Watersavers Autosave B02 User manual

INSTALLATION
INSTRUCTIONS
Autosave B02 6v Battery operated
Urinal Flush Control - Remote Valve
Version
PLUMBING EMPTY CISTERN then turn off water supply to cistern. Remove any existing trickle cock or restrictor from
supply pipe. Locate unit on supply pipe in suitable position for detection by PIR lens. Fit the Autosave valve into urinal
supply pipe using compression fittings. Ensure water supply is connected to valve inlet (marked IN on underside).
Valve may be rotated through 180 degrees if required. Fit isolating valve (supplied) on inlet side of Autosave valve, leave in
fully open position. Fix unit to wall using screws and plugs provided, fit plastic caps over screws.
COMMISSIONING Turn on water supply to Autosave. Insert batteries (supplied) into holder, connect lead from PCB
to battery holder.
LED behind lens will flash twice upon connection, Autosave is now in SETUP mode.
After approx 30 seconds settling time, LED will flash each time it detects movement within it's range in the toilet area.
REPLACING BATTERIES LED flashes briefly once per second to indicate a low battery condition.
Simply replace with 4 x 1.5v AA size alkaline cells and Autosave is ready for use - no need to setup again!
TO RESET AUTOSAVE Disconnect battery, press and hold blue FILL button while re-connecting battery.
Release button. Autosave is in setup mode again.
please read carefully
FOR TECHNICAL SUPPORT
Earl Road Rackheath Industrial Estate
Norwich NR13 6NT
Watersavers
TM
Tel [phone] Fax [phone]
email [email protected]
website www.watersavers.co.uk
B02a Rev 1.1
Press and release blue FILL button inside lid, valve opens after a few seconds, LED flashes continuously while cistern fills.
When cistern starts to flush (normally takes around 5 to 10 minutes according to supply pressure) press and release blue
FILL button again. Valve closes immediately and setup is complete. TIP to abort, disconnect battery while filling, re-connect
again to close valve, repeating sequence if required.
SETTING CISTERN FILL TIME IT IS IMPORTANT THAT THE CISTERN IS EMPTY BEFORE PROCEEDING!
(See simple step by step guide overleaf)
SETTING FLUSH PROGRAMME Once the cistern fill time has
been set as above, select flushing interval and hygiene flush times on the
blue dipswitch according to the table opposite. The default (factory) settings
are 20 minute flush interval and 24 hour hygiene flush as shown below.
FLUSH INTERVAL is the time delay between detecting someone entering the
toilet area and the flushing cycle that follows.
HYGIENE FLUSH is a flush cycle following a period of either 12 or 24 hours
of non-detection.
5 Mins
10 Mins
15 Mins
20 Mins
25 Mins
30 Mins
35 Mins
X
X
X
X
X
X
X
UP DWN DWN
DWN UP DWN
UP UP DWN
DWN DWN UP
UP DWN UP
DWN UP UP
UP UP UP
X = not applicable
X DWN DWN DWNTEST
(5 secs)
SW1 SW2 SW3 SW4TIME
12 Hour
24 Hour
UP X X X
DWN X X X
FLUSH INTERVAL
HYGIENE FLUSH
1234
ON
20MINS
12-24HRS
5MINS
10MINS
(HYGIENE)
MAGI-TEST Using magnetic
test wand, just touch square above
lens as shown here
Autosave will do an immediate fill
and flush cycle, LED will confirm
detection.
Or touch again with wand to abort
fill cycle and close valve.
This will test batteries, sensor, valve, water supply
and correct cistern fill time.
ELECTRICAL Insert free end of pre-wired solenoid valve cable into hole in Autosave B02 enclosure. Squeeze and
push home rubber cable gland. Cable should protrude approx. 6" into enclosure. Push connector onto VALVE connector

LED flashes upon detection
Autosave is in SETUP mode
1
FILL
Press & release blue FILL button
- valve opens
ENSURE CISTERN IS EMPTY!
LED flashes while cistern fills
That's it - finished!
Autosave is now in RUN mode
When cistern starts to flush .....
Press & release blue FILL button
- valve closes
FILL
2
3
Autosave B02 with remote valve - setting-up guide
Allow 30 seconds settling time
Connect 4 x AA batteries
4
B02b Rev 1.1
*
TO EMPTY CISTERN: follow steps 1 to 3 until cistern flushes, disconnect battery, re-connect then follow setup guide again.
*
TO RETURN TO SET-UP MODE: Disconnect battery, press & hold blue FILL button while re-connecting battery.
Release button. Autosave is in setup mode again.
PLEASE NOTE: LED will flash TWICE in setup mode and ONCE in run mode upon connection of batteries.
PLEASE LEAVE THESE INSTRUCTIONS WITH THE END USER - THANK YOU
1234
ON
20MINS
12-24HRS
5MINS
10MINS
(HYGIENE)
1234
ON
20MINS
12-24HRS
5MINS
10MINS
(HYGIENE)
Watersavers
Autosave - B02
01603 720999
Watersavers
Autosave - B02
01603 720999
IMPORTANT!!! Once in RUN mode the
LED does not flash upon detection
- use Magi-Test wand to check operation
