Watchguard XTM 545 Installation instructions

WatchGuard
XTM 5 Series
Hardware Guide
XTM 515, 525, 535, 545
NC2AE8

ii WatchGuard XTM 5 Series
ADDRESS
505 Fifth Avenue South
Suite 500
Seattle, WA 98104
SUPPORT
www.watchguard.com/support
U.S. and Canada +877.232.3531
All Other Countries +1.206.521.3575
SALES
U.S. and Canada +1.800.734.9905
All Other Countries +1.206.613.0895
ABOUT WATCHGUARD
WatchGuard offers affordable, all-in-one network and content security solutions that
provide defense-in-depth and help meet regulatory compliance requirements. The
WatchGuard XTM line combines firewall, VPN, GAV, IPS, spam blocking and URL
filtering to protect your network from spam, viruses, malware, and intrusions. The new
XCS line offers email and web content security combined with data loss prevention.
WatchGuard extensible solutions scale to offer right-sized security ranging from small
businesses to enterprises with 10,000+ employees. WatchGuard builds simple, reliable,
and robust security appliances featuring fast implementation and comprehensive
management and reporting tools. Enterprises throughout the world rely on our
signature red boxes to maximize security without sacrificing efficiency and
productivity.
For more information, please call 206.613.6600 or visit www.watchguard.com.
Copyright and Patent Information
Copyright© 1998–2012 WatchGuard Technologies, Inc. All rights reserved.
WatchGuard, the WatchGuard logo, LiveSecurity, and any other mark listed as a trademark in the “Terms of Use” portion of
the WatchGuard Web site that is used herein are either registered trademarks or trademarks of WatchGuard Technologies,
Inc. and/or its subsidiaries in the United States and/or other countries. All other trademarks are the property of their
respective owners.
Printed in the United States of America.
Part Number: 275-4210-001 Rev A
Revised: June 15, 2012
U.S. Patent Nos. 6,493,752; 6,597,661; D473,879. Other Patents Pending.
Notice to Users
Information in this guide is subject to change without notice. Updates to this guide are posted at:
http://www.watchguard.com/help/documentation/hardware.asp
Companies, names, and data used in examples herein are fictitious unless otherwise noted. No part of this guide may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express
written permission of WatchGuard Technologies, Inc.
Complete copyright, trademark, patent, and licensing information
can be found in the WatchGuard product documentation. You can
find this document online at:
http://www.watchguard.com/help/documentation/

Hardware Guide 1
Hardware Specifications
WatchGuard® XTM security appliances deliver unparalleled unified threat management, superior
performance, ease of use, and value for your growing network. Our security subscriptions give you fully
integrated protection from spyware, spam, viruses, worms, trojans, web-based exploits, and blended threats.
From firewall and VPN protection to secure remote access, WatchGuard devices support a broad range of
network environments.
This guide introduces the XTM 5 Series, a series of RoHS-compliant (lead-free) hardware products offered by
WatchGuard.
WatchGuard’s XTM 5 Series devices use dynamic, multi-layered security to proactively protect your network.
The XTM 5 Series has the reliability, redundancy, traffic management, and port density that demanding, high-
speed networks require.
You can upgrade some XTM 5 Series devices to a higher model in the XTM 5 Series line for more capacity and
performance with a software license key.
Note
This Hardware Guide applies to XTM 5 Series devices with model numbers XTM 515, 525, 535,
and 545. If your 5 Series device has a different model number, your hardware is described in the
XTM 5 Series Hardware Guide that applies to that model.
Fireware XTM OS
The XTM 5 Series devices support WatchGuard’s next generation UTM OS—Fireware® XTM. Each XTM 5 Series
device includes Fireware XTM and delivers exceptional protection against today's sophisticated threats to
make sure that your business stays connected. As an option, you can purchase a Pro upgrade to Fireware XTM
to enable additional advanced networking capabilities. For more information on the features of Fireware XTM
OS, see the current Fireware XTM WatchGuard System Manager Help or Fireware XTM Web UI Help.

2WatchGuard XTM 5 Series
Hardware Specifications
Package Contents
CD-ROM with this Hardware Guide
XTM 5 Series appliance
Quick Start Guide
Hardware warranty card
LiveSecurity® Service activation card
Safety Notices
Declaration of Conformity
1 straight-through Ethernet cable (green)
1 cross-over Ethernet cable (red)
1 serial cable with an RJ45 connector
1 power cord
4 rubber pads for the bottom of the device
1 rack-mounting kit
About Your Hardware
Hardware Specifications
Interface Specifications
XTM 5 Series
Processor Intel Dual Core
Memory: Flash 1 GB
Memory: RAM 2 GB
Power supply 100-240 VAC
Autosensing
Dimensions D= 11.25” (28.6 cm)
W= 17” (43.18 cm)
H= 1.75” (4.45cm)
Weight 10.15 lbs
Network interfaces • 6x 1000Base-T (10/100/1000 Mbps), RJ45 connector
• 1x 100Base-TX (10/100 Mbps), RJ45 connector
I/O interfaces •2USB
• 1 RJ45 serial

Hardware Guide 3
Hardware Specifications
Environmental Requirements
To safely install your XTM 5 Series device, we recommend that you:
Install it in a network rack
Put it in a secure area, such as a locked room, to block the device from people who do not have
permission to use it
Connect it to a conditioned power supply to prevent damage from sudden power changes
Other environmental requirements:
Operating temperature 0 – 40°C
(32 – 104°F)
Operating relative humidity 10% - 85% non-condensing
Non-operating temperature –40 – 70°C
(–40 – 158°F)
Non-operating relative humidity 10% – 90%

4WatchGuard XTM 5 Series
Hardware Specifications
Front View
The front of the device.
This is a close-up of the right side of the front of the device.
LCD indicator panel
Device status information appears on the LCD screen. Press the buttons below the screen to change
the information that appears on the screen.
For more information, see “Use the LCD Interface” on page 8.
LCD console buttons
Press the LCD console buttons to see status information and start recovery procedures.
To boot the device in safe mode, press and hold the down arrow button when you power on the
device.
For detailed information about the LCD indicator panel and the LCD console buttons, see “Use the
LCD Interface” on page 8.
Power ( )
When the device is powered on, the power indicator is green.
Arm/Disarm
When the device is armed, this indicator is green. When the device is disarmed, this indicator is red.
Storage ( )
When there is activity on the compact flash, this indicator is yellow.
All interfaces are on the front of the device.
Serial port (Console)
An RJ45 connector for the serial interface.

Hardware Guide 5
Hardware Specifications
Dual USB interface
Connect a USB storage device to use for USB backup and restore, or to store a support snapshot.
For more information about USB functions, see the Fireware XTM WatchGuard System Manager Help
or Fireware XTM Web UI Help.
Network Interfaces
The interfaces have standard RJ45 connectors and are labeled 0,1,2,3,4,5,6.
Interface 0 — supports link speeds of 10 or 100 Mbps.
Interfaces 1 - 6 — support link speeds of 10, 100, or 1000 Mbps.
Interface 0 does not support Auto-MDIX, which automatically senses the cable polarity. Use these
guidelines to decide which type of Ethernet cable to use with Interface 0.
To connect Interface 0 to an interface on a switch or router that supports Auto-MDIX, you can
use either Ethernet cable.
To connect Interface 0 to an interface on an older switch or router that does not support Auto-
MDIX, use the green Ethernet cable. Your switch or router could be set to a different polarity. If
the green Ethernet cable does not work, try the red cross-over Ethernet cable.
To connect Interface 0 to a PC, use the red cross-over Ethernet cable.
Indicators for network interfaces
At the top of each labeled network interface, there is a pair of indicators. The indicator at the left of
the interface is the activity indicator for that interface. The indicator at the right shows the connection
speed for that interface.
Note
When the device is powered off, but the AC power is plugged in, the Link and Activity indicators for
interface 0 continue to operate, but the interface does not pass traffic. All other network interface
indicators are inactive.
Indicator Indicator color Interface Status
Activity (upper left) Yellow Power on, connection established
Not lit Power off, no connections
Blinks
(speed of blink increases as the
data flow increases)
Data sent and received
Connection Speed
(upper right)
Not lit Link speed: 10 Mbps
Green Link speed: 100 Mbps
Yellow Link speed: 1000 Mbps

6WatchGuard XTM 5 Series
Hardware Specifications
Rear View
The AC receptacle, fans, and power switch are on the rear of the device.
AC receptacle
Accepts a detachable AC power cord supplied with the device. The power supply for the device is a
WatchGuard standard auto-sensing AC power supply.
Fans
The fans decrease the internal temperature of the device.
Power switch
Controls the power supplied to the device. To power on the device, press the switch. To power off the
device, press and hold the switch for at least 5 seconds.
Caution
You must disconnect the power supply before you remove the cover of the XTM 5 Series
device. If you open the cover without prior authorization from WatchGuard, this voids the
Hardware Warranty.
Rack Mount Instructions
Each WatchGuard XTM 5 Series device ships with a rack mount kit. When you install the XTM 5 Series device
in a rack, make sure you consider:
Elevated Operating Ambient Temperature
If you install the XTM 5 Series device in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment could be greater than the ambient temperature of the room.
The XTM 5 Series device is certified to operate correctly between 0 – 40°C (32 – 104°F).
Reduced Air Flow
When you install the XTM 5 Series device in a rack, make sure that the amount of air flow required for
safe operation of the equipment is not compromised.
Mechanical Loading
When you mount the XTM 5 Series device in the rack, avoid hazardous conditions caused by uneven
mechanical loading.
Circuit Overloading
Make sure you connect the XTM 5 Series device to the power supply circuit to make sure there is no
overloading of the circuits, and no impact on overcurrent protection and supply wiring.
Reliable Grounding
Make sure all rack-mounted equipment is correctly grounded. For example, use power strips instead
of direct connections to the branch circuit.

Hardware Guide 7
Hardware Specifications
Safety Notices
All WatchGuard products are designed and tested to meet strict safety requirements. These requirements
include product safety approvals and other global compliance standards. Read these instructions carefully
before you operate the product, and refer to them as needed for continued safe operation of your product.
Product Safety Certification
The WatchGuard product is safety certified for these standards:
oCAN/CSA C22.2 No.60950-1-07
oIEC 60950-1, Second Edition
oUL 60950-1, Second Edition
Safety Warning
oDo not place objects on the power cord.
oDo not obstruct the ventilation openings. These openings prevent overheating of the XTM device.
oNever push objects of any kind into slots or openings on this equipment. If you make contact with a
voltage point or short out a part, it can result in fire or electrical shock.
oIf the equipment is supplied with a three-conductor AC power cable, the power cable must be
plugged in to an approved three-contact electrical outlet with the grounding wire connected to an
electrical ground (safety ground) at the power outlet.
oWhen you remove or install an appliance, follow the general installation safety instructions provided
in this Hardware Guide to avoid injury or damage to the device.
oThe lithium battery used in the security appliance may not be replaced by the user. Return the
appliance to a WatchGuard authorized service center for replacement with the same or equivalent
type recommended by the manufacturer. If, for any reason, the battery or security appliance must be
disposed of, do so following the battery manufacturer’s instructions.

8WatchGuard XTM 5 Series
Hardware Specifications
Use the LCD Interface
You can use the LCD interface and buttons for different operations.
The XTM 5 Series can operate in two modes:
Normal Mode
The device normal operating mode, with the XTM 5 Series device booting from the Fireware XTM OS
and operating with the rules set in the configuration file you have saved to the device.
Safe Mode
In safe mode, you can get access to an XTM 5 Series device when normal access to the device is lost.
You can also use safe mode to reset device passphrases when you do not know or have forgotten
them. To recover the device while started from safe mode, you must use the WSM Quick SetupWizard
or the Web Setup Wizard.
You must put the XTM 5 Series device in safe mode to use the setup wizards. In safe mode, the device
runs Fireware XTM and is configured with factory-default IP addresses. When you put the device in
safe mode, the license files and certificates are saved. You can then use the saved files if you
reconfigure a device with one of the setup wizards.
To put an XTM 5 Series device into safe mode, press and hold the down arrow button on the device
front panel when you power on the device. Hold down the button until “Safe Mode Starting” appears
on the LCD screen. When the device is in safe mode, the model number followed by the word “Safe”
appears on the LCD screen and the factory default IP address for Eth1 is 10.0.1.1/24.
LCD Keypad Button Control
Below the LCD screen, there are four arrow buttons.
Up Arrow
With this button, you can increase the value of a selected item, or move up in a group menu.
Down Arrow
With this button, you can decrease the value of a selected item, or move down in a group menu.
Left Arrow
This is the “selection” or “Enter” button. Press it to confirm your menu selections and select different
options.
Right Arrow
Press this button to select fields in the LCD display. You can use it like the “TAB” key in a Windows
dialog box.
