WEB Biotechnology SPYDER BLUETOOTH User manual

SPYDER BLUETOOTH
USER MANUAL
SPBT20A

2
At WEB Biotechnology, we take the responsibility to provide the
best medical products to our users. This User Manual, although
sufficient, will be constantly updated as our products are im-
proved. Do keep a look out at:
www.web-biotech.com/downloads/spyderBT/usermanuals
Last update 18/June/2012

3
Table of Contents
Intended use of Spyder Bluetooth 4
Complementary Products 5
Detachable Parts 6
Product Technical Specifications 7
Safety Precautions and Warnings 9
Storage Conditions 11
Using Spyder Bluetooth 12
Replacing the Batteries 14
Using Spyder App 16
Troubleshooting 19
Service Information 22
Certification Statements 23
Legend For Logos 25
Legal Information 26

4
Introduction:
Intended use of Spyder Bluetooth
Spyder Blutooth Intended Use:
Spyder Bluetooth is a ECG sensor for monitoring of heart rhythm
with bluetooth devices. It is attached to the chest with a
specially-designed adhesive pad. The device is practically
inconspicuous when worn, providing remarkable quality of life to
user. Spyder Bluetooth continuously measures and transmits ECG
signal to a computer server programmed to identify abnormal
heart rhythm patterns. It is easy to administer and hassle–free to
use. Spyder Bluetooth truly simplifies the life of user and medical
professionals.”
Spyder Bluetooth is intended to be used in the mobile healthcare
environment accessed with mobile phone application. Information
provided are intended only for information to the user.

5
Android Smartphone:
All smartphones running on Android OS with minimum specifica-
tions of v2.1 Eclair are suitable for hosting the Spyder App.
Spyder App:
The Spyder Android App must be installed on the android smart-
phone. The most updated Spyder App can be found on Google
Play, from the authorized distributor or at the url provided below.
www.web-biotech.com/downloads/spyderBT/Spyderapp
Doctor Spyder (Server)
The Doctor Spyder is our server which stores the encrypted ECG
data. The server can be accessed by authorised medical
professionals at the url provided below.
www.doctorspyder.com
Adhesive Electrode Pad:
For users’ safety, we advise users to use the official adhesive pad
provided by WEB Biotechnology Pte Ltd only.
Complementary Products

6
Cover:
The cover can be removed for easy changing of batteries by
sliding the cover upwards gently.
Detachable Parts

7
Product Technical Specifications
Function:
Acquisition:
Sample Rate:
Dynamic Range:
Resolution:
Freq. Response:
Common Mode Rejection:
Input Impedence:
Patient Leakage:
Battery Type:
Battery Voltage:
Battery Life:
Battery Included:
Data Transfer Method:
Weight:
Dimensions:
Operating Temperature:
Real-time ECG monitoring with
Bluetooth devices
3 leads
125 per second
-2.5 to 7.7mV
10µV
0.01 to 150Hz
> 100dB @ 50Hz
> 10MΩ@ 10HzΩ
< 10µA
2 x AAA
3V
3 days per pair
No
Bluetooth 2.0
26g (without batteries)
60 x 55 x 18mm
-15 to 42ºC

8
Product Technical Specifications
Operating Relative Humidity:
Operating Pressure:
Data Analysis:
Data Access:
Accessories:
Firmware version:
Product Life:
25 to 95%
700 to 1060hPa
Signal Measurements & Arrhythmia Detection
Doctor Spyder Website
User Manual, Spyder App for mobile devices
Ver 1.0 (release date 1/Sep/2011.)
Should there be any further update in firmware
version, user may upgrade the product via
WEB-Bio online site by downloading the latest
version of firmware.
5 years

9
Safety Precautions and Warnings
1. Remove the batteries inside Spyder Bluetooth when the device is not
likely to be used for some time to avoid risk of leakage from batteries.
2. Avoid having Spyder Bluetooth in contact with water.
3. To clean Spyder Bluetooth, always use a clean and dry cloth.
4. No modification of Spyder Bluetooth is allowed.
5. This product must be disposed properly according to local laws and
regulations. Since this product contains a battery, the battery must
be disposed separately from household waste.
6. Spyder Bluetooth was not evaluated for use in an oxygen rich
environment.
7. Spyder Bluetooth is not intended for use with flammable anesthetics.
8. Spyder Bluetooth is not intended for use in conjunction with
flammable agents.

10
Safety Precautions and Warnings
9. If the product is received in a damage state, do not use. Return the
product according to service information section in user manual.
10. If the on/off switch does not work, or if the cover of Spyder Bluetooth
becomes loose, there is no risk to the patient. However, return the
parts according to service information section in user manual.
11. In case of Spyder Bluetooth failing to function normally, follow the
instructions in troubleshooting section of the user manual.

11
Storage Conditions
Temperature:
Relative Humidity:
Pressure:
-15 to 42˚C
25 to 95%
700 to 1060 hPa
Users are advised to store Spyder Bluetooth in a cool and dry
place.

12
Using Spyder Bluetooth
To Turn “On” Spyder Bluetooth
ON
OFF
Step 1:
Turn on Spyder Bluetooth by pushing the
switch to the “ON” position.
Step 2:
A green light will illuminate for 2 seconds
to indicate that Spyder Bluetooth has
been successfully switched on.
Step 3:
Attach an adhesive pad to Spyder
Bluetooth by securing the buttons.

13
Using Spyder Bluetooth
To Turn “Off” Spyder Bluetooth
Step 1:
Switch Spyder Bluetooth off by pushing
the switch to the “OFF” position.
Step 4:
Peel off the plastic cover from the
adhesive pad and affix Spyder Bluetooth
on chest.
ON
OFF

14
Replacing the Batteries
Step 1:
A red light will flash once every 5 seconds
to indicate that the batteries need to be
replaced soon.
Step 2:
Push open the top cover of
Spyder Bluetooth.

15
Replacing the Batteries
Step 3:
Replace 2 AAA batteries as shown.
Step 4:
Replace the top cover of Spyder
Bluetooth.
+
+

16
Using Spyder App
Step 1:
Launch the Spyder App. The Application displays the following
information.
Step 2:
The server connectivity icon will turn red if there is a problem
with the server connection. Restart the phone or application if
the problem persists.
Heartbeat Rate Time
Server Connectivity Battery Indicator
Marker
71 BPM 11:28 Settings

17
Using Spyder App
Step 3:
A marker can be sent to the server by tapping the screen at the
area labelled ‘Marker’. A red line will appear on the screen to
indicate successful creation of the marker.
Step 4:
Do not exit the application or the detected ECG may not be trans-
mitted to the phone and server. Simply ‘hide’ the application while
the Spyder Bluetooth is in use.
Red line
Button
Marker
71 BPM 11:28 Settings

18
Using Spyder App
Step 5:
The phone will sound when Bluetooth connection with the Spyder
Bluetooth device is lost.
Step 6:
Start or re-enter the application by tapping on the Spyder
Application.
Step 7:
To terminate the session, simply exit the application.

19
Troubleshooting
What should I do when the app screen goes blank, no waveform is
seen or the notification alarm on the phone rings?
1. Check the Bluetooth connection between your android
smartphone and Spyder Bluetooth.
2. Ensure the Spyder Bluetooth has working batteries.
3. Restart the application by exiting and launching it again.
4. The notification alarm will stop ringing when the waveform
appears on the phone screen.
5. If the waveform does not appear, the screen is blank or
notification ring tone continues to ring after action (1), (2) &
(3), please return the product according to service informa-
tion section in user manual.

20
Troubleshooting
What should I do, if the green indicator light fail to turn on for 2-3
seconds after switching on the Spyder.
1. Ensure the Spyder Bluetooth has working batteries.Make
sure that the phone apps is receiving constant signal from
Spyder Bluetooth.
2. Ensure that the batteries are inserted according to the
indicated polarities.”
3. If Spyder Bluetooth indicator light still does not turn on
after checking with point (1) & (2), please return the product
according to service information section in user manual.
