WaterTech Pool Blaster CX-1 User manual

EN
OPERATOR’S MANUAL
1
Contents
1. WARNINGS & CAUTIONS......................................................................
2. PACKAGE CONTENTS...........................................................................
3. SPECIFICATIONS....................................................................................
4. KNOWING YOUR UNIT...........................................................................
5. KNOWING THE CONTROL PANEL / Smart Features..........................
a. Select Cleaning Cycle........................................................................
b. Weekly Mode Running Schedule / Select Cleaning Mode.............
6. PREPARE THE CLEANER FOR USE.....................................................
a. Charging..............................................................................................
b. Filter Bag Mounting...........................................................................
7. START CLEANING..................................................................................
8. RETRIEVAL AFTER USE.......................................................................
9. OWNER PERFORMED MAINTENANCE................................................
a. Cleaning the Filter Bag......................................................................
b. Check the Filter Screen.....................................................................
c. Cleaning Bottom Cover.....................................................................
d. Impeller Maintenance.......................................................................
e. Long Term Storage............................................................................
10. CX-1 Calibration Procedure................................................................
11. CX-1 Troubleshooting..........................................................................
12. CX-1 FAQs.............................................................................................
2
3
4
5
6
7
8
9
9
11
13
14
15
15
15
16
17
19
20
22
23
Dear Valued Water Tech Customer,
Thank you for choosing Water Tech’s innovative new swimming pool
cleaner, the CX-1. The CX-1 has been designed to be completely “user
friendly” beginning with its “Hands-Free” launch into your pool. Simply
place the cleaner at poolside, press one button and the CX-1 will climb
into the pool by itself and get to work.
CX-1 VIP CUSTOMER SERVICE
Tel: [phone] EXT. 250
Email: [email protected]

2
IMPORTANT SAFETY INSTRUCTIONS
Save these instructions
This appliance is not intended for use by persons (including
children) with reduced physical, sensory and mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instructions concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
1. This product contains Li-Ion batteries. Do NOT abuse this product. If you suspect any damage to the
batteries, do NOT attempt to charge the robot, contact Water Tech Customer Service.
2. Do NOT store the CX-1 near heat or an open ame.
3. The safe temperature range for both use and storage is 41 to 113°F (5 to 45°C). Do not attempt to charge,
use, or store the CX-1 in temperatures outside of this range.
4. Using any charger other than the one provided with the unit will cause damage and possible injury.
Always charge the unit inside a dry, sheltered area.
5. Place the charger in a shaded dry area during both charging and storage. Keep away from
direct sunlight and liquids.
6. Maintain a minimum distance of 3m (10ft.) from the edge of the pool when recharging the batteries of the
cleaner.
7. Before operation, unplug the charging cable from the control box.
8. Unit is NOT intended for COMMERCIAL USE. Unit is NOT intended for OPENING A POOL.
9. Do not enter the pool while the pool cleaner is working. When the robot is in sleep mode, it is safe to
enter the pool.
10. Ensure the electrical outlet used for charging is protected by a ground fault circuit interrupter (GFCI) or
an earth leakage interrupter (ELI). DO NOT use an extension cord or power strip.
11. The pool cleaner must be charged for 1.5 - 2.5 hours before long term storage.
12. The sole purpose of this product is for use as a robotic pool cleaner as described in this manual; any
modications or other use will VOID the warranty.
13. Do not allow children to use, touch, or play near or around the unit and the charger.
14. Do not use if the unit or charger is damaged in any way.
15. MAKE SURE the robotic pool cleaner is unplugged from its power supply and turned o󰀨 before opening
the unit or performing any other maintenance.
16. It is recommended that you clean your lter and check the impeller to make sure it is free and clear of
debris after every use.
17. Disconnect the charger from the outlet when not in use.
18. If your robotic pool cleaner is not working as it should or has been dropped or damaged in any way,
contact Water Tech Customer Service.
19. Save these instructions. Refer to them frequently. Provide these instructions to others who may use
the product.
Before using your CX-1, please read the following warnings
and read carefully through this Operator Manual.

3
Package Contents
Pool Blaster CX-1
Hook Charger
* The hook attaches to your
standard size pool pole to help you
retrieve the unit from your pool.

4
Specications
Cleaning Coverage (sq. ft./hr.).................3542 sq. ft./hr.
Minimal Operation Depth........................................16 in.
Maximum Operation Depth.....................................15 ft.
Run Time.................................................Up to 4 Hours.
Charging Time................................................6-8 Hours.
Cleaning Width.......................................................18.0”.
Suction Power...................................Up to 7200 gal. /hr.
Unit Size..........................................19.85 x 18.0 x 11.0”.
Unit Weight...........................................................21 lbs.
Shipping Weight...................................................27 lbs.
Retrieval Hook Adapter............................................Yes.
Warranty.............................................................2 years.
CX-1 Specications
Charger Specications
AC-DC CHARGER:
• Input: 100-240AC Volts
50-60Hz
60W
1.5A
•Output: 29V
2.0A
Battery Specications
Battery type..............................................Li-Ion.
Battery Conguration................................6S4P.

5
Knowing Your Unit
Full Unit Full Unit - Rear
Full Unit - Bottom Bottom - Cover Closed
Bottom - Filter Bag - Cover Filter Bag with Cover

*
6
Knowing The Control Panel
On the next page, you will nd more detail on how each mode and cycle works.
*Note: When your CX-1 is in sleep mode, only the Battery LEDs (and ON/OFF LED for “Weekly”
Mode) will stay ON.
No matter which modes are chosen, these smart features are included into the software:
• Upside-down: The CX-1 is fully capable of detecting when it is upside-down and can then reorient itself
to continue cleaning. It also has a feature where, if it cannot ip itself over (such as if it is stuck on an
obstacle or too full of heavy debris), it will shut itself OFF to avoid wasting energy from the batteries.
When this happens, you can ip over your CX-1 and it will start cleaning again.
• Out of water: The CX-1 can detect when it is in or out of water and will avoid wasting energy when it is
out of the water. It will also drive itself back into the water, which is especially useful for beach style
pools or pools with steps. If the CX-1 is out of water for too long, it will shut itself down (with the LEDs
still ON). To continue operation you must turn it OFF and ON again.
• Cleaning Path: The CX-1 is programmed with a completely unique cleaning path that will t any non-
commercial size, shape, and style of pool.
Smart Features

7
You can program the CX-1 to run continuously or in intervals over a week long period.
a. Select Cleaning Cycle
1-Day Cleaning Cycle
• 1-Day: The CX-1 will run continuously for up to 2
hours and then go into sleep mode. If 2 hours is not
enough, you can wake the robot from the sleep mode
to start another 2-hour cycle. The robot can run for
two “1-Day” cycles on a single charge. This mode is
most e󰀨ective for thorough cleaning of a dirty pool.
Weekly Cleaning Cycle
• In “1-Day” Sleep mode the ON/OFF LED is o󰀨 and
both battery LEDs stay on. The robot will not wake
from this “Sleep” mode until you turn the robot OFF
and ON (or press the “Cleaning Cycle” button). It is
recommended to turn the robot OFF if you do not
intend on using it again immediately.
Sleeping during 1-Day
Cleaning Cycle
Sleeping during Weekly
Cleaning Cycle • When in Weekly Sleep mode, both Cleaning Mode and
Cleaning Cycle LEDs will turn o󰀨. Only the ON/OFF
LED and the battery LEDs will stay on for the entire
time that the robot is in sleep mode. You can leave the
CX-1 in your pool while it’s in sleep mode. If you take
your CX-1 out of the pool, make sure you place it facing
the pool so it can drive itself back in when it wakes up.
• Weekly: The CX-1 will run on a schedule (illustrated
on next page) that will end after 7 days, at which point
the battery will be fully discharged. This mode is most
e󰀨ective for maintaining a clean pool as it will clean
the debris that slowly accumulates throughout the
week.

Floor Only Mode
8
b. Select Cleaning Mode
• Cleaning Modes: The CX-1 is equipped with tilt sensors to help achieve the customer’s
desired cleaning mode.
• Floor & Walls – The CX-1 will clean the
oors and climb the walls, enabling the
CX-1 to scrub the waterline.
Floor & Walls Mode
• Floor Only – The CX-1 will stay on the
oor, picking up debris and scrubbing
scum. It will partially climb the walls
enough for it to clean the hard to reach
edges along the bottom of some pools.
Weekly cycle runs your robot every day for a full week. Starting from when you rst turn it
on, the robot will clean approximately 60 minutes. Then at the same time every day for the
remainder of the week, the robot will run for approximately 30 minutes.
Weekly Cycle Running Schedule

9
Prepare the Cleaner for Use
a. Charging your cleaner
• End #1: To unit’s charging jack.
• End #2: To an Indoor Grounded
Residential power source.
Make sure there is no water present on
the pins of the Unit’s charging jack.
CHARGING TIME: 6-8 HOURS
Be sure to charge in a dry, shaded area.
1.
2.
(The CX-1 will not run when the charger is plugged in).
The robot cannot be charged while in the pool. But the robot can be charged immediately after removing from the pool. Just
make sure that the pins of the robot’s charging jack are dry before plugging in the charger.
Charger Unit’s Charging Jack
DO NOT charge outside of the accepted temperature range: 41 to 113°F (5 to 45°C)
DO NOT use extension cord or power strip.
DO NOT expose charger to water or direct sunlight.
DO NOT leave unit plugged into charger for extended periods of time.
DO NOT leave unit plugged into charger during long term storage.
ONLY USE the charger that came with the unit.

10
If the CX-1 is charging with the Power (ON/OFF)
Button turned ON, the “1-Day”, “Weekly”, and “ON/
OFF” LEDs will be ON (as shown on the left). The
CX-1 will not be able to operate until the Power (ON/
OFF) Button is turned OFF and then back ON. If
you notice these LEDs are ON during charging, it
is recommended that you turn the Power (ON/OFF)
Button OFF.
*This is a safety feature to ensure that the CX-1 does not
turn itself ON while charging or shortly after unplugging
the charger.
Battery Packs Charging (Flashing) Battery Packs Charged (Solid)
If one or both LEDs are not ashing or do not turn solid, contact Water Tech Customer Service.
As both battery packs are charging,
the LEDs (shown above) will ash.
Once a battery pack is fully charged, its
LED will turn solid. It is common for 1 LED to
turn solid before the other.

11
Prepare the Cleaner for Use
b. Filter Bag mounting
Closed Cover Unlocked Cover
Filter Bag & Cover (Out) Filter Bag
To remove the Filter Bag, ip the CX-1
upside-down and turn the knob on the
bottom counter-clockwise.
You will feel the knob “snap” as the lock
is undone. Note that the locks will move
inwards. This means the cover
is unlocked.
Pull out the entire bottom cover. The lter
bag will be locked by the locking tabs
inside the cover (Illustrated above as #1
and #2). To remove the lter bag, carefully
push the lter bag out of the locking tabs.
Remove the bag and rinse out with a
hose or in a sink.

12
Filter Bag & Cover (In) Lock Cover
Closed Cover
Re-insert the lter bag with the cover on
top. Make sure you lock the bag under
the two locking tabs (Illustrated above as
#1 and #2). Then, insert bag into unit as
you lower the cover into place.
Turn the knob clock-wise to lock the
cover. You will hear a “snap” again as the
cover locks.
The locking tabs will move outwards.
This means the cover is locked.

13
Start Cleaning
Aim at the pool
Aim the CX-1 at the pool (place robot roughly
3 ft. from the edge of the pool).
For above ground pools, drop the robot in the pool after
selecting your desired settings
Push the ON/OFF button and select your
desired Cleaning Cycle and Cleaning Mode.
When the CX-1 is done charging, it’s
important that you DO NOT submerge the
CX-1 in water without replacing the rubber
plug covering the charging jack. Failure to
follow this step could damage your unit.
(After the robot is turned on, you will have 10 seconds to
select your desired Cleaning Mode and Cleaning Cycle
shown on Page 7-8)

14
Retrieval After Use
Rest the CX-1 on the edge of the pool to allow water to drain from the
drain valve. Turn the power switch OFF when removing from pool, even
if the batteries are fully discharged.
Cleaner can stay in the pool for up
to 7 continuous days, even with
the battery fully drained.
Lift the CX-1 to the surface using a slow, steady pulling
motion. Remember, the CX-1 is heavy while full of water.
Warning! Risk of Drowning!
NOT a life saving device. Never allow
children or persons who cannot swim to
use this product. This product is designed
to be used around a residential swimming
pool and a person who cannot swim can
drown if they accidentally fall into the pool
while using or retrieving this product.

15
Owner Performed Maintenance
a. Filter Bag
Always remove and clean the lter bag
after every use. Do not store the unit with
a dirty lter.
b. Filter Screen
Check the lter screen (Highlighted in
red above) for any debris that may have
escaped the lter bag. It is recommended
to occasionally clean the inside of the
unit with a hose.

16
3. Align the valve mounts with the
bottom cover and press down
into place.
4. Press until triangular tabs snap back
over valve mounts.
c. Cleaning bottom cover
1. Press outward on the bottom cover so
the valve mount can t around triangular
tabs (shown circled above).
2. While still pressing outward, lift the
valve mount up and out of the bottom
cover. Rinse out the valve mounts and
bottom cover.

17
3. If you notice any debris around the
impellers, then follow these steps. Use a
screwdriver to remove the small screw
used to hold in the cover.
4. Tilt the cover. Lift away from the unit.
CAUTION: Make sure the unit is turned OFF
before performing maintenance to impellers!
1. It is important to routinely check for
debris trapped in the impeller. The
“Floor Only” LED on the control box
will start ashing if the unit detects
that there is signicant debris
in the impellers.
2. Look down at the unit from the
top and check for debris around the
impellers (circled above).
d. Impeller Maintenance

18
6. Reassembling Covers: Insert the tab
of the cover into the slot on the top
of the unit.
7. Align the screw hole of the cover with
the screw hole on the top of the unit.
8. Tighten the small screw into the
screw hole mentioned above.
5. Check inside for any debris and
remove the debris by hand.
CAUTION: Make sure the unit is turned OFF
before performing maintenance to impellers!

19
e. Long Term Storage
3 Months
Number of Months
to be Stored
Number of Hours
to be Charged
Charge for
1.5 hours
Charge for
2 hours
Charge for
2.5 hours
6 Months 9 Months
• The CX-1 must be stored at a temperature between 41 to 113°F (5 to 45°C).
• After 9 months of storage, charge the batteries for 2 hours every 6 months.
• Always store your CX-1 in a warm, dry, indoor shelter.
• Don’t leave the CX-1 plugged into the charger.
• At the start of the next season, charge the robot and make sure BOTH BATTERY LEDs
start ashing while charging.
If one or both LEDs are not ashing, contact Water Tech Customer Service.
• Before long term storage, run the CX-1 until the batteries are fully discharged. Then use the chart
below to charge the batteries the appropriate amount before storing.
