WebDT 170 Assembly instructions

ENGLISH
Note: The actual package contents may vary depending on the configuraon acquired.
WebDT 170
ENGLISH 4
BASIC OPERATION GUIDE
WebDT 170
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2011, DT Research, Inc. All Rights Reserved. DT Research and WebDT are registered trademarks of DT Research, Inc.
This guide is available in German, Spanish, French, or Italian, please contact your device provider for these versions.
INTRODUCTION
Thank you for acquiring the latest
addion to DT Research’s line of thin client devices - the WebDT 170, featuring compact and robust
construcon powered by the high-performance and energy efficient AMD processor. The WebDT
170 supports major embedded operang systems as well as Microso® Windows® XP Embedded or
Windows® XP Pro and provides complete soluons for a variety of compung needs. The user is offered
a choice of soware soluons on a plaorm characterized by the following:
H
•igh-integraon and energy-efficient processor technology
E
•xpanded graphics capabilies for mulmedia applicaons
R
•obust construcon for reliable operaon
Cost-effecve
•compung in compact and versale packaging
Package Contents
WebDT 170•
AC/DC Power Adapter•
V
•ESA Bracket
Basic Operaon G•uide
2
2
3
3
4
11
Thin Client/
Embedded Controller
SPECIFICATIONS
System
Processor AMD Sempron™, 1.6GHz/ Turion™, 2.1GHz Dual-Core
GPU ATI Radeon X1270
Memory (RAM) 1GB or 2GB
Storage 4GB to 16GB Flash or HDD
Operang Systems Microso® Windows® XP Embedded or Windows® XP Pro
Display Resoluon Up to 1920 x 1080
Network Interface 10/ 100/ 1000Mb BaseT LAN;
Wi-Fi 802.11a/b/g or Wi-Fi 802.11a/b/g/n (oponal)
Expansion PCI Express; USB
Input/Output Ports
1 S-video input; 1 Composite input; 1 VGA port; 1
HDMI port; 1 COM port; 18.5V DC-in jack; 3 Audio jacks
(Microphone-in, Line-in, Headphone-Out jacks); 2 USB 2.0
ports; RJ45 connector for Ethernet;
Wi-Fi dipole antenna (oponal)
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 18.5V DC
Mechanical
Enclosure Aluminum + steel
Dimensions (H x W x D) 2.16 x 5.82 x 6.5 in/ 55 x 148 x 165.1 mm
Weight 3.16 lbs/ 1430 g
Environmental
Regulatory FCC Class B, CE, C-Tick, UL, RoHS compliant
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing
* Specificaons subject to change without noce.

WebDT 170
ENGLISH 23ENGLISH
THE WebDT 170
Rear ViewFront View
Powering ON and OFF
The Power Buon is located in the front of the WebDT 170. The Power Buon may be configured
to funcon differently depending on the operang soware. In general, to turn the WebDT 170 on,
push and release the Power Buon on the front bezel. The adjacent power LED will be lit (blue) and
the corresponding interface will be displayed on the display monitor.
To turn offthe device, again depending on soware operang system, push and release the Power
Buon or use a soware shutdown interface.
In the event of system lockup, the Power Buon may be used to perform a reset on the device. To
do that, push and hold the Power Buon for at least 4 seconds. The system will shut down and all
unsaved work may be lost. Pushing on the Power Buon again will restart the device.
Device Ports
The WebDT 170 features an opmal set of I/O ports while preserving the compact size of the
system. The HDMI connector, S-Video, Composite video, Network (10/100/1000 BaseT Ethernet),
and Power ports are supplemented by a set of two USB 2.0 and three Audio ports.
Through its USB ports, the WebDT 170 supports a wide range of USB-based peripherals. These
peripherals are applicable in providing the means for soware installaon, applicaon storage, data
storage, and system soware recovery and updates.
Memory and Storage
The WebDT 170 may be available in storage configuraons ranging from 4GB to 16GB of flash
memory or HDD. Depending on base soware configuraon, the user may use the internal memory
of the WebDT 170 for user’s installed soware and storage. The user may also supplement storage
space with USB-based peripherals such as flash disks, disk drives, etc.
RAM capacity ranges from 1GB to 2GB, depending on the processor plaorm.
VESA Mounng Bracket Installaon for WebDT 170
Opons
The WebDT 170 is designed to work with a range of custom and off-the-shelf opons to enhance its
applicability for various deployments.
Built-in PCI Express wireless LAN, with external antenna•
Bracket and Cable for Internal HDD Mounng•
It is quite simple to mount the WebDT 170 to VESA adapters or LCD monitors using the external
mounng bracket.
Precauons
Always exercise care when operang and handling the WebDT 170.•
Never disassemble any poron of the enclosure. It will void any product warranty on the WebDT•
170.
Do not use any AC/DC adapter other than the one provided with the device or acquired from the•
manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power•
down the WebDT 170 and disconnect all power sources. Please report the problem to your
device provider immediately.
ABC D EFH
GIJ
Ethernet port
HDMI connecter
VGA port
RS232 COM port
DC-in
F
H
G
I
J
A
B
C
D
E
Audio jacks
Composite Video input
S-video input
Power buon
USB 2.0 (2)
