Wayl buzz4000 User manual
USER MANUAL
solar powered
emergency
crank radio
buzz4000 by wayl
WB 162.400 162.550
FM MHz87 92 98 102 108
52 80 110 140 170 KHz x10
AM
TUN
OFF
WB FM AM
T
U
N
I
N
G
V
O
L
BAND/SOS
FEATURES
2
Speaker
Tuner
Antenna
Volume
SOS Alarm
MP3 Controls
Solar Panel
Reading Light
Flashlight
Flashlight Button
LI-ION Charge
Indicator
Tuner Light
USB Charge Port
Headphone Jack
USB MP3 Port
TF Card Port
AAA - Li-ION Power Switch
AAA Battery Cover
Hand Crank LI-ION Battery Cover
Speaker
Micro USB Port
Band
Stations
Null
Reading Light Button
CHARGING THE RADIO
A. Solar Power
Place the radio (solar panel) directly in or near sunlight.
When charging, the LI-ION charge indicator ( ) will have a
strong blue glow. The less light the solar panel receives the
more dim the blue glow will be. The 4000mAh LI-ION power
bank will take 25-30 hours to be fully charged. The solar
panel life span lasts a minimum of 25 years (with an average
radio use of 6 hours a day).
B. USB
Use the Micro USB cable provided to charge the radio
(connect to a USB power source like a computer or wall
adapter). The LI-ION charge indicator ( ) will keep blinking
blue while being charged, and will turn a solid blue when
fully charged.
Note: The LI-ION charge indicator will glow blue from
sunlight or any light source (natural light, interior lighting,
etc) which indicates that the radio is charging, however direct
sunlight will charge the radio the fastest.
3
Solar Panel
C. Hand Crank
Unfold the Hand Crank from the back of the radio and
continuously rotate (clockwise or counter clockwise) the
crank for 3-5 minutes to activate the internal power bank for
initial use.
CHARGING THE RADIO
USB Charging Port
It takes around 8 hours to fully charge the 4000mAh LI-ION
power bank and can last up to 4 months without being used.
At full charge, the radio can provide 10-12 hours of playtime
(depending on the volume) or 10-12 hours of flashlight/read-
ing light time.
4
LI-ION Battery Cover
USB Micro Charging
Cable Included
CHARGING THE RADIO
One minute of cranking (at 130-150RPM) supports 5-10 minutes
of radio play or 8-14 minutes of light usage. At this rate, the radio
can be fully charged in 5 hours.
5
D. AAA Batteries
The radio can be used independently from the LI-ION power
bank with 3 AAA batteries (not included).
• Remove the battery cover at the bottom of the radio and
insert 3 AAA batteries (close the battery cover).
• Select 'AAA' from the AAA - LI-ION power switch at the
bottom of the radio and turn on the radio for use.
• Do not leave the AAA batteries in the radio if its stored and
not routinely in use so that the batteries do not corrode.
Note: The LI-ION charge indicator will glow blue when the
radio is in light regardless if the radio is in AAA mode (The
radio is always being charged through the solar panel).
AAA Battery Cover
6
RADIO
Turn on the radio by rotating the volume knob clockwise and
continue to adjust the volume.
• Select WB (NOAA Weather Band), FM or AM from the
band switch.
• Extend the antenna to get better signal reception.
• Rotate the tuner knob to select a station. The tuner light will
turn a solid green when a station is reached.
SOS Alarm
Hold the BAND/SOS button for 3 seconds to sound the alarm
in case of an emergency in order to alert others nearby.
Press the BAND/SOS button again to stop the alarm.
MP3 PLAYER
8
TF Card Port
With the radio on, insert an MP3 USB Flash Drive to the USB
MP3 Port or a TF card (Class 10) to the TF card port.
USB MP3 Port
• Press the BAND/SOS button to switch to MP3 mode which
will play the first MP3 file (press the button again to
switch to a band - WB/FM/AM).
• To play other MP3 files, press ( ) or ( ) which will start
playing the next MP3 after a 1 second delay.
Note: If the USB flash drive or TF card (Class 10) is not
formatted properly, nothing will happen when pressing the
MP3 controls. Make sure there are only .mp3 files on the
root of the drive or card with no other folders or files.
LIGHTING
9
A. Flashlight
Press the flashlight button to turn on the flashlight. The LED
flashlight emits 100 lumen in a concentrated light projection.
B. Reading Light
Rotate the folded radio handle up and press the small
centered white button to turn the reading light on or off. The
LED reading light emits 20 lumen. Rotate the radio handle as
needed to direct the light.
Light Projection
CHARGING USB DEVICES
10
USB Charge Port
A. LI-ION Power Bank
Select ‘LI-ION’ to use the 4000mAh Li-ION power bank to
charge devices - maximum output is 800mAh. Using the
Li-ION will consume the power bank and should be used only
for emergency purposes and is not intended as a routine
charging source.
B. AAA Batteries
Select ‘AAA’ (be sure 3 AAA batteries are inserted) to charge
the devices with the batteries.
Note: Look at your device notification to make sure its
charging as there is no device notification within the radio.
Charge devices such as mobile phones, tablets, portable
media/games through the USB charge port (cable not
provided). Choose a mode to charge the device from the
bottom of the radio:
Portable Devices,
Mobile, Tablet
SPECIFICATIONS
11
Frequency Range
Dimensions / Weight
Product Material
Power Consumption
Working Voltage
Output Voltage/Current
Water-Resistant Level
LED Flashlight / Reading Light
Power Source
AM 520-1710Khz
FM 87-108MHz
NOAA WB 162.400-162.550MHz
Safety Instructions
• Wind the hand crank for 3-5 minutes before use to activate
and keep the internal LI-ION power bank healthy.
• Charge the radio by USB (recommended) at least once a
month so it has power in case its needed during a disaster.
• Dropping this radio can cause injury or damage. The radio
will not resist strong impact or contact with corrosive liquids.
• The radio is NOT waterproof. It is only water resistant. Keep
the radio dry as moisture and liquids can damage it.
• Store the radio at room temperature when possible.
Warranty
This radio has a 12 month Manufacturers Warranty from the
date of purchase for any defects not caused by human error.
7.4”x3.9“x2.7” / 1.2lbs
ABS/PC/PVC
5W (max)
2.7V-4.2V
5.1V/800mA
IPX - 3
100 Lumen / 20 Lumen
3.7V / 4000mAh LI-ION
