Waves DiGiGrid MGR User manual

User Guide
DiGiGrid MGR

DiGiGrid MGR / User Guide
2
Contents
INTRODUCTION................................................................................................................................................................. 3
HARDWARE AND CONNECTIONS ................................................................................................................................... 4
MGR REAR PANEL ............................................................................................................................................................ 4
GETTING STARTED........................................................................................................................................................... 6
Connect the Hardware ..................................................................................................................................................... 6
One I/O......................................................................................................................................................................... 6
Add I/Os ....................................................................................................................................................................... 7
Download and Install Software ........................................................................................................................................ 8
Configure the System .................................................................................................................................................... 10
Manual Device Configuration ..................................................................................................................................... 11
Automatic Device Configuration ................................................................................................................................. 11
Device Firmware ........................................................................................................................................................ 12
Identify a Device on the SoundGrid Network.............................................................................................................. 12
MGR (MGB/MGO) CONTROL PANELS ........................................................................................................................... 13
MADI Options Page ....................................................................................................................................................... 14
Clock Page .................................................................................................................................................................... 15
System Info Page and About Page................................................................................................................................ 17
Presets........................................................................................................................................................................... 18
USING AN I/O DEVICE WITH A DAW .............................................................................................................................. 19
SPECIFICATIONS ............................................................................................................................................................ 20
Waves Inc
2800 Merchants Drive, Knoxville, TN 37912 USA
1-865-909-9200
www.waves.com

DiGiGrid MGR / User Guide
3
Introduction
The DiGiGrid MGR is used to connect MADI-enabled devices to a Waves SoundGrid network for plugin processing
and/or DAW playback and recording. The MGR unit is equipped as standard with Quad MADI BNC connections across
two Dual MADI Interface modules. Optical MADI connection are available as an upgrade option by swapping either one
or both BNC modules. Dual redundant PSU’s ensure uninterrupted operation and guaranteed performance. Use the
second SoundGrid network port to connect additional SoundGrid devices.
A SoundGrid I/O device is part of a SoundGrid network. SoundGrid is the Waves high-speed networking protocol for
moving audio, clock, and other information between a host system and I/O devices—and between I/O devices
themselves. A SoundGrid host configures the network, assigning servers and I/O devices to mix, process, or record,
depending on the host. SoundGrid I/Os link to the SoundGrid network with standard Ethernet cable.
SoundGrid is scalable. Connect one I/O device to a DAW and you have a high-quality sound card. Add more I/Os and
your system becomes more flexible and powerful. Depending on the host application, a SoundGrid host can assign up to
sixteen I/O devices. Complete SoundGrid systems can be networked together to share devices.
Add a server to a SoundGrid system to offload plugin processing from the host CPU to a SoundGrid DSP server. This
dramatically increases processing power and enables greater plugin counts, as well as providing very low system
latency.

DiGiGrid MGR / User Guide
4
Hardware and Connections
MGR REAR PANEL
Mains Inputs A &B– Connect both for redundant operation.
MADI Modules 1 & 2 – Either BNC or optical connections; connect to any MADI device.
Word Clock Input – Connect external word clock source; feeds both modules.
SoundGrid Net Status LEDs
SoundGrid network found = Blue
SoundGrid network not found = Flashing red
Firmware update in progress = Yellow
Hardware error = White
Device Identify mode = Revolving colors
SoundGrid Network Port has two LEDs to indicate status
Link/Activity Led = Flashing green
GigE (Gigabyte Connection Indicator) = Solid orange

DiGiGrid MGR / User Guide
5
MADI Status LEDs – Colors and respective status as follows:
Green = MADI link
Off = no MADI link
MGR FRONT PANEL
EtherCON port switched to rear RJ45 SoundGrid network connection
Power Switches A and B
The built-in network switch provides both front and rear mounted SoundGrid ports, making redundant recordings possible
without any additional hardware. You can connect an MGR directly to a host computer and to one other device (e.g.,
I/Os, SoundGrid server) without needing an Ethernet switch. For installations that include more than two SoundGrid
ports, a 1 GB SoundGrid approved Ethernet switch is necessary. It is not important which of the two Ethernet ports is
used to connect to the SoundGrid network.

DiGiGrid MGR / User Guide
6
Getting Started
Connect the hardware
Install the software
Configure your system
Connect the Hardware
One I/O
In this example, one MGR is connected directly to the SoundGrid host computer using a Cat 5e Ethernet cable or better.
The SoundGrid ASIO/Core Audio driver is used for plugin processing and/or DAW playback/recording.
Host computer with SoundGrid application
MADI-enabled console
MGB/MGO
MADI connection
SoundGrid connection
The host computer’s LAN port that’s connected to the SoundGrid network should be used for SoundGrid only. Do not
share this port with the internet or other networks.
In this configuration, all plugin processing is carried out on the host computer. The speed and power of the host defines
overall latnecy.

DiGiGrid MGR / User Guide
7
Add I/Os
Adding I/O devices not only increases the number of I/O channels, but lets you have separate devices for stage and
FOH, or live room and control room. When there is more than one network connection, use a "star" network configuration
with a 1GB Ethernet switch. Only use switches tested and approved by Waves.
Host computer
MADI-enabled console or device
MGR
One or more SoundGrid I/O devices
1GB Ethernet switch
See this support article for a list of
supported switches.
You can connect and assign up to 16 SoundGrid I/O devices to the network, depending on the SoundGrid Host
Application. You can also add more computers to enable audio streaming between hosts.
ADD A SERVER
To add a server to your SoundGrid system, just connect it to the Ethernet switch and configure it in your host application.
This moves all DSP processing from the host computer to the server, which provides a higher plugin count and enables
the eMotion LV1 and ST mixers. Visit the waves.com hardware pages to learn more about SoundGrid servers. Consult
your SoundGrid host application’s user guide to learn about using servers.

DiGiGrid MGR / User Guide
8
Download and Install Software
INSTALLING A NEW SOUNDGRID HOST SYSTEM
Installing the Waves SoundGrid host application will also install the SoundGrid ASIO/Core Audio driver and applicable
device drivers. Your devices will appear in the Inventory of your host system. If a device is not visible in the Inventory,
you may need to install a specific driver from Waves Central—please see below. First, however, check the device’s
connections and power.
ADDING AN I/O DEVICE TO AN EXISTING SOUNDGRID HOST SYSTEM
If you are already using a Waves SoundGrid host application and your device does not appear in the Network Devices
list, use Waves Central to update the host application, which also updates the device drivers—or install just the missing
device driver from Waves Central.1
Waves Central
All Waves software is downloaded and installed via the Waves Central application. To install a specific device driver,
launch Waves Central and follow these steps:
Choose All Products
Search for the driver by name
Choose the driver and click Install
If you are new to Waves products, begin by downloading the Waves Central installer from the Waves Download
Page. See the Waves Central User Guide for instructions on how to install drivers, plugins, and applications.
LICENSES
You do not need a license to use this device. However, many hosts or specific host configurations do require a license.
Refer to your host’s product page for details.
1The SoundGrid QRec host is installed with any I/O.

DiGiGrid MGR / User Guide
9
IMPORTANT INFORMATION REGARDING DIGIGRID MGR DRIVERS
The BNC and optical MADI modules used in the DiGiGrid MGR are identical to those used in the DiGiGrid MGB and
MGO products. When connected to a SoundGrid Network, the MGR will identify as either an MGB (BNC) or MGO
(Optical) device. When installing SoundGrid Drivers for the MGR, install the MGB/MGO package.

DiGiGrid MGR / User Guide
10
Configure the System
A SoundGrid network is configured and devices are assigned in a host’s Setup window. At the heart of this window are
racks where devices are assigned. Any compatible device that’s part of the host’s SoundGrid network will be available for
assignment. This collection of devices is called the Inventory. Setup is similar with all hosts: identify the host’s LAN port,
select a device slot, and use the drop-down menu to choose an available device.
All SoundGrid devices are configured in a similar manner. Throughout this section, we show DiGiGrid IOS as an
example.
SoundGrid QRec
SoundGrid Studio Setup Window

DiGiGrid MGR / User Guide
11
Manual Device Configuration
You can assign, remove, and manage a device manually. Click on the plus or arrow
symbol in a device slot to open the Device Menu, then select a device.
Any device not already used will be available for assignment. If no other devices are
assigned, the current device will become your clock master. Drivers and servers are
assigned in the same manner.
See the user guide of your host system for specific instructions on device
assignment and I/O channel patching.
Automatic Device Configuration
Certain SoundGrid hosts—including SoundGrid Studio, eMotion LV1 or SuperRack SoundGrid—offer an Auto-
Config tool. Once your devices are connected and powered up, click Auto Config to start the configuration.
Auto-Config chooses the correct LAN port on the host computer and scans the SoundGrid network for devices. It then
patches the devices to the host. We recommend that you let Auto-Config take care of things, at least when you are
getting started. If later you add, remove, or swap a device, Auto-Config will reconfigure your inventory and re-patch.
Note that SoundGrid Studio assigns the SoundGrid driver automatically. SuperRack SoundGrid and eMotion LV1
require that the SoundGrid ASIO/Core Audio driver is assigned manually.
SoundGrid QRec
SoundGrid Studio

DiGiGrid MGR / User Guide
12
Device Firmware
An I/O that is using outdated or incompatible firmware will not work properly in a SoundGrid network until its firmware is
updated. The color of the FW button in a device slot indicates the current firmware status.
If a device requires updated firmware, click on the FW button to start a hardware scan. Do not disconnect the device or
turn off the computer before Done appears. Once the update is ready, turn the device off and on to reset.
Identify a Device on the SoundGrid Network
Click on the ID button to activate a hard-to-miss LED on the panel of the
corresponding hardware device. You can also activate the LED from the top
bar of the device’s control panel.
Grey Compatible firmware
Blue Compatible firmware, but a newer version exists
Red Firmware not compatible and must be updated in order to use
SoundGrid QRec
SoundGrid QRec
SoundGrid Studio
SoundGrid Studio

DiGiGrid MGR / User Guide
13
MGR (MGB/MGO) Control Panels
Depending on which modules are installed (BNC and/or Optical) the MGR will identify as either MGB (BNC) or MGO
(Optical) device with their respective control panels. There are two ways to open the device control panel:
FROM THE DEVICE RACK
Click on the Gear button on a device in the rack slot.
FROM THE DRIVER CONTROL PANEL
You can also access the control panels of all assigned I/O devices from Driver Control
Panel application, which is located here:
PC: C:\Program Files (x86)\Waves\SoundGrid\Driver Control Panel
Mac: System HD/Applications/Waves/SoundGrid
MGR CONTROL PANEL PAGES
The About and System Info pages provide information about the unit, such as MAC address, SOE master MAC
Address, firmware version, and more. The Clock and MADI Options pages are used to set up and manage the MGR.
SoundGrid Studio
SoundGrid QRec

DiGiGrid MGR / User Guide
14
MADI Options Page
The MGR has Dual MADI Interface modules. Each module has its respective Control Panel. Click the Identify button to
indicate which module belongs to this Control Panel.
One MADI connection supports 56 or 64 in/out
channels at 44.1kHz/48kHz, and 28 or 32 in/out
channels at 88.2kHz/96kHz.
In MADI Port Settings, set the number of available
channels according to your MADI device settings.
Range: 56/28, 64/32
While the MGR can deliver up to 256 channels at sample rates of 44.1kHz/48kHz, SoundGrid Driver is limited to 128
channels at any sample-rate.

DiGiGrid MGR / User Guide
15
Clock Page
Use the Clock page to set the clock source and sample rate settings for the device and to assess clock status.
SOURCE sets the clock source
Internal The interface itself provides the clock
External WC The interface has a Word Clock Input connector to connect an external clocking source to sync all
devices in your network to the external clock
Digital Syncs via the BNC or optical MADI connection on MADI Port 1 or Port 2 (selectable). The MGB/MGO
interfaces sync to the incoming MADI from the console or MADI enabled device.
Sync over Internet Send or receive clock and sample rate over an Ethernet cable between SoundGrid network devices
SAMPLE RATE sets the sample rate when Clock Source is set to Internal. Range: 44.1 / 48 / 88.2 / 96 kHz
SAMPLE RATE MODE sets the MADI mode for 88.2 kHz / 96 kHz operation. Check your MADI enabled console or device
manual for the proper selection.
Range: High-Speed, SMUX

DiGiGrid MGR / User Guide
16
CLOCK STATUS INDICATORS
Three windows on the right side of the Clock control panel help you to quickly assess the network status of the device.
When the device is a slave in the SoundGrid network, you will likely sync it to the SoundGrid network clock (via SOE).
Even when the device is an SOE slave, you can lock it to an external clock source. For example, if another SoundGrid
I/O device is the SOE master and is locked to a word clock device, you may choose to receive clock from the same
external device over word clock from the master device rather than via network SOE.
CLOCK SOURCE AUTO-SWITCHING
In the event that the selected clock source fails, MGR has a series of clock fallback layers, in this order: Word Clock
input, MADI (port A), SOE, Internal. If an MGR is clocked to WC and this external source fails, it will first try to clock to
MADI (port A), then SOE. If that not successful, it will fall back to Internal.
Status Reports the presence or absence of sync between the MGR and
the SoundGrid network
Current Clock
Status
Displays the current sync method. This may differ from the choice
made in the Source menu
SOE
Indicates whether this MGR is the master or a slave in the SoundGrid
network. This mirrors the status information in the SoundGrid Studio
Device Rack

DiGiGrid MGR / User Guide
17
System Info Page and About Page
The About page contains a description of the device. The System Info page contains technical details about the device,
including MAC address, Firmware version, and Module version. This information is useful for troubleshooting. Please
have this information handy if you contact Waves technical support concerning the device.

DiGiGrid MGR / User Guide
18
Presets
The Top Bar is used to load and save device presets and to identify device hardware. A saved preset includes all Clock
and MADI Options panels parameters. Save MGR presets to use on future sessions or copy them to another computer to
duplicate a configuration.
Click the Identify button to indicate which MGB/MGO module belongs to this Control Panel. Clicking the button causes
the Network LED on the panel of the module to flash in a rather psychedelic manner.

DiGiGrid MGR / User Guide
19
Using an I/O Device with a DAW
Setting up SoundGrid devices with a DAW involves these steps:
PATCH THE I/O DEVICE AND THE SOUNDGRID ASIO/CORE AUDIO DRIVER
When using a DAW on a SoundGrid network, the SoundGrid ASIO/Core Audio driver serves as a bridge between the I/O
device and the DAW. It enables the I/O to communicate with the DAW and it provides patches. Patching an I/O to the
SoundGrid ASIO/Core Audio driver differs slightly among hosts. When you use a host’s Auto-Config tool, the host input
channels are patched automatically, in an order based on rack. The order of the devices in the Device Rack determines
the default patching order. Please refer to your SoundGrid host’s user guide for details.
CONFIGURE THE DAW FOR SOUNDGRID
1. Set the DAW playback engine to “Waves SoundGrid.” The SoundGrid driver channels will now appear in the DAW
I/O preferences and in the Input/Output selector in each DAW channel.
2. Route the DAW inputs and outputs to SoundGrid.

DiGiGrid MGR / User Guide
20
Specifications
•1U rackmount
•Quad MADI to SoundGrid interface
•Fitted with dual BNC MADI (MGB) I/O Modules as standard. Optional MGO module for Optical MADI support.
•Supported sample rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
•Built-in SoundGrid network switch
•2 SoundGrid Ethernet ports (RJ45)
•Support for 64 and 56 channel modes
•Support for double wire (48k frame) and single wire (96k frame) @ 96kHz
•224/256 channel I/O @ 48kHz (Recording and playback of more than 128 channels at 48kHz requires a second
computer.)
•112/128 channel I/O @ 96kHz
•Clock Synchronization via (in fallback order): Word Clock input, MADI (port A), SoundGrid (SOE), Internal
•Dual AC input power supplies with redundant operation
Dimensions: 482.6mm (w) x 306mm (d) x 43.6mm (h)
Weight: 4.5kg (7kg boxed)
Power Requirements: 100VAC–240 VAC, 1.5 amp, 50/60 Hz
Specifications are subject to change without notice
