WBOX Technologies WBXHD041S User manual

Digital Video Recorder(DVR)
User Manual
WBXHD041S
WBXHD041S1T
WBXHD082S
WBXHD082S2T
WBXHD162S
WBXHD162S4T
If you have any questions, please
contact your ADI salesperson.

Digital Video Recorder(DVR)
User Manual
Precautions
Issue V1.0 (2018-06-04)
i
Precautions
Precautions
Fully understand this document before using this device, and strictly observe rules in
this document when using this device. If you install this device in public places,
provide the tip "You have entered the area of electronic surveillance" in an eye-
catching place. Failure to correctly use electrical products may cause fire and severe
injuries. To prevent accidents, carefully read the following context:
Symbols
This document may contain the following symbols whose meanings are described
accordingly.
Symbol
Description
It alerts you to fatal dangers which, if not avoided, may
cause deaths or severe injuries.
It alerts you to moderate dangers which, if not avoided,
may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may cause
device damage, data loss, device performance
deterioration, or unpredictable results.
It provides a tip that may help you resolve problems or
save time.
It provides additional information.
To prevent electric shocks or other dangers, keep power plugs dry and clean.
Strictly observe installation requirements when installing the device. The
manufacturer shall not be held responsible for device damage caused by users' non-
conformance to these requirements.

Precautions
Digital Video Recorder(DVR)
User Manual
ii
Issue V1.0 (2018-06-04)
Strictly conform to local electrical safety standards and use power adapters that are
marked with the LPS standard when installing and using this device. Otherwise,
this device may be damaged.
Use accessories delivered with this device. The voltage must meet input voltage
requirements for this device.
If this device is installed in places with unsteady voltage, ground this device to
discharge high energy such as electrical surges in order to prevent the power supply
from burning out.
When this device is in use, ensure that no water or any liquid flows into the device.
If water or liquid unexpectedly flows into the device, immediately power off the
device and disconnect all cables (such as power cables and network cables) from
this device.
Do not focus strong light (such as lighted bulbs or sunlight) on this device.
Otherwise, the service life of the image sensor may be shortened.
If this device is installed in places where thunder and lightning frequently occur,
ground the device nearby to discharge high energy such as thunder strikes in order
to prevent device damage.
Avoid heavy loads, intensive shakes, and soaking to prevent damages during
transportation and storage. The warranty does not cover any device damage that is
caused during secondary packaging and transportation after the original packaging
is taken apart.
Protect this device from fall-down and intensive strikes, keep the device away from
magnetic field interference, and do not install the device in places with shaking
surfaces or under shocks.
Clean the device with a soft dry cloth. For stubborn dirt, dip the cloth into slight
neutral cleanser, gently wipe the dirt with the cloth, and then dry the device.
Do not jam the ventilation opening. Follow the installation instructions provided in
this document when installing the device.
Keep the device away from heat sources such as radiators, electric heaters, or other
heat equipment.
Keep the device away from moist, dusty, extremely hot or cold places, or places
with strong electric radiation.
If the device is installed outdoors, take insect- and moisture-proof measures to
avoid circuit board corrosion that can affect monitoring.
Remove the power plug if the device is idle for a long time.
Before unpacking, check whether the fragile sticker is damaged. If the fragile
sticker is damaged, contact customer services or sales personnel. The manufacturer
shall not be held responsible for any artificial damage of the fragile sticker.

Digital Video Recorder(DVR)
User Manual
Precautions
Issue V1.0 (2018-06-04)
iii
Special Announcement
All complete products sold by the manufacturer are delivered along with nameplates,
operation instructions, and accessories after strict inspection. The manufacturer shall
not be held responsible for counterfeit products.
This manual may contain misprints, technology information that is not accurate enough,
or product function and operation description that is slightly inconsistent with the
actual product. The manufacturer will update this manual according to product function
enhancement or changes and regularly update the software and hardware described in
this manual. Update information will be added to new versions of this manual without
prior notice.
This manual is only for reference and does not ensure that the information is totally
consistent with the actual product. For consistency, see the actual product.

Contents
Digital Video Recorder(DVR)
User Manual
iv
Issue V1.0 (2018-06-04)
Contents
Precautions.................................................................................................................... i
1 Specifications............................................................................................................ 1
2 Hard Disk .................................................................................................................. 3
2.1 Precautions..................................................................................................................... 3
2.2 Hard Disk Recommendation .......................................................................................... 3
2.3 Approximate Video Storage Duration............................................................................. 3
2.4 Hard Disk Installation .................................................................................................... 4
3 Operation Instruction.............................................................................................. 8
3.1 Front panel ..................................................................................................................... 8
3.2 Rear panel....................................................................................................................... 8
3.3 Startup.......................................................................................................................... 10
3.4 Powering off the Device................................................................................................11
3.5 Logging In to the System ..............................................................................................11
3.6 Changing the Password ................................................................................................ 12
3.7 Adding Cameras........................................................................................................... 13
4 Quick Navigation................................................................................................... 15
4.1 PTZ Operations............................................................................................................ 17
4.1.1 PTZ .................................................................................................................. 17
4.1.2 UTC ................................................................................................................. 19
4.2 Playback....................................................................................................................... 20
4.3 Search........................................................................................................................... 21
4.4 Picture Grid.................................................................................................................. 22
4.5 Event ............................................................................................................................ 23
4.6 Main Menu................................................................................................................... 23
5 Camera Management ............................................................................................ 25
5.1 Camera Management.................................................................................................... 26
5.1.1 Lock a Camera ................................................................................................. 26
5.1.2 Unlock a Camera.............................................................................................. 26
5.2 Picture Parameter ......................................................................................................... 27
5.3 Encode Parameter......................................................................................................... 28

Digital Video Recorder(DVR)
User Manual
Contents
Issue V1.0 (2018-06-04)
v
5.4 Video loss..................................................................................................................... 29
5.5 Motion Detection.......................................................................................................... 33
5.6 Privacy Area................................................................................................................. 35
5.7 Camera tamper ............................................................................................................. 35
5.8 OSD settings................................................................................................................. 36
6 System setting......................................................................................................... 38
6.1 Basic............................................................................................................................. 38
6.1.1 System.............................................................................................................. 39
6.1.2 Time ................................................................................................................. 39
6.1.3 Time zone......................................................................................................... 40
6.1.4 DST.................................................................................................................. 41
6.2 Network........................................................................................................................ 42
6.2.1 Ipv4.................................................................................................................. 42
6.2.2 Port................................................................................................................... 44
6.2.3 UPNP............................................................................................................... 45
6.2.4 SMTP............................................................................................................... 46
6.2.5 DDNS............................................................................................................... 47
6.2.6 Blacklist ........................................................................................................... 48
6.3 Record.......................................................................................................................... 50
6.4 Output........................................................................................................................... 51
6.5 Alarm Manager............................................................................................................. 54
6.5.1 Surveillance...................................................................................................... 54
6.5.2 Alarm in ........................................................................................................... 55
6.6 Disk.............................................................................................................................. 56
6.6.1 Viewing Disk Information................................................................................ 57
6.6.2 Clearing Disk Data........................................................................................... 57
6.7 Privilege manager......................................................................................................... 58
6.7.1 User manager ................................................................................................... 58
6.7.2 Modify Password ............................................................................................. 60
6.8 Privacy ......................................................................................................................... 60
6.9 Advanced setting .......................................................................................................... 61
6.10 App............................................................................................................................. 62
7 Log Center ............................................................................................................... 64
8 Alarm........................................................................................................................ 66
8.1 Event ............................................................................................................................ 66
8.2 Timeline ....................................................................................................................... 67
8.3 Clear alarm................................................................................................................... 68

Contents
Digital Video Recorder(DVR)
User Manual
vi
Issue V1.0 (2018-06-04)
9 Web Access.............................................................................................................. 69
9.1 Login............................................................................................................................ 69
9.2 Live Video.................................................................................................................... 70
9.3 Video Playback............................................................................................................. 70
9.4 Alarm Search................................................................................................................ 72
9.5 DVR Setting................................................................................................................. 74
9.5.1 Viewing basic information ............................................................................... 75
9.5.2 Network management ...................................................................................... 76
9.5.2.1 IPv4 ............................................................................................. 76
9.5.2.2 Port.............................................................................................. 77
9.5.2.3 DDNS.......................................................................................... 78
9.5.2.4 SMTP .......................................................................................... 79
9.5.3 Device management......................................................................................... 80
9.6 Alarm............................................................................................................................ 82
9.7 Storage.......................................................................................................................... 84
9.8 User.............................................................................................................................. 85
9.8.1 Privilege management...................................................................................... 85
9.8.2 Modify password.............................................................................................. 88
9.8.3 Local ................................................................................................................ 88
10 FAQ ........................................................................................................................ 90

Digital Video Recorder(DVR)
User Manual
1Specifications
Issue V1.0 (2018-06-04)
1
1 Specifications
Model
WBXHD041S
WBXHD041S1T
WBXHD082S
WBXHD082S2T
WBXHD162S
WBXHD162S4T
VIDEO
Video Compression
H.264 High Profile
Encode Ability
4ch*1080P@15fps
8ch*1080P@15fps
16ch*1080P@15fps
Decode Ability
4ch *1080P@15fps
8ch*1080P@15fps
16ch*1080P@15fps
Video Input
Pure Analog:
4ch*1080P/4ch*720
P
Pure Analog:
8ch*1080P/8ch*720
P
Pure Analog:
16ch*1080P/8ch*72
0P
Mixed Input:
4ch*1080P(AHD+T
VI+CVI)
Mixed
Input:8ch*1080P(A
HD+TVI+CVI)
Mixed
Input:16ch*1080P(
AHD+TVI+CVI
4ch*1080P(AHD
+CVI+ Network
8ch*1080P(AHD
+CVI+ Network
16ch*1080P(AHD
+CVI+ Network)
4ch*1080P(TVI
+CVI+ Network)
8ch*1080P(TVI
+CVI+ Network)
16ch*1080P(TVI+C
VI + Network
Pure Network:
4ch*1080P/4ch*720
P
Pure Network:
8ch*1080P/8ch*720
P
Pure
Network:16*1080P/
16ch*720P
AUDIO
Audio Compression
G711A
Two Way Audio
Support
RECORD AND PLAYBACK
Hard Drive
1 SATA(Each
maximum support
6T )
2 SATA(Each
maximum support
6T )
2 SATA(Each
maximum support
6T )
Record
Manual/Event/Timer
Playback
4ch(pure local input
mode)
8ch(pure local input
mode)
16ch(pure local
input mode)
STORAGE AND BACKUP
Space Occupation
960H:12G~20G/ day*channel

1Specifications
Digital Video Recorder(DVR)
User Manual
2
Issue V1.0 (2018-06-04)
Model
WBXHD041S
WBXHD041S1T
WBXHD082S
WBXHD082S2T
WBXHD162S
WBXHD162S4T
720P:10G~20G/ day*channel
1080P: 20G~30G/ day*channel
Audio:691.2M/ day*channel
Backup Mode
USB HDD
INTERFACE
Video Input
4ch BNC
（AHD/TVI/CVI/C
VBS）
8ch BNC
（AHD/TVI/CVI/C
VBS）
16ch BNC
（AHD/TVI/CVI/C
VBS）
Video Output
1ch VGA,1ch HDMI,1ch CVBS
Audio Input
4ch RCA
8ch RCA
6ch RCA
Audio Output
1ch RCA
Alarm Input
N/A
4ch
Alarm Output
N/A
1ch
Network Interface
1 RJ45 10M/100M Adaptive Ethernet Port
PTZ Control
RS485, Support Multiple PTZ Protocols
USB
2 USB
Hard Disk
1 SATA
2 SATA
GENERAL
Power
DC12V/2A
DC12V/4A
Operating
Temperature
-10°C ~ 50°C (14°F ~ 122°F )
Dimension
255mm(L)*255mm(
W)*45mm(H)
350mm(L)* 295mm(W)*45mm(H)
Product Weight
(Excluding hard
disk)
900g
1900g

Digital Video Recorder(DVR)
User Manual
2Hard Disk
Issue V1.0 (2018-06-04)
3
2 Hard Disk
2.1 Precautions
Formatting will clear all video data on the hard disk. Use this function only when
necessary.
Be sure to uninstall the hard disk before removing it from the DVR during runtime;
otherwise, the hard disk may be damaged or data may be lost.
The DVR must be connected to a stable power supply during runtime; otherwise,
the hard disk may be damaged or data may be lost.
The maximum capacity of a single hard disk cannot exceed 6 TB.
2.2 Hard Disk Recommendation
Seagate or Western Digital hard disks which are highly stable and inexpensive are
recommended.
2.3 Approximate Video Storage Duration
Table 2-1 Approximate Video storage duration
Maximum Hard Disk
Capacity
Maximum Bit Rate
Approximate Video
Storage Duration
1 ×6 TB
18 Mbps
28 days
2×6 TB
36 Mbps
28 days
4 ×6 TB
72 Mbps
28 days
Formulae for calculating the approximate video storage duration:
Step 1 Use the following formula to calculate the storage capacity q(unit: MBybte)
required to record a single video per hour:
q = d/8×3600/1024

2Hard Disk
Digital Video Recorder(DVR)
User Manual
4
Issue V1.0 (2018-06-04)
dindicates the bit rate (unit: Kbit/s).
Step 2 Use the following formula to calculate the approximate video storage duration t
(unit: day)
windicates the capacity (unit: Mbyte) of a single hard disk.
nindicates the number of disks.
hindicates the recording duration per day.
cindicates the number of video inputs of the DVR.
Table 2-2 shows examples of approximate video storage duration (his 24 hours).
Table 2-2 Examples of approximate video storage duration
Hard Disk
Capacity
Bit Rate
Video Count
Approximate Video
Storage Duration
1×6TB
D1, 1.5Mbps
4
85 days
1×6TB
720p, 3Mbps
4
47 days
1×6TB
1080p, 4.5Mbps
4
28 days
2×6TB
D1, 1.5Mbps
8
85 days
2×6TB
720p, 3Mbps
8
47 days
2×6TB
1080p, 4.5Mbps
8
28 days
4×6TB
D1, 1.5Mbps
16
85 days
4×6TB
720p, 3Mbps
16
47 days
4×6TB
1080p, 4.5Mbps
16
28 days
The data listed in the preceding table is only for your reference. The recording time estimate
may be different from the actual recording time. The user shall be liable for any loss
incurred as a result thereof.
2.4 Hard Disk Installation
Take the following steps to install a hard disk:
Step 1 Unscrew the four fixing screws on both sides and one fixing screw on the back, then
remove the upper cover, as shown in Figure 2-1.

Digital Video Recorder(DVR)
User Manual
2Hard Disk
Issue V1.0 (2018-06-04)
5
Figure 2-1 Removing the upper cover
Step 2 Take out the hard disk fixing screws and silicone cushion included in the accessory
package, route the fixing screw through the silicone cushion, and install it to the screw
holes, as shown in Figure 2-2.
Figure 2-2 Installing the hard disk fixing screw
Step 3 Route the hard disk fixing screws through the holes on the base, push the hard disk to
the appropriate position according to the direction of arrow, as shown in Figure 2-3.

2Hard Disk
Digital Video Recorder(DVR)
User Manual
6
Issue V1.0 (2018-06-04)
Figure 2-3 Inserting the hard disk
Step 4 Turn the device over, and fasten two hard disk fixing screws, as shown in Figure 2-4.
Figure 2-4 Fixing the hard disk
Step 5 Install the other hard disk according to Step 2, Step 3, and Step 4, then insert the hard
disk data cable and power cable, as shown in Figure 2-5.

Digital Video Recorder(DVR)
User Manual
2Hard Disk
Issue V1.0 (2018-06-04)
7
Figure 2-5 Inserting the cable
Step 6 Put on the upper cover, and fasten the fixing screws, as shown in Figure 2-6.
Figure 2-6 Put on the upper cover
----End

3Operation Instruction
Digital Video Recorder(DVR)
User Manual
8
Issue V1.0 (2018-06-04)
3 Operation Instruction
3.1 Front panel
Figure 3-1 shows the front panel of DVR. Table 3-1 shows the description of front
panel.
Figure 3-1 Front panel
Table 3-1 Elements of the front panel
NO.
Element
Description
1
POWER
Power indicator, When DVR is operating, the
Power indicator is steady on. When DVR is
shut down, the PWR indicator is turned off.
2
ALARM
Alarm indicator
This indicator flashes when alarm is transmitted
3
REC
Record indicator
This indicator flashes when DVR is recording
4
NET
Net indicator
This indicator flashes when DVR record
5
USB
Supports connection to a USB mouse, a USB
flash drive or USB removable hard disk.
3.2 Rear panel
Figure 3-2 shows the rear panel of 0E-HD4C1TB and the interfaces on it.

Digital Video Recorder(DVR)
User Manual
3Operation Instruction
Issue V1.0 (2018-06-04)
9
Figure 3-2 Rear panel of 0E-HD4C1TB
Figure 3-3 shows the rear panel of 0E-HD8C2TB and the interfaces on it.
Figure 3-3 Rear panel of 0E-HD8C2TB
Figure 3-3 shows the rear panel of 0E-HD16C2TB and the interfaces on it.
Figure 3-4 Rear panel of 0E-HD16C2TB
Table 3-2 shows the description of rear panel
Table 3-2 Elements of the real panel
NO.
Name
Description
1
AUDIO IN
Audio Input
2
ALARM I/O
Alarm Input/Output
3
VIDEO IN
Video input
4
CVBS
CVBS output interface
5
A-OUT
Audio output
6
HD-OUT
Video output interface
7
VGA
8
AUDIO IN
Audio Input

3Operation Instruction
Digital Video Recorder(DVR)
User Manual
10
Issue V1.0 (2018-06-04)
NO.
Name
Description
9
LAN network
interface
RJ45 10 /100/1000 Mbps adaptive
Ethernet interface
10
USB
Supports connection to a USB mouse, a USB
flash drive or USB removable hard disk.
11
RS485
RS485 port
12
DC power
interface
Connected to an external power adapter
13
Power switch
-(Optional for different DVR)
14
Ground screw
Safe ground screw of the device
3.3 Startup
Before starting the DVR, ensure that the DVR is connected to a power supply.
When the DVR is connected to a power supply, it starts automatically upon the initial
power-on.
Ensure that a power supply is connected to the DVR correctly.
Before starting the DVR, ensure that a monitor is connected to the HD-OUT or
VGA interface of the DVR correctly.
The DVR may not operate normally when a power supply exception occurs, likely
causing damage to the DVR in serious conditions. In such a circumstance, you are
advised to use a regulated power supply.
After the DVR is connected to a power supply, the power indicator is steadily on. Start
the DVR. The real-time video screen is displayed, as shown in Figure 3-5.

Digital Video Recorder(DVR)
User Manual
3Operation Instruction
Issue V1.0 (2018-06-04)
11
Figure 3-5 Real-time video screen
Users need to provide a hard disk for the DVR. The hard disk is strictly detected during
device startup. If the detection result failed, the possible causes are as follows:
The hard disk is new and is not formatted. Log in to the system and format the hard disk.
The hard disk is formatted, but the file system is inconsistent with the file system
supported by the DVR. Format the hard disk.
The hard disk is damaged.
3.4 Powering off the Device
Click the main menu and choose System setting > Advanced setting, the advanced
setting page is displayed, click shutdown to power off the DVR. If there is a power
switch on the rear panel of the DVR, you can turn off the power switch to disconnect
the DVR from the power supply.
3.5 Logging In to the System
Logging In to the Device
Step 1 On the DVR login page, select the language, as shown in Figure 3-6.

3Operation Instruction
Digital Video Recorder(DVR)
User Manual
12
Issue V1.0 (2018-06-04)
Figure 3-6 Login page
Step 2 Enter the username and password.
The username and password are both admin.
If you forget password, click Forgot password. You can choose a way to find previous
password:
1. Scan the QR code and send the QR code to your seller.
2. Click Send Password to you E-mail. A password retrieval email will be sent to your
email address (for details, see 6.2.4 Step 6). Then, you can retrieve password by
following operations described in the email.
Step 3 Click Login to access the main User Interface (UI).
----End
3.6 Changing the Password
Description
The change default password page will be displayed as shown in Figure 3-7, when you
login the system for the first time.
