Watts LF1170 Series User manual

IS-1170-M2_L1170-M2
Instructions
Series LF1170 and LFL1170
Hot Water Temperature Control Valves
Size: 1⁄2", 3⁄4", 1"
LF1170-UT-M2 LF1170-QC-M2
Installation
Valve should be installed and adjusted by a licensed contractor
in accordance with local codes and ordinances. Further, this
valve should be installed in a location where it is accessible for
cleaning, service or adjustment.
1. Close both the hot and cold water shutoff valves upstream
nearest to the intended installation.
2. Bleed the remaining water from the system.
3. Connect the water supply to valve as shown in Figure 1 or 2,
depending on the application. Supply piping must be flushed
clean before making connections to the valve.
NOTICE
To prolong the life of the Model LF1170-M2 or LFL1170-M2
valve, it is recommended that it be trapped as shown (Figure1):
i.e. the hot water inlet to the LF1170-M2 valve should be 8" –
12" (200 – 305mm) below the hot water supply feed.
4. Valve can be installed in any position. Note: the inlet hot sup-
ply is to be connected to the “H” side of the valve, the cold
supply side to the “C” side and the mixed water outlet to the
“M” side.
5. Make sure union nuts are placed over tailpieces prior to
soldering or threading to pipe.
6. For valves with Quick-Connect tailpieces refer to “Quick-
Connect Installation” instructions below.
NOTICE
To prevent damage to valve from excessive heat during
soldering, remove unions and gaskets from valve body prior to
soldering.
7. After soldering, flush piping and install valve using filter wash-
er on hot and cold water inlet and fiber washer on the mixed
water outlet.
8. Start-up: Open cold water supply, then hot water supply.
Inspect for leaks.
9. Adjust temperature to desired setting (see Temperature
Adjustment Section).
WARNING
!
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use information
can result in death, serious personal injury, property
damage, or damage to the equipment.
Keep this Manual for future reference.
WARNING
!
Use caution when soldering. Protect yourself and others. FUMES
AND GASES can be hazardous to your health. HEAT RAYS (INFRARED
RADIATION) from flame or hot metal can injure eyes.
WARNING
!
You are required to consult the local building and plumbing
codes prior to installation. If the information in this manual
is not consistent with local building or plumbing codes,
the local codes should be followed. Inquire with governing
authorities for additional local requirements.
WARNING
!
WARNING
!
Need for Periodic Inspection and Yearly Maintenance:
Periodic inspection and yearly maintenance by a licensed
contractor is required. Corrosive water conditions, tempera-
tures over 200°F, unauthorized adjustments or repair could
render the valve ineffective for service intended. Regular
checking and cleaning of the valve’s internal components and
check stops helps assure maximum life and proper product
function. Frequency of cleaning and inspection depends upon
local water conditions.
FAILURE TO COMPLY WITH PROPER INSTALLATION AND
MAINTENANCE INSTRUCTIONS COULD CONTRIBUTE TO THE VALVE
FAILURE.
This Hot Water Master Tempering Valves cannot be used for temper-
ing water temperature at fixtures. Severe bodily injury (i.e., scalding
or chilling) and/or death may result depending upon system water
pressure changes and/or supply water temperature changes. ASSE
standard 1016, 1069 or 1070 listed devices should be used at fix-
tures to prevent possible injury.
These Hot Water Tempering Valves are designed to be installed at or near
the boiler or water heater. They are not designed to compensate for sys-
tem pressure fluctuations and should not be used where ASSE standard
1016, 1069 or 1070 devices are required. These valves should never be
used to provide “anti-scald” or “anti-chill” service.
The components of the system must be of materials with a construction
capable of withstanding the high limit output temperatures of the water
heating source.
WARNING
!
http://waterheatertimer.org/How-to-save-hot-water-using-mixing-valve.html
Figure 2
Radiant Heat Application
from Boiler
Cold
Radiant Return
Mixed
to Radiant
to Boiler
Watts Flow
Check Watts
Ball Valve
TP
Test Plug
Watts
Ball Valve
RPV
CV, CVS
Check Valve
Circulator
LF1170-M2,
LFL1170-M2
Hotter
3/32" Hex Wrench
Turn
Colder
Unscrew, lift
cap to adjust
Figure 3
Temperature Adjustment
Factory Preset:
LF1170-M2: 120°F (49°C)
LFL1170-M2: 90°F (31°C)
Under following conditions:
Cold Inlet: 60-70°F (16-21°C)
Hot Inlet: 140-145°F (60-63°C)
Supply Pressure: 45psi (3.15 bar)
1. Let water flow for at least two minutes to allow supply tem-
perature to stabilize.
2. Calibrate the mixed water outlet temperature by placing a
thermometer in the mixed water stream.
3. To adjust the setting of the valve, loosen locking cap screw
with hex wrench, see Figure 3. Cap must be lifted 1/4" to
adjust temperature. To increase the temperature, turn coun-
terclockwise. To decrease temperature turn clockwise.
4. Lower handle and tighten screw.
5. Check outlet temperature.
Quick-Connect Installation
1. Mark pipe as shown.
This is pipe insertion depth.
2. Clean pipe end.
1. Remove collet clip. 2. Depress collet.
3. Pull tubing from tailpiece.
3. If using PEX tubing, insert pipe
stiffener (provided) into end of pipe. 4. Push tubing into tailpiece up to mark.
5. Insert collet clip.
To Connect
To Disconnect
PEX tubing only
Pipe Stiffener
Tail Piece
Mark
Collet clip
Collet depressed
11/2in. (38.1mm)
13/4in. (44.45mm)
17/8in. (47.63mm)
3/4in.Pipe (19.05mm)
1 in.Pipe (25.4mm)
1/2in.Pipe (12.7mm)
Figure 1
Domestic Hot Water Application
Watts
Vacuum Relief
Valve
Watts
Temperature
Gauge
Cold
Cold
Cold
LF1170-M2 or
LFL1170-M2
Tempered †
Hot
Hot to
Appliances
Watts T&P
Relief Valve
*8" – 12"
H
C
M
Domestic Hot Water Application
NOTICE
To prolong the life of the valve, it is recommended the valve
be trapped as shown
†Devices tested to ASSE 1016, ASSE 1070 or ASSE 1069
such as Watts LFUSG, LFL111 or LFMMV should be used
at fixture to prevent possible injury.
Troubleshooting Guide
Series LF1170-M2 and LFL1170-M2
Period Inspection/Maintenance
This valve requires periodic inspection and verification of the out-
let temperature by a licensed contractor. Corrosive water condi-
tions, hot inlet water temperature over 200°F (93°C), unauthor-
ized adjustments or repairs could render the valve ineffective for
its intended service. Regular cleaning and checking of thermo-
stat assembly helps to maximize valve life and mixing function.
Frequency of cleaning depends on local water conditions.
Pressure — Temperature
Minimum Supply Pressure (Static): 30psi (207 kPa)
Inlet Temperatures: hot inlet, 120°F – 200°F (49°C – 93°C),
cold inlet, 40°F – 85°F (4°C – 29°C)
Hot Water Inlet to Outlet Differential Temperature: 5°F (3°C)
LF1170-M2 Temperature Out:
Field range: 90°F – 160°F (32°C – 71°C), adjustable.
Accurate within ±3°F (1.7°C)
LFL1170-M2 Temperature Out:
Field range: 60°F – 120°F (16°C – 49°C), adjustable.
Accurate within ±3°F (1.7°C)
Maximum Temperature: 200°F (93°C)
Maximum Pressure: 150psi (10.3 bar)
Maximum Pressure Differential Between Hot and Cold
Water Supplies: 25%.
Approval: CSA B125 certified
Listing: ASSE 1017 and IAPMO UPC
Symptom Cause Solution
Unable to reach required set point or set
point difficult to set
1. Supply temperatures not within specified
limits
2. Hot and cold supplies reversed
3. Filters are blocked by debris
1. Check differential temperature between hot
and cold supplies and outlet 10°F (5.6°C)
minimum required
2.Reinstall valve with supplies connected to
marked inlets
3. Clean filters
Unable to achieve required flow 1. Too much pressure drop at fixture
2. Checks valve/filters blocked by debris
1. Measure supply pressures and check
against flow chart. Look for restrictions in
valve or piping
2. Clean check valves/filters
Valve does not maintain required temper-
ature or temperature changes over time
1. Fluctuation in supply pressures
2. Check valve/filters blocked by debris
3. Recirculation loop not piped properly
1. Stabilize water pressures with pressure
regulating or balancing valves
2. Clean check valves/filters
3. Pipe recirculated tempered water return so
it connects to hot water source and cold
side of mixing valve (see Product Guide for
piping details)
Discharge temperature too hot or cold 1. Valve not calibrated properly 1. Readjust valve temperature per installation
instructions
Hot water from cold water tap or cold
from hot
1. Check valves fouled 1. Clean check valves/filters
Valve is noisy 1. Water velocity is too high
2. Valve not sized properly
1. Reduce water velocity with pressure
regulating valves
2. Check flow required versus rated flow
capacity of valve
No flow from valve 1. Hot or cold water supply failure or shutoffs
closed
2. Check valve/filters blocked by debris
1. Open shutoffs or restore hot and cold sup-
ply
2. Clean check valves and filters
Flow from valve fluctuates 1. Fluctuation in supply pressures
2. Check valve/filters blocked by debris
1. Stabilize water pressure with pressure regu-
lating valves
2. Clean check valves and filters
ATTENTION INSTALLER: After installation, please leave this
Instruction Sheet for occupant’s information.
IS-1170-M2_L1170-M2 1325 EDP# 1915905 © 2013 Watts
USA: Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.watts.ca
Limited Warranty: Watts Regulator Co. (the “Company”) warrants each product to be free from defects in material and workmanship under normal usage for a period of one year from the date of
original shipment. In the event of such defects within the warranty period, the Company will, at its option, replace or recondition the product without charge.
THE WARRANTY SET FORTH HEREIN IS GIVEN EXPRESSLY AND IS THE ONLY WARRANTY GIVEN BY THE COMPANY WITH RESPECT TO THE PRODUCT. THE COMPANY MAKES NO OTHER
WARRANTIES, EXPRESS OR IMPLIED. THE COMPANY HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for breach of warranty, and the Company shall not be responsible for any incidental, special
or consequential damages, including without limitation, lost profits or the cost of repairing or replacing other property which is damaged if this product does not work properly, other costs resulting
from labor charges, delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions, chemical, or any other circumstances over which the Company has no
control. This warranty shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or alteration of the product.
Some States do not allow limitations on how long an implied warranty lasts, and some States do not allow the exclusion or limitation of incidental or consequential damages. Therefore the above
limitations may not apply to you. This Limited Warranty gives you specific legal rights, and you may have other rights that vary from State to State. You should consult applicable state laws to
determine your rights. SO FAR AS IS CONSISTENT WITH APPLICABLE STATE LAW, ANY IMPLIED WARRANTIES THAT MAY NOT BE DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL SHIPMENT.
A Watts Water Technologies Company
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm.
For more information: www.watts.com/prop65
For valves with CPVC or PEX end connections, do not exceed the
tubing manufacturers pressure and temperature ratings. Refer to the
tubing manufacturers product specications for that information.
WARNING
!

This manual suits for next models

5

Other Watts Control Unit manuals

Watts Ames 920GD-15 Owner's manual

Watts

Watts Ames 920GD-15 Owner's manual

Watts AMES Deringer 20X User manual

Watts

Watts AMES Deringer 20X User manual

Watts LFM118-4 Owner's manual

Watts

Watts LFM118-4 Owner's manual

Watts AMES 960GD-15-17 Installation and operating instructions

Watts

Watts AMES 960GD-15-17 Installation and operating instructions

Watts LFM127-32 Installation and operating instructions

Watts

Watts LFM127-32 Installation and operating instructions

Watts WFC-03 HCM RF 230 User manual

Watts

Watts WFC-03 HCM RF 230 User manual

Watts AMES 981GD User manual

Watts

Watts AMES 981GD User manual

Watts AMES 960GD-17 Installation and operating instructions

Watts

Watts AMES 960GD-17 Installation and operating instructions

Watts LFM513-6 Installation and operating instructions

Watts

Watts LFM513-6 Installation and operating instructions

Watts CIVIC4 User manual

Watts

Watts CIVIC4 User manual

Watts AMES 910GD-11 Installation and operating instructions

Watts

Watts AMES 910GD-11 Installation and operating instructions

Watts iDROSET CF Series User manual

Watts

Watts iDROSET CF Series User manual

Watts AMES 979GD User manual

Watts

Watts AMES 979GD User manual

Watts LF70A Series User manual

Watts

Watts LF70A Series User manual

Watts LFM115-58 Installation and operating instructions

Watts

Watts LFM115-58 Installation and operating instructions

Watts 995 Series Setup guide

Watts

Watts 995 Series Setup guide

Watts Ames 912GD-11 Owner's manual

Watts

Watts Ames 912GD-11 Owner's manual

Watts 980GD-16-19 User manual

Watts

Watts 980GD-16-19 User manual

Watts LFM114-1 Installation and operating instructions

Watts

Watts LFM114-1 Installation and operating instructions

Watts USG-P-M1 User manual

Watts

Watts USG-P-M1 User manual

Watts AMES 979GD-20 Installation and operating instructions

Watts

Watts AMES 979GD-20 Installation and operating instructions

Watts 007 Series Instruction Manual

Watts

Watts 007 Series Instruction Manual

Watts MS20 User manual

Watts

Watts MS20 User manual

Watts AMES 950GD Installation and operating instructions

Watts

Watts AMES 950GD Installation and operating instructions

Popular Control Unit manuals by other brands

FDI ELI43-CR quick start guide

FDI

FDI ELI43-CR quick start guide

ADTRAN MX2820 manual

ADTRAN

ADTRAN MX2820 manual

MD mXion PSD user manual

MD

MD mXion PSD user manual

Progres Agronic 2000 Series instruction manual

Progres

Progres Agronic 2000 Series instruction manual

WAMGROUP VCP R03 Series manual

WAMGROUP

WAMGROUP VCP R03 Series manual

Cavli Wireless C16QS Hardware manual

Cavli Wireless

Cavli Wireless C16QS Hardware manual

Harvia C260 manual

Harvia

Harvia C260 manual

Monacor ATT-324PEU operating instructions

Monacor

Monacor ATT-324PEU operating instructions

DeZurik BAW AWWA Installation, operation and maintenance manual

DeZurik

DeZurik BAW AWWA Installation, operation and maintenance manual

Ecolab EMP Kompakt II Quick reference guide

Ecolab

Ecolab EMP Kompakt II Quick reference guide

Superior Electric SLO-SYN Micro Series instructions

Superior Electric

Superior Electric SLO-SYN Micro Series instructions

CRE Technology i4GEN Technical documentation

CRE Technology

CRE Technology i4GEN Technical documentation

Team Blacksheep TBS FUSION manual

Team Blacksheep

Team Blacksheep TBS FUSION manual

Graco PD44 operation & maintenance

Graco

Graco PD44 operation & maintenance

Frequency Central Raging Bull 2.0 Build documentation

Frequency Central

Frequency Central Raging Bull 2.0 Build documentation

Allen-Bradley Micro800 2080-MEMBAK-RTC2 user manual

Allen-Bradley

Allen-Bradley Micro800 2080-MEMBAK-RTC2 user manual

Nexta Tech TOP-M400/One manual

Nexta Tech

Nexta Tech TOP-M400/One manual

Lutron Electronics GRAFIK Eye QSGRJ-3P Installation and operation guide

Lutron Electronics

Lutron Electronics GRAFIK Eye QSGRJ-3P Installation and operation guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
