Wayfair WF281704AA User manual

ASSEMBLY INSTRUCTION
SKU:WF281704AA
BUNK BED
220LBS
300LBS
SAFETY WARNINGS AND GENERAL NOTES：
-Follow the information on the warnings on the bunk bed end structure and on the carton.
-Do not remove the warning label from the bed.
-Always use the recommended size mattress on mattress support, or both, to help prevent the likelihood
of entrapment or falls.
-The top surface of the mattress must be at least 5* (127mm) below the upper edge of the guardrail.
-Do not allow children under 6 years of age to use the upper bunk.
-Periodically check and ensure the guardrail, ladder and other components are in their proper position,
free from damage, and all connectors are tight.
-Prohibit horseplay on or under beds. Always prohibit jumping on the bed.
-Prohibit more than one person on upper bunk.
-Always use the ladder for entering and leaving the upper bunk.
-Do not use substitute parts.Contact the manufacturer or dealer for replacement parts.
-Use of a night-tight may provide added safely precaution for a child using the upper bunk.
-Always use guardrails on both long sides of the upper bunk.
-If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be placed
against the wall to prevent entrapment between the bed and the wall.
-The use of water or sleep flotation mattresses is prohibited.
-Keep these instructions for future reference.
-We recommend assembling your bunk bed on the shipping carton to protect your floor or carpet.
-Be certain all staples are out of the box before beginning assembly on the shipping carton.
STRANGULATION HAZARD - Never attach or hang items to any part of the bunk bed that are not designed for use with the bed;
for example, but not limited to, hooks, belts, and jumping ropes.
Page 1 of 8

ASSEMBLY INSTRUCTION
SKU:WF281704AA
BUNK BED
PART LIST
A
2PCS
B
1PC
C
2PCS
D
1PC
E
1PC
F
1PC
G
1PC
H
10PCS
I
3PCS
J
2PCS
K
1PC
L
M
3PCS
N
3PCS
O
10PCS
P
2PCS
Q
3PCS
Page 2 of 8

HARDWARE LIST
1
1/4*35MM
3PCS
2
5/16*60MM
16PCS
3
1/4*60MM
3PCS
4
1/4*19MM
20PCS
⑤
1/4*32MM
9PCS
⑥
4MM
1PC
⑦
5MM
1PC
Page 3 of 8

ASSEMBLY INSTRUCTION
SKU:WF281704AA
Note:Please do not tighten all bolts until the bed is assembled completely
STEP1
○
4
1/4*19MM
6PCS
○
6
4MM
1PC
STEP2
○
2
5/16*60MM
8PCS
⑦
5MM
1PC
1.1 Inserting two end of N(3PCS)、
H(10PCS) to hole of D(1PC)and
E(1PC),using tool ○ 6 locking D、E and
N with ○ 4 （6PCS）.
These named group 1.
2.1 Putting hole of group 1 align
with hole of A,using tool ○
7
locking Ａ D and AE with ○
2
（8PCS）.These named group 2.
Page 4 of 8
D
E
N
N
N
H
H
H
H
H
H
H
H
H
H
A
A
D
E
N
E
2
E
4

ASSEMBLY INSTRUCTION
SKU:WF281704AA
STEP3
○
1
1/4*35MM
3PCS
⑥
4MM
1PC
STEP4
○
5
1/4*32MM
3PCS
⑥
4MM
1PC
3.1 Putting hole of L(1PC) align with
hole of M(3PCS),using tool ○
6
locking LM with ○
1（3PCS）.These
named group 3.
4.1 Putting hole of group 2 align with
hole of group 3,using tool ○ 6
locking group 2 and group 3 with ○ 5
（3CS）.These named group 4.
Page 5 of 8
L
M
M
M
L
L
L
M
M
M
1
1
1
5
5
5

ASSEMBLY INSTRUCTION
SKU:WF281704AA
STEP5
④
1/4*19MM
6PCS
⑥
4MM
1PC
STEP6
④
1/4*19MM
4PCS
⑥
4MM
1PC
6.1 Inserting C(2PCS)、J(2PCS) to hole
of group 4,using tool ○
6locking C、
J and group 4 with ○
4（4PCS）.These
named group 6.
J
C
J
C
4
4
5.1 Inserting hole of I (3PCS) 、
O(10pcs) to hole of G(1PC) and
F(1PC）,using tool ○
6locking G、F and
I with ○
4（6PCS）.These named group 5.
I
I
I
O
O
O
O
O
O
O
O
O
G
F
I
G
4
O
Page 6 of 8

ASSEMBLY INSTRUCTION
SKU:WF281704AA
STEP7
STEP8
②
5/16*60MM
8PCS
③
1/4*60MM
3PCS
⑥
4MM
1PC
⑦
5MM
1PC
7.1 Inserting B(1PC)、K(1PC) to hole of
group 6.These named group 7.
B
K
8.1 Putting hole of group 5 align
with hole of group 7,using tool○
7
locking group 5 and group 7 with ○
2
（8PCS）,using tool○
6locking group
5 and group 7 with ○
3（3PCS）.These
named group 8.
2
3
Page 7 of 8

ASSEMBLY INSTRUCTION
SKU:WF281704AA
STEP9
⑤
1/4*32MM
6PCS
⑥
4MM
1PC
STEP10
④
1/4*19MM
4PCS
⑥
4MM
1PC
P
10.1 Putting hole of group 8（1PCS）
align with hole of group 9（1PC）as
picture ， using tool ○
6locking
group 8 and group 9 with ○
4（4PCS）.
Assembly OK.
4
4
9.1 Putting P(2PCS) Q(3PCS) as
picture position,using tool ○
6
locking PQ with ⑤ （ 6PCS ） .These
named group 9.
P
P
Q
Q
Q
Q
P
5
Page 8 of 8
