR
Allow 4-7/8 inch clearance above actuator
for removal.
Actual shipping weights may vary.
Valve Size (IN)
1/2, 3/4, 11-1/4 & 1-1/22
A 250THD 4-7/85-3/4 6-1/2
300THD 56-1/8 6-1/2
300BWE 15-3/8 16-7/817
B 250THD 2-23/32 3-13/164
300THD 2-23/32 3-3/8 3-3/4
300 BWE8 8-3/49
C 250THD 2-7/83-1/2 3-3/4
300THD & BWE2-7/8 3-1/23-3/4
Dimension (IN)
2830
Weight (LB) 250THD 9 15-1/220
300THD 815 18-1/2
300BWE 10-1/2 19 23-1/2
Valve Size (IN)
11-1/2 2
A 250THD 4-7/85-3/4 6-1/2
300THD 56-1/8 6-1/2
300BWE 15-3/8 16-7/817
B 250THD 3-15/32 3-13/164
300THD 2-23/32 3-3/8 3-3/4
300 BWE8 8-3/49
C 250THD 2-7/83-1/2 3-3/4
300THD & BWE2-7/8 3-1/23-3/4
Dimension (IN)
2832
Weight (LB) 250THD 9 16-1/221
300THD 816 19-1/2
300BWE 10-1/2 20 24-1/2
Valve Size (IN)
1/2, 3/4, 1
A 250THD 4-7/8
300THD5
300BWE 15-3/8
B 250THD 2-3/4
300THD & BWE3
C 250THD 2-7/8
300THD & BWE 2-7/8
Dimension (IN)
2828
Weight (LB) 250THD 8-1/2
300THD8
300BWE 9-1/2
Valve Size (IN)
8
2600 Emrick Blvd., Bethlehem, PA 18020-8010 www.WarrenControls.com
Te l: 800-922-0085 or 610-317-0800 Fax: [phone]
DL49 Direct 11 6-3/8 12-1/4 16 25 CF
DL49 49XR Reverse 11 6-3/811-1/4 13-3/425CF
DL84 Direct 13-7/88-1/8 16-3/424-1/8 48-1/2CF
DL84 84XR Reverse 13-7/8 8-1/85-3/4 24 48-1/2 CF
Actuator
H MAX (IN) WEIGHT (LB)
HTIWHTIW)ni(d)ni(D
ACTUATOR HANDWHEEL STD*HANDWHEEL STD HANDWHEEL
Top mounted
Handwheel
Valve shown with DL49 Actuator as typical.
For additional actuator information see Series 2800 Product Specification and
the Installation Operation and Maintenance Instructions for the actuator in use.
DIMENSION (IN)
2820
VALVE SIZE (IN)
1/2, 3/4,
1
1-1/4 &
1-1/2 2
A
250THD 4-7/8 5-3/4 6-1/2
300THD 5 6-1/8 6-1/2
300BWE 15-3/8 16-7/8 17
B250THD 2-3/4 3-1/4 3-5/8
300THD & BWE 3 3-1/2 3-7/8
C250THD 2-7/8 3-1/2 3-3/4
300THD & BWE 2-7/8 3-1/2 3-3/4
Weight (LB)
250THD 8-1/2 14-1/2 18-1/2
300THD 8 15-1/2 19
300BWE 9-1/2 18 22-1/2
DIMENSION (IN)
2830
VALVE SIZE (IN)
1/2, 3/4, 1 1-1/4 & 1-1/2 2
A
250THD 4-7/8 5-3/4 6-1/2
300THD 5 6-1/8 6-1/2
300BWE 15-3/8 16-7/8 17
B
250THD 2-23/32 3-13/16 4
300THD 2-23/32 3-3/8 3-3/4
300BWE 8 8-3/4 9
C250THD 2-7/8 3-1/2 3-3/4
300THD & BWE 2-7/8 3-1/2 3-3/4
Weight (LB)
250THD 9 15-1/2 20
300THD 8 15 18-1/2
300BWE 10-1/2 19 23-1/2
DIMENSION (IN)
2828
VALVE
SIZE (IN)
1/2, 3/4, 1
A
250THD 4-7/8
300THD 5
300BWE 15-3/8
B250THD 2-3/4
300THD & BWE 3
C250THD 2-7/8
300THD & BWE 2-7/8
Weight (LB)
250THD 8-1/2
300THD 8
300BWE 9-1/2
DIMENSION (IN)
2832
VALVE SIZE (IN)
1 1-1/2 2
A
250THD 4-7/8 5-3/4 6-1/2
300THD 5 6-1/8 6-1/2
300BWE 15-3/8 16-7/8 17
B
250THD 3-15/32 3-13/16 4
300THD 2-23/32 3-3/8 3-3/4
300BWE 8 8-3/4 9
C250THD 2-7/8 3-1/2 3-3/4
300THD & BWE 2-7/8 3-1/2 3-3/4
Weight (LB)
250THD 9 16-1/2 21
300THD 8 16 19-1/2
300BWE 10-1/2 20 24-1/2
Face to face dimensions conform to Historical
Warren Controls standard and are NOT ANSI/ISA
compatible.
Actual shipping weights may vary.
TRIM
MATERIALS
FLOWING
DIFFERENTIAL
PRESSURE
LIMIT
Bronze 50 PSID
316 Stainless Steel 100 PSID
TFE 100 PSID
PEEK 100 PSID
17-4 pH
Hardened Steel 200 PSID
Alloy 6 300 PSID
Pressure reatings are PSIG
For applications below 32° consult factory.
For applications above 375°, 300THD Stainless
Steel Body is recommended.
BODY PRESSURE-
TEMPERATURE RATINGS:
Temperature
(F)
250 THD
Bronze
300
THD&
BWE SS
+32° To 100°F 400 720
150° 400 670
175° 392 645
200° 385 620
225° 375 605
250° 365 590
275° 350 575
300° 335 560
325° 317 548
350° 300 537
375° 275 526
400° 250 515
450° - 497
500° - 480

82600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
See also separate actuator and accessory instructions for addi-
tional installation guidelines.
• Be sure that the flow medium, ambient temperature and the selected loca-
tion will not exceed the maximum temperature of the valve, actuator, or ac-
cessories. Information can be found in the product specifications and on the
nameplate(s) regarding these limits (See Information Present on Control Valves
section for location of important information on valve).
• Follow good piping practices. Install a bypass around the valve. Install stop
valves in inlet and outlet piping to provide means to isolate valve.
• A straight run of pipe is recommended for 10 pipe diameters upstream of the
valve and 20 pipe diameters downstream of the valve.
• Protect valve and downstream equipment with a self-cleaning strainer.
• Provide proper inlet and outlet drainage in steam service to prevent water
hammer or possible erosion in equipment.
• Install gauges in inlet and outlet piping to provide means for checking adjust-
ment and operation.
• For maximum efficiency and minimum wear install valve in vertical position
with the stem pointing upward.
• Actuators mounted in any position other than vertical must be supported inde-
pendent of the valve.
• Be sure to leave clearance to allow for actuator removal (See Dimensions &
Weights section of Product Specification for actuator removal clearance).
• Before installing, be sure valve and piping are clean inside and free of scale,
chips, welding spatter, and foreign material. Thoroughly blow out or flush pipe
lines.
• The valve must be installed with the fluid flowing in the correct direction(s). For
proper operation in all applications, control valves must be piped according to
the corresponding flow arrows, inlet markings, and port markings present on
each valve (See Information Present on Control Valves section for location of
important information on valve).
• Pipes must be aligned squarely with the valve at each connection.
• If the valve has screwed ends, do not apply pipe dope to the threads of the
valve body or to the first two threads of the pipe.
• If the valve has flanged ends, tighten flange bolts evenly to prevent excessive
stress and the possibility of cracking.
• If the valve has welded ends, prevent plug and cage distortion by keeping ex-
cess heat from the body.
!
Check valve for any
damage due to improper
storage or transportation.
Immediately notify your
sales organization of any
damaged goods upon
receipt. Do not attempt to
move or disturb the valve
further so photos may
be taken. If the shipping
container is noticeably
damaged refuse receipt,
as the shipping company
should be held liable until
a shipping representative
is available to take photos.
INSTALLATION

9
Series 2800 2800_IOM_RevBa_1219
• The valve, actuator, and accessories (if so equipped) are assembled, tested, and
calibrated at the factory. The actuator nameplate specifies set-up parameters
used (See Information Present on Control Valves section for location of impor-
tant information on valve). Do not exceed the supply pressure listed on the
actuator nameplate or you will damage the valve and void the warranty.
• Supply air or voltage, instrument signal, and accessories should be connected
to ports or terminals as indicated on the control valve.
• Final tuning may be required under actual operating conditions.
• On critical or dangerous equipment, provide suitable safety and emergency
systems to protect personnel and property from injury due to a valve malfunc-
tion. If the valve handles flammable, toxic, corrosive or explosive fluids, pro-
vide for safety in the event of valve leakage or malfunction.
• Do not obscure flow arrow plates or nameplates with paint. If flow arrow plates
or nameplates will be covered with insulation, it is recommended the informa-
tion on the plates be transcribed on the outside of the insulation in the same
location as the plate.
OPERATION
• Close inlet and outlet stop
valves.
• Check that valve responds
through rated travel in re-
lation to changes in input
signal. Rated travel is shown
by position of travel indica-
tor on valve stem relative to
travel indicator on yoke.
• For valves fitted with a
handwheel, manually oper-
ate valve using handwheel
through rated travel to
check freedom of move-
ment. Return handwheeel to
its standby position.
• Place valve in operation.
INSTALLATION CONT.

10 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
Series 2800 Precision Globe Control Valves are for the most part
maintenance free when properly selected and installed. Rebuild-
ing of these valves should not be necessary under normal operat-
ing conditions. For best operation follow installation guidelines (See
Installation section); maintain the fluid pressure, temperature, flow,
flowing differential pressure, and shut-off differential pressure within
the limits of the valve (See Series 2800 Product Specification for de-
tails). In installations where high vibration exists, pneumatic and/or
electrical connections should periodically be checked for integrity. In
water or water and glycol applications, good water quality must be
maintained or the service life of the valve may be reduced (See Water
Quality Guidelines). The valve stem must be kept free of debris, de-
posits, dirt, dust, and scratches or the packing parts may be damaged
resulting in a packing leak. Control valve hunting will cause excessive
stroking of the valve stem and result in premature failure of the pack-
ing seal. The system must be stabilized to prevent hunting to ensure
reasonable packing life and optimal control performance. Oversizing
of a control valve will result in an unstable condition, which can cause
noise, vibration, and premature trim and packing seal failure. The use
of Warren Controls ValveWorks sizing program will facilitate the selec-
tion of the optimum valve.
MAINTENANCE
PACKING ADJUSTMENT
PARTS/OVERHAUL
Series 2800 Precision Globe Control Valves have either self-adjust-
ing packing or adjustable packing. Valves with Body Material BBronze
and Packing Type TV-ring, VVacuum Service, or LLip Packing have
self-adjusting packing and require no external adjustment. If the valve
has self-adjusting packing and a packing leak is observed replace the
packing and if necessary the stem and plug assembly.
Valves with Body Material BBronze and Packing Type GGraphite have
adjustable packing. Valves with Body Material SCF8M and Packing
Type TV-ring, GGraphite, or VVacuum Service Packing also have ad-
justable packing. If the valve has adjustable packing and a packing
leak is observed, tighten the packing nut ¼ turn and observe. If the
leak continues tighten the packing nut another ¼ turn and observe.
Repeat as necessary. If the leak continues and the packing nut cannot
be tightened further with reasonable force replace the packing and if
necessary the stem and plug assembly.
Damaged or worn parts can decrease performance and shorten valve
life.
Damaged or worn packing parts including the packing, bearings,
spring, and other bonnet parts can cause a packing leak resulting in
damage to the actuator, accessories, and surrounding equipment.
Damaged or worn packing parts can also cause increased hysteresis
resulting in poor control.
Damaged or worn trim parts including the plug, stem, seat ring, pis-
ton, and o-ring can cause increased hysteresis, poor control, excessive
internal leakage, and poor shut-off. Damaged or worn trim parts can
also cause damage to the packing parts resulting in a packing leak.
Damaged or worn body gaskets or o-ring seals can cause external
leakage resulting in damage to the actuator, accessories, and sur-
rounding equipment.
Should parts become worn or damaged, parts kits are available. Re-
pack Kits are available to replace the packing. Repack/Inspection
Kits are available to allow the valve to be opened for inspection of
its internal parts. Rebuild/Repack Kits are available to completely re-
build/ overhaul the valve. Parts kits come with complete step-by-step
instructions. Each kit has its own part number. Please provide the
valve’s serial number to ensure getting the correct kit part number
and correct parts.
!
DO NOTDO NOT ATTEMPT
TO SERVICE A
SERIES 2800
VALVE WITHOUT
HAVING A
REPACK/
INSPECTION KIT &
SUPPLEMENTAL
INSTRUCTIONS
ON HAND.

11
Series 2800 2800_IOM_RevBa_1219
PARTS KITS
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE T V-RING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 RETAINER BEARING 7 1 PACKING SPRING
3 1 PACKING RETAINER 8 1 O-RING RETAINER
5 1 V-RING PACKING SET 9 1 O-RING
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE T V-RING
SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
3 1 O-RING 7 1 V-RING PACKING SET
4 1 O-RING RETAINER 9 1 RETAINER BEARING
5 1 SPRING 10 1 PACKING RETAINER
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE G GRAPHITE
SEE DWG C3769952
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 PACKING RETAINER 5 1 PACKING CARTRIDGE
3 1 RETAINER BEARING 8 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE G GRAPHITE
SEE DWG C3760955
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
3 1 PACKING CARTRIDGE 6 1 PACKING RETAINER
5 1 RETAINER BEARING 8 1 TUBE STEM LUBE
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE V VACUUM SERVICE
SEE DWG C3761956
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 PACKING RETAINER 8 1 PACKING SPRING
3 1 RETAINER BEARING 9 1 O-RING RETAINER
5 1 MALE ADAPTER 10 1 O-RING
6 1 V-RING PACKING SET 13 1 TUBE STEM LUBE
7 1 FEMALE ADAPTER
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE V VACUUM SERVICE
SEE DWG C3760961
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 Packing Retainer 8 1 Spring
3 1 Retainer Bearing 9 1 O-Ring Retainer
5 1 Male Adapter 10 1 O-Ring
6 1 V-Ring Packing Set 13 1 Tube Stem Lube
7 1 Female Adapter
REPACK KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & TYPE L LIP PACKING
SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM OTY DESCRIPTION
2 1 RETAINER BEARING 5 3 LIP PACKING
3 1 PACKING RETAINER 8 1 TUBE STEM LUBE

12 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
PARTS KITS
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 20 BODY MATERIAL B BRONZE
SEE DWG D3210959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
11 VALVE STEM (Trim Material S, 6, or H) 13 1 TUBE PERMATEX #2
41 GROOVE PIN
(Valve size 1-1/4, 1-1/2, & 2 in) 16 1
PLUG & STEM ASSEMBLY
(Valve size ½, ¾, & 1 in,
Trim Material Tor P)
5 1 PLUG
(Trim Material S, 6, or H)17 1
PLUG ASSEMBLY
(Valve size 1-1/4, 1-1/2, & 2 in,
Trim Material Tor P)
6 1 SEAT RING 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
9 1
SELF LOCKING NUT
(Valve size ½, ¾, & 1 in,
(Trim Material S, 6, or H)
1 REPACK KIT
12 1 TRAVEL STOP
(Valve size ½, ¾, & 1 in)
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 20 BODY MATERIAL B BRONZE
SEE DWG D3210959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
13 1 TUBE PERMATEX #2 1 REPACK KIT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 20 BODY MATERIAL F CF8M
SEE DWG D3210961
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
92 O-RING
15 1 TUBE PST SEALANT 1 REPACK KIT
16 1 O-RING LUBE

13
Series 2800 2800_IOM_RevBa_1219
PARTS KITS
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 20 BODY MATERIAL F CF8M
SEE DWG D3210691
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
11 VALVE STEM
(Trim Material S, 6, or H) 14 1 TRAVEL STOP (Valve size ½, ¾, & 1 in)
51 GROOVE PIN
(Valve size 1-1/4, 1-1/2, & 2 in) 15 1 TUBE PST SEALANT
6PLUG
(Trim Material S, 6, or H)16 1 O-RING LUBE
7 1 SEAT RING 19 1
PLUG & STEM ASSEMBLY
(Valve size ½, ¾, & 1 in,
(Trim Material Tor P)
9 2 O-RING 20 1
PLUG ASSEMBLY
Valve size 1-1/4, 1-1/2, & 2 in,
(Trim Material T OR P)
10 1 BOTTOM PLUG
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
11 1
SELF LOCKING NUT
(Valve size ½, ¾, & 1 in,
(Trim Material S, 6, or H)
1 REPACK KIT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL B BRONZE
SEE DWG D3210959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
13 1 TUBE PERMATEX #2 1 REPACK KIT
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL B BRONZE
SEE DWG D3210959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
61 SEAT RING 19 1 SEAT RING ASSEMBLY
(Trim Material T OR P)
13 1 TUBE PERMATEX #2 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
18 1 PLUG, TRAVEL STOP, &
STEM ASSEMBLY 1 REPACK KIT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL F CF8M
SEE DWG D3210961
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
92 O-RING
15 1 TUBE PST SEALANT 1 REPACK KIT
16 1 O-RING LUBE

14 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
PARTS KITS
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 28 BODY MATERIAL FCF8M
SEE DWG D3210961
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
7 1 SEAT RING 21 1 PLUG, TRAVEL STOP,
& STEM ASSEMBLY
9 2 O-RING 22 1 SEAT RING ASSEMBLY
(Trim Material T or P)
10 1 BOTTOM PLUG 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
15 1 TUBE PST SEALANT 1 REPACK KIT
16 1 O-RING LUBE
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL BBRONZE
SEE DWG D3270957
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
12 1 TUBE PERMATEX #2 1 REPACK KIT
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL BBRONZE
SEE DWG D3270957
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 9 1 SELF LOCKING NUT (Valve size ½, ¾, & 1 in)
7 2 SEAT RING 12 1 TUBE PERMATEX #2
5 1 GROOVE PIN (Valve size
1-1/4, 1-1/2, & 2 in) 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
6 1 PLUG 1 REACK KIT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL FCF8M
SEE DWG D3270958
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
4 2 O-RING
14 1 TUBE PST SEALANT 1 REPACK KIT
15 1 O-RING LUBE

15
Series 2800 2800_IOM_RevBa_1219
PARTS KITS
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 30 BODY MATERIAL FCF8M
SEE DWG D3270958
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 11 1 SELF LOCKING NUT (Valve size ½, ¾, & 1 in)
4 2 O-RING 14 1 TUBE PST SEALANT
6 1 GROOVE PIN (Valve size
1-1/4, 1-1/2, & 2 in) 15 1 O-RING LUBE
7 1 PLUG 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
8 2 SEAT RING 1 REACK KIT
10 1 BOTTOM PORT
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL BBRONZE
SEE DWG C3270959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 9 1 TUBE PERMATEX #2
5 4 JAMNUT 10 1 O-RING LUBE
6 1 O-RING 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
7 1 PISTON 1 REPACK KIT
8 1 BOTTOM PORT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL BBRONZE
SEE DWG C3270959
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
9 1 TUBE PERMATEX #2 1 REPACK KIT
REPACK / INSPECTION KIT
FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL FCF8M
SEE DWG D3270963
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
3 2 O-RING
10 1 O-RING LUBE 1 REPACK KIT
11 1 TUBE PST SEALANT

16 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
PARTS KITS
REBUILD / REPACK KIT
FOR MODEL 28N VALVE TYPE 32 BODY MATERIAL F CF8M
SEE DWG D3270963
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
11 VALVE STEM 8 1 BOTTOM PORT
3 2 O-RING 10 1 O-RING LUBE
5 1 PISTON 11 1 TUBE PST SEALANT
6 1 O-RING 1
ADDITIONAL BONNET
SUBASSEMBLY PARTS
(SEE TABLE)
7 4 JAMNUT 1 REPACK KIT
ADDITIONAL BONNET SUBASSEMBLY PARTS IN REPACK/INSPECTION KIT
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE T V-RING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
10 1 BONNET BEARING
11 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL F CF8M & PACKING TYPE T V-RING
SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 BONNET
2 1 BONNET BEARING
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & TYPE G GRAPHITE
SEE DWG C3769952
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 BONNET 7 1 BONNET BEARING
FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE G GRAPHITE
SEE DWG C3760955
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 BONNET 2 1 BONNET BEARING
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE V VACUUM SERVICE
SEE DWG C3761956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
11 1 BONNET BEARING
12 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL F CF8M & TYPE V VACUUM SERVICE
SEE DWG C3760961
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
11 1 BONNET BEARING
12 1 BONNET
FOR 28N MODELS WITH BODY MATERIAL B BRONZE & PACKING TYPE L LIP PACKING
SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 BONNET 7 1 BONNET BEARING

17
Series 2800 2800_IOM_RevBa_1219
C3270959

18 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
C3760953

19
Series 2800 2800_IOM_RevBa_1219
C3760955

20 2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com 2800_IOM_RevBa_1219
C3760961
