Webb WEV20HT User manual

v
Save these instructions
Sales & Support: 01793 333212
Before use please read & understand this manual; paying particular attention to the safety instructions before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every eff ort has been made to ensure the accuracy of information contained in this manual, our policy of continuous improvement
determines the right to make modifi cations without prior warning.
Images are used for illustration purposes only.
en - Original Instructions
ASSEMBLY REQUIRED
Minimum Two Persons
50cm Hedge Trimmer
with 20V 2Ah Lithium-Ion Battery & Charger
WEV20HT
1938201002

CONTENTS
INTENDED USE
GENERAL SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
BATTERY
CHARGING
OPERATION
CLEANING & MAINTENANCE
STORAGE & TRANSPORTATION
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
EC DECLARATION OF CONFORMITY
INTENDED USE
The basic version of the equipment is a handheld lithium battery powered hedge-trimmer, intended for
private use, i.e. for use in home and gardening environments. It is designed to cut foliage with a maximum
diameter of 16mm.
The hedge-trimmer is for private use only, whose annual operating time generally does not exceed 50
hours. Public facilities, sporting facilities and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily
set up, operate and maintain your machine. Please be sure that you and any other persons who will
operate the machine, always carefully follow the recommended safety practices. Failure to do so could
result in personal injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and
operation. Please be aware that this Instruction Manual may cover a range of product specifications for
various models. Characteristics and features discussed and/or illustrated in this manual may not be
applicable or exact to all models.
We reserve the right to change product specifications, designs, and equipment without notice and
without incurring obligation. If you have any problems or questions concerning the machine, phone your
local authorised service dealer or ourselves. Throughout this manual, all references to right and left side
of the machine are observed from the operating position.
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
14 October 20
INSTRUCTION MANUAL

CONTENTS
INTENDED USE
GENERAL SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
BATTERY
CHARGING
OPERATION
CLEANING & MAINTENANCE
STORAGE & TRANSPORTATION
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
EC DECLARATION OF CONFORMITY
INTENDED USE
The basic version of the equipment is a handheld lithium battery powered hedge-trimmer, intended for
private use, i.e. for use in home and gardening environments. It is designed to cut foliage with a maximum
diameter of 16mm.
The hedge-trimmer is for private use only, whose annual operating time generally does not exceed 50
hours. Public facilities, sporting facilities and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily
set up, operate and maintain your machine. Please be sure that you and any other persons who will
operate the machine, always carefully follow the recommended safety practices. Failure to do so could
result in personal injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and
operation. Please be aware that this Instruction Manual may cover a range of product specifications for
various models. Characteristics and features discussed and/or illustrated in this manual may not be
applicable or exact to all models.
We reserve the right to change product specifications, designs, and equipment without notice and
without incurring obligation. If you have any problems or questions concerning the machine, phone your
local authorised service dealer or ourselves. Throughout this manual, all references to right and left side
of the machine are observed from the operating position.
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL

GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn
its application and limitations as well as the specific potential hazards. Retain these instructions for future
reference. The operator is responsible for following the warnings & instructions in this manual and on the
product.
Read & understand operator’s
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
Always hold the hedge trimmer
with both hands when operating.
Wear gloves to protect your hands
Wear safety shoes.
Check your machine before turning
it on. Keep guards in place & in
working order. Frequently check to
see that foreign objects are
removed from the working area
before turning it on. Replace
damaged, missing or failed parts
before using it.
Whenever the machine is in use,
safety glasses must be worn to
safeguard against flying objects.
Hearing protection must also be
used to protect the users hearing.
Face masks are also recommended
to avoid inhalation of debris.
Do not expose to rain or damp
conditions
Keep all bystanders & animals at
least 15 metres away from the
machine during operation.
If approached, stop the machine
immediately.
STAY ALERT
Safety alert symbol. Used to alert
you to potential personal injury
hazards. Obey all safety messages
that follow this symbol to avoid
possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided,
could result in serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert
symbol, indicates a potentially
hazardous situation which, if not
avoided, may result in property
damage.
According to the European directive
2012/19/EU for Waste Electrical &
Electronic Equipment and its
implementation into national law,
electrical and electronic equipment
that are no longer usable must be
collected separately & disposed of in
an environmentally correct manner.
Sound Power Level
(Image used for illustration
purposes only, check machine and
Declaration of Conformity for
actual reading)
CE marking is a certification mark
that indicates conformity with
health, safety, and environmental
protection standards for products
sold within the European Economic
Area.
Separate collection of used
products and packaging allow
materials to be recycled & used
again. Reuse of recycled materials
helps prevent environmental
pollution and reduces the demand
for raw material.
WARNING
For safety reasons, the hedge-trimmer may not be used as a drive unit for other equipment or toolkits
of any kind, unless specifically advised to do so by the manufacturer. The equipment is to be used only
for its prescribed purpose. Any other use is deemed to be a case of misuse. The user/operator and not
the manufacturer will be liable for any damage or injuries of any kind caused because of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or
industrial businesses or for equivalent purposes.
INSTRUCTION MANUAL

GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn
its application and limitations as well as the specific potential hazards. Retain these instructions for future
reference. The operator is responsible for following the warnings & instructions in this manual and on the
product.
Read & understand operator’s
manual before using the machine.
Failure to follow instructions could
result in death or serious injury.
Always hold the hedge trimmer
with both hands when operating.
Wear gloves to protect your hands
Wear safety shoes.
Check your machine before turning
it on. Keep guards in place & in
working order. Frequently check to
see that foreign objects are
removed from the working area
before turning it on. Replace
damaged, missing or failed parts
before using it.
Whenever the machine is in use,
safety glasses must be worn to
safeguard against flying objects.
Hearing protection must also be
used to protect the users hearing.
Face masks are also recommended
to avoid inhalation of debris.
Do not expose to rain or damp
conditions
Keep all bystanders & animals at
least 15 metres away from the
machine during operation.
If approached, stop the machine
immediately.
STAY ALERT
Safety alert symbol. Used to alert
you to potential personal injury
hazards. Obey all safety messages
that follow this symbol to avoid
possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided,
could result in serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert
symbol, indicates a potentially
hazardous situation which, if not
avoided, may result in property
damage.
According to the European directive
2012/19/EU for Waste Electrical &
Electronic Equipment and its
implementation into national law,
electrical and electronic equipment
that are no longer usable must be
collected separately & disposed of in
an environmentally correct manner.
Sound Power Level
(Image used for illustration
purposes only, check machine and
Declaration of Conformity for
actual reading)
CE marking is a certification mark
that indicates conformity with
health, safety, and environmental
protection standards for products
sold within the European Economic
Area.
Separate collection of used
products and packaging allow
materials to be recycled & used
again. Reuse of recycled materials
helps prevent environmental
pollution and reduces the demand
for raw material.
WARNING
For safety reasons, the hedge-trimmer may not be used as a drive unit for other equipment or toolkits
of any kind, unless specifically advised to do so by the manufacturer. The equipment is to be used only
for its prescribed purpose. Any other use is deemed to be a case of misuse. The user/operator and not
the manufacturer will be liable for any damage or injuries of any kind caused because of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or
industrial businesses or for equivalent purposes.
INSTRUCTION MANUAL

the disengaged position when released.
17. Never operate in wet grass. Always be sure of your footing. A slip and fall can cause serious personal
injury. If you feel you are losing your footing, release the trigger/lever immediately and the blades
stop moving after release.
18. Operate only in daylight or good artificial light. Walk, never run.
19. Stop the blades when moving to another work area.
20. If the machine starts to vibrate abnormally, stop the motor, and check immediately for the cause.
Vibration is generally a warning of trouble.
21. Shut the motor off and wait until the blades come to a complete stop. Then remove the battery
before cleaning the blades. Never place any part of the body in the blade area until you are sure they
have stopped moving and battery has been removed from the machine and contact cannot be made
between the two.
22. Never operate without proper shields, discharge cover, trigger/lever or other safety protective
devices in place and working. Never operate with damaged safety devices. Failure to do so can result
in personal injury.
23. Only use parts and accessories made for this machine by the manufacturer. Failure to do so can result
in personal injury.
24. If situations occur which are not covered in this manual, use care and good judgement. Contact your
nearest Approved Service Dealer for assistance
SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on
slopes requires extra caution. If you feel uneasy on a slope, or it is greater than 15 degrees, do not scarify
on it.
Do:
1. Exercise extreme caution when changing direction on slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass
can hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are
losing your balance, release the trigger/lever immediately and the blades will stop immediately.
Do Not:
1. Do not use near drop-offs, ditches, or embankments, you could lose your footing or balance.
2. Do not scarify on slopes greater than 15 degrees.
3. Do not scarify on wet grass. Unstable footing could cause slipping.
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often
attracted to the machine and the activity. They do not understand the dangers. Never assume that
children will remain where you last saw them.
1. Keep children out of the cutting area and under care of a responsible adult other than the operator.
2. Be alert and turn the hedge-trimmer off, if a child enters the area.
3. Before and while moving backwards, look behind and down for small children.
4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that
may obscure your vision of a child who may run into the operator.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read
and understand the instructions and safe operation practices in this manual and on the machine and
be trained and supervised by an adult.
GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to remove the risk of personal
injury or material damage. Please also observe the special safety instructions in the respective chapters.
Where applicable, follow the legal directives or regulations for the prevention of accidents in relation to
the use of this machine.
When using electric/battery tools, basic safety precautions, including the following, should always be
followed to reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine.
Read, understand, and follow all instructions on the machine and in the manual(s) before operation.
Keep this manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, always exercise
extreme caution. This machine has been designed to perform one job: to cut out moss and weeds
from the root. Do not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read
and understand the instructions and safe operation practices in this manual and on the machine and
should be trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to
use this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire,
bones, toys, and other foreign objects, which could be tripped over or picked up and thrown by the
machine. Thrown objects can cause serious personal injury.
7. Plan your working pattern to avoid discharge of material toward roads, pathways, bystanders, and
the like. Also, avoid discharging material against a wall or obstruction, which may cause discharged
material to ricochet back toward the operator.
8. To help avoid blade contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers, and pets at least 20 metres from machine while it is in operation. Stop
machine if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that
cover the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare
feet, sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or in moving parts, especially the cutting blades.
12. Never operate the machine without proper shields, guards, control lever or other safety protective
devices in place and working.
13. Never operate the machine with damaged safety devices. Failure to do so, can result in personal
injury.
14. Do not hold on to the machine if you are falling; release the handle immediately.
15. Do not operate the machine while under the influence of alcohol or drugs.
16. The trigger/lever mechanisms are a safety device. Never attempt to bypass its operation. Doing so
makes the safety device inoperative and may result in personal injury through contact with the
moving blades. The trigger/lever must operate easily in both directions and automatically return to
INSTRUCTION MANUAL

the disengaged position when released.
17. Never operate in wet grass. Always be sure of your footing. A slip and fall can cause serious personal
injury. If you feel you are losing your footing, release the trigger/lever immediately and the blades
stop moving after release.
18. Operate only in daylight or good artificial light. Walk, never run.
19. Stop the blades when moving to another work area.
20. If the machine starts to vibrate abnormally, stop the motor, and check immediately for the cause.
Vibration is generally a warning of trouble.
21. Shut the motor off and wait until the blades come to a complete stop. Then remove the battery
before cleaning the blades. Never place any part of the body in the blade area until you are sure they
have stopped moving and battery has been removed from the machine and contact cannot be made
between the two.
22. Never operate without proper shields, discharge cover, trigger/lever or other safety protective
devices in place and working. Never operate with damaged safety devices. Failure to do so can result
in personal injury.
23. Only use parts and accessories made for this machine by the manufacturer. Failure to do so can result
in personal injury.
24. If situations occur which are not covered in this manual, use care and good judgement. Contact your
nearest Approved Service Dealer for assistance
SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on
slopes requires extra caution. If you feel uneasy on a slope, or it is greater than 15 degrees, do not scarify
on it.
Do:
1. Exercise extreme caution when changing direction on slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass
can hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are
losing your balance, release the trigger/lever immediately and the blades will stop immediately.
Do Not:
1. Do not use near drop-offs, ditches, or embankments, you could lose your footing or balance.
2. Do not scarify on slopes greater than 15 degrees.
3. Do not scarify on wet grass. Unstable footing could cause slipping.
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often
attracted to the machine and the activity. They do not understand the dangers. Never assume that
children will remain where you last saw them.
1. Keep children out of the cutting area and under care of a responsible adult other than the operator.
2. Be alert and turn the hedge-trimmer off, if a child enters the area.
3. Before and while moving backwards, look behind and down for small children.
4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that
may obscure your vision of a child who may run into the operator.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read
and understand the instructions and safe operation practices in this manual and on the machine and
be trained and supervised by an adult.
GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to remove the risk of personal
injury or material damage. Please also observe the special safety instructions in the respective chapters.
Where applicable, follow the legal directives or regulations for the prevention of accidents in relation to
the use of this machine.
When using electric/battery tools, basic safety precautions, including the following, should always be
followed to reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine.
Read, understand, and follow all instructions on the machine and in the manual(s) before operation.
Keep this manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, always exercise
extreme caution. This machine has been designed to perform one job: to cut out moss and weeds
from the root. Do not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read
and understand the instructions and safe operation practices in this manual and on the machine and
should be trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to
use this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire,
bones, toys, and other foreign objects, which could be tripped over or picked up and thrown by the
machine. Thrown objects can cause serious personal injury.
7. Plan your working pattern to avoid discharge of material toward roads, pathways, bystanders, and
the like. Also, avoid discharging material against a wall or obstruction, which may cause discharged
material to ricochet back toward the operator.
8. To help avoid blade contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers, and pets at least 20 metres from machine while it is in operation. Stop
machine if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that
cover the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare
feet, sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or in moving parts, especially the cutting blades.
12. Never operate the machine without proper shields, guards, control lever or other safety protective
devices in place and working.
13. Never operate the machine with damaged safety devices. Failure to do so, can result in personal
injury.
14. Do not hold on to the machine if you are falling; release the handle immediately.
15. Do not operate the machine while under the influence of alcohol or drugs.
16. The trigger/lever mechanisms are a safety device. Never attempt to bypass its operation. Doing so
makes the safety device inoperative and may result in personal injury through contact with the
moving blades. The trigger/lever must operate easily in both directions and automatically return to
INSTRUCTION MANUAL

BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the manufacturer. A charger that is unsuitable for one
type of battery may create a risk of fire when used with another battery.
2. Use power tools only with specifically designated battery. Use of any other battery may create a risk
of injury and fire
3. When the battery is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, which can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact.
5. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
HEDGE TRIMMER SAFETY WARNINGS
1. Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to
be cut when blades are moving. Make sure the switch is off when clearing jammed materials. A
moment of inattention while operating the hedge trimmer may result in serious personal injury.
2. Carry the hedge trimmer by the handle with cutter blade stopped. When transporting or storing the
hedge trimmer always fit the cutting device cover. Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
3. Hold the power tool by insulated gripping surface only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a “live” wire may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
INTENDED USE
The product is only intended for use outdoors. For safety reasons the product MUST be adequately
controlled by using the two-handed operation. The product is designed for home or domestic use. It is
intended to cut and trim hedges, shrubs and similar vegetation. It should be used in dry, well illuminated
conditions. It is NOT intended to cut grass, trees or branches. It should not be used for any other purpose
than hedge trimming.
RESIDUAL RISK
Even when the product is used as described, it is still impossible to eliminate certain residual risk factors.
The following hazards may arise in use and the operator should pay special attention to avoid the
following:
1. The blades cannot be guarded whilst cutting. Contact with the blades can cause serious injury. Keep
the blade away from yourself and others. Cover it with the blade protector whenever not in use.
2. Injury caused by vibration. Always use the right tool for the job, use designated handles and restrict
working time and exposure.
3. Exposure to noise can cause hearing injury. Wear ear protection and limit exposure
RISK REDUCTION
It has been reported that vibrations from hand-held tools may contribute to a condition called Raynaud’s
Syndrome in certain individuals. Symptoms may include tingling, numbness and blanching of the fingers,
usually apparent upon exposure to cold. Hereditary factors, exposure to cold and dampness, diet,
smoking and work practices are all thought to contribute to the development of these symptoms. There
are measures that can be taken by the operator to possibly reduce the effects of vibration:
1. Keep your body warm in cold weather. When operating the unit wear gloves to keep the hands and
wrists warm. It is reported that cold weather is a major factor contributing to Raynaud’s Syndrome.
2. After each period of operation, exercise to increase blood circulation.
3. Take frequent work breaks. Limit the amount of exposure per day.
If you experience any of the symptoms of this condition, immediately stop use and see your doctor about
these symptoms.
SERVICE
General Service:
1. Before cleaning, repairing, or inspecting, make certain the blades and all moving parts have stopped.
Disconnect the battery from the machine to prevent unintended starting.
2. Check the blades at frequent intervals for proper tightness. Also, visually inspect blades for damage.
Replace with the original equipment manufacture’s (O.E.M.) parts only, listed in this manual. “Use of
parts which do not meet the original equipment specifications may lead to improper performance
and compromise safety!”
3. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
4. Never tamper with safety devices. Check the correct operation regularly.
5. After striking a foreign object, stop the motor, disconnect the battery from the machine. Thoroughly
inspect for any damage. Repair the damage before starting and operating the machine.
6. Hedge-trimmer components, guards and shields are subject to wear and damage which could expose
moving parts or allow objects to be thrown. For safety protection, frequently check components and
replace immediately with original equipment manufacturers (O.E.M.) parts only, listed in this manual.
“Use of parts which do not meet the original equipment specifications may lead to improper
performance and compromise safety!”
7. Do not change the motor’s settings. The motor has been set for the maximum safe operating speed.
8. Maintain or replace safety and instruction labels, as necessary.
9. Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the
environment.
DO NOT MODIFY THE MOTOR
To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor settings
can cause it to operate at unsafe speeds and lead to premature failure. Never tamper with factory
settings of the motor. Please refer to this manual, before undertaking any inspection, repair, or
maintenance.
PERSONAL SAFETY
1. This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
2. Children should be supervised to ensure that they do not use or play with the machine.
3. Stay alert, watch what you are doing and use common sense when operating this machine.
4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating this machine can cause you to lose control &
may result in series personal injury.
5. Use safety equipment. Always wear eye protection. Safety equipment such as a dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate condition will reduce personal
injuries.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7. Prolonged use of the machine may lead to disorders of blood circulation in hands caused by vibration.
These effects can be worsened by low ambient temperatures and/or by gripping the handgrips
excessively tightly. Period of use you can extend with appropriate gloves or regular breaks. Take
frequent work breaks. Limit the amount of exposure per day.
INSTRUCTION MANUAL

BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the manufacturer. A charger that is unsuitable for one
type of battery may create a risk of fire when used with another battery.
2. Use power tools only with specifically designated battery. Use of any other battery may create a risk
of injury and fire
3. When the battery is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, which can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact.
5. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
HEDGE TRIMMER SAFETY WARNINGS
1. Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to
be cut when blades are moving. Make sure the switch is off when clearing jammed materials. A
moment of inattention while operating the hedge trimmer may result in serious personal injury.
2. Carry the hedge trimmer by the handle with cutter blade stopped. When transporting or storing the
hedge trimmer always fit the cutting device cover. Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
3. Hold the power tool by insulated gripping surface only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a “live” wire may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
INTENDED USE
The product is only intended for use outdoors. For safety reasons the product MUST be adequately
controlled by using the two-handed operation. The product is designed for home or domestic use. It is
intended to cut and trim hedges, shrubs and similar vegetation. It should be used in dry, well illuminated
conditions. It is NOT intended to cut grass, trees or branches. It should not be used for any other purpose
than hedge trimming.
RESIDUAL RISK
Even when the product is used as described, it is still impossible to eliminate certain residual risk factors.
The following hazards may arise in use and the operator should pay special attention to avoid the
following:
1. The blades cannot be guarded whilst cutting. Contact with the blades can cause serious injury. Keep
the blade away from yourself and others. Cover it with the blade protector whenever not in use.
2. Injury caused by vibration. Always use the right tool for the job, use designated handles and restrict
working time and exposure.
3. Exposure to noise can cause hearing injury. Wear ear protection and limit exposure
RISK REDUCTION
It has been reported that vibrations from hand-held tools may contribute to a condition called Raynaud’s
Syndrome in certain individuals. Symptoms may include tingling, numbness and blanching of the fingers,
usually apparent upon exposure to cold. Hereditary factors, exposure to cold and dampness, diet,
smoking and work practices are all thought to contribute to the development of these symptoms. There
are measures that can be taken by the operator to possibly reduce the effects of vibration:
1. Keep your body warm in cold weather. When operating the unit wear gloves to keep the hands and
wrists warm. It is reported that cold weather is a major factor contributing to Raynaud’s Syndrome.
2. After each period of operation, exercise to increase blood circulation.
3. Take frequent work breaks. Limit the amount of exposure per day.
If you experience any of the symptoms of this condition, immediately stop use and see your doctor about
these symptoms.
SERVICE
General Service:
1. Before cleaning, repairing, or inspecting, make certain the blades and all moving parts have stopped.
Disconnect the battery from the machine to prevent unintended starting.
2. Check the blades at frequent intervals for proper tightness. Also, visually inspect blades for damage.
Replace with the original equipment manufacture’s (O.E.M.) parts only, listed in this manual. “Use of
parts which do not meet the original equipment specifications may lead to improper performance
and compromise safety!”
3. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
4. Never tamper with safety devices. Check the correct operation regularly.
5. After striking a foreign object, stop the motor, disconnect the battery from the machine. Thoroughly
inspect for any damage. Repair the damage before starting and operating the machine.
6. Hedge-trimmer components, guards and shields are subject to wear and damage which could expose
moving parts or allow objects to be thrown. For safety protection, frequently check components and
replace immediately with original equipment manufacturers (O.E.M.) parts only, listed in this manual.
“Use of parts which do not meet the original equipment specifications may lead to improper
performance and compromise safety!”
7. Do not change the motor’s settings. The motor has been set for the maximum safe operating speed.
8. Maintain or replace safety and instruction labels, as necessary.
9. Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the
environment.
DO NOT MODIFY THE MOTOR
To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor settings
can cause it to operate at unsafe speeds and lead to premature failure. Never tamper with factory
settings of the motor. Please refer to this manual, before undertaking any inspection, repair, or
maintenance.
PERSONAL SAFETY
1. This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
2. Children should be supervised to ensure that they do not use or play with the machine.
3. Stay alert, watch what you are doing and use common sense when operating this machine.
4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating this machine can cause you to lose control &
may result in series personal injury.
5. Use safety equipment. Always wear eye protection. Safety equipment such as a dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate condition will reduce personal
injuries.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7. Prolonged use of the machine may lead to disorders of blood circulation in hands caused by vibration.
These effects can be worsened by low ambient temperatures and/or by gripping the handgrips
excessively tightly. Period of use you can extend with appropriate gloves or regular breaks. Take
frequent work breaks. Limit the amount of exposure per day.
INSTRUCTION MANUAL

SPECIFICATION
Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and
configuration of any of its products without notice or obligation. Therefore, please treat the text and
images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal
claim.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am -
5:00pm (Closed Bank Holidays)
Model
WEV20HT
Product Number
1938201002
Voltage
18Vd.c (20Vd.c Max)
No Load Speed
1200 rpm
Blade Length
500 mm
Cutting Capacity
16 mm
Maximum Run Time (Unloaded)
45 mins
Charge Time (Up to)
4 hours
Guarantee Sound Power Level
LwA 99 dB(A) - KpA 3 dB(A)
Vibration
Front Handle 1.55 m/s2,
Rear Handle 1.58 m/s2
Uncertainty K: 1.5 m/s2
Weight without Battery
N.W 2.8kg
WARNING:
Injuries may be caused, or aggravated, by prolonged use of a tool. When using any tool for prolonged
periods, ensure you take regular breaks.
DANGER OF FIRE!
Never charge batteries in the vicinity of acids or easily flammable materials.
Charge battery only at a temperature bet-ween 10 - 45 °C. After a heavy load, first allow the battery to
cool.
DANGER OF EXPLOSION!
Protect the device from direct exposure to heat and fire.
Do not place on heating units or expose to strong sunlight for an extended period.
Operate the device only at temperatures between -10 °C to + 45 °C..
RISK OF SHORT CIRCUIT!
For disposal, transport or storage, pack the battery in a plastic bag or a cardboard box, or isolate the
contacts with adhesive tape.
Do not open the battery pack.
SAFE DISPOSAL OF BATTERIES
Our batteries are designed according to the latest state of technology and optimised for the use in electric
tools. Lithium ion cells contain hazardous substances and may therefore not be disposed off with normal
household waste.
Our batteries are lithium ion cells and are therefore subject to special disposal regulations. Bring defective
batteries to your specialist dealer. Before disposing of the tool, remove the battery.
We wish to encourage users to act in an environmentally friendly manner.
INSTRUCTION MANUAL

SPECIFICATION
Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and
configuration of any of its products without notice or obligation. Therefore, please treat the text and
images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal
claim.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am -
5:00pm (Closed Bank Holidays)
Model WEV20HT
Product Number
1938201002
Voltage
18Vd.c (20Vd.c Max)
No Load Speed 1200 rpm
Blade Length 500 mm
Cutting Capacity 16 mm
Maximum Run Time (Unloaded) 45 mins
Charge Time (Up to)
4 hours
Guarantee Sound Power Level LwA 99 dB(A) - KpA 3 dB(A)
Vibration
Front Handle 1.55 m/s2,
Rear Handle 1.58 m/s2
Uncertainty K: 1.5 m/s
2
Weight without Battery N.W 2.8kg
WARNING:
Injuries may be caused, or aggravated, by prolonged use of a tool. When using any tool for prolonged
periods, ensure you take regular breaks.
DANGER OF FIRE!
Never charge batteries in the vicinity of acids or easily flammable materials.
Charge battery only at a temperature bet-ween 10 - 45 °C. After a heavy load, first allow the battery to
cool.
DANGER OF EXPLOSION!
Protect the device from direct exposure to heat and fire.
Do not place on heating units or expose to strong sunlight for an extended period.
Operate the device only at temperatures between -10 °C to + 45 °C..
RISK OF SHORT CIRCUIT!
For disposal, transport or storage, pack the battery in a plastic bag or a cardboard box, or isolate the
contacts with adhesive tape.
Do not open the battery pack.
SAFE DISPOSAL OF BATTERIES
Our batteries are designed according to the latest state of technology and optimised for the use in electric
tools. Lithium ion cells contain hazardous substances and may therefore not be disposed off with normal
household waste.
Our batteries are lithium ion cells and are therefore subject to special disposal regulations. Bring defective
batteries to your specialist dealer. Before disposing of the tool, remove the battery.
We wish to encourage users to act in an environmentally friendly manner.
INSTRUCTION MANUAL

TO REMOVE
Depress release button (A) on the back of battery cartridge (B) to release the battery. Pull the battery
cartridge out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only
be installed one way.
(Images may differ from actual machine)
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without recharging.
•Store in a cool dry place.
CHARGING
The battery must be charged for approximately 4 hours before using it for the first time. Use only the
original charger supplied with this machine or approved replacement. Use charging unit only in dry
rooms.
CHARGING LIGHTS
Remove the battery from the charger once it is fully charged. Charging an empty battery will take up to 4
hours to fully recharge.
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the
cable is not damaged. Replace cable if it appears to be damaged in any way
KNOW YOUR MACHINE
BATTERY
CARE
•There will be some charge present in the Battery on delivery, but to ensure maximum running time,
charge your Battery for 4-hours before first use.
•If over a period the Battery quickly runs down after a full 4-hour charging period, a replacement
Battery is needed.
•To prevent permanent Battery damage, never store in a discharged condition.
•Contact your retailer or local approved service dealer for a replacement Battery and for safe disposal
of your old Battery.
•The Battery is a "High Power", 20 Volt 2.0 Amp-Hour item. It is “Sealed for Life and no maintenance is
required.
IMPORTANT
Dispose of your old battery safely. Do not cut open, burn or incinerate.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing battery cartridge.
Failure to hold the tool and the battery cartridge firmly may cause them to slip off your hands and result
in damage to the tool and battery cartridge and a personal injury.
1. Rear Handle
2. Trigger
3. Front Handle
4. Safety Lever
5. Hand Guard
6. Blade Assembly
7. Blade Guard
8. Battery 2Ah
9. Charger
INSTRUCTION MANUAL

TO REMOVE
Depress release button (A) on the back of battery cartridge (B) to release the battery. Pull the battery
cartridge out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only
be installed one way.
(Images may differ from actual machine)
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without recharging.
•Store in a cool dry place.
CHARGING
The battery must be charged for approximately 4 hours before using it for the first time. Use only the
original charger supplied with this machine or approved replacement. Use charging unit only in dry
rooms.
CHARGING LIGHTS
Remove the battery from the charger once it is fully charged. Charging an empty battery will take up to 4
hours to fully recharge.
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the
cable is not damaged. Replace cable if it appears to be damaged in any way
KNOW YOUR MACHINE
BATTERY
CARE
•There will be some charge present in the Battery on delivery, but to ensure maximum running time,
charge your Battery for 4-hours before first use.
•If over a period the Battery quickly runs down after a full 4-hour charging period, a replacement
Battery is needed.
•To prevent permanent Battery damage, never store in a discharged condition.
•Contact your retailer or local approved service dealer for a replacement Battery and for safe disposal
of your old Battery.
•The Battery is a "High Power", 20 Volt 2.0 Amp-Hour item. It is “Sealed for Life and no maintenance is
required.
IMPORTANT
Dispose of your old battery safely. Do not cut open, burn or incinerate.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing battery cartridge.
Failure to hold the tool and the battery cartridge firmly may cause them to slip off your hands and result
in damage to the tool and battery cartridge and a personal injury.
1. Rear Handle
2. Trigger
3. Front Handle
4. Safety Lever
5. Hand Guard
6. Blade Assembly
7. Blade Guard
8. Battery 2Ah
9. Charger
INSTRUCTION MANUAL

CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage and frequency specified in this manual and on the rating plate.
Put the electric plug in an earthed socket-outlet. The LED on the battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it the first time.
⚫Install charger on the top of battery and push until the charger connects firmly with the battery.
⚫The LED will turn RED on the charger, when the battery is connected to the battery charger.
⚫When the LED on the charger turns to GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the power cable of the charger to disconnect it from the wall
socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled
or started whatever the battery’s charge level is.
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without re-charge.
•Store in a cool dry place.
GENERAL INSTRUCTIONS:
In order to maintain the long service life of the battery, always follow the instructions below:
The line trimmer will automatically switch off when the battery voltage is low. The battery must then be
recharged before the tool can be used again.
Always recharge the lithium-ion battery prior to any prolonged period of non-use, i.e. before storing away
in autumn/winter.
The charging time is 4-hours maximum for a battery that is completely empty.
The lithium-ion rechargeable battery can be charged at any charge level and charging can be interrupted
at any time without damaging the battery (no memory effect).
OPERATION
DANGER
Risk of injury! The device may only be put into operation if there are no defects. If a part is defective it
must be replaced before the device is used again.
WARNING
Risk of injury! Before starting work check the area and remove all objects which may be kicked up by
the unit.
SWITCHING ON AND OFF
Ensure the battery is housed in the trimmer, with an audible click.
(Images may differ from actual machine)
INSTRUCTION MANUAL

CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage and frequency specified in this manual and on the rating plate.
Put the electric plug in an earthed socket-outlet. The LED on the battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it the first time.
⚫Install charger on the top of battery and push until the charger connects firmly with the battery.
⚫The LED will turn RED on the charger, when the battery is connected to the battery charger.
⚫When the LED on the charger turns to GREEN, the battery is fully charged.
⚫Disconnect the power plug. Never pull the power cable of the charger to disconnect it from the wall
socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled
or started whatever the battery’s charge level is.
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without re-charge.
•Store in a cool dry place.
GENERAL INSTRUCTIONS:
In order to maintain the long service life of the battery, always follow the instructions below:
The line trimmer will automatically switch off when the battery voltage is low. The battery must then be
recharged before the tool can be used again.
Always recharge the lithium-ion battery prior to any prolonged period of non-use, i.e. before storing away
in autumn/winter.
The charging time is 4-hours maximum for a battery that is completely empty.
The lithium-ion rechargeable battery can be charged at any charge level and charging can be interrupted
at any time without damaging the battery (no memory effect).
OPERATION
DANGER
Risk of injury! The device may only be put into operation if there are no defects. If a part is defective it
must be replaced before the device is used again.
WARNING
Risk of injury! Before starting work check the area and remove all objects which may be kicked up by
the unit.
SWITCHING ON AND OFF
Ensure the battery is housed in the trimmer, with an audible click.
(Images may differ from actual machine)
INSTRUCTION MANUAL

Switching on:
Pull the On/Off trigger upwards with your right hand.
Push in the safety lever with your left hand.
Switching off:
Release the On/Off trigger or safety lever.
WARNING
Never attempt to lock a switch in the ON position
TRIMMING INSTRUCTIONS
WORKING POSITION (Figure 4) –Maintain proper footing and balance and do not overreach. Wear safety
goggles, non-skid footwear when trimming. Hold the unit firmly in both hands and turn the unit ON.
Always hold the trimmer, as shown in the illustrations in this manual, with one hand on the trigger/rear
handle and one hand on the safety lever Never hold the unit by the hand.
TRIMMING NEW GROWTH (Figure 5) - A wide, sweeping motion, feeding the blade teeth through the
twigs is most effective. A slight downward tilt of the blade, in the direction of motion gives the improved
cutting.
CAUTION:
Do not cut stems greater than 16 mm. Use the trimmer only for cutting normal shrubbery around
houses and buildings.
LEVEL HEDGES (Figure 6) –To obtain exceptionally level hedges, a piece of string can be stretched along
the length of the hedge as a guide.
SIDE TRIMMING HEDGES (Figure 8) –Hold the trimmer as shown and begin at the bottom and sweep up.
INSTRUCTION MANUAL

Switching on:
Pull the On/Off trigger upwards with your right hand.
Push in the safety lever with your left hand.
Switching off:
Release the On/Off trigger or safety lever.
WARNING
Never attempt to lock a switch in the ON position
TRIMMING INSTRUCTIONS
WORKING POSITION (Figure 4) –Maintain proper footing and balance and do not overreach. Wear safety
goggles, non-skid footwear when trimming. Hold the unit firmly in both hands and turn the unit ON.
Always hold the trimmer, as shown in the illustrations in this manual, with one hand on the trigger/rear
handle and one hand on the safety lever Never hold the unit by the hand.
TRIMMING NEW GROWTH (Figure 5) - A wide, sweeping motion, feeding the blade teeth through the
twigs is most effective. A slight downward tilt of the blade, in the direction of motion gives the improved
cutting.
CAUTION:
Do not cut stems greater than 16 mm. Use the trimmer only for cutting normal shrubbery around
houses and buildings.
LEVEL HEDGES (Figure 6) –To obtain exceptionally level hedges, a piece of string can be stretched along
the length of the hedge as a guide.
SIDE TRIMMING HEDGES (Figure 8) –Hold the trimmer as shown and begin at the bottom and sweep up.
INSTRUCTION MANUAL

WARNING
To guard against injury, observe the following:
•Read this instruction manual before using. Save the instruction manual.
•Check the hedge for foreign objects, such as wire or fences before each use.
•Keep hands on handles. Don’t overreach.
•Do not use under wet conditions.
CAUTION
Blade may coast after turning off.
DANGER
Keep hands away from blades.
CLEANING & MAINTENANCE
DANGER
Prior to conducting maintenance or cleaning: Remove the battery from the machine.
The trimmer blade could still move after being switched off! Always remove battery befo
re performing
any work on the trimmer!
Note: Clean unit immediately after every use. Hedge debris when dry is very hard and are very difficul
t to
remove.
BEFORE EACH USE
What?
How?
Check the battery, charger and machine for
damage.
Conduct a visual inspection and have any faulty
component replaced.
IF NECESSARY
What?
How?
Cleaning the device
Use a clean soft brush or damp cloth.
Lubricate blades
With a rust preventative solution or light machine
oil
MAINTENANCE
A plastic blade cover is supplied with your trimmer for storing. Remove the battery and slip the hedge
trimmer blade into the sheath, as shown in (Figure 8).
WARNING
Remove battery before servicing, cleaning or removing material from the gardening appliance.
The cutting blades are made from high quality, hardened steel and with normal usage, they will not
require sharpening. However, if you accidentally hit a wire fence (figure 9), stones, glass or other hard
objects, you may put a nick in the blade. There is no need to remove this nick if it does not interfere
with the movement of the blade. If it does interfere, remove the battery and have an approved service
dealer, use a fine-toothed file or sharpening stone to remove the nick. If you drop the trimmer,
carefully inspect it for damage. If the blade is bent, housing cracked, or handles broken or if you see any
other condition that may affect the trimmer’s operation, contact your local approved service dealer for
repairs before putting it back into use.
Fertilisers and other garden chemicals contain agents which greatly accelerate the corrosion of metals.
Do not store the unit on or adjacent to fertilisers or chemicals.
With the battery removed, use only mild soap and a damp cloth to clean the unit. Never let any liquid
get inside the unit; never immerse any part of the unit into a liquid. Prevent the blades from rusting by
applying a film of light machine oil after cleaning.

MAINTENANCE
A plastic blade cover is supplied with your trimmer for storing. Remove the battery and slip the hedge
trimmer blade into the sheath, as shown in (Figure 8).
WARNING
Remove battery before servicing, cleaning or removing material from the gardening appliance.
The cutting blades are made from high quality, hardened steel and with normal usage, they will not
require sharpening. However, if you accidentally hit a wire fence (figure 9), stones, glass or other hard
objects, you may put a nick in the blade. There is no need to remove this nick if it does not interfere
with the movement of the blade. If it does interfere, remove the battery and have an approved service
dealer, use a fine-toothed file or sharpening stone to remove the nick. If you drop the trimmer,
carefully inspect it for damage. If the blade is bent, housing cracked, or handles broken or if you see any
other condition that may affect the trimmer’s operation, contact your local approved service dealer for
repairs before putting it back into use.
Fertilisers and other garden chemicals contain agents which greatly accelerate the corrosion of metals.
Do not store the unit on or adjacent to fertilisers or chemicals.
With the battery removed, use only mild soap and a damp cloth to clean the unit. Never let any liquid
get inside the unit; never immerse any part of the unit into a liquid. Prevent the blades from rusting by
applying a film of light machine oil after cleaning.

STORAGE & TRANSPORTATION
STORAGE
Store the tool in a dry and well-ventilated place.
TRANSPORTATION
Always remove the battery from the machine and ensure the blade guard is securely place over the blade
assembly, when transporting the product.
TROUBLE SHOOTING
Switch off the trimmer and disconnect the battery before inspecting, cleaning or working on the thread.
Error/Fault
Cause
Remedy
Slow running, noisy or hot
blades.
Dry, corroded blades.
Lubricate blades with rust
preventative solution or light machine
oil.
Blades or blade support bent.
Straighten blade or blade support. To
be actioned by an approved service
dealer.
Bent or damaged teeth.
Straighten teeth. To be actioned by an
approved service dealer.
Loose blade bolts.
Tighten blade bolts.
Unit will not start.
Battery not installed properly.
Check battery installation.
Battery not charged.
Check battery charging requirements.
Safety Lever not fully operated.
Check that safety lever is fully pulled
back prior to moving trigger.
Battery won’t charge.
Battery not inserted into
charger.
Insert battery into charger until green
LED appears. Charge up to 4 hours if
battery totally drained.
Charger not plugged in.
Plug charger into a working outlet.
Refer to “Important Charging Notes”
for more details.
Check current at outlet by plugging in
a lamp or other appliance.
Surrounding air temperature
too hot or too cold
Move charger and tool to an area
which has a temperature of above 40o
degree F (4.5°C) or below 105odegree
F (+40.5°C).
If you can’t fix the fault yourself, contact your retailer. Please be aware that any improper repairs will also
invalidate the warranty and additional costs may be incurred.
INSTRUCTION MANUAL
