Wave Point 01031 User manual

• READ AND FOLLOW THE GUIDELINES TO ENSURE THE PROPER USE AND APPLICATION.
FAILURE TO FOLLOW THESE GUIDELINES MAY RESULT IN FIXTURE DAMAGE, ELECTRICAL
SHOCK, FIRE AND/OR INJURY.
• WARNING! LAMPS CAN BE HOT. HANDLE WITH CARE.
• NEVER TOUCH THE LAMP WHILE OPERATING. BEFORE WORKING ON THE FIXTURE AND/OR
AQUARIUM, THE FIXTURE MUST BE DISCONNECTED FROM THE POWER SUPPLY.
HIGH OUTPUT T5 Fluorescent 2 Lamp Lighting System
• World’s Most Advanced Aquatic Lighting System
• 14X Light Amplifying Paradynamic Reector
• Dual Sealed, Moisture Resistant Fixture
• Premium UL Listed GFCI Plug
• Sealed Glass Splash Guard
• On/Off Switch
• Energy Efcient
• Ultra-Silent & No Fan Needed
WARNING! Buyer/user assumes all responsibility
for safety and proper use not in accordance with the
directions and safety labels.

Tab
C
A
D
B
F
E
G
Paradynamic
reflector
Electronic ballast
SUN WAVE®
Super Daylight
12,000k HO T5 Lamp
SUPERBLUE 460®
Super Blue Actinic
460 HO T5 Lamp
GFCI
Plug
Extruded aluminum
fixture
Mounting legs
ON/OFF
Switch
5mm hex driver
(not included)
Drip Loop
GFCI
ONLY
PAGE 2 PAGE 3
IMPORTANT WARNING AND SAFEGUARDS
WAVE POINT® High Output T5 Fluorescent
2 Lamp Lighting System
Includes: 1 Sun Wave®and 1 Superblue 460®lamps
MODEL # DESCRIPTION
01031 48 watt 24in High Output (2x 24w) T5 Fluorescent 2 Lamp Lighting System
01032 78 watt 36in High Output (2x 39w) T5 Fluorescent 2 Lamp Lighting System
01033 108 watt 48in High Output (2x 54w) T5 Fluorescent 2 Lamp Lighting System
PART LIST
1. Extruded aluminum xture
2. 14X Light Amplifying Paradynamic Reector
3. Sun Wave®and Superblue 460®HO T5 lamps
4. Electronic ballast
5. Mounting legs
6. 5 mm hex driver
7. On/Off switch
8. GFCI plug
INSTRUCTIONS FOR INSTALLATION
NOTE: Only place in well ventilated canopy. This light xture is intended to be
above the aquarium. Do not place directly on top of any aquarium without using
mounting legs. Do not place above the aquarium without a glass top.
INSTALLING LEGS TO THE FIXTURE
Required tools: Philips screwdriver
1. Remove tabs on the power supply side of the xture to install legs (A)
2. Position the light xture upside down. Install each leg so
that the at side of the leg is facing outwards (C). Legs
only slide into the xture on the side plate with the power
supply cord.
3. Reinstall tabs (D).
4. Adjust legs for the width of the aquarium (E) and then
Secure the legs buy tightening set screws on the legs (F).
5. Place directly on top of the aquarium (G).
6. Plug directly into a receptacle. Note it may be required to
reset the GFCI to start the light xture. Press reset.
Read and follow the guidelines to ensure the proper
use and application. Failure to follow these guidelines
may result in light xture damage, electrical shock,
re and/or injury.
1. Use this product for its intended use only.
2. Never yank or pull the cord from the electrical outlet.
3. Do not place the light xture directly on top of the aquarium without
using mounting legs.
4. Do not operate if the plug or wire is damaged.
5. The light xture is not to come in contact with water.
6. The light xture must be turned off/disconnected from the power
supply before any maintenance is done to either the light xture or
the aquarium.
7. Verify that hands are dry prior to disconnecting the power.
8. To reduce the risk of electrocution keep all connections dry.
9. If the light xture falls or comes in contact with water/excess moisture,
unplug the light xture from the power supply immediately before
removing. Failure to do so may cause electrical shock or injury.
10. The light xture and connections need to be free of water, moisture
and salt build up at all times. Failure to do so will cause electrical
arching resulting in possible re or electrical shock.
11. Do not place above an open top aquarium.
This product may contain chemicals known to the state of California
to cause cancer and or birth defects or other reproductive harm.
Wash your hand after handling this product.
It is your sole responsibilitiy to verify that the plug and the
receptacle are clean and free of moisture and salt build up at
all times. The receptacle must be free of water, salt, calcium,
magnesium and dust. Failure to do so can cause fire, damage to
property, permanent damage to the product and personal injury not
limited to loss of life.
Do not plug into extension cord/power strip.
Hg lamp contains Mercury
Manage in accordance with disposal laws
See: www.lamprecycle.org
A drip loop must be used when plugging
all electrical aquarium devices. A drip
loop is that part of the cord hanging
below the receptacle.
The national code requires that a GFCI
(Ground fault circuit interrupter) be used
in the branch circuit supplying all power
to water pumps and electrical aquarium
equipment. If you do not have a GFCI,
have an electrician install one prior to
operating any aquarium component.

Press Tab
F
E
A
B
B
C
D
I
K L M
J
H
G
Press Down
Gasket
Push in
Align one side
PAGE 4 PAGE 5
MAINTENANCE
LAMP REPLACEMENT
Tools required: Phillips screwdriver and 5 mm hex driver
1. Unplug the unit from the receptacle (A). Position the light
xture upside down on a at surface so that the light
xture side plate with the AC cord is accessible. Loosen
all 6 screws to remove the side plate (B).
2. Disconnect the side plate from the ballast (C).
3. Slide the reector completely out of the light xture and
replace lamp (D).
4. Verify the lamps are properly installed and are securely in
place before reinstalling the reector.
BALLAST REPLACEMENT:
Tools required: Phillips screwdriver, 5mm hex driver
1. Unplug the unit from the receptacle (A). Position the light
xture upside down on a at surface so that the light
xture side plate with the AC cord is accessible. Loosen
all 6 screws to remove the side plate (B).
2. Disconnect the side plate from the ballast (C).
3. Slide the reector completely out of the light xture and
take out all lamps on the reector to avoid damaging the
lamp (D).
4. Position the reector so the the ballast facing up.
5. Disconnect the power supply. Press on tabs to pull wire
directly out of the socket (E).
6. Use the 5 mm hex driver and screwdriver to loosen nuts
and remove the mounting bracket (F).
7. Use the 5 mm hex driver and screwdriver to loosen nuts
and remove ballast (H).
8. Replace with new ballast and follow the wire diagram
provided on the ballast. When replacing the ballast and
inserting the wire, press tab in then insert wire.
MAINTENANCE:
REINSTALL REFLECTOR
1. Align reector with grooves inside the xture (I).
2. Reconnect the ballast to the side plate.
3. Verify the wires will not crimp or impede the installation (J).
4. Replace gasket if neccesary.
5. Place hood on the side and align the bottom of the side plate with the hood (K). Secure the bottom with a screw. Press
down on the hood and connect the top of the side plate with the hood (L). Secure with all 6 screws (M).
TROUBLESHOOTING
PROBLEM: All lamps will not light.
SOLUTION: Lamps in shipping have moved and are not making a proper connection. See Lamp replacement procedure for proper lamp installation.
FOR QUESTIONS AND ANSWERS, VISIT OUR WEBSITE
www.wave-point.com

PAGE 6 PAGE 7
REPLACEMENT LAMPS
COLOR MODEL # DESCRIPTION
COLOR WAVE®
Optimum Color Enhancer
01004 24 watt COLOR WAVE®Optimum Color Enhancer HO T5 Lamp 21in
01005 39 watt COLOR WAVE®Optimum Color Enhancer HO T5 Lamp 33in
01006 54 watt COLOR WAVE®Optimum Color Enhancer HO T5 Lamp 45in
TROPICAL WAVE®
Full Spectrum Daylight 6,500k
01007 24 watt TROPICAL WAVE® Full Spectrum Daylight 6,500k HO T5 Lamp 21in
01008 39 watt TROPICAL WAVE® Full Spectrum Daylight 6,500k HO T5 Lamp 33in
01009 54 watt TROPICAL WAVE Full Spectrum Daylight 6,500k HO T5 Lamp 45in
SUN WAVE®
Super Daylight 12,000k
01010 24 watt SUN WAVE® Super Daylight 12,000k HO T5 Lamp 21in
01011 39 watt SUN WAVE® Super Daylight 12,000k HO T5 Lamp 33in
01012 54 watt SUN WAVE® Super Daylight 12,000k HO T5 Lamp 45in
SUPERBLUE 460®
Super Blue Actinic 460
01013 24 watt SUPERBLUE 460®Super Blue Actinic 460 HO T5 Lamp 21in
01014 39 watt SUPERBLUE 460®Super Blue Actinic 460 HO T5 Lamp 33in
01015 54 watt SUPERBLUE 460®Super Blue Actinic 460 HO T5 Lamp 45in
REEF WAVE®
Super Violet O3 Actinic 420
01016 24 watt REEF WAVE®Super Violet O3 Actinic 420 HO T5 Lamp 21in
01017 39 watt REEF WAVE®Super Violet O3 Actinic 420 HO T5 Lamp 33in
01018 54 watt REEF WAVE®Super Violet O3 Actinic 420 HO T5 Lamp 45in
CORAL WAVE®
Coral Growth Accelerator
01022 24 watt CORAL WAVE®Coral Growth Accelerator HO T5 Lamp 21in
01023 39 watt CORAL WAVE®Coral Growth Accelerator HO T5 Lamp 33in
01024 54 watt CORAL WAVE®Coral Growth Accelerator HO T5 Lamp 45in
ULTRA GROWTH WAVE®
Plant and Reef Accelerator
01082 24 watt ULTRA GROWTH WAVE®Plant and Reef Accelerator HO T5 Lamp 21in
01083 39 watt ULTRA GROWTH WAVE®Plant and Reef Accelerator HO T5 Lamp 33in
01084 54 watt ULTRA GROWTH WAVE®Plant and Reef Accelerator HO T5 Lamp 45in
30 DAY PRODUCT GUARANTEE
•If within 30 days of purchase you experience any problems with this Wave point® Technology product,
return it to the retailer where purchased for replacement. Product must be returned in its original box,
with all original parts and must be accompanied by the original receipt as proof of purchase.
•Products beyond the 30 days of purchase that experience problems should NOT be returned
to the retailer, supplier, or distributor. These Wave point® products fall under the auspices of the
Wave point® Technology 1 year limited direct manufacturer warranty. All such problems must be addressed
directly with Wave point® by the warranty holder (see below).
1 YEAR DIRECT MANUFACTURER LIMITED WARRANTY
• Wave point® Technology. products are warranted to all registered warranty product owners to be free of defect
in materials and workmanship for one (1) year from date of purchase.
•URGENT: Fill out the warranty registration card included in this box to activate registration
in the Wave Point® limited warranty program. Warranty card must be completed and returned to Wave Point®
Technology. within thirty (30) days of purchase (Warranty Card ).
• Under this program, Wave Point® Technology. will, at its election, repair, replace or make appropriate
adjustment where inspection by the Wave Point® company discloses any such defects occurring in normal
usage within one (1) year after consumer purchase.
• Only properly registered Wave Point® products are eligible for this warranty service.
• After the 30 ( thirty ) day guarantee has expired, contact Wave Point® Technology. directly for warranty
product repair. Do NOT return such Wave Point® products to the retailer, distributor or supplier for repair or
replacement.
• Wave Point® Technology. is not responsible for any removal, installation or shipping costs incurred in the
warranty process.
• Lamps are not covered under the 1 Year limited warranty.
• Warranty is void if the failure of Wave Point® product or system or any part, sealant or component thereof
is found to be caused by misuse, tampering, negligence, abuse, misapplication, failure to properly maintain
the product, failure to keep dry (not to come in contact with water), salt build up, or use without Ground Fault
Circuit Interrupter.
• This warranty is non-transferable.
• This warranty is limited to possible parts replacement and labor connected therewith. Wave Point® Technology.
is not liable for any incidental or consequential damages including but not limited to loss of life, personal
injury, property damage, damage to equipment, or lost wages, income, prots or savings.
Note: some US states do not allow liability limitations or exclusions on incidental or consequential
damages to the extent listed in the above disclaimer. Check your local state regulations for details on
regulations specic to your state.
NOTE: WAVE POINT® TECHNOLOGY’S WARRANTY POLICY IS SUBJECT TO CHANGE WITHOUT NOTICE.

PAGE 8 PAGE 9
OPTIONAL 3 YEAR PREMIUM EXTENDED WARRANTY
is available for purchase online at www.wave-point.com/extendedwarranty.html
• Wave Point® Technology product owners may purchase our 3 Year Premium Extended Warranty online on our
web site within 30 days of purchase prior to the expiration of the 30 Day Product Guarantee. This warranty
covers all major parts and labor for 3 years from date of purchase.
• Costs are based on the equipment being placed under extended warranty. The costs for all extended warranty
plans are available online on the web site.
• Lamps are not covered under 3 year extended warranty.
• For complete details and enrollment go to www.wave-point.com/extendedwarranty.html
NOTE: WAVE POINT® TECHNOLOGY’S WARRANTY POLICY IS SUBJECT TO CHANGE WITHOUT NOTICE.
RETURNING PRODUCTS FOR WARRANTY REPAIR
Contact Wave Point® Customer Support at www.wave-point.com/helpdesk.html for all trouble shooting, warranty
verication and return authorization numbers.
NOTE: Products returned without Return Authorization Numbers will be refused.
Procedures:
I HAVE A COPY OF MY ORIGINAL COMPLETED WARRANTY CARD:
Wave Point® product owners seeking warranty resolution should return their Wave Point® product directly to the
manufacturer along with:
1. Return Authorization Number clearly written on outside of box
2. Copy of warranty card with attached copy of original receipt as proof of purchase
3. Warranty holder’s address, phone number and email address if different than listed on warranty card
4. Written explanation of problem
I DO NOT HAVE A COPY OF MY ORIGINAL COMPLETED WARRANTY CARD:
In the event you do NOT have a copy of your original completed Warranty Card you may choose instead to
forward your full customer contact information and proof of purchase as listed below:
1. Return Authorization Number clearly written on outside of box
2. Copy of original receipt as proof of purchase
3. Warranty holder’s name, address, phone number and email address
4. The Wave Point® serial number as listed on the product being returned
5. Written explanation of the problem
Send to:
Wave Point® Technology. *Email us at [email protected] for the updated address
Warranty Repair Desk
300 South Lewis Rd. Unit J
Camarillo CA 93012
In the event Wave Point® products are returned for warranty work and are found to be outside the parameters of
the warranty or otherwise caused by other than normal usage, the warranty holder will be contacted by phone
or email and offered the option of (a) repair and return at the owner’s expense, (b) return of the product to the
owner “as is” at the owner’s expense, or (c) disposal of the product.
Only prepaid freight returns will be accepted. All freight is the responsibility of the warranty holder.
NOTE: WAVE POINT® TECHNOLOGY’S WARRANTY POLICY IS SUBJECT TO CHANGE WITHOUT NOTICE.
RETURNING PRODUCTS FOR OUT-OF-WARRANTY REPAIR
Wave Point® owners experiencing problems with a Wave Point® product no longer under warranty may send
their Wave Point® product to Wave Point® Technology. for repair.
For help with, or repair of, products no longer under warranty, contact Wave Point® Customer Support at
www.wave-point.com/helpdesk.html for trouble shooting tips and/or return authorization numbers. Products
returned without a return authorization number will be refused.
Procedures:
Wave Point® product owners seeking product repair should return their Wave Point® product directly to the
manufacturer along with:
1. Return Authorization Number clearly written on outside of box
2. Owner’s name, address, phone number and email address
3. The Wave Point® serial number as listed on the product being returned
4. Written explanation of problem
SEND TO:
Wave Point® Technology. *Email us at [email protected] for the updated address
Repair Desk
300 South Lewis Rd. Unit J
Camarillo CA 93012
All repair and shipping costs are the responsibility of the owner. Depending on the problem and/or cost, products
are not always repairable. In such instances all shipping costs remain the responsibility of the owner.
If a Wave Point® product returned for repair is found to be either non-repairable or beyond a reasonable cost to
repair, the owner will be contacted by Wave Point® and offered the option of either disposal of the product or
return to the owner at the owner’s expense.

1 YEAR LIMITED WARANTEE OWNER REGISTRATION CARD
HIGH OUTPUT T5 Fluorescent 2 Lamp Lighting System
• Wave Point® product owners MUST register their purchase with Wave Point® Technology Inc. for their warranty
benets to be in effect. Unregistered products are not eligible for warranty.
• This warranty card must be completed and submitted within 30 days of product purchase.
• Send this completed form along with a copy of the original retail receipt as proof of purchase to:
Wave Point® Technology.*Email us at [email protected] for the updated address
Warranty Submissions Desk
300 South Lewis Rd. Unit J
Camarillo CA 93012
OWNER INFORMATION
Date
Name:
Address:
City: State/Province: Postal Code:
Country
Email: Cell Phone:
Work Phone: Home PHone:
PRODUCT INFORMATION
Product Serial Number: Model No.
(NOTE: This is the digit number located on the PIN tag afxed to the unit)
Date of Purchase:
Seller (Retail Outlet):
Seller’s Location: Seller’s Phone Number:
*Afxacopyofyouroriginalpurchasereceipthere
IMPORTANT: Please make a copy of this warranty card and retain it for your records.
Wave Point® Technology
www.wave-point.com
©2012 Wave Point® Technology
Photo: ©Wave Point®
Made in China. All rights reserved
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

Wave Point® Technology
www.wave-point.com
©2012 Wave Point® Technology
Photo: ©Wave Point®
Made in China. All rights reserved
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
