Water-Loo SG1 Manual

SG1 High Security Grille
SG2 Medium Security Grille
SG3 Low Security Grille
Operating and Maintenance
SG1 SG2 SG3

2
www.waterloo.co.uk Tel: [phone]
Operating and maintenance
Security Grilles
SG1 / SG2 / SG3
Product Description
SG1 High Security Grille With Rear Fixing
SG2 Medium Security Grille With Face and Rear
Fixing
SG3 Low Security Grille With Face Fixing
Material
SG grilles are manufactured from either stainless steel
or galvanised mild steel.
Maintenance
There are no moving parts in the SG range of grilles,
therefore there is no need for any maintenance.
Cleaning
If the SG grilles require cleaning we would recommend
that all accessible faces are cleaned with warm soapy
water.
For regular cleaning a simple wipe down should
VXI¿FHRUXVHRIDYDFXXPFOHDQHUZLWKDVRIWEUXVK
head to remove any debris from inside the grilles.
This may be done using a mild detergent and water
WDNLQJFDUHQRWWRGDPDJHDQ\SDLQW¿QLVKHV$EUDVLYH
cleaners must not be used.
SG1 + OBSS
SG2 + OBSS
SG3 + OBSS
