Watersnake DSB SERIES User manual

OWNERS MANUAL
DSB SERIES BOW MOUNT
MOTOR

WATERSNAKE ELECTRIC MOTORS
Congratulations and welcome to a world of silent motoring. You wont regret your
purchase of this lightweight, Jarvis Marine Watersnake electric motor.
Powerful yet silent, the Watersnake electric motors are built to suit all angling conditions.
High quality materials, superior design and precision engineering make these motors
longwearing and reliable.
ATTACHING THE MOTOR TO YOUR BOAT
Attach the motor to the bow of the boat, taking care to ensure the motor is on the
centreline of the boat and forward enough to avoid the shaft making contact with the
boats gunwale rubber. With the motor in position, mark the holes for drilling, ensuring as
you do that the bow area below the mounting location is clear and accessible.
Mount the plate to the bow using stainless steel bolts, nuts and washers. It is important
when doing this work that the boat is level and the motor is mounted level.
T

Folding scissor
Mount
Power & Battery gauge Extendable handle
featuring variable
speed forward and
reverse control
Weedless
3 blade
propeller
Multi adjustable
depth feature
Automatic cut
off switch
Tilting head design
Corrosion resistant
composite shaft
Motor casing Anti-impact protection and auto - vertical
function. Buffer the impact from any direction
within 15 degrees
Rubber Material
Aluminium
Material
Pull Cord Raise Motor Place Horizontally
Folding Down Motor

CHANGING THE PROPELLOR
Before doing anything with the propeller, ensure the cables to the battery are
disconnected. To detach the propeller it is a simple matter of unscrewing and removing
the locknut using the special tool supplied. When doing this, take hold of the propeller to
stop it turning. Under no circumstances should you attempt to loosen the locknut with a
hammer or similar tool as this may damage the locknut or shaft – or both. (F)
DEPTH ADJUSTMENT
Hold the motor shaft with one hand, loosen the depth adjustment screw and set the
motor to the desired depth, then retighten the adjusting screw securely. (C)
HEAD UNIT & SPEED CONTROL
Power on/off switch is positioned underneath the head unit, activate to use the motor
and when de-activated this function will prevent any amp draw from your battery.
The tiller control is telescopic and can be extended to 16cm. Simply push the button at
the end of the grip (D) to set your desired length. The speed control is variable, rotate the
handle clockwise for forward speed and anti-clockwise for reverse. (E)
The tilting head design allows you to fix the head in your desired position. Loosen the key
lock and move the head in position, then tighten.
POWER & BATTERY GAUGE
Power meter shows speed settings in percentages, full motor speed is 100%. The battery
indicator will only be indicated when the motor speed is at zero.
The Watersnake CV motors are fitted with a 12 LED Jacklight system when fishing at night.
Located underneath the head unit, to turn on open the cover. The lights will turn off
automatically when the cover is closed.
(C) (D) (E)

Once the locknut is removed, the propeller can be slid off. When putting the propeller
back on, verify there is a proper fit of the groove and shear pin otherwise the propeller
will not be locked. (G)
After using the motor always check and clear any weed or fishing line that may have
become tangled around the propeller. Next, give the motor a wipe down with warm
water to remove any salt or sand particles and then spray it with fresh water.
(F) (G)
ELECTRICAL CONNECTIONS
Before connecting the motor’s cables
to the battery terminals, ensure all
switches are in the OFF position and
stand clear of the propeller.
Connect the red cable to the positive
(+) terminal and the black cable to the
negative (-) terminal, making sure the
terminals are clean before doing so. A
clean connection will minimise power
wastage and give you maximum power
from the battery.
The battery should be kept in a
well-ventilated location. We recommend
using a special deep cycle marine
battery for optimum performance.

TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE/SOLUTION
Speed loss 1: Check for line or weed on propeller.
2: Check battery status.
3: Check terminals on battery.
Motor noise/ shake 1: Check propeller for line or weed.
ELECTRICAL CONNECTIONS CONTINUED
MODEL
FWDSB44-42
FWDSB44-48
FWDSB54-48
FWDSB54-54
FWDSB70-48
FWDSB70-54
MAX THRUST
44lbs
44lbs
54lbs
54lbs
70lbs
70lbs
CONTROL
By Hand
By Hand
By Hand
By Hand
By Hand
By Hand
SPEEDS
Variable
Variable
Variable
Variable
Variable
Variable
VOLTAGE
12V
12V
12V
12V
24V
24V
SHAFT MATERIAL
Composite
Composite
Composite
Composite
Composite
Composite
SHAFT LENGTH
42”/105cm
48”/120cm
48”/120cm
54”/135cm
48”/120cm
54”/135cm
Freshwater Models (FWDSB)
Saltwater Models (SWDSB)
MODEL
SWDSB44-42
SWDSB44-48
SWDSB54-48
SWDSB54-54
SWDSB80-48
SWDSB80-54
SWDSB110-54
SWDSB110-60
MAX THRUST
44lbs
44lbs
54lbs
54lbs
80lbs
80lbs
110lbs
110lbs
CONTROL
By Hand
By Hand
By Hand
By Hand
By Hand
By Hand
By Hand
By Hand
SPEEDS
Variable
Variable
Variable
Variable
Variable
Variable
Variable
Variable
VOLTAGE
12V
12V
12V
12V
24V
24V
36V
36V
SHAFT MATERIAL
Composite
Composite
Composite
Composite
Composite
Composite
Composite
Composite
SHAFT LENGTH
42”/105cm
48”/120cm
48”/120cm
54”/135cm
48”/120cm
54”/135cm
54”/135cm
60”/150cm

2: Check to see propeller is secure and not damaged.
3: Check shaft to ensure it is not bent. Detach
propeller and run motor visually to ensure shaft
is not shaking. If shaft is damaged contact your
retailer.
Loss of speed setting 1: Check all wiring connections.
2: Speed coil in motor may be burned,
contact your retailer.
Tight steering 1: Loosen counterforce screw, apply lubricant
and readjust.
For problems not listed contact your retailer
MAINTENANCE
At the end of the day, wipe the motor down with a cloth soaked in warm water and
then rinse unit with light spray from hose. Always check the propeller is clear of line
or weed, regularly check all nuts, bolts and screws and lubricate all moving parts with
an aerosol lubricant. Clean terminal connections regularly and check for frayed wires or
loose connections.
STORAGE
When storing the motor, lubricate all moving parts and screws and store in a well-
ventilated, dry area. Do not leave the motor outside in winter for long periods, as this
will damage the permanent magnet in the unit.
