WebDT 362 Assembly instructions

ENGLISH
Mobile POS Tablet
WebDT 362
ENGLISH 8
BASIC OPERATION GUIDE
WebDT 362
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2011, DT Research, Inc. All Rights Reserved.
DT Research and WebDT are registered trademarks of DT Research, Inc.
INTRODUCTION
Thank you for acquiring the latest addion to
DT Research’s line of tablet devices—the WebDT 362.
Featuring a slim yet robust enclosure, the two-pound
WebDT 362 with 8.4”TFT display is powered by the Intel® Atom™ processor, offering
opmal combinaons of performance and power savings. An external baery expansion
opon provides approximately 3-4 hours of addional baery operaon for up to six
hours of mobile usage.
The WebDT 362 is available in Microso® Windows® Embedded Standard 7, Windows®
7 Professional, Windows® XP Embedded, Windows® XP Pro for Embedded Systems or
Linux operang systems. Each soware operang system features web browser, client/
server compung soware, media player, accessories, and applicaons support.
PACKAGE CONTENTS
One WebDT 362 with Internal Baery Pack (2200mAh), Stylus, Grips and Screen Cover•
AC-DC Power Adapter with Power Cord•
Basic Operaon Guide•
Major opons, depending on configuraon:
* If your WebDT 362 contains MSR, camera or scanner module, please refer to the POS module
operaon guide for detailed operaon.
BOG072611DT362ENG
Desktop Charging Cradle with DC-in•
Power Jack and Ethernet, USB and oponal VGA Ports External Baery Pack•
Internal High Capacity Baery (3760mAh)•External Baery Charger Kit•
SPECIFICATIONS
System
Processor Intel® Atom™ Z530, 1.6GHz
Memory (RAM) 1GB to 2GB DDR2 533MHZ
Storage 2GB to 16GB Internal Flash Module or 32GB to 128GB SSD
Operang Systems
Microso® Windows® Embedded Standard 7,
Windows® 7 Professional, Windows® XP Embedded,
Windows® XP Pro for Embedded Systems, or Linux
Display 8.4”LED-backlight screen with resisve touch;
sunlight readable opon
Display Resoluon 800 x 600 (SVGA)
Network Interface Wi-Fi 802.11a/b/g/n, Bluetooth 2.0
Control Switch and Buons 1 power buon, 7 front buons and 1 trigger buon
Indicator 1 power/ baery status LED and 1 WLAN acve LED
Speaker Built-in speaker
Input/Output Ports 1 DC-in Jack; 1 USB 2.0 port;
1 Headphone-out Jack; 1 Microphone-in Jack
Security
WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-
Enterprise, AES-CCMP 128-bit, WEP 128-bit and 64-bit;
802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAPTLS,
EAP-TTLS
Power
AC/DC Adapter Input: 100 – 240V AC; Output: 12V DC, 3A
Baery Pack Internal 7.4V, 2200mAh or 7.4V, 3760mAh/
Oponal: External 7.2V, 3900mAh
Mechanical
Enclosure ABS + PC plascs and magnesium-aluminum alloy
Stylus Non-electronic p
Protecve Grip Rubber with handstrap
Dimensions (H x W x D) 7.9 x 9.6 x 0.8 in/ 200 x 240 x 18 mm
Weight 1.9 lbs/ 0.86 kg
Environmental
Regulatory FCC Class B, CE, C-Tick, RoHS compliant
Temperature Operaon: 0°C - 40°C; Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing
* Specificaons subject to change without noce.

WebDT 362
ENGLISH 2
Buon Funcons (with Windows XP Operang System)
BUTTON ACTION
Programmable
Programmable, launch so(on-screen) keyboard (default)
Launch SAS (Secure Aenon Sequence)
Generate Ctrl+Alt+Del keys to invoke the security windows defined under Windows XP
Programmable,
Change display orientaon (portrait/ landscape) (default)
Programmable, system ulity menu (default)
Programmable,
As scanner trigger when equipped with the scanner module
Push/release typically enters Standby mode, or Push/release exits Standby mode or
restarts device (soware dependent)
Push and hold (over 4 seconds) invokes hardware shutdown
The WebDT 362 (with Windows XP)
Baery/Power LED
Wireless LED
Stylus
For locking the MSR module
Buon ManagementWireless Network Sengs
Calibraon
Internal Baery Switch
(back panel)
1
8
9
2 3
4
5
6
8
9
7
Input/ Output Ports
USB Ports
Headphone Jack
Microphone Jack
DC Power Input
A
G
C
B
A
B
C
D
1234567
Baery and Power Meter
3ENGLISH
Power/Baery LED Status:
Blue indicates the baery is 25% to 100% charged•
Blinking blue indicates the baery is charging•
Orange indicates that the baery is between 11% to 25%•
Blinking Orange indicates that the baery is below 10%•
Precauons
Always exercise care when operang and handling the WebDT 362.
•
Do NOT apply excessive pressure to the display screen.
•
We recommend using the Stylus provided to keep the screen clean.
•
Avoid prolonged exposure of the display panel to any strong heat source. Wherever
•
possible, the WebDT 362 should face away from direct light to reduce glare.
If the AC-DC power adapter is used to recharge or power the device, do NOT use any
•
AC-DC adapter other than the one provided with the device or acquired from the
manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present,
•
immediately power offthe WebDT 362 and disconnect all power sources. Report the
problem to your device provider immediately.
Never aempt to disassemble the WebDT 362, as this will void the warranty.
•
THE WebDT 362
Basic Features
The WebDT 362 wireless tablet integrates a bright and responsive touch display, a USB
port, and embedded networking elements such as wireless LAN or oponal 3G. The
primary device is complemented by a suite of accessories, including baery expansion,
docking cradles, and carrying cases, for a comprehensive user experience.
A WebDT 362 typically integrates an 802.11a/b/g/n wireless LAN (WLAN) adapter that
may connect to other wireless devices or access points. If your WebDT 362 does not
come with such a network adapter, please consult your device provider to establish the
desired network connecvity.

WebDT 362
ENGLISH 45ENGLISH
OPERATION
Internal Baery Switch
To prevent baery drain during shipping and extended storage, the internal baery may
be disconnected. To connect the internal baery, push the baery buon switch (on the
back panel) to the “up”posion (see page 2 for photo). The internal baery pack has to
be connected for it to operate, be charged, and for the oponal external baery pack to
funcon.
Powering ON and OFF
To acvate the WebDT 362, push and quickly release the Power Buon. The display will
come on in a few seconds. To put the WebDT 362 in Standby mode, push and quickly
release the Power Buon. To turn the WebDT 362 offfor extended storage, power off
the device safely using any soware funcon that “shuts down computer”provided in
the soware operang system.
NOTE: The baery packs shipped with your device may be low in power—please use
the AC-DC adapter with the WebDT 362 when seng up the device for the first me to
fully charge the internal baery pack. You may charge the external baery pack with it
aached to the WebDT 362, or with the oponal external baery charger kit.
NOTE: When the baery pack(s) is (are) charging, the blue-colored Baery LED should
blink slowly. If plugging in the AC-DC adapter does not trigger this blinking acvity
and the LED stays dark, the baery pack(s) may have been drained substanally. Try
unplugging/ replugging the AC-DC adapter to the WebDT 362 a few mes to acvate the
charging process.
NOTE: To conserve power, use (push and quick release) the Power Buon to put the
device in “Standby”mode while not in use. Pushing briefly on the same buon will wake
up the system within seconds.
NOTE: Avoid using the Power Buon (“hold 4+ seconds”feature) to turn offthe
device—this form of hardware shutdown is intended to be a means of recovery from
device lockups, and not as normal operaon.
Start Up
If the power up (from Standby or otherwise) is successful, the appropriate interface will be
displayed aer a launch sequence of several seconds. The wireless LAN connecon may take
10-15 seconds to be established.
Configuring the WebDT 362
The device may be configured using the ulies and methods dictated by the soware
operang system. The WebDT 362 should be configurable for various properes such as
user profiles, network features, and several system elements.
Calibraon
The touch display for the WebDT 362 is calibrated before shipping. In the event that the
calibraon has been modified or is unsasfactory, the respecve calibraon rounes
(e.g., PenMount (PM) for Windows XP) to calibrate the touch interface may be used.
Such applicaons are typically executed through touch input via Stylus or through mouse
click via a USB mouse.
Wireless Networking
Wireless LAN
The WebDT 362 is oen delivered with an embedded (user-inaccessible) 802.11a/b/g/n
WLAN adapter equipped with a hidden custom antenna.
T
•hrough the support of typical WLAN adapters, the WebDT 362 should be able to
detect all 802.11 access points in the vicinity for you to select the access point of
your choice for connecon.
T
•he SSID and WEP/WPA/WPA2 (if enabled) parameters on the WebDT 362 and
the access points have to match. The SSID is case-sensive and it is recommended
that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves) for secure
access.
W
•hen WEP/WPA/WPA2 is enabled, you may need to consult your network admin-
istrator or your networking equipment literature to properly configure associated
sengs such as Authencaon mode, etc.
R
•efer to the access point operang manuals for seng up the 802.11 access points.

WebDT 362
ENGLISH 6
Buon Management
Where supported by soware, many of the hard buons on the WebDT 362 are
programmable to perform a funcon of the user’s choice. The excepon is the Power
Buon and the SAS Buon. To acvate the buon re-assignment applicaon, invoke the
Buon Manager applicaon, e.g., in Windows XP Embedded .
Brightness Control
Where supported by device firmware and soware, a hard buon may be engaged to
manipulate the display brightness. Press the System Menu buon (Buon 7) on the front
of the WebDT 362. The System screen will display a Brightness control secon with up
and down arrows that can be acvated with the stylus.
Baery and Power Management
The WebDT 362 is equipped with an internal 2200mAh Li-Ion baery pack that is capable
of supporng approximately 1.5–2 hours of connuous operaon. With the oponal
internal 3760mAh baery and an external baery pack that clips (hot-pluggable)
onto the back of the device, the maximum period of connuous operaon will be
approximately 3–4 hours. The period between baery recharges can be significantly
lengthened by pung the device into Standby mode through the Power Buon (see
Buons Funcon Table) whenever the device is not in use. Depending on the operang
soware, the WebDT 362 may also be configured to enter various power-saving modes
via the Power Buon or through med entry.
7ENGLISH
Desktop Cradle
The WebDT 362 is complemented by an oponal Desktop Cradle for support, pass-
through charging, and connecon to a range of USB peripherals, including keyboard and
mouse. The Cradle offers the following interfaces: a DC-in port for the AC-DC adapter,
an Ethernet port, a VGA port (oponal), and USB ports. Always seat the WebDT 362
securely onto the cradle. The cradle must be powered by the AC-DC adapter for the
Ethernet and USB ports to funcon. The baery packs on the WebDT 362 may be
recharged by connecng the AC-DC adapter directly to the DC-in port on the WebDT 362
or through the DC-in port on the Desktop Cradle while the WebDT 362 is docked to the
Cradle.
USING THE WebDT 362
Memory configuraon
The WebDT 362 is available with 1GB or 2GB memory configuraons. Storage opons
currently range from: 2GB to 16GB flash memory or 32GB to 128GB SSD.
Peripherals Support
Through its USB ports, the WebDT 362 supports a wide range of USB-based peripherals.
These peripherals are applicable for soware installaon, applicaons storage, data
storage, and system soware recovery and updates. The WebDT 362 is also compable
with custom mountable cradle opons. These securable and mountable cradles provide
an interface to VESA mounts and arms, and to ports that may include USB, Ethernet and
pass-through power.
Remote Management
Depending on soware configuraon, the WebDT 362 can be centrally managed for
asset monitoring and for soware control. Please consult your device provider.
