Wavelet 16-ch Digital Video Recorder User manual

WAVELET DIGITAL VIDEO RECORDER
0

WAVELET DIGITAL VIDEO RECORDER
1
CONTENT VERIFICATION
Before installing the DVR, please make sure that the following items are included in the
box:
1. Digital Video Recorder
2. NVAC-RC110 Remote Controller
3. DVR Client Software CD
4. Power Cable
5. Two AAA Batteries
6. 16-ch Loop Out Cable (Only applicable to 16-ch unit)
7. This Instruction Manual
If any of these materials are missing, please contact the vendor help desk immediately.

WAVELET DIGITAL VIDEO RECORDER
2
DISCLAIMER
zWhile every effort has been made to ensure that the information contained in
this guide is accurate and complete, no liability can be accepted for any errors or
omissions.
zWe reserve the right to change the specifications of the hardware and software
described herein at any time without prior notice.
zNo part of this guide may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language in any form, by any means,
without prior written permission.
zWe make no warranties for damages resulting from corrupted or lost data due to
a mistaken operation or malfunction of the Digital Video Recorder, the software,
the hard drives, personal computers, peripheral devices, or
unapproved/unsupported devices.

WAVELET DIGITAL VIDEO RECORDER
3
FCC NOTICE
Digital Video Recorder, Model Wavelet 4-ch, 8-ch, and 16-ch
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class B
digital devices, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by on or more of the
following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
zConsult the dealer or an experience radio/TV technician for help.
The hard disk provided with the digital video recorder must be used with this equipment
in order to comply with Class B limits in subpart B of Part 15 on FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified
in the manual. If such changes or modifications should be made, you could be required
to stop operation of the equipment.
Canadian Radio Interference Regulations
THIS CLASS B DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.

WAVELET DIGITAL VIDEO RECORDER
4
READ THIS FIRST
Test Sessions
Before you try to record important subjects, we highly recommend that you make
several test recording and playback sessions to ensure that the Digital Video Recorder
is operating and being operated correctly. Please note that subsidiaries and affiliates,
and its distributors are not liable for any consequential damages arising from any
malfunction of a Digital Video Recorder or its accessory, including the hard disk drive,
which results in the failure of an image to be recorded or to be recorded in a format that
is machine sensible.
The Privacy act of 1974 (5 U.S.C. § 552a)
Please note that Digital Video Recorders are intended for recording of surveillance use
and should never be used in a manner that invades other people’s privacy or
contravenes international or domestic privacy act and its regulations. Please be
advised that in certain cases the recording of individuals, private properties, or
commercial properties by means of camera or other devices may contravene legal
rights of such individuals even if the images were recorded for personal use.
Warranty Limitations
This Digital Video Recorder’s warranty is only effective in the country of sale. If a
problem arises while the DVR is in use abroad, please convey it back to the country of
sale before proceeding with a warranty claim.

WAVELET DIGITAL VIDEO RECORDER
5
SAFETY PRECAUTIONS
zBefore using the Digital Video Recorder, please ensure that you read and
understand the safety precautions described below. Always ensure that the
Digital Video Recorder is operated correctly.
zThe safety precautions noted on the following pages are intended to instruct you
in the safe and correct operation of the DVR and its accessories to prevent
injuries or damage to the self, other persons and equipment.
zIn this Instruction Manual, the term “DVR”, “equipment” and “device” refers
primarily to the Digital Video Recorder and its accessories such as power supply
and its remote controller.
WARNING
zDo not cover the ventilation opening or slots on the outer casing. To prevent the
DVR from overheating, provide at least two inches of air space around the vent
and the slots.
zDo not drop metallic parts through slots. This could permanently damage the
Digital Video Recorder. Immediately turn the DVR’s power off or unplug the
power cord from the power outlet. Contact a qualified service personnel
authorized by the equipment distributor or installer.
zDo not attempt to disassemble or alter any part of the equipment that is not
expressly described in this guide. Disassembly or alteration may result in high
voltage electrical shock. Internal inspections, alterations and repairs should be
conducted by qualified service personnel authorized by the equipment distributor.
zStop operating the equipment immediately if it emits smoke or noxious fumes.
Failure to do so may result in fire or electrical shock. Immediately turn the
DVR’s power off, remove the power cable from the power outlet. Confirm that
smoke and fume emissions have ceased. Please consult the DVR distributor.
zStop operating the equipment if a heavy object is dropped or the casing is
damaged. Do not strike or shake. Failure to do so may result in fire or electrical
shock. Immediately turn the DVR’s power off or unplug the power cord from the
power outlet. Please consult the DVR distributor.
zDo not allow the equipment come into contact with, or become immersed in,
water or other liquids. Do not allow liquids to enter the interior. The DVR has
not been waterproofed. If the exterior comes into contact with liquids or salt air,
wipe it dry with a soft, absorbent cloth. In the event that the water or other
foreign substances enter the interior, immediately turn the DVR’s Power off or
unplug the power cord from the power outlet. Continued use of the equipment
may result in fire or electrical shock. Please consult the DVR distributor.
zDo not use substances containing alcohol, benzene, thinners or other flammable
substances to clean or maintain the equipment. The use of these substances
may lead to fire. Use a dry cloth on a regular periodic basis and wipe away the
dust and dirt that collects on the device. In dusty, humid or greasy environments,
the dust that collects around the ventilation or the slots on the outer casing over

WAVELET DIGITAL VIDEO RECORDER
6
long periods of time may become saturated with humidity and short-circuit,
leading to fire.
zDo not cut, damage, alter or place heavy items on the power cord. Any of these
actions may cause an electrical short circuit, which may lead to fire or electrical
shock.
zDo not handle the device or power cord if the hands are wet. Handling it with
wet hands may lead to electrical shock. When unplugging the cord, ensure that
you hold the solid portion of the plug. Pulling on the flexible portion of the cord
may damage or expose the wire and insulation, creating the potential for fires or
electrical shocks.
zUse only the recommended power accessories. Use of power sources not
expressly recommended for this equipment may lead to overheating, distortion
of the equipment, fire, electrical shock or other hazards.
zDo not place the battery near a heat source or expose it to direct flame or heat.
Neither should you immerse them in water. Such exposure may damage the
battery and lead to the leakage of corrosive liquids, fire, electrical shock,
explosion or serious injury.
zDo not attempt to disassemble, alter or apply heat to the battery. There is
serious risk of injury due to an explosion. Immediately flush with water any area
of the body, or clothing that comes into contact with the inner contents of the
battery. If the eyes or mouth contact these substances, immediately flush with
water and seek medical assistance from a medical professional.
zAvoid dropping or subjecting the battery to severe impacts that could damage
the casings. It could lead to leakage and injury.
zDo not short-circuit the battery terminals with metallic objects, such as key
holders. It could lead to overheating, burns and other injuries.
zThe supplied power supply and power cord are designed for exclusive use with
the Digital Video Recorder. Do not use it with other products or battery. There
is a risk of fire and other hazards.

WAVELET DIGITAL VIDEO RECORDER
7
CAUTION
zAvoid using, placing or storing the equipment in places subject to strong sunlight
or high temperatures, such as the greenhouse or trunk of a car. Exposure to
intense sunlight and heat may cause the battery to leak, overheat or explode,
resulting in fire, burns or other injuries. High temperatures may also cause
deformation of the casing. Ensure that there is good ventilation when using the
equipment.
zDo not store the equipment in humid or dusty areas. Storage in such areas
could lead to fire, electrical shock or other damage.
zDo not operate the DVR beyond its specified temperature, humidity or power
source ratings. Do not use the DVR in an extreme environment such as in high
temperature or high humidity. Use the device at temperatures within 41°F -
104°F and humidity below 90 %. The normal operating power source for this
device is 110V-220V AC 50/60Hz.
zFully charge up the backup battery prior to operation. Keep the Digital Video
Recorder turned on or connected to a power outlet for at least 24 hours to
recharge the backup battery. This procedure is necessary when using the DVR
for the first time or after it has been unplugged for a long time from the power
outlet. Insufficient charging of the battery may cause loss of the time and date
settings if the power supply should fail. The battery, when fully charged, will
store the saved settings for approximately 170 hours.
PREVENTING MALFUNCTION
zAvoid Strong Magnetic Fields. Never place the DVR in close proximity to
electric motors or other equipment generating strong electromagnetic fields.
Exposures to strong magnetic fields may cause malfunctions or corrupt image
data.
zAvoid Condensation Related Problems. Moving the equipment rapidly between
hot and cold temperatures may cause condensation (water droplets) to form on
its external and internal surfaces. You can avoid this by placing the equipment
in an airtight, resealable plastic bag and letting it adjust to temperature changes
slowly before removing it from the bag.
zIf Condensation forms inside the Digital Video Recorder. Stop using the
equipment immediately if you detect condensation. Continued use may damage
the equipment. Remove the power cord from the power outlet and wait until the
moisture evaporates completely before resuming use.

WAVELET DIGITAL VIDEO RECORDER
8
TABLE OF CONTENTS
C
CO ON NT TE EN NT T V VE ER RI IF FI IC CA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 1
D
DI IS SC CL LA AI IM ME ER R. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .2 2
F
FC CC C N NO OT TI IC CE E. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .3 3
R
RE EA AD D T TH HI IS S F FI IR RS ST T. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4 4
TEST SESSIONS ..........................................................................................................................4
THE PRIVACY ACT OF 1974 (5 U.S.C. §552A) ............................................................................4
WARRANTY LIMITATIONS ............................................................................................................4
S
SA AF FE ET TY Y P PR RE EC CA AU UT TI IO ON NS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5 5
W
WA AR RN NI IN NG G. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5 5
C
CA AU UT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7 7
P
PR RE EV VE EN NT TI IN NG G M MA AL LF FU UN NC CT TI IO ON NS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7 7
T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .8 8
D
DI IG GI IT TA AL L V VI ID DE EO O R RE EC CO OR RD DE ER R L LA AY YO OU UT T. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 13 3
1. FRONT PANEL LAYOUT ..................................................................................................13
2. REAR PANEL LAYOUT.....................................................................................................16
3. REMOTE CONTROLLER ..................................................................................................18
4. INSTALLATION AND CONNECTION ...............................................................................19
5. P/T/Z CAMERA CONNECTION .........................................................................................20
U
US SI IN NG G T TH HI IS S M MA AN NU UA AL L. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .2 21 1
I
I. . B BA AS SI IC C S SE ET TT TI IN NG GS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .2 22 2
TIME &DATE SETTING ..............................................................................................................22
SCREEN POSITION ADJUSTMENT...............................................................................................22
I
II I. . B BA AS SI IC C O OP PE ER RA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .2 23 3
1. MAIN SCREEN ..................................................................................................................23
2. INFORMATION &LOG LIST .............................................................................................26
3. LIVE VIEW .........................................................................................................................28
1. LIVE VIEW SWITCH SEQUENCE ................................................................................................ 28
Live view switch sequence of NVDV-4000N ..................................................................................................28
Live view switch sequence of NVDV-8000N ..................................................................................................28
Live view switch sequence of NVDV-16000N ................................................................................................29
2. AUTOMATIC SEQUENCE ............................................................................................................ 30
3. ZOOM............................................................................................................................................ 31
4. BASIC RECORDING .........................................................................................................33
5. BASIC PLAYBACK ...........................................................................................................34
1. PLAY / STILL / STOP.................................................................................................................... 34
3. AUDIO PLAYBACK. ...................................................................................................................... 35
I
II II I. . A AD DV VA AN NC CE ED D O OP PE ER RA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .3 36 6
1. LOCK .................................................................................................................................36
2. BACKUP ............................................................................................................................36

WAVELET DIGITAL VIDEO RECORDER
9
1. CD-RW/DVD-RW .......................................................................................................................... 36
2. EXTERNAL HARD DRIVES.......................................................................................................... 37
3. USB 2.0 MEMORY STICK ............................................................................................................ 38
3. PAN /TILT /ZOOM CONTROL..........................................................................................39
1. PAN AND TILT CONTROL. .......................................................................................................... 39
2. FOCUS CONTROL. ...................................................................................................................... 39
3. ZOOM CONTROL. ........................................................................................................................ 40
4. IRIS CONTROL............................................................................................................................. 40
5. AUTOMATIC PAN / TILT / ZOOM CONTROL.............................................................................. 40
6. LIMITING THE CAMREA POSITIONS.......................................................................................... 41
4. ADVANCED RECORDING ................................................................................................42
1. ALARM RECORDING ................................................................................................................... 42
2. MOTION RECORDING ................................................................................................................. 43
5. ADVANCED PLAYBACK ..................................................................................................44
1. TIME SEARCH .............................................................................................................................. 44
2. EVENT SEARCH........................................................................................................................... 44
I
IV V. . A AD DV VA AN NC CE ED D S SE ET TT TI IN NG GS S. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .4 45 5
1. DISPLAY SETUP ...............................................................................................................46
1. PIP SET......................................................................................................................................... 46
2. AUTO SEQUENCE MODE ........................................................................................................... 47
3. SEQUENCE INTERVAL................................................................................................................ 47
4. CAMERA SELECT ......................................................................................................................... 47
CAMERA TITLE.............................................................................................................................................48
SEQUENCE BYPASS ...................................................................................................................................48
PTZ CHANNEL..............................................................................................................................................48
PTZ CAMERA MODEL ..................................................................................................................................49
BRIGHTNESS ...............................................................................................................................................50
CONTRAST ...................................................................................................................................................50
COLOR ..........................................................................................................................................................50
COVERT MODE ............................................................................................................................................51
2. GROUP SELECTION.........................................................................................................52
1. RECORD GROUP......................................................................................................................... 52
2. AUDIO INPUT ............................................................................................................................... 52
3. HDD OVERWRITE........................................................................................................................ 53
1. DEFINE GROUP ........................................................................................................................... 54
2. PICTURE QUALITY ...................................................................................................................... 54
3. AUDIO RECORD........................................................................................................................... 55
4. FIELD RATES, MOTION AND ALARM ACTIVATION .................................................................. 55
A. FIELD RATES ..........................................................................................................................................55
B. MOTION & ALARM ..................................................................................................................................56
4. EVENT SETUP...................................................................................................................57
1. RECORD DURATION ................................................................................................................... 57
2. PRE-RECORD .............................................................................................................................. 57
4. ALARM OUT.................................................................................................................................. 58
5. CAMERA SELECT ........................................................................................................................ 59
MOTION GRID ..............................................................................................................................................59
MOTION LEVEL ............................................................................................................................................59
ALARM INPUT...............................................................................................................................................60
5. SCHEDULE SETUP...........................................................................................................61
DAYS OF THE WEEK (D/W) ............................................................................................................. 61
START - END ..................................................................................................................................... 61
GROUP .............................................................................................................................................. 62
6. TIME AND DATE SETUP...................................................................................................64
7. SYSTEM SETUP................................................................................................................65
1. USER AND THE ADMINISTRATOR PASSWORD....................................................................... 65

WAVELET DIGITAL VIDEO RECORDER
10
2. FORMAT HDD................................................................................................................................ 66
3. BACKUP DEVICE ......................................................................................................................... 67
4. AUTO KEY LOCK.......................................................................................................................... 68
5. KEY TONE .................................................................................................................................... 69
6. SELECT DVR ID ........................................................................................................................... 69
V
V. . N NE ET TW WO OR RK K S SE ET TU UP P. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .7 70 0
1. CONFIGURING THE DVR WITH ASTATIC IP ADDRESS................................................70
2. CONFIGURING THE DVR WITH AROUTER INTO ALOCAL AREA NETWORK............72
3. CONFIGURING THE DVR WITH ACABLE MODEM ........................................................77
4. E-MAIL ...............................................................................................................................78
5. CONFIGURING THE DVR WITH ACROSSOVER CABLE ...............................................79
6. MODEM CONNECTION.....................................................................................................82
CREATING MODEM CONNECTION IN WINDOWS XP ................................................................... 82
CONNECTING TO THE DVR USING DIAL-UP MODEM.................................................................. 85
DISCONNECTING FROM THE DVR................................................................................................. 86
V
VI I. . C CL LI IE EN NT T P PR RO OG GR RA AM M. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .8 87 7
1. INSTALLING THE DVR WEB CLIENT ..............................................................................87
INSTALLING THE DVR WEB CLIENT BY CONNECTING TO A DVR ............................................. 88
INSTALLING THE DVR WEB CLIENT FROM THE PROGRAM CD................................................. 88
CONNECTING TO THE DVR USING THE WEB CLIENT................................................................. 89
2. DVR WEB CLIENT.............................................................................................................91
1. CAMERA DISPLAY SELECTION ................................................................................................. 92
2. WEB CLIENT SETTINGS ............................................................................................................. 92
3. DVR SETTINGS............................................................................................................................ 93
GENERAL......................................................................................................................................................94
DISPLAY SETUP...........................................................................................................................................94
GROUP SELECTION ....................................................................................................................................95
RECORD SETUP ..........................................................................................................................................95
EVENT SETUP..............................................................................................................................................96
SYSTEM SETUP ...........................................................................................................................................96
4. DOWNLOAD MANAGER .............................................................................................................. 97
PREVIEWING DATA FILE.............................................................................................................................98
DOWNLOADING DATA FILE ........................................................................................................................99
5. PRINT.......................................................................................................................................... 101
6. LIVE RECORD ............................................................................................................................ 101
7. CAMERAS................................................................................................................................... 101
8. P/T/Z CAMERA CONTROL......................................................................................................... 101
9. OSD ON / OFF ............................................................................................................................ 101
10. DVR LOCAL PLAYER............................................................................................................... 101
11. PICTURE QUALITY .................................................................................................................. 102
12. FIELDS PER SECOND ............................................................................................................. 102
13. DATE AND TIME....................................................................................................................... 102
14. DVR STATUS............................................................................................................................ 102
15. SCHEDULE STATUS................................................................................................................ 102
16. LOCK STATUS.......................................................................................................................... 102
17. HARD DRIVE INFORMATION .................................................................................................. 102
18. CAMERA NUMBER / TITLE......................................................................................................102
3. DVR LOCAL PLAYER .....................................................................................................103
1. MAIN MENU ................................................................................................................................ 103
2. CAMERA DISPLAY SELECTION ............................................................................................... 103
3. CAMERAS................................................................................................................................... 103
4. PICTURE QUALITY ..................................................................................................................... 104
5. CAMERA NUMBER / TITLE........................................................................................................ 104

WAVELET DIGITAL VIDEO RECORDER
11
6. FIELDS PER SECOND ............................................................................................................... 104
7. OPEN FILE.................................................................................................................................. 104
8. SNAPSHOT SAVE ...................................................................................................................... 104
9. DATE AND TIME......................................................................................................................... 105
10. PLAY BUTTONS ....................................................................................................................... 105
11. PROGRESS SLIDER ................................................................................................................ 105
12. STILL / FIELD BY FIELD........................................................................................................... 105
13. AUDIO PLAYBACK / AUDIO SYNC .........................................................................................105
14. FAST FORWARD / FAST REVERSE ....................................................................................... 105
15. PRINT........................................................................................................................................ 105
16. DVR LOCAL PLAYER STATUS BAR .......................................................................................105
4. MINI PLAYER ..................................................................................................................106
1. MINI PLAYER STATUS BAR ......................................................................................................106
2. OPEN FILE.................................................................................................................................. 106
3. PLAY BUTTONS ......................................................................................................................... 106
4. STILL / FIELD BY FIELD............................................................................................................. 106
5. FAST FORWARD / FAST REVERSE .........................................................................................106
6. PROGRESS SLIDER .................................................................................................................. 107
7. CAMERA SELECTION PULL-DOWN MENU ............................................................................. 107
8. PICTURE QUALITY SELECTION PULL-DOWN MENU ............................................................ 107
9. REGION SETTING PULL-DOWN MENU ................................................................................... 107
V
VI II I. . C CE EN NT TR RA AL L M MA AN NA AG GE EM ME EN NT T S SO OF FT TW WA AR RE E. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 10 08 8
1. SYSTEM REQUIREMENT ...............................................................................................108
2. INSTALLING DVRPLAYER.............................................................................................108
3. EXECUTING DVRPLAYER .............................................................................................111
4. DVRPLAYER ...................................................................................................................111
1. MAIN CAMERA DISPLAY WINDOW .......................................................................................... 111
2. CAMERA DISPLAY SELECTION ............................................................................................... 111
3. MODE DISPLAY.......................................................................................................................... 111
4. TIME AND DATE......................................................................................................................... 112
5. MODE SELECTOR ..................................................................................................................... 112
6. RECORD ..................................................................................................................................... 112
7. CAPTURE ................................................................................................................................... 112
8. OSD MODE ................................................................................................................................. 112
9. SETUP......................................................................................................................................... 112
10. PLAYBACK CONTROL BUTTONS........................................................................................... 113
11. PAN / TILT / ZOOM CONTROL ................................................................................................ 113
12. AUDIO VOLUME....................................................................................................................... 114
13. HEALTH .................................................................................................................................... 114
Warning colors.............................................................................................................................................115
Health report ................................................................................................................................................115
15. VIRTUAL DVR WINDOW.......................................................................................................... 119
16. CAMERA STATUS BAR ........................................................................................................... 119
17. DVR SET LIST MANAGER .......................................................................................................120
18. VIRTUAL DVR SET LIST MANAGER....................................................................................... 121
19. POWER ..................................................................................................................................... 123
5. DVRPLAYER –LIVE MODE ............................................................................................124
INDIVIDUAL DVR MONITORING .................................................................................................... 124
VIRTUAL DVR MONITORING .........................................................................................................125
DUAL DISPLAY................................................................................................................................ 127
6. DVRPLAYER –PLAYBACK MODE ................................................................................130
Click on the Mode Selector button to switch to Playback Mode. ..................................................... 130
Remote Search................................................................................................................................. 131
Remote playback.............................................................................................................................. 132

WAVELET DIGITAL VIDEO RECORDER
12
Selecting a file for download ............................................................................................................ 132
Local Playback ................................................................................................................................. 133
7. CONTEXT MENU.............................................................................................................134
Channel Context Menu..................................................................................................................... 134
DVR Context Menu........................................................................................................................... 135
Virtual DVR Context Menu ............................................................................................................... 136
8. DVR SETUP .....................................................................................................................136
Display Setup ................................................................................................................................... 136
Group Selection................................................................................................................................ 137
Record Setup.................................................................................................................................... 137
Event Setup ...................................................................................................................................... 137
Schedule Setup ................................................................................................................................ 138
System Setup ................................................................................................................................... 139
V
VI II II I. . S SP PE EC CI IF FI IC CA AT TI IO ON N. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 14 40 0
I
IX X. . F FR RE EQ QU UE EN NT TL LY Y A AS SK KE ED D Q QU UE ES ST TI IO ON NS S ( (F FA AQ Q) ). .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 14 41 1
I
IN ND DE EX X. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .1 14 47 7

WAVELET DIGITAL VIDEO RECORDER
13
DIGITAL VIDEO RECORDER LAYOUT
1. FRONT PANEL LAYOUT
1) NUMERIC BUTTONS (1~16, 10/0)
These buttons have a number of functions to enter data and to make selections.
They are used to enter numerical data when prompted for the password, to
make channel/camera selection, to choose the day in schedule option, and to
enter alphabets to label each channel.
2) DISPLAY
This button is used to switch between multiple display modes: single, 4 channel,
6 channel, 8 channel, 9 channel, 13 channel and 16 channel split screen display
modes.
3) STATUS INDICATOR
Four LEDs display the status of the Digital Video Recorder. From the left,
Power (red), Recording (red), Scheduled Recording (green) and Button Lock
(green).
4) RECORD
This button starts recording.
5) STOP
This button stops recording.
6) PLAY / REVERSE PLAY
This button is used to start the playback of recorded data. By default, the
playback starts from the earliest recording in the storage device.

WAVELET DIGITAL VIDEO RECORDER
14
7) IR RECEIVER
Do not block the receiver as the remote controller needs the line of sight to the
receiver.
8) POWER
This button turns the unit on or off. The power LED is turned on when the power
is on, and flashes during the initialization and during the shut down.
9) LOCK
This button locks all buttons on the Digital Video Recorder along with the remote
controller. The LOCK LED light is turned on when this feature is activated. To
unlock, press the lock button again and enter the password when prompted.
10) ZOOM/ ENTER/CH SEL
This button allows to digitally zoom into a specific area in both live and playback
screen. Press the button to display the zoom area box, use the arrow keys to
move the box, then press zoom button again to enlarge the selected area.
This button Also used as a ENTER/CH SEL button which selects and enables
the configuration changes made on the menu and sub-menu screens. It is also
used to reposition the camera from main display with another camera of choice
in six, eight or 13 channel view mode.
11) BACKUP
This button allows backing up onto a blank CD, blank DVD, or external hard
drive.
12) SCHEDULE
This button turns the scheduled recording mode on or off. When the schedule
recording is on, schedule LED will be lit.
13) P/T/Z/FOCUS
This button accesses P/T/Z/Focus control menu.
14) INFO / LOG
This button displays system information screen: USB device, USB vendor, USB
disk size, internal HDD size, system version, firmware version, host name and
IP address. Press this button once more to access the system log.
Also functions as LOG button which displays detailed system log: power loss,
video loss, start/stop recording and alarm triggers.
15) MENU
This button accesses the main menu. It is also used to save and for any menu
screens.
16) DIRECTIONAL BUTTONS

WAVELET DIGITAL VIDEO RECORDER
15
The directional buttons are used in various ways:
zNavigate through menus
zAdjust screen position on the monitor
zMove the zoom box in zoom mode
zThe right directional button is used to access submenus.
zControl PTZ cameras
17) CANCEL/OSD OFF
This button cancels any selection changes in submenus. In Zoom mode,
pressing this button will exit to the original display screen. In the regular display
screen, this button is used to hide the On-Screen-Display information such as
time, date and channel icons. This button also removes any of the alert icons on
the upper right corner of the screen (AL, VL and PL). This button is also used to
turn off the alarm buzzer.
18) TIME SEARCH
This button accesses the time search menu. Use the directional buttons to
select the date and the time. Press this button again to start the playback of the
selection.
19) ALARM SEARCH
This button accesses the alarm search menu. Use the directional buttons to
select the date and the time. Press this button again to start the playback of the
selection.
20) PLAYBACK CONTROL BUTTONS
This button is used to adjust playback speed, advance field by field, forward and
to rewind the images.
21) USB PORT
This port is used to connect USB 2.0 memory stick, External HDD and External
DVD-RW.
22) CD-RW
Built in CD-RW for backup of recorded data.
23) EJECT BUTTON FOR CD-RW
This button will open/eject the CD tray.

WAVELET DIGITAL VIDEO RECORDER
16
2. REAR PANEL LAYOUT
1) CAMERA INPUTS
BNC connectors for composite video inputs
2) LOOP OUTPUTS
BNC connectors for composite video outputs
3) 75 OHM TERMINATION SWITCH
Video signal termination for loop-outs
4) AUDIO OUTPUT
RCA jack connector
5) AUDIO INPUT
RCA jack connector
6) MIC INPUT
1/8 Microphone Jack
7) ALARM SIGNAL INPUTS / OUTPUT
8) USB 2.0 PORT
External backup devices: CD-RW, DVD-RW and external hard drive
9) RJ45 ETHERNET PORT
10/100Base-T RJ45 Ethernet Port for network connection
10) RS-232C
9-Pin port connector to connect an external modem or other communication
devices.
11) S-VIDEO OUTPUT

WAVELET DIGITAL VIDEO RECORDER
17
12) COMPOSITE VIDEO OUTPUT
BNC connector for video output to a monitor
13) AC POWER SOCKET
14) 115V / 230V VOLTAGE SWITCH
15) POWER FAN
16) RS-422 / 485 PORT
17) VGA OUTPUT

WAVELET DIGITAL VIDEO RECORDER
18
3. IR REMOTE CONTROLLER
REWIND
PLAY
POWER
PAN/TILT/ZOOM
BACK UP
DVR ID
MENU
RESTORE
RECORDING
STOP
FAST FORWARD
DISPLAY MODE
LOG
INFORMATION AUDIO-PB
SCHEDULE REC ON/OFF
TIME SEARCH
ENTER / CH SELECT
ZOOM
FIELD BY FIELD
CANCEL / OSD OFF
ALARM SEARCH
NUMBERS & ALPHABET

WAVELET DIGITAL VIDEO RECORDER
19
4. INSTALLATION AND CONNECTION.
A1 A2 A3 A4 G A5 A6 A7 A8 G RELAY
❖Example of a normally open alarm circuit.
