Webb WEV20LT User manual

v
Save these instructions
Sales & Support: 01793 333212
Before use please read & understand this manual; paying particular attention to the safety instructions before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every eff ort has been made to ensure the accuracy of information contained in this manual, our policy of continuous improvement
determines the right to make modifi cations without prior warning.
Images are used for illustration purposes only.
en - Original Instructions
ASSEMBLY REQUIRED
Minimum Two Persons
25cm Line Trimmer
with 20V 2Ah Lithium-Ion Battery & Charger
WEV20LT
1938200002

CONTENTS
INTENDED USE
GENERAL SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
BATTERY
CHARGING
ASSEMBLY
OPERATION
CLEANING & MAINTENANCE
STORAGE & TRANSPORTATION
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
INTENDED USE
The basic version of the equipment is a handheld lithium battery powered line trimmer, intended for private
use, i.e. for use in home and gardening environments. It is designed to tend grass and lawn areas.
The line-trimmer is for private use only, whose annual operating time generally does not exceed 50 hours.
Public facilities, sporting facilities and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set
up, operate and maintain your machine. Please be sure that you and any other persons who will operate the
machine, always carefully follow the recommended safety practices. Failure to do so could result in personal
injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and operation.
Please be aware that this Instruction Manual may cover a range of product specifications for various models.
Characteristics and features discussed and/or illustrated in this manual may not be applicable or exact to all
models.
We reserve the right to change product specifications, designs, and equipment without notice and without
incurring obligation. If you have any problems or questions concerning the machine, phone your local
authorised service dealer or ourselves. Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
WARNING
For safety reasons, the line-trimmer may not be used as a drive unit for other equipment or toolkits of any
kind, unless specifically advised to do so by the manufacturer. The equipment is to be used only for its
prescribed purpose. Any other use is deemed to be a case of misuse. The user/operator and not the
manufacturer will be liable for any damage or injuries of any kind caused because of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or industrial
businesses or for equivalent purposes.
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
21 October 20
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring, or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written
permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL

CONTENTS
INTENDED USE
GENERAL SAFETY INSTRUCTIONS
SPECIFICATION
KNOW YOUR MACHINE
BATTERY
CHARGING
ASSEMBLY
OPERATION
CLEANING & MAINTENANCE
STORAGE & TRANSPORTATION
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY
WARRANTY
INTENDED USE
The basic version of the equipment is a handheld lithium battery powered line trimmer, intended for private
use, i.e. for use in home and gardening environments. It is designed to tend grass and lawn areas.
The line-trimmer is for private use only, whose annual operating time generally does not exceed 50 hours.
Public facilities, sporting facilities and agricultural / forestry applications are excluded.
Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set
up, operate and maintain your machine. Please be sure that you and any other persons who will operate the
machine, always carefully follow the recommended safety practices. Failure to do so could result in personal
injury or property damage.
TO THE OWNER
All information in this manual is relative to the most recent product information available at the time of
printing. Review this manual frequently to familiarise yourself with the machine, its features and operation.
Please be aware that this Instruction Manual may cover a range of product specifications for various models.
Characteristics and features discussed and/or illustrated in this manual may not be applicable or exact to all
models.
We reserve the right to change product specifications, designs, and equipment without notice and without
incurring obligation. If you have any problems or questions concerning the machine, phone your local
authorised service dealer or ourselves. Throughout this manual, all references to right and left side of the
machine are observed from the operating position.
WARNING
For safety reasons, the line-trimmer may not be used as a drive unit for other equipment or toolkits of any
kind, unless specifically advised to do so by the manufacturer. The equipment is to be used only for its
prescribed purpose. Any other use is deemed to be a case of misuse. The user/operator and not the
manufacturer will be liable for any damage or injuries of any kind caused because of this.
Please note that our equipment has not been designed for use in commercial, trade or industrial
applications. Our warranty will be 90 days from the original date of sale for commercial, trade or industrial
businesses or for equivalent purposes.
Copyright Notice
Copyright © Handy Distribution
Permission is granted to reproduce this publication for personal & educational use only.
Commercial copying, redistribution, hiring or lending is prohibited.
No part of this publication may be stored in a retrieval system or transmitted in any other form or means without
written permission from Handy Distribution.
In all cases this copyright notice must remain intact.
INSTRUCTION MANUAL

GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to remove the risk of personal injury or
material damage. Please also observe the special safety instructions in the respective chapters. Where
applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of
this machine.
When using electric/battery tools, basic safety precautions, including the following, should always be
followed to reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine and in the manual(s) before operation. Keep this
manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, always exercise extreme
caution. This machine has been designed to perform one job: to cut out moss and weeds from the root.
Do not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and should be
trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to use
this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, bones,
toys, and other foreign objects, which could be tripped over or picked up and thrown by the machine.
Thrown objects can cause serious personal injury.
7. Plan your working pattern to avoid discharge of material toward roads, pathways, bystanders, and the
like. Also, avoid discharging material against a wall or obstruction, which may cause discharged material to
ricochet back toward the operator.
8. To help avoid blade contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers, and pets at least 20 metres from machine while it is in operation. Stop
machine if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that cover
the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet,
sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or in moving parts, especially the cutting blades.
12. Never operate the machine without proper shields, guards, control lever or other safety protective devices
in place and working.
13. Never operate the machine with damaged safety devices. Failure to do so, can result in personal injury.
14. Do not hold on to the machine if you are falling; release the handle immediately.
15. Do not operate the machine while under the influence of alcohol or drugs.
16. The trigger & safety button mechanisms are a safety devices. Never attempt to bypass its operation. Doing
so makes the safety device inoperative and may result in personal injury through contact with the moving
blades. The trigger & safety button mechanisms must operate easily in both directions and automatically
return to the disengaged position when released.
17. Never operate in wet grass. Always be sure of your footing. A slip and fall can cause serious personal
injury. If you feel you are losing your footing, release the trigger/lever immediately and the blades stop
moving after release.
18. Operate only in daylight or good artificial light. Walk, never run.
GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its
application and limitations as well as the specific potential hazards. Retain these instructions for future
reference. The operator is responsible for following the warnings & instructions in this manual and on the
product.
Read & understand operator’s manual
before using the machine. Failure to
follow instructions could result in
death or serious injury.
DANGER
Beware of sharp blades & nylon line,
which will continue to move after the
motor is switched off. The blades
could reciprocate, even after the plug
has been removed from the power
supply.
Wear gloves to protect your hands
Wear safety shoes.
Check your machine before turning it
on. Keep guards in place & in working
order. Frequently check to see that
foreign objects are removed from the
working area before turning it on.
Replace damaged, missing or failed
parts before using it.
Whenever the machine is in use, safety
glasses must be worn to safeguard
against flying objects.
Hearing protection must also be used
to protect the users hearing.
Face masks are also recommended to
avoid inhalation of debris.
Do not expose to rain or damp
conditions
Keep all bystanders & animals at least
15 metres away from the machine
during operation.
If approached, stop the machine
immediately.
Safety alert symbol. Used to alert you
to potential personal injury hazards.
Obey all safety messages that follow
this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol,
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
Class III Protection
Sound Power Level
(Image used for illustration purposes
only, check machine and Declaration
of Conformity for actual reading)
According to the European directive
2012/19/EU for Waste Electrical &
Electronic Equipment and its
implementation into national law,
electrical and electronic equipment
that are no longer usable must be
collected separately & disposed of in
an environmentally correct manner.
Separate collection of used products
and packaging allow materials to be
recycled & used again. Reuse of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw material.
CE marking is a certification mark that
indicates conformity with health,
safety, and environmental protection
standards for products sold within the
European Economic Area.
INSTRUCTION MANUAL

GENERAL SAFETY RULES
WARNING
Before you put the machine into operation, you must read this instruction manual.
When using this machine, observe the following safety instructions to remove the risk of personal injury or
material damage. Please also observe the special safety instructions in the respective chapters. Where
applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of
this machine.
When using electric/battery tools, basic safety precautions, including the following, should always be
followed to reduce the risk of serious personal injury and/or damage to the unit.
GENERAL OPERATION
1. Read this instruction manual carefully in its entirety before attempting to assemble this machine. Read,
understand, and follow all instructions on the machine and in the manual(s) before operation. Keep this
manual in a safe place for future and regular reference and for ordering replacement parts.
2. Be completely familiar with the controls and the proper use of this machine before operating it.
3. This machine is a precision piece of power equipment, not a plaything. Therefore, always exercise extreme
caution. This machine has been designed to perform one job: to cut out moss and weeds from the root.
Do not use it for any other purpose.
4. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and should be
trained and always supervised by an adult.
5. Only responsible individuals who are familiar with these rules of safe operation should be allowed to use
this machine.
6. Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, bones,
toys, and other foreign objects, which could be tripped over or picked up and thrown by the machine.
Thrown objects can cause serious personal injury.
7. Plan your working pattern to avoid discharge of material toward roads, pathways, bystanders, and the
like. Also, avoid discharging material against a wall or obstruction, which may cause discharged material to
ricochet back toward the operator.
8. To help avoid blade contact or a thrown object injury, stay in operator zone behind handles and keep
children, bystanders, helpers, and pets at least 20 metres from machine while it is in operation. Stop
machine if anyone enters area.
9. Always wear safety glasses or safety goggles during operation and while performing an adjustment or
repair to protect your eyes. Thrown objects which ricochet can cause serious injury to the eyes.
10. Wear sturdy, rough-soled work shoes and close-fitting trousers and shirts. Shirts and trousers that cover
the arms and legs and steel-toed shoes are recommended. Never operate this machine in bare feet,
sandals, slippery or light- weight (e.g. canvas) shoes.
11. Do not put hands or feet near or in moving parts, especially the cutting blades.
12. Never operate the machine without proper shields, guards, control lever or other safety protective devices
in place and working.
13. Never operate the machine with damaged safety devices. Failure to do so, can result in personal injury.
14. Do not hold on to the machine if you are falling; release the handle immediately.
15. Do not operate the machine while under the influence of alcohol or drugs.
16. The trigger & safety button mechanisms are a safety devices. Never attempt to bypass its operation. Doing
so makes the safety device inoperative and may result in personal injury through contact with the moving
blades. The trigger & safety button mechanisms must operate easily in both directions and automatically
return to the disengaged position when released.
17. Never operate in wet grass. Always be sure of your footing. A slip and fall can cause serious personal
injury. If you feel you are losing your footing, release the trigger/lever immediately and the blades stop
moving after release.
18. Operate only in daylight or good artificial light. Walk, never run.
GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its
application and limitations as well as the specific potential hazards. Retain these instructions for future
reference. The operator is responsible for following the warnings & instructions in this manual and on the
product.
Read & understand operator’s manual
before using the machine. Failure to
follow instructions could result in
death or serious injury.
DANGER
Beware of sharp blades & nylon line,
which will continue to move after the
motor is switched off. The blades
could reciprocate, even after the plug
has been removed from the power
supply.
Wear gloves to protect your hands
Wear safety shoes.
Check your machine before turning it
on. Keep guards in place & in working
order. Frequently check to see that
foreign objects are removed from the
working area before turning it on.
Replace damaged, missing or failed
parts before using it.
Whenever the machine is in use, safety
glasses must be worn to safeguard
against flying objects.
Hearing protection must also be used
to protect the users hearing.
Face masks are also recommended to
avoid inhalation of debris.
Do not expose to rain or damp
conditions
Keep all bystanders & animals at least
15 metres away from the machine
during operation.
If approached, stop the machine
immediately.
Safety alert symbol. Used to alert you
to potential personal injury hazards.
Obey all safety messages that follow
this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol,
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
Class III Protection
Sound Power Level
(Image used for illustration purposes
only, check machine and Declaration
of Conformity for actual reading)
According to the European directive
2012/19/EU for Waste Electrical &
Electronic Equipment and its
implementation into national law,
electrical and electronic equipment
that are no longer usable must be
collected separately & disposed of in
an environmentally correct manner.
Separate collection of used products
and packaging allow materials to be
recycled & used again. Reuse of
recycled materials helps prevent
environmental pollution and reduces
the demand for raw material.
CE marking is a certification mark that
indicates conformity with health,
safety, and environmental protection
standards for products sold within the
European Economic Area.
INSTRUCTION MANUAL

19. Stop the blades when moving to another work area.
20. If the machine starts to vibrate abnormally, stop the motor, and check immediately for the cause.
Vibration is generally a warning of trouble.
21. Shut the motor off and wait until the blades come to a complete stop. Then remove the battery before
cleaning the blades. Never place any part of the body in the blade area until you are sure they have
stopped moving and battery has been removed from the machine and contact cannot be made between
the two.
22. Never operate without proper shields, discharge cover, trigger & safety button mechanisms or other
safety protective devices in place and working. Never operate with damaged safety devices. Failure to do
so can result in personal injury.
23. Only use parts and accessories made for this machine by the manufacturer. Failure to do so can result in
personal injury.
24. If situations occur which are not covered in this manual, use care and good judgement. Contact your
nearest Approved Service Dealer for assistance
SLOPE OPERATION
Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on
slopes requires extra caution. If you feel uneasy on a slope, or it is greater than 15 degrees, do not scarify on it.
Do:
1. Exercise extreme caution when changing direction on slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps which can cause you to slip or trip. Tall grass can
hide obstacles.
3. Always be sure of your footing. A slip and fall can cause serious personal injury. If you feel you are losing
your balance, release the trigger/lever immediately and the blades will stop immediately.
Do Not:
1. Do not use near drop-offs, ditches, or embankments, you could lose your footing or balance.
2. Do not scarify on slopes greater than 15 degrees.
3. Do not scarify on wet grass. Unstable footing could cause slipping.
CHILDREN
Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted
to the machine and the activity. They do not understand the dangers. Never assume that children will remain
where you last saw them.
1. Keep children out of the cutting area and under care of a responsible adult other than the operator.
2. Be alert and turn the machine off, if a child enters the area.
3. Before and while moving backwards, look behind and down for small children.
4. Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that may
obscure your vision of a child who may run into the operator.
5. Never allow children under 16 years of age to operate this machine. Children 16 and over should read and
understand the instructions and safe operation practices in this manual and on the machine and be
trained and supervised by an adult.
SERVICE
General Service:
1. Before cleaning, repairing, or inspecting, make certain all moving parts have stopped. Disconnect the
battery from the machine to prevent unintended starting.
2. Check the machine at frequent intervals for proper tightness. Also, visually inspect for damage. Replace
with original equipment manufacturers (O.E.M.) parts only, listed in this manual. “Use of parts which do
not meet the original equipment specifications may lead to improper performance & compromise safety!”
3. Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
4. Never tamper with safety devices. Check the correct operation regularly.
5. After striking a foreign object, stop the motor, disconnect the battery from the machine. Thoroughly
inspect for any damage. Repair the damage before starting and operating the machine.
6. Line-trimmer components, guards and shields are subject to wear and damage which could expose
moving parts or allow objects to be thrown. For safety protection, frequently check components and
replace immediately with original equipment manufacturers (O.E.M.) parts only, listed in this manual.
“Use of parts which do not meet the original equipment specifications may lead to improper performance
INSTRUCTION MANUAL

& compromise safety!”
7. Do not change the motor’s settings. The motor has been set for the maximum safe operating speed.
8. Maintain or replace safety and instruction labels, as necessary.
9. Observe proper disposal laws and regulations. Improper disposal of fluids and materials can harm the
environment.
DO NOT MODIFY THE MOTOR
To avoid serious injury or death, do not modify the motor in any way. Tampering with the motor settings can
cause it to operate at unsafe speeds and lead to premature failure. Never tamper with factory settings of the
motor. Please refer to this manual, before undertaking any inspection, repair, or maintenance.
PERSONAL SAFETY
1. This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
2. Children should be supervised to ensure that they do not use or play with the machine.
3. Stay alert, watch what you are doing and use common sense when operating this machine.
4. Do not use this machine while you are tired, ill or under the influence of drugs, alcohol, or medication. A
moment of inattention while operating this machine can cause you to lose control & may result in series
personal injury.
5. Use safety equipment. Always wear eye protection. Safety equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate condition will reduce personal injuries.
6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing & gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7. Prolonged use of the machine may lead to disorders of blood circulation in hands caused by vibration.
These effects can be worsened by low ambient temperatures and/or by gripping the handgrips excessively
tightly. Period of use you can extend with appropriate gloves or regular breaks. Take frequent work
breaks. Limit the amount of exposure per day.
BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the manufacturer. A charger that is unsuitable for one type of
battery may create a risk of fire when used with another battery.
2. Use power tools only with specifically designated battery. Use of any other battery may create a risk of
injury and fire
3. When the battery is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, which can make a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a fire.
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact.
5. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
LINE TRIMMER SAFETY WARNINGS
1. Keep all parts of the body away from the rotating spool. Do not remove cut material or hold material to be
cut when the spool is moving. Make sure the switch is off when clearing jammed materials. A moment of
inattention while operating the line trimmer may result in serious personal injury.
2. Carry the line trimmer by the handle with cutter blade stopped. When transporting or storing the line
trimmer always remove the battery. Proper handling of the line trimmer will reduce possible personal
injury from the cutter blades.
3. Hold the power tool by insulated gripping surface only, because the cutting device may contact hidden
wiring. Cutting devices contacting a “live” wire may make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
INTENDED USE
The product is only intended for use outdoors. For safety reasons the product MUST be adequately controlled
by using the two-handed operation. The product is designed for home or domestic use. It is intended to cut
and trim lawn/grass edges. It should be used in dry, well illuminated conditions. It is NOT intended to cut
hedges, trees or branches. It should not be used for any other purpose than line trimming.
INSTRUCTION MANUAL

SPECIFICATION
Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and
configuration of any of its products without notice or obligation. Therefore, please treat the text and images in
this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am - 5:00pm
(Closed Bank Holidays)
Model
WEV20LT
Product Number
1938200002
Voltage
18Vd.c (20Vd.c Max)
No Load Speed
8500 min-1
Trimmer Line Diameter
1.6mm
Trimming Cutting Width
25cm
Height Adjustment
20cm
Battery
2.0 Ah
Maximum Run Time (Unloaded)
35 mins
Charge Time (Up to)
4 hours
Protection Rating
III
Guarantee Sound Power Level
LWA 96 dB(A)
Vibration
3.6 m/s2, Uncertainty K=1.5dB m/s2
Weight
N.W 2.2kg
RESIDUAL RISK
Even when the product is used as described, it is still impossible to eliminate certain residual risk factors. The
following hazards may arise in use and the operator should pay special attention to avoid the following:
1. The blades cannot be guarded whilst cutting. Contact with the blades can cause serious injury. Keep the
blade away from yourself and others. Cover it with the blade protector whenever not in use.
2. Injury caused by vibration. Always use the right tool for the job, use designated handles and restrict
working time and exposure.
3. Exposure to noise can cause hearing injury. Wear ear protection and limit exposure
RISK REDUCTION
It has been reported that vibrations from hand-held tools may contribute to a condition called Raynaud’s
Syndrome in certain individuals. Symptoms may include tingling, numbness and blanching of the fingers,
usually apparent upon exposure to cold. Hereditary factors, exposure to cold and dampness, diet, smoking and
work practices are all thought to contribute to the development of these symptoms. There are measures that
can be taken by the operator to possibly reduce the effects of vibration:
1. Keep your body warm in cold weather. When operating the unit wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor contributing to Raynaud’s Syndrome.
2. After each period of operation, exercise to increase blood circulation.
3. Take frequent work breaks. Limit the amount of exposure per day.
If you experience any of the symptoms of this condition, immediately stop use and see your doctor about
these symptoms.
WARNING:
Injuries may be caused, or aggravated, by prolonged use of a tool. When using any tool for prolonged
periods, ensure you take regular breaks.
DANGER OF FIRE!
Never charge batteries in the vicinity of acids or easily flammable materials.
Charge battery only at a temperature bet-ween 10 - 45 °C. After a heavy load, first allow the battery to cool.
DANGER OF EXPLOSION!
Protect the device from direct exposure to heat and fire.
Do not place on heating units or expose to strong sunlight for an extended period.
Operate the device only at temperatures between -10 °C to + 45 °C..
RISK OF SHORT CIRCUIT!
For disposal, transport or storage, pack the battery in a plastic bag or a cardboard box, or isolate the
contacts with adhesive tape.
Do not open the battery pack.
SAFE DISPOSAL OF BATTERIES
Our batteries are designed according to the latest state of technology and optimised for the use in electric
tools. Lithium ion cells contain hazardous substances and may therefore not be disposed off with normal
household waste.
Our batteries are lithium ion cells and are therefore subject to special disposal regulations. Bring defective
batteries to your specialist dealer. Before disposing of the tool, remove the battery.
We wish to encourage users to act in an environmentally friendly manner.
INSTRUCTION MANUAL

SPECIFICATION
Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and
configuration of any of its products without notice or obligation. Therefore, please treat the text and images in
this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am - 5:00pm
(Closed Bank Holidays)
Model
WEV20LT
Product Number 1938200002
Voltage 18Vd.c (20Vd.c Max)
No Load Speed 8500 min-1
Trimmer Line Diameter
1.6mm
Trimming Cutting Width 25cm
Height Adjustment 20cm
Battery 2.0 Ah
Maximum Run Time (Unloaded)
35 mins
Charge Time (Up to) 4 hours
Protection Rating III
Guarantee Sound Power Level LWA 96 dB(A)
Vibration 3.6 m/s2, Uncertainty K=1.5dB m/s2
Weight N.W 2.2kg
INSTRUCTION MANUAL

BATTERY
CARE
•There will be some charge present in the battery on delivery, but to ensure maximum running time,
charge your battery for 4-hours before first use.
•If over a period the battery quickly runs down after a full 4-hour charging period, a replacement
battery is needed.
•To prevent permanent battery damage, never store in a discharged condition.
•Contact your retailer or local approved service dealer for a replacement battery and for safe disposal
of your old battery.
•The battery is a "High Power", 20 Volt 2.0 Amp-Hour item. It is “Sealed for Life and no maintenance is
required.
IMPORTANT
Dispose of your old battery safely. Do not cut open, burn or incinerate.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing the battery.
Failure to hold the tool and the battery firmly may cause them to slip out your hands and result in damage
to the tool, battery or personal injury.
TO REMOVE
Depress release button (A) on the back of battery (B) to release. Slide the battery out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only
be installed one way.
(Images may differ from actual machine)
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without recharging.
•Store in a cool dry place.
KNOW YOUR MACHINE
1. Front Handle
2. Height Adjuster
3. Head Rotating Adjuster
4. Plant Guard
5. Guard
6. Trigger
7. Lawn Edging Wheel
8. 20v 2Ah Battery
9. Head Angle Adjuster
10. Spool & Nylon
11. Safety Button
12. Telescopic Shaft
11
12
INSTRUCTION MANUAL

BATTERY
CARE
•There will be some charge present in the battery on delivery, but to ensure maximum running time,
charge your battery for 4-hours before first use.
•If over a period the battery quickly runs down after a full 4-hour charging period, a replacement
battery is needed.
•To prevent permanent battery damage, never store in a discharged condition.
•Contact your retailer or local approved service dealer for a replacement battery and for safe disposal
of your old battery.
•The battery is a "High Power", 20 Volt 2.0 Amp-Hour item. It is “Sealed for Life and no maintenance is
required.
IMPORTANT
Dispose of your old battery safely. Do not cut open, burn or incinerate.
BATTERY INSTALLATION & REMOVAL
Hold the tool and the battery carriage firmly when installing or removing the battery.
Failure to hold the tool and the battery firmly may cause them to slip out your hands and result in damage
to the tool, battery or personal injury.
TO REMOVE
Depress release button (A) on the back of battery (B) to release. Slide the battery out of tool.
TO INSTALL
Align the battery with the cavity in the handle. Insert the battery into the handle until the battery release
button locks into place. You should hear a “click” once the battery is installed. Note: The battery can only
be installed one way.
(Images may differ from actual machine)
WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without recharging.
•Store in a cool dry place.
KNOW YOUR MACHINE
1. Front Handle
2. Height Adjuster
3. Head Rotating Adjuster
4. Plant Guard
5. Guard
6. Trigger
7. Lawn Edging Wheel
8. 20v 2Ah Battery
9. Head Angle Adjuster
10. Spool & Nylon
11. Safety Button
12. Telescopic Shaft
11
12
INSTRUCTION MANUAL

WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without re-charge.
•Store in a cool dry place.
GENERAL INSTRUCTIONS:
•In order to maintain the long service life of the battery, always follow the instructions below:
•Allow the battery to cool down after continuous use, before attempting to recharge.
•The line trimmer will automatically switch off when the battery voltage is low. The battery must then
be recharged before the tool can be used again.
•Always recharge the lithium-ion battery prior to any prolonged period of non-use, i.e. before storing
away in autumn/winter.
•The charging time is 4-hours maximum for a battery that is completely empty.
•The lithium-ion rechargeable battery can be charged at any charge level and charging can be
interrupted at any time without damaging the battery (no memory effect).
CHARGING
The battery must be charged for approximately 4 hours before first use. Only the original charger
supplied with this machine or approved replacement to be used. Charge unit only in dry rooms.
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the
cable is not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage and frequency specified in this manual and on the rating plate.
Put the electrical plug in an earthed socket-outlet. The LED on the battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it the first time.
⚫Install charger on the top of battery and slide until the charger connects firmly with the battery.
⚫The LED on the charger plug will turn RED, when the battery is connected to the battery charger.
⚫When the LED on the charger plug turns GREEN, the battery is fully charged.
⚫Remove the charger plug from the wall socket. Never pull the charger plug power cable to disconnect it
from the wall socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled
or started whatever the battery’s charge level is.
INSTRUCTION MANUAL

WINTER STORAGE
•Fully charge for 4-hours before winter storage.
•Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery
during winter storage.
•Avoid extended storage without re-charge.
•Store in a cool dry place.
GENERAL INSTRUCTIONS:
•In order to maintain the long service life of the battery, always follow the instructions below:
•Allow the battery to cool down after continuous use, before attempting to recharge.
•The line trimmer will automatically switch off when the battery voltage is low. The battery must then
be recharged before the tool can be used again.
•Always recharge the lithium-ion battery prior to any prolonged period of non-use, i.e. before storing
away in autumn/winter.
•The charging time is 4-hours maximum for a battery that is completely empty.
•The lithium-ion rechargeable battery can be charged at any charge level and charging can be
interrupted at any time without damaging the battery (no memory effect).
CHARGING
The battery must be charged for approximately 4 hours before first use. Only the original charger
supplied with this machine or approved replacement to be used. Charge unit only in dry rooms.
BATTERY CHARGER
WARNING
Risk of electric shock and short circuiting. Use approved and intact wall sockets. Make sure that the
cable is not damaged. Replace cable if it appears to be damaged in any way
CONNECTING CHARGER TO POWER SOURCE
Connect the battery charger to the voltage and frequency specified in this manual and on the rating plate.
Put the electrical plug in an earthed socket-outlet. The LED on the battery charger lights up green.
CONNECTING CHARGER TO BATTERY
⚫The battery must be charged before using it the first time.
⚫Install charger on the top of battery and slide until the charger connects firmly with the battery.
⚫The LED on the charger plug will turn RED, when the battery is connected to the battery charger.
⚫When the LED on the charger plug turns GREEN, the battery is fully charged.
⚫Remove the charger plug from the wall socket. Never pull the charger plug power cable to disconnect it
from the wall socket.
⚫Remove battery from battery charger.
NOTE:
Lithium-ion batteries can be charged at whatever charging level. The charging process can be cancelled
or started whatever the battery’s charge level is.
INSTRUCTION MANUAL

ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am -
5:00pm (Closed Bank Holidays)
PROTECTIVE GUARD
CAUTION
Risk of injury! On the underside of the protective guard there is a sharp blade designed to cut the
thread. Remove the transportation protection before operating.
Place protective guard in position over the spool and align the three fixing holes in the guard, with those
in the main body. Affix with three fixing screws provided and tighten until secure. Remove any
transportation protection from the cutting blade.
FRONT HANDLE
Press in and hold the locking buttons. Slide the front handle onto the product as illustrated.
Release the locking buttons. Tighten the handle into position with the remaining fixing screw, ensuring
the left and right sections of the handle are secured.
PLANT GUARD
Only follow the below action if the plant guard is not fitted to the machine.
Align the plant guard with the two fixing holes on the front of the motor assembly. Prize apart the two
prongs of the plant guard and slide them into the fixing holes.
INSTRUCTION MANUAL

ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents or operation of your machine, please call our
Customer Service Team on 01793 333212 or email [e-mail]
Opening hours weekdays: February to October 8:30am - 5:30pm / November to January 8:30am -
5:00pm (Closed Bank Holidays)
PROTECTIVE GUARD
CAUTION
Risk of injury! On the underside of the protective guard there is a sharp blade designed to cut the
thread. Remove the transportation protection before operating.
Place protective guard in position over the spool and align the three fixing holes in the guard, with those
in the main body. Affix with three fixing screws provided and tighten until secure. Remove any
transportation protection from the cutting blade.
FRONT HANDLE
Press in and hold the locking buttons. Slide the front handle onto the product as illustrated.
Release the locking buttons. Tighten the handle into position with the remaining fixing screw, ensuring
the left and right sections of the handle are secured.
PLANT GUARD
Only follow the below action if the plant guard is not fitted to the machine.
Align the plant guard with the two fixing holes on the front of the motor assembly. Prize apart the two
prongs of the plant guard and slide them into the fixing holes.
INSTRUCTION MANUAL

OPERATION
DANGER
Risk of injury!
The device may only be put into operation if there are no defects. If a part is defective it must be
replaced before the device is used again.
WARNING
Risk of injury!
Before starting work check the area and remove all objects which may be kicked up by the unit.
Check to make sure there are no visible defects.
Check to make sure all device components are correctly mounted
CORRECT POSITION
Hold the unit with the left hand on the front handle, and the right hand at approximately hip level on the
operating handle, balanced in a comfortable way.
SETTING THE ANGLE OF THE FRONT HANDLE (Fig. 5)
1. Press in and hold the locking buttons.
2. Adjust up and down to the required position.
SETTING THE ADJUSTABLE HANDLE (Fig. 6)
1. Loosen the locking lever.
2. Pull the telescopic pole to the desired length.
3. Tighten the locking lever.
SWITCHING ON AND OFF
Ensure the battery is housed in the trimmer, with an audible click.
Switching on:
1. Push in the safety button with your thumb.
2. Pull the On/Off trigger upwards.
3. Release safety button.
Switching off:
1. Release the On/Off trigger.
NYLON LINE
Your trimmer uses 1.6mm diameter nylon line to cut grass and weeds quickly and easily. In time, the tip of the
nylon line will become worn and the auto feed mechanism will automatically feed and trim a fresh length of line.
The cutting line will wear faster if the cutting is done along pathways or other abrasive surfaces or heavier weeds
are being cut. The line will extend approximately ¼ in. with each stop and start of the switch trigger until the line
reaches the length of the guard blade. Do not bump unit on ground in attempt to feed line or for any other
purpose.
AUTOFEED NYLON LINE
When switching on the line trimmer, the inertia of the head spinning will feed a small length of line out.
An ‘impact’ noise can be heard when the nylon line hits the cutting knife, located on the shield. After a
minimal period, the nylon line will be cut to the correct length and the noise will reduce as the motor
reaches operation speed. Make sure the motor is up to full speed before trimming or edging.
If the noise of the nylon line being cut cannot be heard, more line will need to be fed out. To feed more
line, it is first necessary to allow the machine to stop completely, then re-start, allowing it to reach full
speed.
MANUAL FEED NYLON LINE
You can manually feed out the nylon line. To do this, press & release manual feed button, whilst pulling
on the nylon line. Feed until the line reaches the cutting knife. If the line extends past the cutting knife,
remove the spool cap and click spool anti-clockwise until the line is at the desired length.
INSTRUCTION MANUAL

OPERATION
DANGER
Risk of injury!
The device may only be put into operation if there are no defects. If a part is defective it must be
replaced before the device is used again.
WARNING
Risk of injury!
Before starting work check the area and remove all objects which may be kicked up by the unit.
Check to make sure there are no visible defects.
Check to make sure all device components are correctly mounted
CORRECT POSITION
Hold the unit with the left hand on the front handle, and the right hand at approximately hip level on the
operating handle, balanced in a comfortable way.
SETTING THE ANGLE OF THE FRONT HANDLE (Fig. 5)
1. Press in and hold the locking buttons.
2. Adjust up and down to the required position.
SETTING THE ADJUSTABLE HANDLE (Fig. 6)
1. Loosen the locking lever.
2. Pull the telescopic pole to the desired length.
3. Tighten the locking lever.
SWITCHING ON AND OFF
Ensure the battery is housed in the trimmer, with an audible click.
Switching on:
1. Push in the safety button with your thumb.
2. Pull the On/Off trigger upwards.
3. Release safety button.
Switching off:
1. Release the On/Off trigger.
NYLON LINE
Your trimmer uses 1.6mm diameter nylon line to cut grass and weeds quickly and easily. In time, the tip of the
nylon line will become worn and the auto feed mechanism will automatically feed and trim a fresh length of line.
The cutting line will wear faster if the cutting is done along pathways or other abrasive surfaces or heavier weeds
are being cut. The line will extend approximately ¼ in. with each stop and start of the switch trigger until the line
reaches the length of the guard blade. Do not bump unit on ground in attempt to feed line or for any other
purpose.
AUTOFEED NYLON LINE
When switching on the line trimmer, the inertia of the head spinning will feed a small length of line out.
An ‘impact’ noise can be heard when the nylon line hits the cutting knife, located on the shield. After a
minimal period, the nylon line will be cut to the correct length and the noise will reduce as the motor
reaches operation speed. Make sure the motor is up to full speed before trimming or edging.
If the noise of the nylon line being cut cannot be heard, more line will need to be fed out. To feed more
line, it is first necessary to allow the machine to stop completely, then re-start, allowing it to reach full
speed.
MANUAL FEED NYLON LINE
You can manually feed out the nylon line. To do this, press & release manual feed button, whilst pulling
on the nylon line. Feed until the line reaches the cutting knife. If the line extends past the cutting knife,
remove the spool cap and click spool anti-clockwise until the line is at the desired length.
INSTRUCTION MANUAL

LINE TRIMMING (STANDARD)
LINE TRIMMING (SLOPES & UNDER OBSTACLES)
Adjust the angle of the head up or down to ensure you have a clean and unobscured cutting angle.
TRIMMING EDGES
Press in and hold the locking button. Rotate the cutting head 180 degrees. Release the locking button.
Guide the unit, as shown, slowly along the edge of the lawn, using the side wheel. Ensure the Plant
Protector is placed in the upright position, against the motor housing.
CUTTING TIPS
Only cut with the left (shown here as light grey) area of the cutting unit when the unit is being moved
from right to left. In the right (dark grey) area, the threads rotate in your direction.
This represents a high level of kickback risk and objects may be thrown in your direction by the rotation of
the thread. You may be hurt as a result.
When the unit is moved from left to right, ensure that the nylon line is kept away from the grass to ensure
that the grass is not thrown up.
Cut long grass from top to bottom to ensure that the grass does not get tangled around the spool.
Only use the tip of the nylon line. You will use less nylon line & avoid grass getting caught up in the spool.
Only take the nylon line as close as necessary to posts, walls, fences etc. Solid objects will wear the nylon
line. Tree trunks, young trees and bushes may be damaged by the nylon line.
INSTRUCTION MANUAL

LINE TRIMMING (STANDARD)
LINE TRIMMING (SLOPES & UNDER OBSTACLES)
Adjust the angle of the head up or down to ensure you have a clean and unobscured cutting angle.
TRIMMING EDGES
Press in and hold the locking button. Rotate the cutting head 180 degrees. Release the locking button.
Guide the unit, as shown, slowly along the edge of the lawn, using the side wheel. Ensure the Plant
Protector is placed in the upright position, against the motor housing.
CUTTING TIPS
Only cut with the left (shown here as light grey) area of the cutting unit when the unit is being moved
from right to left. In the right (dark grey) area, the threads rotate in your direction.
This represents a high level of kickback risk and objects may be thrown in your direction by the rotation of
the thread. You may be hurt as a result.
When the unit is moved from left to right, ensure that the nylon line is kept away from the grass to ensure
that the grass is not thrown up.
Cut long grass from top to bottom to ensure that the grass does not get tangled around the spool.
Only use the tip of the nylon line. You will use less nylon line & avoid grass getting caught up in the spool.
Only take the nylon line as close as necessary to posts, walls, fences etc. Solid objects will wear the nylon
line. Tree trunks, young trees and bushes may be damaged by the nylon line.
INSTRUCTION MANUAL

•Press the spool down GENTLY and rotate it until you feel it drop into place. (When in place, the spool
will turn a few degrees left and right freely.)
•Snap the spool cover back on, insert the battery and turn the tool on. In a few seconds you’ll hear the
nylon line being cut automatically to the proper length.
STORAGE & TRANSPORTATION
STORAGE
Store the tool in a dry and well-ventilated place.
TRANSPORTATION
Always remove the battery from the machine when transporting the product.
TROUBLE SHOOTING
Switch off the trimmer and disconnect the battery before inspecting, cleaning or working on the thread.
Error/Fault
Cause
Remedy
Nylon Line breaks too frequently
Nylon line too dry or brittle
Place the coil in a container with
water for approx. 24 hours. Dry
and reinstall it.
Nylon line in contact with fence
posts, trees, etc.
Use plant guard
Tilt switch is not working.
Dirt and debris in spool drive
mechanism.
Clean parts with a brush
Line is torn and stuck inside spool
Remove spool, check tightness of
winding and replace spool in the
usual way.
Line is welded to itself or to spool
through heat build-up.
Remove welded line section,
check tightness of winding and
replace spool in the usual way.
If you can’t fix the fault yourself, contact your retailer. Please be aware that any improper repairs will also
invalidate the warranty and additional costs may be incurred.
CLEANING & MAINTENANCE
DANGER
Prior to conducting maintenance or cleaning: Remove the battery from the machine.
The trimmer continues to spin after being switched off!
Always remove battery before performing any work on the trimmer!
Note: Clean unit immediately after. Grass debris when dry is very hard and difficult to remove.
CLEANING
•Do not at any time let brake fluids, petrol, petroleum based products, penetrating oils, etc., come in
contact with plastic parts. They contain chemicals that can damage, weaken or destroy plastic.
•Make sure the battery is detached from the unit, then use only mild soap and a damp cloth to clean
the tool. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid.
•Fertilizers and other garden chemicals contain agents which greatly accelerate the corrosion of
metals Do not store the tool on or adjacent to fertilizers or chemicals.
BEFORE EACH USE
What?
How?
Check the battery, charger and machine for
damage.
Conduct a visual inspection and have any faulty
component replaced.
IF NECESSARY
What?
How?
Clean the device
Wipe the unit with a damp cloth.
Replace the nylon line if it is too short.
Replace the nylon line (1.6mm) and feed following
the directional arrow on the spool or replace with
replacement spool and line.
REPLACING SPOOL / CLEARING JAMS AND TANGLED LINES
From time to time, especially when cutting thick or stocky weeds, the line feeding hub may become
clogged with sap or other material and the line will become jammed as a result. To clear the jam, follow
these steps.
•Turn off the trimmer and remove the battery.
•Press the release tabs on the line spool retainer (1) and remove the cover (2) by pulling it straight off.
•Remove the line spool (3). If necessary, remove any dirt.
•Extend the line jammed or tangled out of the spool fitting (4).
•Insert the spool in the line receptacle (5).
•Thread the end of the line through the eyelet of the spool retainer (6).
•Firmly press both tabs of the spool cover together at the same time and push the cap onto the spool
until it engages.
REWINDING SPOOL FROM BULK LINE (USE ONLY 1.6MM DIAMETER LINE)
Bulk line for your trimmer/edger is available at extra cost from your local dealer. To install bulk line,
follow these steps:
•Turn off the trimmer and remove the battery.
•Press the release tabs on the line spool cover as shown in Fig. 11 and remove the cover by pulling it
straight off. Remove the spool from the tool and remove and discard all line on the spool.
•Insert one end of the bulk line into the hole in the spool.
•Hold the line in the hole and pull the rest of the line through the slot in the spool.
•Snugly and evenly wind the bulk line onto the spool in the direction of the arrow until it is nearly full.
•Insert the line end through the eyelet in the spool hub. Pull the line through the hole to maintain
tension while placing the spool down into the hub with the notched side exposed.
INSTRUCTION MANUAL
