2800W Electric Silent Shredder
WEESS
1938266001

2
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL
4 Sep 2020

3
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
CONTENTS
INTENDED USE
SAFETY INSTRUCTIONS
SPECIFICATIONS
KNOW YOUR MACHINE
ASSEMBLY
OPERATION
ELECTRICAL CONNECTION
MAINTENANCE, CLEANING & STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
INTENDED USE
The basic version of the equipment is an electric shredder intended for private use, i.e. for use in home and
gardening environments. It is designed for compacting fibrous and wood-related materials such as hedge and
tree cuttings, branches, bark and pine cones from medium sized gardens. Any use not expressly permitted in
this manual may damage the shredder and pose a serious danger to the user.
DO NOT FILL THE SHREDDER WITH STONES, GLASS, METAL, BONES, PLASTICS or FABRICS.
The shredder is for private use only, whose annual operating time generally does not exceed 25 hours. Public
facilities, sporting facilities and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set
up, operate and maintain your machine. Please be sure that you and any other persons who will operate the
machine, always carefully follow the recommended safety practices. Failure to do so could result in personal
injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features & operation.
Please note that this Instruction Manual may cover a range of product specifications for various models.
Characteristics & features discussed and/or illustrated in this manual may not be applicable or exact to all
models.
We reserve the right to change product specifications, designs, and equipment without notice and without
incurring obligation. If you have any problems or questions concerning the machine, phone your local
authorised service dealer or ourselves. Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
WARNING
The operator or user is responsible for accidents and injury or damage to third parties.
The equipment is allowed to be used only for its prescribed purpose. Any other use is deemed to be a case
of misuse. The user/operator and not the manufacturer will be liable for any damage or injuries of any kind
resulting from such misuse. Please note that our equipment has not been designed for use in commercial,
trade or industrial applications. Our warranty will be 90 days from the original date of sale for commercial,
trade or industrial businesses or for equivalent purposes.
INSTRUCTION MANUAL

4
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its application and
limitations as well as the specific potential hazards. Retain these instructions for future reference. The
operator is responsible for following the warnings & instructions in this manual and on the product.
Read & understand the instruction
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
Please keep in a safe place for future
reference.
Whenever the machine is in use, safety
goggles or glasses must be worn to
safeguard against flying objects.
Hearing protection must also be used
to protect the operators hearing.
Face masks are also recommended to
avoid inhalation of debris.
Remove the electrical plug from the
power supply before any
maintenance, repair, cleaning or if
the power cable is damaged.
Always wear gloves to protect your
hands.
Wear foot protection or sensible shoes
when using the machine. Steel-toed
shoes are recommended
DANGER
Keep all bystanders & animals away
from the machine during operation.
If approached, stop the machine
immediately.
DANGER —THROWN DEBRIS
Remove objects that can be thrown by
the machine in any direction.
IMPORTANT NOTE!
Risk of injury due to rotating blade!
Keep hands and feet outside of the
openings when the machine is
running.
Keep guards in place and in working
order. Replace damaged, missing, or
failed parts before operating.
Do not misuse as a step or climb
upon the machine.
Do not expose to rain or damp
conditions.
Safety alert symbol. Used to alert
you to potential personal injury
hazards. Obey all safety messages
that follow this symbol to avoid
possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
Noise Level - See label on machine
CE Marking - the product meets
demand and regulations set by the
EU
GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to remove the risk of personal injury or
material damage. Please also observe the special safety instructions in the respective chapters. Where
applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of
this machine.
When using electric tools, basic safety precautions, including the following, should always be followed to
reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine and in the manual(s) before operation. Keep this
manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, always exercise extreme
caution. This machine has been designed to perform one job: compacting fibrous and wood-related
materials. Do not use it for any other purpose.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and should be
trained and always supervised by an adult.
6. Only responsible individuals who are familiar with these rules of safe operation should be allowed to use
this machine.
7. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, bones,
toys, and other foreign objects, which could be tripped over or picked up and placed into the shredder.
Foreign objects can cause serious damage to the machine or increases the chances of personal injury.
8. Stay in operator zone behind operation panel and handles and keep children, bystanders, helpers, and
pets at least 20 metres from shredder while it is in operation. Stop machine if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that cover
the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet,
sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or into rotating parts. Always keep clear of input and discharge areas, as the
rotating blade can cause injury.
12. Never operate the shredder without proper shields, guards, control lever or other safety protective
devices in place and working.
13. Never operate the shredder with damaged safety devices. Failure to do so, can result in personal injury.
14. Do not operate the shredder while under the influence of alcohol or drugs.
15. Never attempt to bypass its operation safety devices. Doing so makes the safety device inoperative and
may result in personal injury through contact with the rotating blade. The collector safety lever must
operate easily in both directions.
16. Never operate the shredder in wet grass. Always be sure of your footing. A slip and fall can cause serious
personal injury.
17. Operate only in daylight or good artificial light. Walk, never run when around the machine.
18. Do not use the machine on a paved, graveled area, which could be damaged by ejected material
19. If the machine starts to vibrate abnormally, stop the motor, and check immediately for the cause.
Vibration is generally a warning of trouble.
INSTRUCTION MANUAL

5
