This document covers the installation, operation and main-
tenance of the 377 Float Cage and the 326L and 322L Lever
Valves presented in the “Level Controls and Accessories”,
Product Specification.
The instructions given herein cover generally the opera-
tion and maintenance of subject equipment. Should any
questions arise which may not be answered specifically by
these instructions, they should be referred to Warren Con-
trols Inc. for further detailed information and technical as-
sistance. This manual cannot possibly cover every situation
connected with the operation, adjustment, inspection, test,
overhaul and maintenance of the equipment furnished. Ev-
ery effort is made to prepare the text of this manual so that
engineering and design data is transformed into the most
easily understood wording. Warren Controls Inc., in furnish-
ing this equipment and this manual, must presume that the
TABLE OF CONTENTS
Overview .................................................Cover
General Information............................Cover
Operation .........................................................4
Installation ...................................................4-6
Maintenance ...................................................7
Overhaul...........................................................7
Information Present............................... 8-10
Specifications.........................................11-13
Parts / Overhaul ....................................14-15
Packing Adjustment.................................. 15
Parts Kits ..................................................16-18
Drawings..................................................19-27
377 FLOAT CAGE/326L
& 322L LEVER VALVES
PRODUCT OVERVIEW
operation and maintenance personnel assigned there to have
sufficient technical knowledge and experience to apply sound
safety and operational practices which may not be covered
herein. In applications where Warren Controls Inc. furnished
equipment is to be integrated with a process or other ma-
chinery, these instructions should be thoroughly reviewed to
determine the proper integration of the equipment into the
overall plant operational procedures. Warren Controls does
not assume responsibility for the selection, use, or mainte-
nance of any product. Responsibility for proper selection,
use, and maintenance of any Warren Controls product re-
mains solely with the purchaser and end-user.
GENERAL INFORMATION
377_326L_322L_IOM_RevCa_0518

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
2
!
WARNING
CHECK FLOAT CAGE AND/OR LEVER VALVE
FOR ANY DAMAGE DUE TO IMPROPER
STORAGE OR TRANSPORTATION.
IMMEDIATELY NOTIFY YOUR SALES
ORGANIZATION OF ANY DAMAGED GOODS
UPON RECEIPT. DO NOT ATTEMPT TO MOVE
OR DISTURB THE FLOAT CAGE AND/OR
LEVER VALVE FURTHER SO PHOTOS MAY
BE TAKEN. IF THE SHIPPING CONTAINER IS
NOTICEABLY DAMAGED REFUSE RECEIPT, AS
THE SHIPPING COMPANY SHOULD BE HELD
LIABLE UNTIL A SHIPPING REPRESENTATIVE
IS AVAILABLE TO TAKE PHOTOS.

3
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
The following is a typical example of a tank filling/deaerator application using properly sized,
selected, and maintained Warren Controls Level Controls. Demand for water reduces the liquid
level in the tank. The [A] 377 Float Cage opens the [B] 322L or 326L Lever Valve to supply intake
water to the tank. When the water reaches the desired level the float cage closes the lever valve
to accurately maintain the liquid at the desired level. Deaerators, tanks with steam blankets,
produce additional liquid as the steam condenses. The [C] 313 Overflow Trap traps and relieves
this condensate through its internal pilot without the steam blanket escaping. Overflow can occur
if the water entering the tank exceeds its capacity. The 313 Overflow Trap relieves the overflow
through its internal single seated main stage valve. Falling liquid levels and condensing steam
can cause a vacuum that can damage the tank. The [D] 200 Vacuum Breaker opens to admit outside
air to relieve the vacuum in the tank. Warren Controls Level Controls are also used on boiler make-up
water tanks and many other storage tank applications.
WARREN CONTROLS
LEVEL CONTROLS AT WORK...

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
4
 A rising or falling liquid level in a tank raises or lowers the float ball in the 377 Float Cage.This motion is converted
to force through the rotation of the float rod and lever arm (lever) about the float shaft assembly. The force is
transmitted through the turnbuckle assembly to the lever actuator of a 326L or 322L Lever Valve where it is used
to open or close the valve. Fully immersed in water the float can exert approximately 150 inch-pounds of torque
onto the float arm shaft. The maximum rotation of the float arm shaft is 23°.
OPERATION – 377 FLOAT CAGE AND 326L OR 322L LEVER VALVE
INSTALLATION – 377 FLOAT CAGE AND 326L OR 322L LEVER VALVE
 
(See Information Present on 326L Lever Valves section or Information Present on 322L Lever Valves section for
location of important information on valve). Then see 326L Lever Valve Specification section or 322L Lever Valve
Specification section to determine the performance and physical characteristics of the valve (configuration). See
the 377 Float Cage Specification section to determine the performance and physical characteristics of the 377
Float Cage.
 -
tion can be found in the product specifications (See 377 Float Cage Specification section).
 
Information can be found in the product specifications (See 326L Lever Valve Specification section or 322L Lever
Valve Specification section) and on the flow diagram plate regarding these limits (See Information Present on 326L
Lever Valves section for location of important information on valve).
 
steel body valves have TFE v-ring packing standard. EPDM lip packing is not suitable for use with oils, hydrocar-
 
valves have EPDM lip packing standard. TFE v-ring packing is optional. EPDM lip packing is not suitable for use with
oils, hydrocarbons, or acids. TFE v-ring packing is not suitable for use with fluid temperatures below 60°F.
 
vibration exists.
 
and outlet piping to provide a means to isolate the lever valve.
 
diameters downstream of the 326L or 322L Lever Valve.
 
 
operation.
 
chips, welding spatter, and foreign material. Thoroughly blow out or flush pipe lines.
 
 
threads of the pipe.
 
cracking.
 
with insulation, it is recommended the information on the plates and markings be transcribed on the outside of
the insulation in the same location as the plate or marking.

5
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
DIMENSION L - RISING LEVER OPENS VALVE
The 377 when installed according to these guidelines will provide a maximum water level in the tank that is 2-1/4 inches below the top of the
377. The 377 Float Cage must be installed with the axis through the 1-1/2 NPT pipe connections oriented vertically. The 326L or 322L Lever
Valve is located above the 377 in rising lever opens valve applications, and below the 377 in rising lever closes valve applications. The lever
valve must be installed with the fluid flowing in the correct direction. For proper operation in all applications, lever valves must be piped
according to the corresponding flow arrows, or inlet markings present on each valve (See Information Present on 326L Lever Valves section
or Information Present on 322L Lever Valves section for location of important information on valve). The lever valve must be installed in the
vertical position with the stem pointing upward. When the maximum desired water level in the tank is reached the 377 closes the lever valve
stopping the flow of water into the tank. When the lever valve is closed its lever is horizontal, the turnbuckle is vertical, the end of the 377
lever connected to the turnbuckle is at its lowest point in rising lever opens valve applications and at its highest point in rising lever closes
valve applications. Clearance must be allowed for each turnbuckle connection and lever rotation. There are four possible turnbuckle con-
necting holes on the lever.
RISING LEVER OPENS VALVE DIAGRAM RISING LEVER CLOSES VALVE DIAGRAM
TURNBUCKLE
CONNECTING
HOLE DIAGRAM
DIMENSION L - RISING LEVER CLOSES VALVE
VALVE HOLE 1 HOLE 2 HOLE 3 HOLE 4
1/2, 3/4 & 1 IN 326L 9 10-1/4 11-3/4 13-1/4
1-1/4 & 1-1/2 IN 326L 13 15-1/4 17-1/2 19-3/4
2 IN 326L 16 18-1/2 21-1/4 NA
1-1/2 & 2 IN 322L 7-1/2 8-3/4 10 11-1/4
2-1/2 & 3 IN 322L 11-1/4 13-1/4 15 17
VALVE HOLE 1 HOLE 2 HOLE 3 HOLE 4
1/2, 3/4 & 1 IN 326L 7-1/2 9 10-1/4 11-3/4
1-1/4 & 1-1/2 IN 326L 11 13 15-1/4 17-1/2
2 IN 326L 13-1/4 16 18-1/2 21-1/4
1-1/2 & 2 IN 322L 6-1/4 7-1/2 8-3/4 10
2-1/2 & 3 IN 322L 9-1/2 11-1/4 13-1/4 15
INSTALLATION GUIDELINES
BEFORE YOU BEGIN
The guidelines presented here are for a typical tank filling application utilizing a 377 Float Cage and a Warren Controls Lever Valve. As
shown in the Typical Installation Drawings the 377 closes the Lever Valve when the water in the tank reaches the desired level. Since there
are numerous possible working configurations it is necessary for you to determine where the 377 and Lever Valve will be located before
you install them. The INSTAL LATION GUIDELINES are presented for this purpose. Please read all guidelines thoroughly before
you begin.

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
6
INSTALLATION GUIDELINES CONTINUED
Corresponding turnbuckle connections on the 377 lever are designated by the dimension“L”. Dimension “L”is the distance in inches from
the center of the rocker arm to the point where the turnbuckle connects to the 377 lever. (See diagrams and tables) The 377 lever may be
moved in the rocker arm if the hole for the turnbuckle connection is not present at dimension “L”. To move the 377 lever loosen the lever
capscrew and slide the lever until a hole is in the correct location. Finally to facilitate the turnbuckle connection the lever valve lever may
be rotated 360o around the valve stem. To rotate the lever loosen the yoke locknut, lift the lever slightly, and turn the lever to the desired
position. Tighten the locknut to hold the lever in position. The turnbuckle must then be adjusted so the clevises line up with the levers.
Before mounting the Lever Valve and 377 the water level in the tank must be at least 19 inches below the maximum desired level. Do not
apply water pressure to the Lever Valve inlet until you are ready to test it.
Mount the 377 according to the INSTALLATION GUIDELINES.
Mount the 326L or 322L Lever Valve according to the INSTALLATION GUIDELINES.
Remove the weights from the levers. Move the lever valve lever full up and down to break the packing friction so the lever moves
smoothly. Connect the turnbuckle to the correct hole on the lever valve lever. Push the end of the 377 lever farthest away from the float
ball down until you hear the float ball hit the top of the 377. With the lever valve lever down as far as it will go (horizontal) for rising lever
opens valve applications or up as far as it will go (horizontal) for rising lever closes valve applications adjust the turnbuckle length and
connect the turnbuckle to the 377 lever at the correct dimension“L”. Shorten the turnbuckle so the float ball just misses hitting the top of
the 377 (you do not hear it hit the top). Make sure that the levers and turnbuckle move freely without binding or locking up then tighten
the turnbuckle jamnuts.
Position the weights as necessary on the levers to balance the assembly. Readjust the weights until the lever valve lever just moves on its
own from horizontal to full up for rising lever opens valve applications or from horizontal to full down for rising lever closes valve applica-
tions. Tighten the weight capscrews to hold the weights in position. (You may only need one weight)
BEFORE MOUNTING THE LEVER VALVE AND 377
MOUNT THE 377
MOUNT THE LEVER VALVE
CONNECT THE TURNBUCKLE
POSITION THE WEIGHTS
TEST THE LEVER VALVE AND 377
Apply water pressure to the lever valve inlet. Water should pass through the Lever Valve and enter the tank. The water level in the tank
should rise to the maximum desired level then the 377 should close the lever valve stopping the flow of water into the tank.

7
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
 
and temperature within the limits of the 377 Float Cage (See 377 Float Cage Specification section for additional details).
 
the fluid pressure, temperature, flow, and shut-off differential pressure within the limits of the valve (See Information Present
on 326L Lever Valves section or Information Present on 322L Lever Valves section for location of important information on valve
and 326L Lever Valve Specification section or 322L Lever Valve Specification section for additional details).
 
free of debris, deposits, dirt, dust, and scratches or the packing parts may be damaged resulting in a packing leak.
 
326L or 322L Lever Valve may be reduced (See Warren Controls Water Quality Guidelines for details).
MAINTENANCE – 377 FLOAT CAGE AND 326L OR 322L LEVER VALVE
 
Should the 377 Float Cage and 326L or 322L Lever Valve become worn or defective, parts kits are available. See Parts/ Overhaul.
OVERHAUL – 377 FLOAT CAGE, AND 326L OR 322L LEVER VALVE

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
8
There is information present on each float cage ranging in importance from the part number and serial number to casting numbers.
This information is important for identifying the float cage, installing it correctly, and obtaining parts. An example of the current
factory serial number label used on 377 float cages is shown here. The accompanying table identifies the information present
and where to find it on the float cage. There may also be other casting numbers and foundry marks present that do not provide useful
information. Customer specific tagging may also present. The labels or plates used, and information present, on Warren Controls other
product lines or older float cages may be different, contact the factory for details.
FACTORY SERIAL NUMBER LABEL
INFORMATION PRESENT ON 377 FLOAT CAGE
There is information present on each lever valve ranging in importance from the part number and serial number to casting numbers.
This information is important for identifying the valve, installing it correctly, and obtaining parts. Examples of the current factory
serial number label used on bronze and stainless steel ½ thru 2 inch 326L Lever Valves and the flow diagram plate used on
stainless steel ½ thru 2 inch 326L Lever Valves are shown here. The accompanying table identifies the information present and
where to find it on the lever valve. There may also be other casting numbers and foundry marks present that do not provide useful
information. Customer specific tagging may also present. The labels or plates used, and information present, on Warren Controls other
product lines or older valves may be different, contact the factory for details.
PART NUMBER & SERIAL NUMBER
Information Symbol(s) Location Notes
Part number P/N On float box body * On Factory Serial Number Label attached to float box body.
Serial Number SERIAL NO. On float box body
and float box neck
* On Factory Serial Number Label attached to float box body.
* Sales order number only stamped on float box neck flange.*
* Number stamped using approximately 1/8 inch tall characters
INFORMATION PRESENT ON 377 FLOAT CAGE
INFORMATION PRESENT ON 326L LEVER VALVES

9
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
FACTORY SERIAL NUMBER LABEL
INFORMATION PRESENT ON 326L LEVER VALVES
BRONZE OR STAINLESS STEEL 1/2 THRU 2 INCH
FLOW DIAGRAM PLATE
Cv Tmax
SIZE 1
D
Flow Diagram Plate
For 326L
Stainless Steel Valves
Size 1/2 thru 1
(Size 1 Shown)
PART NUMBER & SERIAL NUMBER
INFORMATION SYMBOL(S) LOCATION NOTES
Part number P/N On actuator Factory Serial Number Label attached to actuator.
Serial Number SERIAL NO. On actuator
and valve body
Factory Serial Number Label attached to actuator.

* Number stamped using approximately 1/8 inch tall characters
FLOW DIRECTION
INFORMATION SYMBOL(S) LOCATION NOTES
Flow direction
through valve
On valve body Flow Diagram Plate attached to mounting boss on valve body
between the end connections (S/S valves ½ thru 1 inch).

(2-way S/S 1-1/4 - 2 inch).
Inlet location INLET On valve body 
½ thru 2 inch & S/S valves 1-1/4 thru 2 inch).
VALVE ATTRIBUTES
INFORMATION SYMBOL(S) LOCATION NOTES
Maximum
temperature rating of
valve body
Tmax On valve body On Flow Diagram Plate attached to mounting boss on valve body
between the end connections (S/S valves ½ thru 1 inch).
Trim Cv
(Flow coefficient)
Cv On valve body Flow Diagram Plate attached to mounting boss on valve body
between the end connections (S/S valves ½ thru 1 inch).
Valve Size SIZE On valve body Flow Diagram Plate attached to mounting boss on valve body
between the end connections (S/S valves ½ thru 1 inch).
Valve Body Material On valve body 

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
10
There is information present on each lever valve ranging in importance from the part number and serial number to the color of the paint
and casting numbers. This information is important for identifying the valve, installing it correctly, and obtaining parts. An example
of the current factory serial number label used on 1-1/2 thru 3 inch 322L Lever Valves is shown here. The accompanying table
identifies the information present and where to find it on the lever valve. There may also be other casting numbers and foundry marks
present that do not provide useful information. Customer specific tagging may also present. The labels or plates used, and information
present, on Warren Controls other product lines or older valves may be different, contact the factory for details.
FACTORY SERIAL NUMBER LABEL
INFORMATION PRESENT ON 322L LEVER VALVES
IRON 1-1/2 THRU 3 INCH
PART NUMBER & SERIAL NUMBER
INFORMATION SYMBOL(S) LOCATION NOTES
Part number P/N On actuator Factory Serial Number Label attached to actuator.
Serial Number SERIAL NO. On actuator
and valve body
Factory Serial Number Label attached to actuator.

or top of valve body*
* Number stamped using approximately 1/8 inch tall characters
FLOW DIRECTION
INFORMATION SYMBOL(S) LOCATION NOTES
Flow direction
through valve
On valve body 
VALVE ATTRIBUTES
INFORMATION SYMBOL(S) LOCATION NOTES
Valve Body Material On valve body 
INFORMATION PRESENT ON 322L LEVER VALVES

11
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
377 Float Cage
8” diameter 316 stainless
steel float ball with brass
float rod, 3’ adjustable
turnbuckle assembly
shown separately
Serial number label located here
Sales order (serial) number stamped here
377 FLOAT CAGE SPECIFICATIONS
377 PART NUMBER
Standard 377 0377XXXXX000
377 with sight glass tappings 0377XXXXX002
377 with sight glass assembly 0377XXXXX003
Extra Turnbuckle Sections
2 Ft Section B3100033
3 Ft Section B3100034
BODY PRESSURE
TEMPERATURE RATINGS:
PRESSURE RATINGS AND PSIG
Temperature
(°F)
Iron Body
125 Flg
+32 to 100°F 175 PSIG
150°F 175 PSIG
175°F 170 PSIG
200°F 165 PSIG
225°F 155 PSIG
250°F 150 PSIG
275°F 145 PSIG
300°F 140 PSIG
APPLICATION:
The 377 Float Cage opens a 322L or 326L Lever Valve to supply intake water to a tank.
When the water reaches the desired level the Float Cage closes the Lever Valve to
accurately maintain the liquid at the desired level. Buoyancy of its internal float ball
provides the force to actuate the lever valve.
FEATURES:
Cast iron body, 1-1/2” NPT connections, 316 stainless steel float ball, epr o-ring, steel
lever and turnbuckle assembly.
- Lever and turnbuckle assembly are adjustable to ease installation
and connection to lever valve.
- Standard turnbuckle is adjustable from 30 to 36 inches in length.
- Extra turnbuckle sections are available for a combined length up to
10 feet.
- Mounting bosses present on body can be provided with 1/2” NPT
pipe tappings for optional sight glass assembly.
- Optional sight glass assembly is available complete with brass ball
check, shut-off valves, and drain valves.
PRESSURE — TEMPERATURE RATINGS:
APPROXIMATE SHIPPING WEIGHT:
Body 125lb rated cast iron
190 lb
FOR DIMENSIONS SEE DRAWINGS 03770524101

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
12
322L LEVER VALVE
2” Bronze 326L
3” Iron 322L
Serial number
label located here
Sales order
(serial) number
stamped here
326L LEVER VALVE
Serial number
label located here
Sales order
(serial) number
stamped here
LEVER VALVES SPECIFICATIONS
326L PART NUMBER
Description Size End Connection Part Number
BRONZE BODY
WITH EQ% ST. STL.
TRIM
1/2 NPT VA2604AC-L000
3/4 NPT VA2605AC-L000
1 NPT VA2606AC-L000
1-1/4 NPT VA2607AC-L000
1-1/2 NPT VA2608AC-L000
2 NPT VA2609AC-L000
ST.STL.BODY
WITH EQ% ST. STL.
TRIM
1/2 NPT VA2604EC-L000
3/4 NPT VA2605EC-L000
1 NPT VA2606EC-L000
1-1/2 NPT VA2608EC-L000
2 NPT VA2609EC-L000
322L PART NUMBER
Description Size End
Connection
Part Number
DOUBLE SEAT IRON BODY
WITH EQ% ST. STL. TRIM
1-1/2 NPT VA2208BC-L000
2 NPT VA2209BC-L000
DOUBLE SEAT IRON BODY
WITH EQ% BRONZE TRIM
2-1/2 125 FLG VA2210CA-L000
3125 FLG VA2211CA-L000
DOUBLE SEAT IRON BODY
WITH EQ% ST. STL.TRIM
2-1/2 125 FLG VA2210CC-L000
3125 FLG VA2211CC-L000
A 377 Float Cage opens the 326L Lever Valve to supply intake water to a tank.
When the water reaches the desired level the Float Cage closes the Lever Valve to
accurately maintain the liquid at the desired level. The 326L combines a balanced,
pilot operated, single seated Type 26 globe valve with a rugged lever actuator.
APPLICATION:
FEATURES:
Bronze or stainless steel body, stainless steel trim, TFE v-ring packing, epr o-ring, cast
iron lever actuator, and steel lever.
Sizes 1/2” through 2” with NPT connections.
Lever actuator is adjustable 360° around top of valve for ease of installation and
connection to float cage.
Lever actuator can be reversed from rising lever opens valve to rising lever closes
valve.
Cv’s to 40
Shut-off pressures to 100 PSI
Nominal leakage rate 0.1% of rated capacity
FOR DIMENSIONS SEE DRAWINGS
0260521101, 00260521102 & 03000521101.
APPLICATION:
A 377 Float Cage opens the 322L Lever Valve to supply intake water to a tank.
When the water reaches the desired level the Float Cage closes the Lever Valve to
accurately maintain the liquid at the desired level. The 322L combines a double
seated Type 22 globe valve with a rugged lever actuator.
FEATURES:
Cast iron body, bronze trim with EPDM lip packing or stainless steel trim with TFE
v-ring packing, cast iron lever actuator and steel lever.
Sizes 1-1/2” and 2” with NPT connections,
2-1/2” and 3” with 125FLG
Lever actuator is adjustable 360° around top of valve for ease of installation and
connection to float cage.
Lever actuator can be reversed from rising lever opens valve to rising lever closes
valve.
Cv’s to 100
Shut-off pressures to 100PSI
Nominal leakage rate 0.5% of rated capacity
For dimensions see drawings
0220521101 & 03000521101.

13
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
LEVER VALVES SPECIFICATIONS
Temp (F)
Bronze &
Iron Thd
Iron
125 Flg
St Steel
Thd
+32 to 100F 400 PSIG 175 PSIG 400 PSIG
WHAT’S AVAILABLE
Features
326L 322L
Size (IN) Size (IN)
1/2,3/4,1 1-1/4 1-1/2,2 1-1/2,2 2-1/2,3
Trim
Material
BRONZE
ST STL
Body Material &
End Connection
BRONZE THREADED (NPT)
IRON THREADED (NPT)
ST STL THREADED (NPT)
IRON 125FLG
Pkg.
TFE V-RING (S/S Trim)
EPDM (Brz Trim)
PRESSURE-TEMPERATURE:
STANDARD
326L/322L MAXIMUM SHUTOFF PSID USING 377 FLOAT CAGE
Valve Size (IN)
Valve 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3
326L 100 100 100 100 100 100 - -
322L - - - - 100 100 80 60
SHUT-OFFS:
APPROXIMATE SHIPPING WEIGHTS:
FLOW COEFFICIENTS Cv:
326L/322L WEIGHTS LB
Valve Size (IN)
Valve 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3
326L 24 24 25 32 32 37 - -
322L - - - - 33 33 50 60
326L/322L CV
Valve Size (IN)
Valve 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3
326L 6.9 7.7 10 19 25 40 - -
322L - - - - 30 42 70 100
FLOW CAPACITIES:
326L GPM
Valve Size (IN)
DP (PSI) 1/2 3/4 1 1-1/4 1-1/2 2
5 15 17 22 42 56 89
10 22 24 32 60 79 126
15 27 30 39 74 97 155
20 31 34 45 85 112 179
25 35 39 50 95 125 200
30 38 42 55 104 137 219
35 41 46 59 112 148 237
40 44 49 63 120 158 253
45 46 52 67 127 168 268
50 49 54 71 134 177 283
326L GPM
Valve Size (IN)
DP (PSI) 1-1/2 2 2-1/2 3
5 67 94 157 224
10 95 133 221 316
15 116 163 271 387
20 134 188 313 447
25 150 210 350 500
30 164 230 383 548
35 177 248 414 592
40 190 266 443 632
45 201 282 470 671
50 212 297 495 707

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
14
Damaged or worn parts can decrease performance and shorten the life of the float cage.
A damaged float ball and/or float rod can result in poor control and poor shut-off of the attached lever valve.
A damaged or worn float arm shaft with elbow can result in poor control and poor shut-off of the attached lever valve, and
can also cause damage to the bonnet and o-ring.
A damaged or missing e-ring can result in damage to the float rod, float arm shaft, o-ring, and linkage.
A damaged or worn bonnet can result in poor control and poor shut-off of the attached lever valve, and can also cause dam-
age to the float shaft and o-ring.
A damaged or worn o-ring can result in poor control and poor shut-off of the attached lever valve, and can also cause damage
to the bonnet and float shaft.
A damaged or worn gasket or o-ring can cause external leakage resulting in damage to surrounding equipment.
A damaged lever arm or turn buckle assembly can result in poor control and poor shut-off of the attached lever valve.
Two different parts kits are available. The float ball kit allows for the float ball to be replaced. The replacement neck assembly
kit allows for the entire neck assembly including the float rod, float arm shaft, and bonnet, minus the float ball, to be replaced.
Individual parts are also available. Please provide serial number to get the correct kit or individual part numbers.
377 FLOAT CAGE PARTS / OVERHAUL

15
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
326L and 322L Lever Valves have self-adjusting packing and require no external adjustment. 326L and 322L Lever Valves with
stainless steel trim have TFE V-ring Packing. 322L Lever Valves with bronze trim have EPDM Lip Packing. If the valve has self-
adjusting packing and a packing leak is observed replace the packing and if necessary the stem and plug assembly.
PACKING ADJUSTMENT
Damaged or worn parts can decrease performance and shorten valve life.
Damaged or worn packing parts including as applicable the packing, bearings, spring, and other bonnet parts can cause
a packing leak resulting in damage to the actuator and surrounding equipment. Damaged or worn packing parts can also
cause increased hysteresis resulting in poor control.
Damaged or worn trim parts including as applicable the plug, stem, seat ring(s), piston, pilot retainer, and o-ring can cause
increased hysteresis, poor control, excessive internal leakage, and poor shut-off. Damaged or worn trim parts can also cause
damage to the packing parts resulting in a packing leak.
Damaged or worn body gaskets can cause external leakage resulting in damage to the actuator, accessories, and surround-
ing equipment.
Should parts become worn or damaged, parts kits are available. Repack Kits are available to replace the packing. Repack/
Inspection Kits are available to allow the valve to be opened for inspection of its internal parts. Rebuild/Repack Kits are avail-
able to completely rebuild/ overhaul the valve. Parts kits come with complete step-by-step instructions. Each kit has its own
part number. Please provide the valve’s serial number to ensure getting the correct kit part number and correct parts.
326L AND 322L LEVER VALVE PARTS/ OVERHAUL

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
16
(PROVIDE FLOAT CAGE SERIAL NUMBER TO GET KIT PART NUMBERS)
Two different parts kits are available. The float ball kit allows for the float ball to be replaced. The replacement neck assembly kit
allows for the entire neck assembly including the float rod, float arm shaft, and bonnet, minus the float ball, to be replaced.
(PROVIDE VALVE SERIAL NUMBER TO GET KIT PART NUMBERS)
Three different kinds of parts kits are available. The repack kit allows a valve to be repacked. The repack/ inspection kit allows a
valve to be opened for inspection of internal parts and then repacked. The rebuild/ repack kit allows a valve to be overhauled
and then repacked.
377 FLOAT BALL KIT - SEE DWG 03770524101
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 FLOAT BALL 3 1 GASKET
377 REPLACEMENT NECK ASSEMBLY KIT
SEE DWG 03770524101
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
3 1 GASKET 18 1 BONNET
8 1 FLOAT BOX NECK 19 1 O-RING
16 1 FLAT ARM SHAFT W/ BRAZED ELBOW 20 1 FLOAT ROD
17 1 E-RING
REPACK KIT - FOR 26 BRONZE VALVE WITH TEFLON V-RING PACKING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
2 1 RETAINER BEARING 7 1 PACKING SPRING
3 1 PACKING RETAINER 8 1 O-RING RETAINER
5 1 V-RING PACKING SET 9 1 O-RING
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT - FOR 26 ST STL VALVE WITH TEFLON V-RING PACKING
SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
3 1 O-RING 7 1 V-RING PACKING SET
4 1 O-RING RETAINER 9 1 RETAINER BEARING
5 1 PACKING SPRING 10 1 PACKING RETAINER
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK/ INSPECTION KIT - FOR 26 BRONZE VALVE WITH TEFLON V-RING PACKING
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 TUBE PERMATEX #2 1 REPACK KIT
377 FLOAT CAGE PARTS KITS
26 VALVE PARTS KITS

17
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
REPACK/ INSPECTION KIT - FOR 26 BRONZE VALVE WITH TEFLON V-RING
PACKING
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 TUBE PST SEALANT 1 REPACK KIT
REBUILD/ REPACK KIT - FOR 26 BRONZE VALVE WITH TEFLON V-RING PACKING
SEE DWG 00260521101
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 7 1 SEAT RING
3 1 PILOT RETAINER 1 TUBE PERMATEX #2
4 1 O-RING 1 TUBE O-RING LUBE
5 1 GROOVE PIN 1 ADDITIONAL BONNET SUBASSEMBLY PARTS (SEE TABLE)
6 1 PISTON & PLUG 1 REPACK KIT
REBUILD/ REPACK KIT - FOR 26 ST STL VALVE WITH TEFLON V-RING PACKING
SEE DWG 00260521102
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 7 1 SEAT RING
3 1 PILOT RETAINER 1 TUBE PST SEALANT
4 1 O-RING 1 TUBE O-RING LUBE
5 1 GROOVE PIN 1 ADDITIONAL BONNET SUBASSEMBLY PARTS (SEE TABLE)
6 1 PISTON & PLUG 1 REPACK KIT
ADDITIONAL BONNET SUBASSEMBLY PARTS IN REBUILD/ REPACK KIT
FOR 26 BRONZE VALVE WITH TEFLON V-RING PACKING
SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
10 1 BONNET BEARING 11 1 BONNET
FOR 26 ST STL VALVE WITH TEFLON V-RING PACKING - SEE DWG C3760953
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 BONNET 2 1 BONNET BEARING
26 VALVE PARTS KITS CONTINUED

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
18
(PROVIDE VALVE SERIAL NUMBER TO GET KIT PART NUMBERS)
Three different kinds of parts kits are available. The repack kit allows a valve to be repacked. The repack/ inspection kits allow a
valve to be opened for inspection of internal parts and then repacked. The rebuild/ repack kits allow a valve to be overhauled and
then repacked.
REPACK KIT - FOR 22 VALVE WITH STAINLESS STEEL TRIM
AND TEFLON V-RING PACKING - SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
2 1 RETAINER BEARING 7 1 PACKING SPRING
3 1 PACKING RETAINER 8 1 O-RING RETAINER
5 1 V-RING PACKING SET 9 1 O-RING
6 1 MALE ADAPTER 12 1 TUBE STEM LUBE
REPACK KIT - FOR 22 VALVE WITH BRONZE TRIM
AND EPDM LIP PACKING SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
2 1 PACKING RETAINER 5 3 LIP PACKING
3 1 RETAINER BEARING 8 1 TUBE STEM LUBE
REPACK/ INSPECTION KIT - FOR 22 VALVE SIZE 1-1/2 THRU 3 INCH
SEE DWG 00220521101
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 GASKET 1 REPACK KIT
REBUILD/ REPACK KIT - FOR 22 VALVE SIZE 1-1/2 THRU 3 INCH
SEE DWG 00220521101
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
1 1 VALVE STEM 9 1 PLUG
3 1 TRAVEL STOP (As required) 1 TUBE PERMATEX #2
7 1 GROOVE PIN 1 ADDITIONAL BONNET SUBASSEMBLY PARTS (SEE TABLE)
6 1 GASKET 1 REPACK KIT
SEAT RINGS ARE MACHINED IN VALVE AND ARE NOT AVAILABLE SEPARATELY
ADDITIONAL BONNET SUBASSEMBLY PARTS IN REBUILD/ REPACK KIT
FOR 26 BRONZE VALVE WITH TEFLON V-RING PACKING - SEE DWG C3769950
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
10 1 BONNET BEARING 11 1 BONNET
FOR 22 VALVE WITH BRONZE TRIM AND EPDM LIP PACKING - SEE DWG C3769956
ITEM QTY DESCRIPTION ITEM QTY DESCRIPTION
6 1 BONNET 7 1 BONNET BEARING
22 VALVE PARTS KITS

19
LEVEL CONTROLS_IOM 377 FLOAT CAGE/326L & 322L LEVER VALVES 377_326L_322L_IOM_RevCa_0518
DRAWING 037705241011
Type 377 Float Cage

2600 Emrick Blvd • Bethlehem, PA 18020 • USA • 800-922-0085 • www.warrencontrols.com
20
DRAWING 037705241012
Type 377 Float Cage
